Castleton Home CX1125 User manual

For assistance with assembly contact:
Wayfair Customer Service,
877-WAYFAIR (877-929-3247)
www.wayfair.com
CX1125 slipper chair –brown PU
leather
CX1125 slipper chair –black PU
leather
Assembly Instructions

A Quantity
of 1
Back & Seat
B Quantity
of 2
Metal Leg
C Quantity
of 2
Bottom Rail
1 Quantity
of 6
Bolt
2 Quantity
of 1
Allen Wrench
Care and Cleaning Instructions:
Please see care and cleaning label attached to bottom
of chair seat.
For replacement parts or questions, please
call Customer Service at 877-WAYFAIR
(877-929-3247)
SLIPPER CHAIR
Parts List
Before beginning assembly, separate all parts and carefully study the parts diagrams below.
Review all parts and hardware before disposing of any packaging.
You may receive extra hardware with your unit.
Call Customer Service for missing hardware.

Figure 1
Unpack and lay parts on clean,
padded surface like carpet or
blanket. Check that you have all
parts indicated on the front page.
Pull the zipper on the bottom of
Back & Seat (A).
Then lift the black dust cover from
the bottom of Back & Seat (A) and
take out the 2 legs (B) and the 2
bottom rails (C).
Close the black dust cover. Zip up
the bottom of Back & Seat (A).
Figure 2
Attach the 2 bottom rails (C) to
the bottom of Back & Seat (A) by
bolts (1).
Tighten them by using Allen
wrench (5) as shown on Figure 2
Don’t tighten them too tight just
yet.
Figure 3
Insert the legs (B) into the bottom
rails( B). Please make sure Legs
(B)’s tenon go into bottom
rails( C)’ends.
SLIPPER CHAIR
Assembly Instructions
12
B
B
C

Figure 4
Use 4 bolts (1) to connect legs (B)
to the bottom of Back & Seat (A)
Tighten bolts (1) by using Allen
wrench ( 5) as shown on Figure 4.
Figure 5
Tighten all bolts.
Turn over the chair.
Now your slipper chair is ready to
use!
Figure 6
When you need to assemble
CX1123 left facing club chair and
CX1124 right facing club and
CX1125 slipper chair
Please swirl the connector on
bottom of CX1124/ CX1125 firstly,
then you can put CX1123/
CX1124/ CX1125 together as
shown in Figure 6.
SLIPPER CHAIR
Assembly Instructions
CB
90¡ã
CX1123 left facing club chair
CX1125 slipper chair
CX1124 right facing club
chair

Figure 7
Now your CX1123/ CX1124/
CX1125 whole set chair is ready to
use!
