Castleton Home ZH1825-1IVY Instruction sheet

For assistance with assembly or questions contact:
Wayfair Customer Service, 877-WAYFAIR (877-929-3247) | www.wayfair.com
Product Instructions for:
Page 1
Product Instructions for:
ZH1825-1IVY CLUB CHAIR / ZH1825-2GY CLUB CHAIR /
ZH1825-3OA CLUB CHAIR

For assistance with assembly or questions contact:
Wayfair Customer Service, 877-WAYFAIR (877-929-3247) | www.wayfair.com
ZH1825-1IVY CLUB CHAIR / ZH1825-2GY CLUB CHAIR /
ZH1825-3OA CLUB CHAIR
Before beginning assembly, separate all parts and carefully study the parts diagrams below. Review all
parts and hardware before disposing of any packaging. You may receive extra hardware with your unit.
Call Customer Service for missing hardware. Please see care and cleaning label attached to bottom of
chair.
A Quantity
of 1
Seat
B Quantity
of 1
Back Panel
C Quantity
of 1
Left Side Panel
DQuantity
of 1
Right Side Panel
EQuantity
of 1
Pillow
FQuantity
of 1
Left Leg
G Quantity
of 1
Right Leg
HQuantity
of 1
Bottom Rail
Page 2
Parts List

For assistance with assembly or questions contact:
Wayfair Customer Service, 877-WAYFAIR (877-929-3247) | www.wayfair.com
1 Quantity
of 8
Screw:1”L
2 Quantity
of 2
Bolt:1/4”* 1-3/4”L
3 Quantity
of 13
Bolt:5/16”* 2-1/2”L
4 Quantity
of 13
Spring Washers
5Quantity
of 13
Flat Washers
6 Quantity
of 2
Wood Plugs
7 Quantity
of 1
Allen Wrench 5/16”
8 Quantity
of 1
Allen Wrench 1/4”
Page 3

For assistance with assembly or questions contact:
Wayfair Customer Service, 877-WAYFAIR (877-929-3247) | www.wayfair.com
ZH1825-1IVY CLUB CHAIR / ZH1825-2GY CLUB CHAIR /
ZH1825-3OA CLUB CHAIR
Figure 1
Unpack and lay parts on clean,
padded surface like carpet or
blanket. Check that you have all
parts indicated on the front page.
Lift the Velcro strip from bottom of
the Seat (Part B).
Attach Seat (Part A) to Back Panel
(Part B) by inserting Bolts (3)
through Spring Washer (4) and
Flat Washer (5). Don’t tighten
Bolts until all are in place, as
shown in Figure 1.
Figure 2
Attach Left Side Panel (Part C)
and Right Side Panel (Part D) to
Back Panel (Part B) by hand as
shown. Please make sure male
hook on side panel will exactly go
into female hook on back panel.
Use Bolts (3), Spring Washer (4)
and Flat Washer (5) to connect
Left Side Panel (Part C) and Right
Side Panel (Part D) to Seat (Part
A). Don’t tighten Bolts until all are
in place, as shown in Figure 2.
Then close Velcro Strip on the
bottom of Seat (Part A).
Page 4
Assembly Instructions
7
3
4
5A
B
7
3
4
5
A
B
C
D
A
B
C
D
BD
7
3
45

For assistance with assembly or questions contact:
Wayfair Customer Service, 877-WAYFAIR (877-929-3247) | www.wayfair.com
Figure 3
Attach the Bottom Rail (Part H) to
the Left Leg (Part F) and the Right
Leg (Part G) using Bolts. Tighten
by Allen Wrench. Plug the Wood
Plugs into the hole as shown in
Figure 3.
Figure 4
Attach the Left Leg (Part F) and
the Right Leg (Part G) to the Seat
(Part A) and tighten Screw (1)
using Philips screwdriver, as
shown in Figure 4.
Page 5
H
G
F
2
8
6
F
G
F
G
H
C
D
A
A
D
B
C
B
H
1

For assistance with assembly or questions contact:
Wayfair Customer Service, 877-WAYFAIR (877-929-3247) | www.wayfair.com
Figure 5
Turn over the chair then place the
Pillow on the chair as shown.
Now your chair is ready to use!
