Channel Vision IC512 User manual

Channel Vision Technology will repair or replace any defect in
material or workmanship which occurs during normal use of this
p
roduct with new or rebuilt parts, free of charge in the USA, for ten
years from the date of original purchase. This is a no hassle warranty
with no mail in warranty card needed. This warranty does not cover
damages in shipment, failures caused by other products not supplied
by Channel Vision Technology, or failures due to accident, misuse,
abuse, or alteration of the equipment. This warranty is extended only
to the original purchaser, and a purchase receipt, invoice, or other
p
roof of original purchase date will be required before warranty
repairs are provided.
Mail in service can be obtained during the warranty period by calling
[phone] toll free. A Return Authorization number must be
obtained in advance and can be marked on the outside of the shipping
carton.
This warranty gives you specific legal rights and you may have other
rights (which vary from state to state). If a problem with this product
develops during or after the warranty period, please contact Channel
Vision Technology, your dealer or any factory-authorized service
center.
500-205 rev A
10
www.channelvision.com
234 Fischer Avenue, Costa Mesa, California 92626 USA
[phone] [phone] [phone] fax
email: [email protected]
IC512
5.25” IN-CEILING SPEAKER
8

2
Model IC512
Installation:
h
h
h
h
h
h
Use the included template to mark and cut a 6” hole in
drywall away from ceiling joists.
We recommend wiring with AWG 16 or larger, stranded
wire.
For proper phasing, both voice coils must be wired alike.
Connect red wires to red terminals on speaker and to red
or plus terminals on amplifier.
Install IC512 in hole. Tighten the mounting screws. The
mounting dog ears will rotate outward and grip the
drywall.
Aim tweeter
To control the volume of the speaker locally, use an
impedance matching volume control, such as the
Channel Vision VC-302.
Mounting screws (4)
3
Specifications:
Frequency range:
Sensitivity:
Power Handling:
Drivers:
Impedance:
Finish:
Dimensions:
Weight:
50Hz - 20kHz ± 3dB
88dB (1W/1m)
100 Watts peak
1- 1” Soft dome tweeter
1- 5 ” polypropylene woofer
8 ohms
ABS plastic
8” OD. 4.21 height
(from surface of wall board)
2.25 Lbs as shipped
¼
”
Specifications subject to change without notice.
Features:
5 ” High performance in-ceiling loudspeaker
High power handling capacity
Gold speaker terminals
Proprietary pivoting “Pole Piece” technology with 1” voice
coil, neodymium magnet, and silk soft dome
Mica-filled polypropylene woofer with butyl rubber surround
and a 18 oz magnet
Small perforated designer grille
Recommended power: 20W to 100W (peak)
¼
