CDA SK320 Quick start guide

www.cda.eu
SK320
Single oven
Installation, use and maintenance

2
Contents:
3 Important information
5 Safety instructions
6 First use of the oven
7 Oven controls, functions and use
10 Electronic programmer/timer
11 Setting the current time
11 Minute minder function
12 Semi-automatic cooking
13 Automatic cooking
14 Cleaning and maintenance
16 Removing the appliance door
17 Replacing the appliance door
18 Removing the inner door glass
19 Changing the oven light bulb
20 Installation
22 Mains electrical connection
24 Troubleshooting
25 Energy Eciency Information
IMPORTANT: Please read the user instructions carefully before
using the appliance for the first time and before installing it.
Failure to install the oven, or to have it installed, as per the user
manual could invalidate the warranty. Any service calls relating to
misuse or incorrect installation could incur a service charge.

3
Important
This appliance must only be used for the purpose for which it is
intended, i.e. domestic cooking. Any other use could be dangerous
and may lead to premature failure of the appliance.
The CDA Group Ltd cannot be held responsible for injuries or losses
caused by incorrect use or installation of this product. Please note that
CDA reserve the right to invalidate the guarantee supplied with this
product following incorrect installation or misuse of the appliance.
Under no circumstances should any external covers be removed for
servicing or maintenance except by suitably qualified personnel.
User information:
• Ovens become hot during and immediately after use.
•The oven door can become very hot during operation.
•After use, please ensure that the oven switches are in the ‘O’
position.
•Keep children away from the appliance when in use, and
immediately after use.
•Do not allow children to play with or on the appliance.
•Keep the oven door closed whilst grilling.
Appliance information:
Please enter the details from the appliance rating plate on to the
following page for reference, to assist CDA Customer Care in the
event of a fault with your appliance and to register your appliance for
guarantee purposes.

4
Appliance Model
Serial Number
EU Declarations of Conformity:
This oven has been designed, constructed and marketed in
compliance with safety requirements of EU Directive 2014/35/EU (Low
voltage) and requirements of EU Directive 2014/30/EU.
This appliance has been manufactured to the strictest standards and
complies with all applicable legislation, including Electrical safety (LVD)
and Electromagnetic interference compatibility (EMC). Parts intended
to come into contact with food conform to 1935/2004/EC.
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE
PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2012/19/EU.
At the end of its working life, the product must not be disposed
of as urban waste. It must be taken to a special local authority
dierentiated waste collection centre or to a dealer providing this
service.
Disposing of a household appliance separately avoids possible
negative consequences for the environment and health deriving from
inappropriate disposal and enables the constituent materials to be
recovered to obtain significant savings in energy and resources. As a
reminder of the need to dispose of household appliances separately,
the product is marked with a crossed-out wheeled dustbin.

5
Important
• Read the user instructions carefully before using the oven
for the first time.
• Follow the instructions for first use of the oven.
•Clean the oven regularly.
•Remove spills as soon as they occur.
•Always use oven gloves when removing shelves and trays
from the ovens.
•Do not allow children near the oven when in use.
•Do not allow fat or oils to build up on the oven shelves, grill
pan or oven base.
•Do not place any cooking utensils or plates directly on the
oven base.
•Always grill with the oven door closed.
•Do not grill food containing fat without using the grill pan
grid.
•Do not cover the grill pan grid, the oven walls or the base
with aluminium foil.
•Do not use the oven tray for roasting.
•Do not perform maintenance or cleaning of the oven
without first switching o the electricity supply. If the oven
has recently been used, allow to cool.
•Do not place hot enamel parts in water. Leave them to
cool first.
•Do not allow vinegar, coee, milk, saltwater, lemon or
tomato juice to remain in contact with enamel parts.
•Do not use abrasive cleaners or powders that will scratch
the surface of the enamel.
•Do not attempt to repair the internal workings of your oven.

6
• Do not dismantle any parts without disconnecting the oven
from the mains power supply.
•Do not use the appliance if any part is broken (e.g. door
glass). Disconnect it from the mains power supply and
contact CDA Customer Care.
•The cooling fan may run even long after the oven has
finished cooking.
•During use the appliance becomes very hot; do not touch
the heating elements inside the oven or the interior.
•Do not allow children near the oven when in use, nor to play
with it.
•This appliance is not intended for use by persons (including
children over the age of 8) with reduced physical, sensory
or mental capabilities, or lack of experience or knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for
their safety.
•Children may not perform cleaning and maintenance
unsupervised.
•Do not harsh abrasive cleaners or sharp metal scrapers to
clean the oven door glass since they can scratch the
surface, which may result in shattering of the glass.
•Abrasive detergents and steam cleaning equipment should
not be used for cleaning.
•The oven may require increased ventilation on the before
first use steps. This can be achieved either from an open
window or the use of an extractor.
•Clean up any major spills to avoid the risk of fire or
excessive smoke.

7
•Do not hang towels or cloths on the oven handle at any
time.
•Ensure that the oven is cool and power to the appliance
has been turned o before carrying out any cleaning or
maintenance including door removal.
•Always wear adequate PPE (Personal Protective Equipment)
when carrying out any handling, maintenance or cleaning.

8
First use of the oven
First use
•The metal casing of this appliance has been coated with a
preservative to protect it during transport and storage. This should
be removed during installation by using a non-abrasive stainless
steel cleaner. Always follow the instructions given with the cleaner
being used.
•Before using the oven for the first time we recommend that you
clean the oven with soapy water, rinse carefully. Set the current
time on the programmer as per page 13. Heat on each of the
below programmes at maximum temperature for the specified time.
A slightly unpleasant smell may be produced, caused by grease
remaining on the oven elements from the production process.
15 minutes full grill 60 minutes fan oven
60 minutes conventional oven
Please note:
•This oven has been fitted with a cooling fan to achieve maximum
eciency and to maintain low surface temperatures. The cooling fan
will switch on automatically when the oven switches on. It is normal
for the cooling fan to run for an hour or more after use, depending
on the duration, temperature and type of cooking programme used.
IMPORTANT - Always operate within the temperature ranges
stated for each function on pages 9 - 11.

9
Oven controls and use
IMPORTANT: You must set the current time on the oven
programmer, as per page 13, for the oven to operate properly.
Cooking function knob (B in Fig. 1)
To set the function, turn the cooking function knob (B in Fig. 1) to
the required function. You will need to set a temperature on all
functions except the defrost function. The neon indicator next to
the temperature knob will extinguish when the temperature has been
reached.
below and on the following two pages:
Fan oven
This function uses the circular heating element with a
temperature between 50°C and 250°C. The fan then
circulates the hot air which helps to achieve uniform
heat distribution.
Defrost
This function uses the fan to circulate air, at ambient
_+
Fig. 1 A B
BCD
F

10
temperature, within the oven which helps to accelerate
the defrosting process. 1 kg takes approximately 1 hour
to defrost, depending on the type of food.
Fanned Grill
This function radiates the heat from the grill element but
also uses the fan to circulate the hot air. The hot air is
distributed over and under the food that you are grilling.
This fully temperature variable grill is ideal for grilling
fish or other items whose appearance can be spoiled by
a normal grill function.
It can be set between 50°C and 250°C.
When fan grilling, please note:
• Always grill with the oven door closed.
• The grill pan does not need to be as close to the
grill as possible.
• Do not grill for more than 30 minutes at a time.
• Preheat the grill for up to five minutes with the
oven door closed.
Full Grill
This function radiates the heat from the grill element
and the top element.
This fully temperature variable grill is ideal for grilling a
full family meal. It can be set between 50°C and
250°C.

11
When grilling, please note:
• Always grill with the oven door closed.
• Put the grill pan as close to the grill as possible.
• Do not grill for more than 30 minutes at a time.
• Preheat the grill for up to five minutes with the
oven door closed.
Fanned conventional
This function uses the upper and lower heating
elements and the fan with a temperature range of 50°C
to 225°C. The fan circulates the heated air around the
cavity meaning temperatures are achieved quicker and
cooking is more even.
Conventional
This function uses the upper and lower heating
elements with a temperature range of 50°C to 240°C.
Convection creates an ideal cooking zone in the centre
of the oven, ideal for fruit cakes and pastries.
Warming
Using heat produced from the bottom element, this heat
setting creates an ideal environment for dough proving
and blind-baking

12
Temperature knob (A)
•To set the temperature, turn the temperature knob clockwise to the
required temperature.
•Once the oven has reached the required temperature, the
•The temperature indicator lamp will light up when the oven
elements are in operation.
Electronic programmer/timer
1 - Cooking time indicator 5 - Decrease key
2 - End of cooking time indicator 6 - Mode key
3 - Minute minder indicator 7 - Increase key
4- Current time indicator
1
2
3
4
567
Fig. 2

13
This oven’s electronic timer is equipped with touch control sensors.
Each registered touch of a sensor field is confirmed by a single beep.
It is advisable to keep the sensor fields clean at all times to avoid
errors in operation.
Setting the current time
After connection to the mains supply, or re-connection after a power
outage, the display will show ‘12.00’ and the clock symbol will flash.
•Set the current time using the and sensors. After an
approximately 5 second wait, the time will be set.
•The time can be amended at any time by following these steps.
However, you will firstly need to press until the display shows
the flashing symbol.
Please note: The time must be set for the oven to work.
Setting the minute minder function
The minute minder function can be set at any time, regardless of the
state of activity of the oven. The minute minder can be set anywhere
from 1 minute to 23 hours and 59 minutes.
•Press until the display shows the flashing symbol.
•Set the desired duration of the minute minder using the and
sensors. After an approximately 5 second wait, the minute
minder will be set and the symbol will be solidly lit.
•Press any of the three sensors in order to deactivate the acoustic
signal that sounds once the minute minder time has elapsed. The
timer will then revert to showing the current time.

14
Please note:
deactivate automatically after approximately 2 minutes.
Cancelling the minute minder function
The minute minder function can be cancelled at any time.
•Press to select the minute minder settings. This is indicated by
the symbol .
•Press the sensor until the time returns to 0.00 and wait 5
seconds.
Semi-automatic cooking
This function allows for a cooking time to be set. When the set time
will sound to alert the user.
To switch on semi-automatic cooking
•Set the desired oven function and temperature.
•Press the menu sensor until the display illuminates the symbol
and the timer display shows 0.00.
•Set the required cooking time using the timer left and right
sensors. The cooking time that can be set ranges from between
1 minute and 10 hours. After an approximately 5 second wait, the
time will be set and the symbol will remain lit.
•Once the set cooking time has elapsed the set function will be
symbol will flash. Press any of the three sensors in order to
deactivate the acoustic signal that sounds once the cooking time
has elapsed. The timer will then revert to showing the current time.

15
•Switch both control knobs to the o position.
To cancel semi-automatic cooking
The semi-automatic function can be cancelled at any time. To do this,
simply press until the display shows the symbol and use the
sensor to return the timer display to 0.00.
Please note: The acoustic signal, if not switched o manually, will
deactivate automatically after approximately 2 minutes.
Automatic cooking
This function allows for a duration and an end time to be set for
cooking. With this, the oven will start cooking automatically due to
the set duration determining how long before the end time that the
function will activate and begin cooking. For example, if you set the
cooking duration to 1 hour, and the end time to 15:30, then the oven
will activate the function at 14:30. When the set time elapses, the oven
will switch the set function o and an acoustic signal will sound.
To switch on automatic cooking
•Press until the display illuminates the symbol and the timer
display shows 0.00.
•Set the required cooking time using the and sensors.
The cooking time that can be set ranges from between 1 minute
and 10 hours.
•The cooking time will be set after approximately 5 seconds. The
display will revert to showing the current time and the symbol
will be illuminated.

16
• Press until the display illuminates the symbol and it begins
to flash.
•Set the end of cooking time using the and sensors.
The end of cooking time can be set no more than 23 hours and 59
minutes ahead of the current time.
•Set the desired function and temperature using the relevant
control knobs. The automatic function will now be set. Once the
end of cooking time has been reached an acoustic signal will
sound and the symbol will flash. To deactivate the acoustic
signal, press any of the three timer sensors. Alternatively, the
signal will deactivate automatically after approximately 2 minutes.
•Switch both control knobs to the o position.
To cancel automatic cooking
The semi-automatic function can be cancelled at any time. To do this,
simply press until the display shows the symbol and use the
sensor to return the timer display to 0.00.
Please note: It is not possible to adjust the time (of day) setting whilst
the semi-automatic and automatic cooking functions are operational.
Cleaning and maintenance
Keeping your oven clean and well maintained helps to prolong the
fault-free lifespan of it and helps prevent your home from being
filled with odours. It is important that, before any cleaning or
maintenance is performed, you switch o the oven at the mains
supply. Do not start any cleaning or maintenance until the oven
has been allowed to cool completely.

17
We recommend always wearing PPE (Personal Protective
Equipment) when carrying out any cleaning or maintenance.
Cleaning the oven exterior
As the oven has, glass, stainless steel and enamel surfaces you
should use a nonabrasive cleaner. Any abrasive cleaner (including Cif)
will scratch the surfaces and could erase the control panel markings.
Stainless steel can be eectively cleaned by simply using a dilute
solution of water and mild detergent and drying to a shine with a
clean cloth.
Proprietary stainless steel cleaners are available. We recommend
a microfibre cloth for stainless steel surfaces. If necessary, wipe
any area that has been cleaned using a damp soft cloth or tissue to
remove any residual cleaning fluid and then wipe dry with a clean, dry
cloth or tissue (such as kitchen towel).
Cleaning the oven interior
The oven should always be cleaned after use when it has been
allowed to cool down.
The cavity should be cleaned using a mild detergent solution and
warm water and then wiped dry with a suitable, clean cloth.
Suitable proprietary chemical cleaners may be used after first
consulting with the manufacturers’ recommendations and testing a
sample on a small area of the oven cavity. Abrasive cleaning agents
or scouring pads/cloths should not be used on the cavity surface.
IMPORTANT:
•Steam cleaners must not be used when cleaning this appliance.

18
•Once care and maintenance is complete, ensure that all parts
are correctly replaced before using the oven.
Removing the appliance door
In order to allow for easier access into the oven cavity for cleaning, it
is possible to remove the door. Before removing the door, ensure that
you have an area prepared in which you can place the removed door.
This area should ideally be protected by something like a folded, dirt-
free, towel to help prevent damage to surfaces and the door.
•Open the door to the full extent (1).
•Open the lever A completely on the left and right hinges (2).
• Raise and hold the door as shown in image 5 on page 19.
•Gently close the door (3) until left and right hinge levers A are
hooked to part B of the door (2).
•Withdraw the hinge hooks from their location following arrow C (4).
•Rest the door on the pre-prepared soft, clean surface.
B
B
C
`
A
12
3 4

19
Replacing the appliance door
•Hold the door to the appliance in
the closed position and manoeuvre
the hinges so that the part of the
hinge, highlighted by the star in fig.
3, inserts into the hinge slot in the
cavity frame.
•Next, ensure the notch on the
underside of the hinge sits on the
lip of the hinge slot. Open the door
fully. Each hinge should be seated
in the same way as the hinge in
fig. 4. If it is not, follow the steps for
removing the door and try replacing
it again.
•Finally, lift the safety catch part of the hinges back into place so
that they are lying flat against the hinges.
Please note: If the hinge safety catches are not in the correct
place then the door and/or appliance may receive damage when
attempting to close the door.
Fig. 3
Fig. 4
5

20
Removing the inner door glass
The inner pane of glass can be removed for cleaning purposes. To do
so, follow the steps below.
Important: Do not disassemble the door without it having been
removed from the oven as per page 18. Weight dierences could
cause the door to snap shut, causing damage to the oven and/or
the user.
•Remove both door top corner pieces. These can be removed by
pressing in the arrow-marked tabs (indicated in image below) and
sliding the corner pieces in the direction indicated in the image
below.
•Lift the top edge of the glass slightly and then slide the lower edge
from its clips.
•After cleaning the glass, replacement is a reversal of the removal
process. Take care to replace the glass the correct way round -
the printed surface must be visible when the door is opened.
Tab
