Central Machinery 91762 User manual

6-1/2 HP PLATE COMPACTOR
91762
SET UP, OPERATING, AND SERVICING
INSTRUCTIONS
Using an engine indoors CAN KILL YOU IN
MINUTES.
Engine exhaust contains carbon monoxide.
This is a poison you cannot see or smell.
NEVER use inside
a home or garage,
EVEN IF doors and
windows are open.
Only use OUTSIDE
and far away from
windows, doors,
and vents.
Distributed exclusively by Harbor Freight Tools®.
3491 Mission Oaks Blvd., Camarillo, CA 93012
Visit our website at: http://www.harborfreight.com
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
Copyright©2004 by Harbor Freight Tools®. All rights reserved. No portion of this manual or any artwork
contained herein may be reproduced in any shape or form without the express written consent of Harbor
Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing improvements,
actual product may differ slightly from the product described herein.
For technical questions or replacement parts, please call 1-800-444-3353.

SKU 91762 For technical questions, please call 1-800-444-3353. PAGE 2
PRODUCT SPECIFICATIONS
SAVE THIS MANUAL
You will need this manual for the safety warnings and precautions, assembly, operating,
inspection, maintenance and cleaning procedures, parts list and assembly diagram. Keep
your invoice with this manual. Write the invoice number on the inside of the front cover.
Keep this manual and invoice in a safe and dry place for future reference.
GENERAL SAFETY PRECAUTIONS
WARNING!
READ AND UNDERSTAND ALL INSTRUCTIONS
Failure to follow all instructions listed in the following
pages may result in electric shock, fire, and/or serious injury.
SAVE THESE INSTRUCTIONS
UNPACKING
When unpacking, check to make sure all the parts shown on the Parts List on page 14
are included. If any parts are missing or broken, please call Harbor Freight Tools at the
number shown on the cover of this manual as soon as possible.
Operating Speed 0-82 Feet (0-25 Meters) Per Minute
Maximum Shock Force 3,000 Pounds
Vibration Frequency 5,500 Vibrations Per Minute
Maximum Performance 350 m2/hr
Engine Type 6.5 HP Briggs & Stratton
4 Stroke
Unleaded Gasoline Powered
Engine Approval: EPA - Phase 2
Plate Size 16-1/2” x 22”
Overall Dimensions 34-1/2” L x 15-1/4” W x 35-3/8” H
Weight 189 Pounds
REV 08d

SKU 91762 For technical questions, please call 1-800-444-3353. PAGE 3
WORK AREA
Keep your work area clean and well lit.1. Cluttered benches and dark areas invite
accidents.
Do not operate power tools in explosive atmospheres, such as in the presence2.
of flammable liquids, gases, or dust. Power tools create sparks which may ignite
flammables.
Keep bystanders, children, and visitors away while operating a power tool.3.
Distractions can cause you to lose control. Protect others in the work area from
debris such as chips and sparks. Provide barriers or shields as needed.
PERSONAL SAFETY
Stay alert. Watch what you are doing, and use common sense when operating1.
a power tool. Do not use a power tool while tired or under the influence of
drugs, alcohol, or medication. A moment of inattention while operating power
tools may result in serious personal injury.
Dress properly. Do not wear loose clothing or jewelry. Contain long hair.2.
Keep your hair, clothing, and gloves away from moving parts. Loose clothes,
jewelry, or long hair can be caught in moving parts.
Avoid accidental starting. Be sure the Gasoline Engine Ignition Switch is3.
off before transporting the Vibrator Plate or performing any maintenance or
service on the unit. Transporting or performing maintenance or service on a power
tool with its Engine Ignition Switch on invites accidents.
Remove adjusting keys or wrenches before turning on the tool.4. A wrench or a
key that is left attached to a rotating part of the tool may result in personal injury.
Do not overreach. Keep proper footing and balance at all times.5. Proper footing
and balance enables better control of the tool in unexpected situations.
Use safety equipment. Always wear ANSI approved safety goggles under-6.
neath a full face shield, a dust mask or respirator, hearing protection and
heavy duty work boots.
TOOL USE AND CARE
Do not force the tool. Use the correct tool for your application.1. The correct
tool will do the job better and safer at the rate for which it is designed.

SKU 91762 For technical questions, please call 1-800-444-3353. PAGE 4
Do not use the power tool if the Engine Ignition Switch does not turn it on or2.
off. Any gasoline powered tool that cannot be controlled with the Engine Ignition
Switch is dangerous and must be replaced.
Disconnect the Engine Spark Plug Wire from the Spark Plug before making3.
any adjustments, changing accessories, or storing the tool. Such preventive
safety measures reduce the risk of starting the tool accidentally.
Store idle tools out of reach of children and other untrained persons.4. Tools
are dangerous in the hands of untrained users.
Maintain tools with care.5. Do not use a damaged tool. Tag damaged tools “Do
not use” until repaired.
Check for misalignment or binding of moving parts, breakage of parts, cracking6.
or breakage of parts, and any other condition that may affect the tool’s
operation. If damaged, have the tool serviced before using. Many accidents
are caused by poorly maintained tools.
Use only accessories that are recommended by the manufacturer for your7.
model. Accessories that may be suitable for one tool may become hazardous
when used on another tool.
SERVICE
Tool service must be performed only by qualified repair personnel.1. Service or
maintenance performed by unqualified personnel could result in a risk of injury.
When servicing a tool,use only identical replacement parts. Follow instructions2.
in the “Inspection, Maintenance, And Cleaning” section of this manual. Use
of unauthorized parts or failure to follow maintenance instructions may create a
risk of injury.
SPECIFIC SAFETY PRECAUTIONS
Maintain labels and nameplates on the Vibrator Plate.1. These carry important
information. If unreadable or missing, contact Harbor Freight Tools for a
replacement.
CAUTION! To avoid injury, keep hands, fingers, and feet away from the2.
Compactor Base (27). Grip the Upper Handle (46) of the Vibrator Plate firmly with
both hands. If both hands are holding the Handle and your feet are clear of the
Compactor Base, your hands, fingers, and feet cannot be injured by the Compactor
Base. Never place tools under the Compact Vibrator Plate.

SKU 91762 For technical questions, please call 1-800-444-3353. PAGE 5
FIRE AND EXPLOSION PRECAUTIONS
1. Gasoline fuel and fumes are flammable, and potentially explosive. Use
Always use recommended replacement parts.3. The recommended replacement
parts are available from Harbor Freight Tools. Servicing should be done by a qualified
service technician.
Use safety equipment. Always wear ANSI approved safety goggles underneath4.
a full face shield, a dust mask or respirator, and hearing protection.
Industrial applications must follow OSHA requirements.5.
Keep all spectators6. at least six feet from the Compact Vibrator Plate during
operation.
It is recommended that the Vibrator Plate be used only in well ventilated7.
outdoor areas. Carbon monoxide fumes are a colorless, odorless gas that, if
inhaled, can cause serious injury or death. If the Vibrator Plate is used in enclosed
spaces, the Engine exhaust fumes must be piped out of the enclosed space using
leak-free, heat-resistant piping. The pipes should not use any flammable materials,
nor should they be installed near the same. Engine exhaust fumes must be within
legal limits.
Only use a suitable means of transport and lifting devices with sufficient8.
weight bearing capacity when transporting the Compact Vibrator Plate.
Only use sturdy loading ramps with sufficient weight bearing capacity.9. Secure
the Vibrator Plate on transport vehicles to prevent the tool from rolling, slipping, and
tilting.
Never leave the Compact Vibrator Plate unattended while it is running.10.
Always keep a safe distance away from the edges and banks of ditches and11.
avoid any actions that may cause the Vibrator Plate from toppling over.
Always ascend slopes carefully in a direct path.12.
Reverse up steep slopes to prevent theVibrator Plate from toppling over onto13.
the operator.
When performing compacting work in the vicinity of buildings or above14.
pipelines, make sure to check the affect of the vibrations on the buildings and
pipelines. If necessary, immediately stop the compacting work.
Always park the Vibrator Plate on a firm and level surface.15.

SKU 91762 For technical questions, please call 1-800-444-3353. PAGE 6
2. Keep the Vibrator Plate and surrounding area clean at all times.
3. When spills of fuel or oil occur, they must be cleaned up immediately.
Dispose of fluids and cleaning materials as per any local, state, or federal codes
and regulations. Store oil rags in a covered metal container.
4. Never store fuel or other flammable materials near the Vibrator Plate.
5. Do not smoke, or allow sparks, flames or other sources of ignition around
the Engine and Fuel Tank. Fuel vapors are explosive.
6. Keep grounded conductive objects, such as tools, away from exposed, live
electrical parts and connections to avoid sparking or arcing. These events
could ignite fumes or vapors.
7. Do not refill the Fuel Tank while the Engine is running or while the Engine
is still hot. Do not operate the Vibrator Plate with known leaks in the fuel
system.
8. Excessive buildup of unburned fuel gases in the exhaust system can create
a potentially explosive condition. This buildup can occur after repeated
failed start attempts, valve testing, or hot engine shutdown. If this occurs,
open exhaust system drain plugs, if equipped, and allow the gases to dissipate
before attempting to restart the Engine.
9. Always check the Engine oil level prior to starting the Engine. Make sure to
read and understand the Engine Owner’s Manual for the proper oil level and oil
change schedules.
10. Use only engine manufacturer recommended fuel and oil. Refer to the
Engine Owner’s Manual for further instructions.
proper fuel storage and handling procedures. Always have multiple ABC
class fire extinguishers nearby.
MECHANICAL PRECAUTIONS
1. ALWAYS make sure the Engine’s Power Switch is in its “OFF” position.
Disconnect the spark plug wire, and allow the Engine to completely cool
before carrying out maintenance.
2. Check for damaged parts. Before using the Vibrator Plate, any part that
appears damaged should be carefully checked to determine that it will operate

SKU 91762 For technical questions, please call 1-800-444-3353. PAGE 7
properly and perform its intended function. Check for alignment and binding of
moving parts, any broken parts or mounting fixtures, and any other condition
that may affect proper operation. Any part that is damaged should be properly
repaired or replaced by a qualified technician.
3. Make sure to read and understand all instructions and safety precautions
as outlined in the Engine manufacturer’s Owner’s Manual. Do not attempt
to operate the Vibrator Plate until you fully understand how to properly operate
and maintain the Engine and how to avoid accidental injuries and/or property
damage.
4. Do not alter or adjust any part of the Vibrator Plate that is assembled and
supplied by the manufacturer.
5. Always follow and complete scheduled Engine and Vibrator Plate
maintenance.
NOISE PRECAUTIONS
Prolonged exposure to noise levels above 85 dBA is hazardous to hearing.
Always wear ANSI approved ear protection when operating or working around
the Vibrator Plate when it is running.
BURN AND CHEMICAL PRECAUTIONS
1. Avoid contact with hot fuel, oil, exhaust fumes, and hot solid surfaces.
2. Avoid body contact with fuels, oils, and lubricants used in the Engine. If
swallowed, seek medical treatment immediately. Do not induce vomiting if
fuel is swallowed. For skin contact, immediately wash with soap and water. For
eye contact, immediately flush eyes with clean water.
HEART PACEMAKER WARNING
WARNING! People with pacemakers should consult their physician(s)
before using this product. Electromagnetic fields in close proximity to a heart
pacemaker could cause interference to or failure of the pacemaker.

SKU 91762 For technical questions, please call 1-800-444-3353. PAGE 8
CALIFORNIA PROPOSITION 65 WARNINGS
1. WARNING! Operation of this Vibrator Plate and/or Engine exhaust from
this product contains chemicals known to the State of California to cause cancer,
birth defects, or other reproductive harm.
(California Health & Safety Code § 25249.5, et seq.)
2. WARNING! Some dust created by compacting materials, power sanding,
sawing, grinding, drilling, and other construction activities, contain chemicals
known (to the State of California) to cause cancer, birth defects or other
reproductive harm. Some examples of these chemicals are: lead from lead-
based paints, crystalline silica from bricks and cement or other masonry
products, arsenic and chromium from chemically treated lumber. Your risk
from these exposures varies, depending on how often you do this type of work.
To reduce your exposure to these chemicals: work in a well ventilated area,
and work with approved safety equipment, such as those dust masks that are
specially designed to filter out microscopic particles.
(California Health & Safety Code § 25249.5, et seq.)
WARNING! The warnings, precautions, and instructions discussed in this
manual cannot cover all possible conditions and situations that may occur. The
operator must understand that common sense and caution are factors which
cannot be built into this product, but must be supplied by the operator.
OWNER/OPERATOR WARNING
REV 04g, 07j

SKU 91762 For technical questions, please call 1-800-444-3353. PAGE 9
ASSEMBLY INSTRUCTIONS
NOTE: For additional references to the parts listed in the following pages, refer to the
Assembly Diagram on page 15.
Handle Setup:
1. Loosen the Knob Handle (53) on each side of the Upper Handle (46).
2. Swing the Upper Handle until it points straight out from the Lower Handle (14).
Tighten both Knob Handles (53) securely.
3. Make sure that the Upper Handle (46) is FIRMLY attached to the unit BEFORE
use. See the parts list and assembly diagram on pages 14 and 15.
VIBRATION HAZARD
This tool vibrates during use. Repeated or long-term exposure to vibration may
cause temporary or permanent physical injury, particularly to the hands, arms
and shoulders. To reduce the risk of vibration-related injury:
Anyone using vibrating tools regularly or for an extended period should first1.
be examined by a doctor and then have regular medical check-ups to ensure
medical problems are not being caused or worsened from use. Pregnant women
or people who have impaired blood circulation to the hand, past hand injuries,
nervous system disorders, diabetes, or Raynaud’s Disease should not use this
tool. If you feel any medical or physical symptoms related to vibration (such as
tingling, numbness, and white or blue fingers), seek medical advice as soon as
possible.
Do not smoke during use. Nicotine reduces the blood supply to the hands and2.
fingers, increasing the risk of vibration-related injury.
Wear suitable gloves to reduce the vibration effects on the user.3.
Use tools with the lowest vibration when there is a choice between different4.
processes.
Include vibration-free periods each day of work.5.
To reduce vibration, maintain the tool as explained in this manual. If any6.
abnormal vibration occurs, stop use immediately.
REV 07j; 08d

SKU 91762 For technical questions, please call 1-800-444-3353. PAGE 10
CONTROLS
Fast Speed
Lever Position Slow Speed
Lever Position
Figure 1 Figure 2
Speed Control Lever
Choke Control Lever
Engine
Power
Switch
Fuel Valve
Lever
Figure 3
Figure 4
Start Handle
REV 08d
Pre-Start Checks:
1. Check to make sure the Engine’s Power Switch is in its “OFF” position. See
Figure 4 above.
OPERATING INSTRUCTIONS
Figure 4

SKU 91762 For technical questions, please call 1-800-444-3353. PAGE 11
2. IMPORTANT ! Prior to first using the Vibrator Plate, the Engine MUST be
filled with a high quality SAE 10W-30 grade engine oil. To do so, unscrew
and remove the Engine’s Oil Fill Plug located at the bottom of the Engine Crank-
case. Fill the Engine’s Crankcase until the oil level is level with the Oil Fill Hole.
Then, screw the Oil Fill Plug back into the Oil Fill Hole. (For additional informa-
tion, refer to the engine manufacturer’s manual.)
3. Before the first use, remove the Engine’s Fuel Tank Cap and fill the Fuel Tank
with unleaded gasoline. Then, replace the Fuel Tank Cap. Thereafter, check the
Fuel Tank for the amount of unleaded gasoline. Refill the Fuel Tank with unlead-
ed gasoline only.
To Start And Operate The Vibrator Plate:
1. Turn the Fuel Valve on the Engine to “ON”. See Figure 3, page 10.
2. Turn the Choke Lever on the Engine to its “CHOKE” position. See Figure 4.
3. Set the Speed Control Lever (19) to its “FAST” position. See Figure 1, page 10.
4. Turn the Engine’s Power Switch to its “ON” position. See Figure 4, page 10.
5. Hold the Start Handle of the Engine loosely and pull it slowly several times
to allow the gasoline to flow into the Engine’s carburetor. Then hold the Start
Handle firmly and pull the rope hard and fast. Pull the rope all the way out, using
two hands if necessary. If necessary, pull the rope several times until the Engine
starts. See Figure 4, page 10.
6. Allow the Engine to run for several seconds. Then, move the Choke Lever very
slowly to its “RUN” position.
NOTE: Moving the Choke Lever too fast could kill the engine. See engine
manual.
7. Grip the Upper Handle (46) firmly with both hands.
8. Depending on the desired speed at which the Vibrator Plate will vibrate, adjust
the Speed Control Lever (19) between its “LOW” to “HIGH” position.
9. Slowly push or pull the Vibrator Plate while guiding the tool in the desired
direction.
10. Always keep a safe distance away from the edges and banks of ditches and
avoid any actions that may cause the Vibrator Plate to topple over.
11. Always ascend slopes carefully in a direct path. Reverse up slopes to prevent the
Vibrator Plate from toppling over onto the operator.
To Stop The Vibrator Plate:
1. Turn the Speed Control Lever (19) to its “LOW” position. See Figure 1, page 10.
2. Turn the Engine’s Power Switch to its “OFF” position.
3. Turn the Fuel Valve on the Engine to “OFF”.
NOTE: Always park the Vibrator Plate on a firm and level surface. REV 04g, 08c

SKU 91762 For technical questions, please call 1-800-444-3353. PAGE 12
INSPECTION, MAINTENANCE, AND CLEANING
1. CAUTION! Always make sure the Engine’s Power Switch is in its
“OFF” position. Disconnect the spark plug wire from the engine. Allow
sufficient time for the Engine to completely cool before performing any
inspection, maintenance, or cleaning on the Vibrator Plate and/or Engine.
2. Before each use, inspect the general condition of the Vibrator Plate. Check for
loose screws, misalignment or binding of moving parts, cracked or broken parts,
and any other condition that may affect its safe operation. If an Engine problem
occurs, always have the Engine immediately checked out by a qualified service
technician before further use.
Do not use damaged equipment.
3. Before each use, check to make sure the Engine’s oil level is adequate. If
necessary, fill the Engine’s Crankcase until the oil level is even with the Oil Fill
Hole.
4. Before each use, remove all debris from the Vibrator Plate using a soft brush,
vacuum, or a compressed air gun. Use a premium quality, lightweight machine oil
to lubricate all moving parts.
5. Read the engine manual for instructions on when to replace the motor oil
and how to properly maintain the engine. Make sure to contact a local
environmental or recycling center for proper disposal of old oil.
6. Every 300 hours of use, have a qualified, certified technician perform thorough
maintenance on the Vibrator Plate and its Engine.
7. The Knob Handles (53) can be loosened and the Upper Handle (46) folded down
to aid in storage.
Lubricating the Grease Bearing
REV 04g; 05j; 08d
After every 120 hours of use, the1.
Grease Bearing (33) must be greased
through the Grease Port (52) .
First, remove the Pulley Cover (11) by2.
removing the four Bolts (13). See the
parts list and assembly diagram on
pages 14 and 15.
Using a grease gun with a Zerk grease3.
adapter, insert high temperature bear-
ing grease ( NLGI Grade 2 ) into the
Grease Port (52). See the photo to the
right.
Grease Port (52)

SKU 91762 For technical questions, please call 1-800-444-3353. PAGE 13
Belt Tension Adjustment Instructions:
Turn off engine.1.
Loosen, but do not remove, the 4 nuts (40) that hold the engine (36) to the con-2.
necting plates (39).
Slide the engine (36), away from the Driven Pulley (29), until the belts are prop-3.
erly tensioned. Tighten the 4 nuts (40) that hold the engine (36) to the connecting
plates (39).
Belt Replacement Instructions:
Turn off engine.1.
Loosen, but do not remove, the 4 nuts (40) that hold the engine (36) to the con-2.
necting plates (39).
Using nut (38) and bolt (37), slide the engine (36) towards to the driven pulley (29)3.
until belts (9) can be removed.
Remove the old belts, then install new ones.4.
Using nut (38) and bolt (37), slide engine (36) away from driven pulley (29) until5.
belt is properly tensioned.
Retighten the 4 nuts (40) that hold the engine (36) to the connecting plates (39).6.
Draining The Gas Tank:
Refer to the engine manual for instructions on how to safely remove gas from the1.
fuel tank.
We recommend that you add fuel stabilizer to the gas if you are planning to store2.
the Plate Compactor for a long period of time.

SKU 91762 For technical questions, please call 1-800-444-3353. PAGE 14
REV 04g; 06i; 08d
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND
ASSEMBLY DIAGRAM INTHIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER
OR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER
THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS
QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR
DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE
UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER
ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL
PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION
OF REPLACEMENT PARTS THERETO.
Part Description Qty. Part Description Qty.
1 Shaft Circlip 1 28 Base Cover 1
2 Hole Circlip 2 29 Driven Pulley 1
3 Ball Bearing (6006) 2 30 Bolt (M8x25) 12
4 Bolt (M12x60) 2 31 Washer (Φ8) 16
5 Drive Pulley 1 32 Bearing Cover (2) 1
6 Cover 1 33 Bearing (6308) 2
7 Friction Block 6 34 Bearing Cover(1) 1
8 Spring 1 35 Screw 1
9 Cone Belt 2 36 Gas Engine 1
10 Flap Wheel 1 37 Bolt(M10x60) 1
11 Pulley Cover 1 38 Nut (M10) 1
12 Washer (Φ12) 22 39 Connecting Plate 2
13 Bolt (M10x25) 4 40 Nut (M8) 4
14 Lower Handle 1 41 Single Threaded Rubber Shaft 2
15 Screw 3 42 Inner Hex Screw 6
16 Rubber Sleeve 2 43 Bearing Housing 1
17 Nut (M5) 1 44 Stopper Plate 1
18 Washer 2 45 Bolt (M12x30) 1
19 Speed Control Lever 1 46 Handle (upper) 1
20 Flexible Shaft 1 47 Bolt (M10x60) 2
21 Washer (Φ8) 2 48 Rivet Φ8 2
22 Nut (M12) 10 49 Oil Seal 1
23 Spacer Plate 8 50 Flat Washer 1
24 Double Threaded Rubber Shaft 4 51 Bolt 1
25 Eccentric Shaft 1 52 Grease Port 2
26 Flat Pin 1 53 Knob Handle 2
27 Compactor Base 1

SKU 91762 For technical questions, please call 1-800-444-3353. PAGE 15
ASSEMBLY DIAGRAM
NOTE: Some parts are listed
and shown for illustration pur-
poses only, and are not avail-
able individually as replace-
ment parts.
REV 04g; 08d

SKU 91762 For technical questions, please call 1-800-444-3353. PAGE 16
LIMITED 1 YEAR / 90 DAY WARRANTY
Harbor Freight Tools Co. makes every effort to assure that its products meet high
quality and durability standards, and warrants to the original purchaser that for a period
of ninety days from date of purchase that the engine/motor, the belts (if so equipped),
and the blades (if so equipped) are free of defects in materials and workmanship. Har-
bor Freight Tools also warrants to the original purchaser, for a period of one year from
date of purchase, that all other parts and components of the product are free from
defects in materials and workmanship (90 days if used by a professional contractor or
if used as rental equipment). This warranty does not apply to damage due directly or
indirectly, to misuse, abuse, negligence or accidents, repairs or alterations outside our
facilities, normal wear and tear, or to lack of maintenance. We shall in no event be liable
for death, injuries to persons or property, or for incidental, contingent, special or con-
sequential damages arising from the use of our product. Some states do not allow the
exclusion or limitation of incidental or consequential damages, so the above limitation
of exclusion may not apply to you. THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL
OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE WARRANTIES OF
MERCHANTABILITY AND FITNESS.
To take advantage of this warranty, the product or part must be returned to us
with transportation charges prepaid. Proof of purchase date and an explanation of the
complaint must accompany the merchandise. If our inspection veries the defect, we
will either repair or replace the product at our election or we may elect to refund the
purchase price if we cannot readily and quickly provide you with a replacement. We will
return repaired products at our expense, but if we determine there is no defect, or that
the defect resulted from causes not within the scope of our warranty, then you must
bear the cost of returning the product.
This warranty gives you specic legal rights and you may also have other rights
which vary from state to state.
3491 Mission Oaks Blvd. • PO Box 6009 • Camarillo, CA 93011 • [phone]
