Castleton Home CX1124 User manual

For assistance with assembly contact:
Wayfair Customer Service,
877-WAYFAIR (877-929-3247)
www.wayfair.com
CX1124 right facing club chair –
brown PU leather
CX1124 right facing club chair –
black PU leather
Assembly Instructions

A Quantity
of 1
Back & Seat
B Quantity
of 1
Armrest
C Quantity
of 2
Metal Leg
D Quantity
of 2
Bottom Rail
1 Quantity
of 6
Short Bolt ∅1/4*1-1/2”L
2 Quantity
of 5
Long Bolt ∅5/16*3-3/4”L
3Quantity
of 5
Flat Washer
4Quantity
of 5
Spring Washer
5Quantity
of 1
Allen Wrench M4
6Quantity
of 1
Allen Wrench M5
Care and Cleaning Instructions:
Please see care and cleaning label attached to bottom
of chair seat.
For replacement parts or questions, please
call Customer Service at 877-WAYFAIR
(877-929-3247)
RIGHT FACING CLUB CHAIR
Parts List
Before beginning assembly, separate all parts and carefully study the parts diagrams below.
Review all parts and hardware before disposing of any packaging.
You may receive extra hardware with your unit.
Call Customer Service for missing hardware.

Figure 1
Unpack and lay parts on clean,
padded surface like carpet or
blanket. Check that you have all
parts indicated on the front page.
Pull the zipper on bottom of Back
& Seat (A).
Lift the black dust cover from the
bottom of Back & Seat (A) and
take out the 2 legs (C) and 2
bottom rails (D).
Figure 2
Attach armrest (B) to Back & Seat
(A) with long bolts (2),flat washer
(3) and spring washer (4)
Tighten bolts (2) using the Allen
wrench (6) as shown on Figure 2.
Close the black dust cover. Then
close the zipper on the bottom of
Back & Seat (A).
RIGHT FACING CLUB CHAIR
Assembly Instructions
B
3
4
2
6
A
C
D

Figure 3
Attach 2 bottom rails (D) to the
bottom of Back & Seat (A) with
short bolts (1).
Tighten them using Allen wrench
(5) as shown on Figure 3
Don’t tighten them too tight.
Figure 4
Insert legs (C) into bottom
rails( D). Please make sure legs
(C)’s tenon go into bottom
rails(D)’end.
RIGHT FACING CLUB CHAIR
Assembly Instructions
D
1
D

Figure 5
Use 4 short bolts (1) to connect
the legs (C) to the bottom of Back
& Seat (A)
Tighten short bolts (1) using the
Allen wrench (5) as shown on
Figure 5.
Figure 6
Tighten all bolts.
Turn over the chair.
Now your chair is ready to use!
Figure 7
When you need to assemble
CX1123 left facing club chair and
CX1124 right facing club and
CX1125 slipper chair
Please swirl the connector on
bottom of CX1124/ CX1125 firstly,
then you can put CX1123/
CX1124/ CX1125 together as
shown in Figure 7.
B
C
D
90¡ã
CX1123 left facing club chair
CX1125 slipper chair
CX1124 right facing club
chair

Figure 8
Now your CX1123/ CX1124/
CX1125 whole set chair is ready to
use!
