Castleton Home DD-QB7992 Instruction sheet

For assistance with assembly or questions contact:
Wayfair Customer Service, 877-WAYFAIR (877-929-3247) | www.wayfair.com
PAGE 1
DD-QB7992
Queen Upholstered Bed 3
Product Instructions for:

For assistance with assembly or questions contact:
Wayfair Customer Service, 877-WAYFAIR (877-929-3247) | www.wayfair.com
PAGE 2
DD-QB7992
Queen Upholstered Bed 3
Before beginning assembly, separate all parts and carefully study the parts
diagrams below. Review all parts and hardware before disposing of any
packaging. You may receive extra hardware with your unit. Call Customer
Service for missing hardware.
A: Headboard (1)
B: Rail (2)
C: Footboard (1)
D: Support Rail (1)
E: Support Slats (1)
F: Leg (4)
G: Support Leg (2)
1: Allen Wrench (1)
2: Bolt Dia. 1/4”x3-1/4”L (8)
3: Bolt Dia. 1/4”x1-1/4”L (8)
4: Flat Washer (12)
5: Spring Washer (12)
Parts list

For assistance with assembly or questions contact:
Wayfair Customer Service, 877-WAYFAIR (877-929-3247) | www.wayfair.com
PAGE 3
DD-QB7992
Queen Upholstered Bed 3
Figure 1
Step 1
Connect Legs (F) to
Headboard (A) using Bolts
(2), Spring Washers (5) and
Flat Washers (4) as shown in
Figure 1.
Tighten Bolts (2) using Allen
Wrench (1).
Figure 2
Step 2
Connect Legs (F) to
Footboard (C) using Bolts (2),
Spring Washers (5) and Flat
Washers (4) as shown in
Figure 2.
Tighten Bolts (2) using Allen
Wrench (1).
Assembly Instructions
A
F
45
1
2
C
F
451
2

For assistance with assembly or questions contact:
Wayfair Customer Service, 877-WAYFAIR (877-929-3247) | www.wayfair.com
PAGE 4
Figure 3
Step 3
Attach Rails (B) to connect
Headboard (A) and Footboard
(C) as shown in Figure 3.
Figure 4
Step 4
Attach Support Legs (G) to
Support Rail (D) by inserting
bolts of Legs (G) into predrilled
holes. Rotate Support Legs (G)
clockwise until tight.
B
C
A
D
G

For assistance with assembly or questions contact:
Wayfair Customer Service, 877-WAYFAIR (877-929-3247) | www.wayfair.com
PAGE 5
Figure 5
Step 5
Use Bolts (3), Spring Washers
(4) and Flat Washers (5) to
connect Support Rail (D) to
Headboard (A) and Footboard
(C) as shown in Figure 5.
Tighten Bolts (3) using Allen
Wrench (1).
Figure 6
4
F2
J2
Step 6
Put the Support Slats (E) onto
the bed frame.
Use Bolts (3) to connect the
Support Slats (E) to Rails (B).
Tighten Bolts (3) using Allen
Wrench (1).
A
B
C
D
3
1
5
4
3
1
E

For assistance with assembly or questions contact:
Wayfair Customer Service, 877-WAYFAIR (877-929-3247) | www.wayfair.com
PAGE 6
Figure 7
Step 7
Now your Queen Upholstered
Bed 3 is ready to use!
