Castleton Home DD-KB1262 User manual

For assistance with assembly or questions contact:
Wayfair Customer Service, 877-WAYFAIR (877-929-3247) | www.wayfair.com
PAGE 1
DD-KB1262
King Upholstered Bed 1
Product Instructions for:

For assistance with assembly or questions contact:
Wayfair Customer Service, 877-WAYFAIR (877-929-3247) | www.wayfair.com
PAGE 2
DD-KB1262
King Upholstered Bed 1
Before beginning assembly, separate all parts and carefully study the parts
diagrams below. Review all parts and hardware before disposing of any
packaging. You may receive extra hardware with your unit. Call Customer
Service for missing hardware.
A: Headboard (1)
B: Base Headboard (1)
C: Right Arm Post (1)
D: Left Arm Post (1)
E: Right Rail (1)
F: Left Rail (1)
G: Footboard (1)
H: Slat (4)
I: Leg (4)
J: Support Leg (4)
K: Support Block (2)
Parts list

For assistance with assembly or questions contact:
Wayfair Customer Service, 877-WAYFAIR (877-929-3247) | www.wayfair.com
PAGE 3
1: Bolt Dia. 1/4”x2-1/4”L (4)
2: Bolt Dia. 1/4”x2-3/8”L (10)
3: Bolt Dia. 1/4”x1-1/4”L (12)
4: Threaded Bolt Dia. 5/16”x4-1/4”L
(8)
5: Bolt Dia. 5/16”x2”L (3)
6: Flat Washer Dia. 5/16” (3)
7: Nut Dia. 5/16” (8)
8: Spring Washer Dia. 5/16” (11)
9: Allen Wrench (1)
10: Metal Plate (4)
11: Wrench (1)
12: Tooth Lock Washer (4)
13: Flat Washer Dia. 1/4” (10)
14: Spring Washer Dia. 1/4” (10)

For assistance with assembly or questions contact:
Wayfair Customer Service, 877-WAYFAIR (877-929-3247) | www.wayfair.com
PAGE 4
DD-KB1262
King Upholstered Bed 1
Figure 1
Step 1
Place a Tooth Lock Washer
(12) onto the bolt on each
Leg (I). Then, attach Legs (I)
and Tooth Lock Washers
(12) to Base Headboard (B)
by inserting Legs (I) into the
predrilled holes on Base
Headboard (B) and rotating
clockwise until Legs (I) are
tight.
Figure 2
Step 2
Use Bolts (1) to connect
Support Blocks (K) to Right
Arm Post (C) and Left Arm
Post (D) as shown in Figure
2.
Tighten Bolts (1) using Allen
Wrench (9).
Assembly Instructions
KD
C9
1
B
I
12

For assistance with assembly or questions contact:
Wayfair Customer Service, 877-WAYFAIR (877-929-3247) | www.wayfair.com
PAGE 5
Figure 3
Step 3
Lift the velcro strip cover at
the back of Headboard (A).
Using Bolts (5), Spring
Washers (8) and Flat
Washers (6), connect
Headboard (A) to Base
Headboard (B) as shown in
Figure 3.
Tighten Bolts (5) using Allen
Wrench (9).
Figure 4
Step 4
Lift the velcro strip cover at
the back of Base Headboard
(B).
Attach Headboard (A) and
Base Headboard (B) to
Right Arm Post (C) and Left
Arm Post (D) using Bolts (2),
Spring Washers (14) and
Flat Washers (13) as shown
in Figure 4.
Tighten Bolts (2) using Allen
Wrench (9).
Close the velcro strip
covers.
A
B
9
5
86
13
2
9
A
D
B
C
14

For assistance with assembly or questions contact:
Wayfair Customer Service, 877-WAYFAIR (877-929-3247) | www.wayfair.com
PAGE 6
Figure 5
Step 5
Place a Tooth Lock Washer
(12) onto the bolt on each
Leg (I). Then, attach Legs (I)
and Tooth Lock Washers
(12) to Footboard(G) by
inserting Legs (I) into the
predrilled holes on
Footboard(G) and rotating
clockwise until Legs (I) are
tight.
Figure 6
4
F2
J2
Step 6
Screw Threaded Bolts (4)
into predrilled holes on Right
Arm Post (C) and Footboard
(G). Attach Right Rail (E) to
Right Arm Post (C) and
Footboard (G) by inserting
exposed part of Threaded
Bolts (4) into predrilled holes
on Right Rail (E).
Repeat process on left side.
I
12
G
4
C
A
BE
FG
D

For assistance with assembly or questions contact:
Wayfair Customer Service, 877-WAYFAIR (877-929-3247) | www.wayfair.com
PAGE 7
Figure 7
Step 7
Insert a Metal Plate (10) into
each cavity on Right Rail
(E), placing Metal Plates
(10) onto exposed ends of
Threaded Bolts (4).
Use Nuts (7) and Spring
Washers (8) to secure Right
Rail (E) as shown in Figure
7.
Tighten Nuts (7) using
Wrench (11).
Repeat process on left side.
4
7
10
11
7
Figure 8
Step 8
Attach Support Legs (J) to
Slats (H) using Bolts (3).
Tighten Bolts (3) using Allen
Wrench (9).
8
10
11
7
8
7
9
3
H
J

For assistance with assembly or questions contact:
Wayfair Customer Service, 877-WAYFAIR (877-929-3247) | www.wayfair.com
PAGE 8
Figure 9
Step 9
Align Slat (H)/Leg (J) units
from Figure 8 with predrilled
holes on the inside of
bedframe Rails (E & F).
Use Bolts (3) to secure Slat
(H)/Leg (J) units to Rails (E
& F).
Tighten Bolts (3) using Allen
Wrench (9).
Figure 10
Step 10
Now your King
Upholstered Bed 1 is ready
to use!
3
9
