Castleton Home DD-KHB8270-1CR User manual

For assistance with assembly or questions contact:
Wayfair Customer Service, 877-WAYFAIR (877-929-3247) | www.wayfair.com
PAGE 1
DD-KHB8270-1CR/DD-KHB8270-2LG
Headboard
Product Instructions for:

For assistance with assembly or questions contact:
Wayfair Customer Service, 877-WAYFAIR (877-929-3247) | www.wayfair.com
PAGE 2
DD-KHB8270-1CR/DD-KHB8270-2LG
Headboard
Before beginning assembly, separate all parts and carefully study the parts
diagrams below. Review all parts and hardware before disposing of any
packaging. You may receive extra hardware with your unit. Call Customer
Service for missing hardware.
Before beginning assembly, separate all parts and carefully study the parts
A：Headboard Cushion(1)
B：Right Leg (1)
C：Left Leg (1)
1：Allen Wrench (1)
2：Bolt: Dia. 1/4x2” (8)
3：Flat Washer (8)
4：Spring Washer (8)
Parts list

For assistance with assembly or questions contact:
Wayfair Customer Service, 877-WAYFAIR (877-929-3247) | www.wayfair.com
PAGE 3
DD-KHB8270-1CR/DD-KHB8270-2LG
HEADBOARD
Figure 1
Step 1
Unpack and lay parts on a clean,
padded surface like a carpet or
blanket. Check that you have all
parts indicated on the front page.
Lift the velcro strip cover found
on Headboard Cushion (A) and
take out Left Leg (C) and Right
Leg (B).
Close the velcro strip cover.
Figure 2
Step 2
Attach Left Leg (C) and Right
Leg (B) to back of Headboard
Cushion (A) as shown in Figure
2.
Use Bolts (2) with Spring
Washers (4) and Flat Washers
(3) to connect the Left Leg (C)
and Right Leg (B) to Headboard
Cushion (A).
Tighten Bolts (2) using Allen
Wrench (1)
Assembly Instructions
A
AC
12
43

For assistance with assembly or questions contact:
Wayfair Customer Service, 877-WAYFAIR (877-929-3247) | www.wayfair.com
PAGE 4
Figure 3
Step 3
Double check to be sure that
Bolts (2) are securely
tightened.
Now your Headboard is ready
to use!
