Challenger SMART FORCE User manual

S
mart
F
orce
Quick Guide
Package Content
1 x Gateway
1 x PIR Motion 1 x Magnetic 1 x Keyfob
Detector Contact Detector
1 x utdoor Solar Sensor
Gateway Installation
1. Choose a suitable location for the Gateway, e.g. living room.
2. Connect internet cable from your router to one of the ports on the Gateway, as shown below.
3. Plug the DC adaptor to the Gateway to power it on.
. Wait until the Internet LED on the gateway turns green (this may take some time).
Register the Gateway via PC
Create a new account at https://smartforce.myluxhome.com/
1. Click on “Create a new account”
2. Enter the required information and click “Submit”.
Router
DC
adaptor

Challenger_Smart_Force_Quick_Set_Up_Guide_Rev01
3. Enter the Access code. It is printed on the label at the back of the Gateway. Click “Next step” when
finished.
. The system will now test if the gateway is connected to the server.
5. The system may upgrade the Gateway software, do not unplug the power or internet connection during
the upgrade.
6. Click “Terminate” when the test is complete. The Gateway is now ready for use.
Download the APP to your smartphone (via Google Play or APP store)
Search for SmartForce APP:
For
IOS
For
Android
1. Install the App into your smartphone.
2. Login into the App using the account you created earlier.
Device Installation
The devices supplied in the kit HAVE already been learnt to the Gateway Hub and do not require learning
to the ASFK1 Gateway Hub.
1. Insert the batteries into the devices.
Note: The devices are already pre-linked (paired) to gateway at factory.
2. Additional radio devices equipment will need to be learnt to the Gateway Hub
3. Connect up the batteries inside the solar siren.
Access code label
SmartForce SmartForce

Challenger_Smart_Force_Quick_Set_Up_Guide_Rev01
. Select the location to mount the devices.
Adding Additional Devices (that are not supplied in the kit)
1. Log into the system screen.
2. Select “System”.
3. Select “Add a New Device”.
4. Select appropriate device.

Challenger_Smart_Force_Quick_Set_Up_Guide_Rev01
Testing the devices
1. Close the window fixed with the magnetic window / door detector.
Testing Keyfob, Magnetic Door contact, App notification message
2. Press Keyfob PANIC button, the solar siren will sound. Press Keyfob’s disarm button for turning the siren
off.
Panic Button
3. Wait for 30 secs then open the window or door.
. The installation is successful if the solar siren sounds. Press disarm button via App, Web or Keyfob to turn
the siren off
5. Check your smart phone or tablet. It should have notifications from the SmartForce APP.
Testing PIR Motion detector
6. Use the Keyfob to arm the system again.
7. Walk past the PIR.
8. The installation is successful if the solar siren sounds. Use your mobile to disarm the system.
Troubleshooting
1. Minimum distance
Please keep all accessories at least 30cm away from each other.
2. Metal objects
Please keep accessories away from metal objects as they may interfere with radio signals.
3. Environments with high concentration of radio signals
Environments with high concentration of electricity and wireless signals may interfere and limit the
maximum distance of accessories from the control panel.
. Internet connection problem
The gateway will periodically check internet connections. Try restarting the gateway if a problem occurs.
The gateway uses DHCP to get its IP.
5. Battery status
Please check the LED battery level if battery devices are not responding properly.
6. Pairing
When the device is triggered but there is no response, a possible reason may be the pairing during
factory setting has failed. Refer to the user manual for each device to perform manual pairing.
Due to our policy of continuous improvement we reserve the right to change specification without prior notice.
Errors and omissions excepted. These instructions have been carefully checked prior to publication. However, no responsibility can be
accepted by Challenger for any misinterpretation of these instructions.
Challenger Security Products
10 Sandersons Way, Blackpool, FY4 4NB
Tel: [phone], Fax: [phone]
Email: enquiries.challenge[email protected]
Web: www.challenger.co.uk
