Channel Vision LCR65B User manual

Channel Vision Technology will repair or replace any defect in
material or workmanship which occurs during normal use of this
p
roduct with new or rebuilt parts, free of charge in the USA, for ten
years from the date of original purchase. This is a no hassle warranty
with no mail in warranty card needed. This warranty does not cover
damages in shipment, failures caused by other products not supplied
by Channel Vision Technology, or failures due to accident, misuse,
abuse, or alteration of the equipment. This warranty is extended only
to the original purchaser, and a purchase receipt, invoice, or other
p
roof of original purchase date will be required before warranty
repairs are provided.
Mail in service can be obtained during the warranty period by calling
[phone] toll free. A Return Authorization number must be
obtained in advance and can be marked on the outside of the shipping
carton.
This warranty gives you specific legal rights and you may have other
rights (which vary from state to state). If a problem with this product
develops during or after the warranty period, please contact Channel
Vision Technology, your dealer or any factory-authorized service
center.
500-0
3
0 rev C
10
www.channelvision.com
234 Fischer Avenue, Costa Mesa, California 92626 USA
[phone] [phone] [phone] fax
email: [email protected]
LCR625
6.5” In-Wall Left-Center-Right Speaker
8

2
Model LCR625
Installation:
h
h
h
h
h
Use the included template to mark and cut a hole in the
drywall.
We recommend wiring with AWG 16 or larger, stranded
wire.
For proper phasing, all speakers in the system must be
wired alike. Connect red wires to red terminals on
speaker and to red or plus terminals on amplifier.
Install LCR625 in hole. Tighten the mounting screws. The
mounting dog ears will rotate outward and grip the
drywall.
Aim tweeter
Mounting screws (6)
3
Specifications:
Frequency range:
Sensitivity:
Power Handling:
Drivers:
Impedance:
Finish:
Dimensions:
Weight:
40Hz - 20kHz ± 3dB
90dB (1W/1m)
150-Watts Peak
1- 1” silk soft dome tweeter
2- 6.5” polypropylene woofer
8 ohms
ABS plastic
8.94”H x 20.3”W x 3.7”D
(Depth is from surface of wall board)
12 Lbs as shipped
Specifications subject to change without notice.
Features:
High power handling capacity
Dual 6.5” polypropylene woofers with butyl rubber surrounds
1” pivoting soft dome tweeter
Gold speaker terminals
Small perforated designer grille
Mounting template and paint shield included
Recommended power: 20W to 150W
