CB2 RADIUS User manual

Made in China - r02 Page 1 of 4
radius CHAISE
1
hardware
components
tools required
Thank you for purchasing the Radius Chaise This
page lists all the contents included in the box. Please
take the time to identify the hardware as well as the
individual components to this product. As you unpack
and prepare for assembly, place the contents on a
carpeted or padded area to protect them from
damage.
Note: 2 people are required to safely assemble this product.
Missing hardware?
Please call 800.606.6387 for replacements.
Attach crossbars to each leg frame with 4
threaded inserts and 4 small bolt caps as
shown. Secure, but do not over tighten, the bolt
caps using an allen wrench.
2 - leg frames
1 - mattress 1 - mattress
cover
1 - frame
allen wrench
(included)
NOTE: Do not over
tighten the bolt caps
Customer Service 800.606.6252 | Latest instructions available at www.cb2.com
12 - threaded
inserts
8 - small
bolt caps
4 - large
bolt caps
2 - crossbars
crossbar
leg frame

radius CHAISE
Made in China - r02 Page 2 of 4
3
Customer Service 800.606.6252 | Latest instructions available at www.cb2.com
A. Place mattress cover upside
down as shown onto a clean,
padded surface. Unzip and open
small cover as shown.
B. Unzip and open large and inside
cover as shown.
2
A. With the assistance of another
adult, fit mattress into mattress
cover as shown.
B. Flip inside cover over mattress
as shown.
mattress cover
A
B
small cover
large cover
large cover inside cover
inside cover
mattress
mattress cover
A
B
inside cover
CLOSE
CLOSE
OPEN
OPEN

radius CHAISE
Made in China - r02 Page 3 of 4
5
Customer Service 800.606.6252 | Latest instructions available at www.cb2.com
With the assistance of another
adult, carefully place frame, with
slates facing down, into matress
cover as shown.
4
A. Zip up large cover as shown.
B. Wrap tabs of large cover around
bar of frame as shown. Secure by
firmly pressing down on tabs.
C. Zip up small cover as shown.
frame
matress cover
A
B
B
C
matress cover
large cover
tab
small cover
bar

radius CHAISE
Made in China - r02 Page 4 of 4
Customer Service 800.606.6252 | Latest instructions available at www.cb2.com
With the assistance of another
adult, carefully place leg frame
assembly onto mattress assembly
as shown. Secure with 4 threaded
inserts and 4 large bolt caps using
an allen wrench.
6
leg assembly
mattress assembly
CLEANING AND CARE
Clean surfaces with a dry or damp cloth. Do not
use abrasive cleaners. Wipe up spots and spilled
immediately. Keep out of direct sunlight to prevent
the cover from fading.
FABRICS ARE TEFLON TREATED TO RESIST
LIGHT STAINS ONLY. FOR HEAVIER STAINS,
PROFESSIONALLY DRY CLEAN.
7
With the assistance of another adult, position
assembled unit upright. Adjust seat back of chaise
up and down to desired position.
Assembly is now complete.
seat back
