Channel Vision ID652 User manual

Channel Vision Technology will repair or replace any defect in
material or workmanship which occurs during normal use of this
p
roduct with new or rebuilt parts, free of charge in the USA, for ten
years from the date of original purchase. This is a no hassle warranty
with no mail in warranty card needed. This warranty does not cover
damages in shipment, failures caused by other products not supplied
by Channel Vision Technology, or failures due to accident, misuse,
abuse, or alteration of the equipment. This warranty is extended only
to the original purchaser, and a purchase receipt, invoice, or other
p
roof of original purchase date will be required before warranty
repairs are provided.
Mail in service can be obtained during the warranty period by calling
[phone] toll free. A Return Authorization number must be
obtained in advance and can be marked on the outside of the shipping
carton.
This warranty gives you specific legal rights and you may have other
rights (which vary from state to state). If a problem with this product
develops during or after the warranty period, please contact Channel
Vision Technology, your dealer or any factory-authorized service
center.
500-008 rev C1
10
www.channelvision.com
234 Fischer Avenue, Costa Mesa, California 92626 USA
[phone] [phone] [phone] fax
email: [email protected]
ID652
6.5” Dual Voice Coil In-Ceiling Speaker
8

2
Model ID652
Installation:
h
h
h
h
h
h
Cut 8” hole in drywall away from ceiling joists.
We recommend wiring with AWG 16 or larger, stranded
wire.
For proper phasing, both voice coils must be wired alike.
Connect red wires to red terminals on speaker and to red
or plus terminals on amplifier.
Install ID652 in hole. Tighten the mounting screws. The
mounting dog ears will rotate outward and grip the
drywall.
Aim tweeters
To control the volume of the speaker locally, use an
impedance matching volume control, such as the
Channel Vision VC302.
Mounting screws (4)
3
Specifications:
Frequency range:
Sensitivity:
Power Handling:
Drivers:
Impedance:
Finish:
Dimensions:
Weight:
55Hz - 20kHz ± 3dB
89dB (for 2.83V pink noise)
65 Watts RMS (92 Watts Peak)
2- ½” Mylar dome tweeter
1- 6 ½” polypropylene woofer
8 ohms
ABS plastic
9¼” OD. 3½” height
(from surface of wall board)
5 Lbs as shipped
Specifications subject to change without notice.
Features:
Dual voice coil speaker delivers stereo sound from a single
speaker
Use when only one speaker will fit or to balance coverage in
a whole house audio system
Use in bathrooms, hallways, entry ways
Mica-filled polypropylene woofer with true rubber surround
Dual ½" fluid-cooled ultra-wide dispersion mylar tweeters
Tweeters swivel independently up to 45 degrees
Tweeter protection using thermal sensing polymer switches
Dual 2nd order Butterworth crossover networks
Recommended power: 5W to 90W
