Channel Vision OS610 User manual

Channel Vision Technology will repair or replace any defect in
material or workmanship which occurs during normal use of this
p
roduct with new or rebuilt parts, free of charge in the USA, for ten
years from the date of original purchase. This is a no hassle warranty
with no mail in warranty card needed. This warranty does not cover
damages in shipment, failures caused by other products not supplied
by Channel Vision Technology, or failures due to accident, misuse,
abuse, or alteration of the equipment. This warranty is extended only
to the original purchaser, and a purchase receipt, invoice, or other
p
roof of original purchase date will be required before warranty
repairs are provided.
Mail in service can be obtained during the warranty period by calling
[phone] toll free. A Return Authorization number must be
obtained in advance and can be marked on the outside of the shipping
carton.
This warranty gives you specific legal rights and you may have other
rights (which vary from state to state). If a problem with this product
develops during or after the warranty period, please contact Channel
Vision Technology, your dealer or any factory-authorized service
center.
500-00
3
rev D
10
www.channelvision.com
234 Fischer Avenue, Costa Mesa, California 92626 USA
[phone] [phone] [phone] fax
email: [email protected]
OS610
6.5” Marine/Outdoor Speaker
8

2
1) Weather resistant design
2) Aluminum grilles, and brackets
3) hardware
4) abinet resists sun fade
) 14 AWG gold plated terminal posts
) 6.5" woofer with mica mix cone
) 1" Soft dome tweeter
) 18dB /octave crossover network
) Tweeter protected by poly switch
Stainless steel
UV protected c
5
6
7
8
9
Model OS610
To set your OS610 on a shelf,
attach the rubber feet here
3
Specifications:
Frequency range:
Sensitivity:
Power Handling:
Drivers:
Impedance:
Finish:
Dimensions:
Weight:
55Hz - 20kHz ± 3dB
88dB (1W/1M)
100 Watts
1- 1” fabric dome tweeter
1- 6 ½”polygraphite woofer
6 ohms
ABS plastic
12 1/2”H x 8 1/2” W x 7 3/4” D
7 ½ Lbs with bracket
Specifications subject to change without notice.
Installation:
h
h
h
h
h
The OS610 may be mounted vertically or horizontally.
The OS610’s case is weather resistant and made with UV
stabilized ABS. But for longest life, we recommend
placement in a protected area, such as under an eave.
We recommend wiring with AWG 16 or larger, stranded
wire.
For proper phasing, both speakers must be wired alike.
Connect red wire to red terminal on speakers and to red
or plus terminal on amplifier.
To control the volume of the speakers locally, use an
impedance matching volume control, such as the
Channel Vision VC302.
