Channel Vision OS611 User manual

Channel Vision Technology will repair or replace any defect in material or
workmanship which occurs during normal use of this product with new or rebuilt
parts, free of charge in the USA, for ten years from the date of original purchase.
This is a no hassle warranty with no mail in warranty card needed. This warranty
does not cover damages in shipment, failures caused by other products not
supplied by Channel Vision Technology, or failures due to accident, misuse, abuse,
or alteration of the equipment. This warranty is extended only to the original
purchaser, and a purchase receipt, invoice, or other proof of original purchase date
will be required before warranty repairs are provided.
Mail in service can be obtained during the warranty period by calling (800) 840-
0288 toll free. A Return Authorization number must be obtained in advance and
can be marked on the outside of the shipping carton.
This warranty gives you specific legal rights and you may have other rights (which
vary from state to state). If a problem with this product develops during or after the
warranty period, please contact Channel Vision Technology, your dealer or any
factory-authorized service center.
Channel Vision products are not intended for use in medical, lifesaving, life
sustaining or critical environment applications. Channel Vision customers using or
selling Channel Vision products for use in such applications do so at their own risk
and agree to fully indemnify Channel Vision for any damages resulting from such
improper use or sale.
500-241 rev B
10
www.channelvision.com
234 Fischer Avenue, Costa Mesa, California 92626 USA
[phone] [phone] [phone] fax
email: [email protected]
OS611
6.5” Marine/Outdoor Speaker
9

2
1) Weather resistant design
2) Aluminum grills and brackets
3) hardware
4) abinet resists sun fade
) 14 AWG gold plated terminal posts
) 6.5"
) High compliance polymer tweeter
) 18dB /octave crossover network
) Tweeter protected by poly switch
Stainless steel
UV protected c
5
6
7
8
9
Long excursion woofer
½”
Model OS611
3
Specifications:
Frequency range:
Sensitivity:
Power Handling:
Drivers:
Impedance:
Finish:
Dimensions:
Weight:
40Hz - 20kHz ± 3dB
90dB (1W/1M)
200 Watts
1- ” High Compliance Polymer
tweeter
1- 6 ½” Long excursion woofer
6 ohms
ABS plastic
11.54” H x 8.54” W x 7.60” D
7 ½ lbs with bracket
½
Specifications subject to change without notice.
Installation:
h
h
h
h
h
The OS611 may be mounted vertically or horizontally.
The OS611’s case is weather resistant and made with UV
stabilized ABS. But for longest life, we recommend
placement in a protected area, such as under an eave.
We recommend wiring with AWG 16 or larger, stranded
wire.
For proper phasing, both speakers must be wired alike.
Connect red wire to red terminal on speakers and to red
or plus terminal on amplifier.
To control the volume of the speakers locally, use an
impedance matching volume control, such as the
Channel Vision VC-302.
