Challenger ADWC User manual

Installation and Operation Manual
Smart Anti-theft Alarm System
SOS
ADWC

Installation Safety
1. Keep children and bystanders away while installing the products.
2. The Alarm PIR Unit must be mounted in a location free from vibration as
unwanted alarm conditions will occur.
3.Wear ANSI-approved safety goggles during installation.
4. This product is not a toy. Mount it out of reach of children.
Operation Safety
1. Do not operate electrically powered products in explosive atmospheres, such as
in the presence of flammable liquids, gases, or dust. Electrically powered
products create sparks which may ignite the dust or fumes.
2. The warnings, precautions, and instructions discussed in this instruction manual
cannot cover all possible conditions and situations that may occur. It must be
understood by the operator that common sense and caution are factors which
cannot be built into this product, but must be supplied by the operator.
3. Do not expose the product to rain or wet conditions. Water entering the Power
Adapter will increase the risk of electric shock.
1
Packing List
Remote control User Manual
2
SOS
Alarm PIR Unit
Alarm PIR Unit
Arm button
Disarm button
Speaker
Register button
Battery indicator
Base
Battery Installation
Transmission Frequency
868.35 Mhz
1
about 30 seconds
100db (Distance: 30cm)
6V(1.5V 4pcs) AAbattery
70mA~100mAH
0~5m
0
120
Function:
1. Receiving and processing remote control.
2. Alarm bells
3. Doorbell rings
(Low battery the LED light)
Quantity
Ring Time
Alarm sound intensity
Supply Voltage
Operating current
PIR
Mounting Screw
Detection distance
Detection angle

3
REMOTE CONTROL
Arm button: click the button, the system enter arming status
Disarm button: Click the button, the system enter disarming status
Bell button: Click the button, the system enter doorbell mode
SOS button: click the button,the alarm will sound on the PIR unit.
SOS
SOS
Battery Installation
Function: Remote Host conversion mode
Battery indicator: Low battery the LED light
Transmission Frequency
868.35 Mhz
Transmission Distance
Supply Voltage
Operating current
The total numbercoding
0~150m
3V CR2032 battery
5mA~6mAH
1000000
1. Keep on press button
about 5 seconds
2.The LED light
on the host
SOS
3. press button on the
remote control the
LED turn off on the host
Learning remote control
Clears the original component identification code to enter this feature! When you need to replace
the components need to use this feature!
. press button
to exit learn model.
PIR+PIR Alarm Unit
SOS
1.press the button on the host
or keep on press button on
remote control until ring "DI" tone .
2.Host sound "DI" tone
4.when the host is triggered
5. Wait about 10 seconds 6. The host enters alarm
status (about 30 seconds)
4
3.Wait about 50~70 seconds
until the host response "DI"
tone, enter the armed status
50~
70
Note: Only learn oneremote unit ata time.

5
SOS alarm
SOS
2. The host enters alarm status
(about 30 seconds)
SOS
3.press the button on the host
or button on remote control to
stop the alarm and disarm
1. Press the SOS button
Doorbell function
2. When the host is triggered
3. Host ring "DINGDONG" sound
7.press the button on the host
or button on remote control to
stop the alarm and disarm
SOS
SOS
1.press the button on the host or keep on press
button on remote control until ring "Ding Dong" tone .
NOTICE: If there is no in operation ,after the alarm ends to enter the theft mode.
Due to our policy of continuous improvement we reserve the right to change
specification without prior notice. Errors and omissions accepted. These instructions
have been carefully checked prior to publication. However, no responsibility can be
accepted by Challenger Security Products for any misinterpretation of these
instructions.
CHALLENGER SECURITY PRODUCTS
10 SANDERSONS WAY, BLACKPOOL, FY4 4NB
Email:
Website:
[email protected]
www.challenger.co.uk
Challenger_AWDC_Instructions_Rev01
RoHS
