Charge Amps Aura 131293 User manual

www.chargeamps.com
English
Charge Amps Aura
Installation
Manual
Charge Amps Aura 131293
Charge Amps Aura 131294
The Electric Vehicles (Smart Charge Points)
Regulation 2021

2
English
Table of content
1 Safety 5
2 Technical data 7
3 Product overview 10
3.1 Package contents 11
4 Before installation 13
4.1 Recommended tools 13
4.2 Materials provided by installer 13
4.3 Mounting requirements 14
4.4 Electric requirements 15
4.4.1 Short circuit safety 15
4.4.2 Residual current safety 15
4.5 Internet access 16
4.5.1 Wi-Fi 16
4.5.2 4G-LTE 17
4.5.3 LAN 17
4.5.4 Network daisy chain of Charge Amps Aura 17
5 Installation 18
5.1 Mounting 18
5.2 Connection 22
5.2.1 Cable connection 22

3
English
6 Before configuration 29
7 Configuration 29
7.1 Connect via Charge Amps Aura Wi-Fi access point 30
7.2 Connect via LAN 31
7.3 Connect via 4G-LTE 31
7.4 Local management interface settings 32
7.4.1 Electrical installation settings 32
7.4.2 RFID management for offline chargers 32
7.5 Configuration in the Fuuse Charge Point Management platform 33
7.5.1 Adding chargers as an existing Fuuse Admin User 33
7.5.2 Adding chargers as a new Fuuse Admin User 34
7.5.3 Adding drivers in the Fuuse web portal 34
7.5.4 Set up and enable RFID payment in the Fuuse web portal 35
7.6 Reconnect to the Fuuse Charge Point Management Platform 35
8 Complete the installation 40
8.1 Protection against attack 40
8.2 Handover and training 41
9 Use 42
10 Dismounting 43
11 Maintenance 43
11.1 Regular maintenance 43
11.2 Preventative maintenance 44
12 Product support and service 44
13 Warranty 45

4
Neglecting to follow and carry out the directions, instructions and safety precautions in this Installation
Manual implies that any warranty provisions will be cancelled and that Charge Amps can reject any and
all claims for compensation in connection with any injuries/damage or incidents – direct or indirect –
that are a result of such negligence.
Charge Amps AM does not give any warranties as to the accuracy or completeness of this document
and shall have no liability for the consequences of using such information. Charge Amps AB reserves
the right to make changes to information published in this document without notice.
Visit www.chargeamps.com for the latest document releases.
© Copyright Charge Amps AB. All rights reserved. Copying, amending and translating are strictly
forbidden without prior written approval from Charge Amps AB.
In conformity with the relevant EU directives.
Respect the environment! Must not be discarded with household
waste! This product contains electrical or electronic components.
Leave the product for separate collection and proper treatment at
a designated location e.g. the local authority’s recycling station.

5
English
1 Safety
WARNING! Read all instructions before installation.
• The product must only be installed or opened by a qualified
electrician in accordance with the Installation Manual.
• Charge Amps Aura complies with the device-level requirements
set out under the Electric Vehicles (Smart Charge Point)
Regulations 2021, as detailed in the technical file, which is
available online.
• Installers must adhere to the instructions stated in this
Installation Manual regarding installation and configuration
of the charger to ensure compliance with the Electric Vehicle
(Smart Charge Point) Regulations 2021.
• It is the responsibility of the installer to provide proof of
compliance to the Electric Vehicle (Smart Charge Point)
Regulations 2021 of the complete charge point installation.
• Make sure to switch the power off at the main switch before
installation or service.
• For this product, automatic reclosing of protective devices are
not allowed.
• Improper use and negligence to follow the instructions of this
Installation Manual may create a risk of personal injury.
• National installation requirements and restrictions apply.
• Only use this product for charging compatible electric vehicles.
• Inspect the product for visible damage before use.
• Never attempt to repair or use the product if it is damaged.
• Make sure that the product is in good condition and that all
cables are properly seated before use.

6
English
• Do not immerse the product in water, subject it to physical
abuse or insert foreign objects in any part of the product.
• Never attempt to disassemble the product in any way other
then what is described in the Installation Manual.
• Make sure no flammable, explosive, corrosive or combustible
materials, chemicals, or fumes are nearby the mounting
position.
• Make sure the front cover does not interfere with any
cables inside and that the front cover is locked in place upon
completion of installation.
• To avoid muscle strain or back injury, use lifting aids and proper
lifting techniques.

7
English
2 Technical data
Charging mode Mode 3
EV power supply identifier
Metering 1 to 3 phase voltage, current and
power
Socket Type 2, up to 2x22 kW
Rated voltage (Un)230/400 V
Rated insulation voltage (Ui)250/400 V
Rated impulse withstand voltage
(Uimp)
4 kV
Rated operational voltage (Ue)230/400 V
Rated frequency (fn)50 Hz
Rated current (In)63 A
Rated output current (Inc)32 A/socket
Rated diversity factor (RDF) 1 (can be lowered if used together with
a load balancing functionality)
Rated peak withstand current (Ipk)3 kA, 20 kA²
Rated short-time withstand current
(Icw)
192 A for 2 s
Residual current safety Separate DC fault current protection.
Type A RCBO complying with
EN 61009-1 and EN 61009-2-1 is
integrated to the charging station for
each socket.
Protection against electrical shock Class I
Types of earthing system TN, TT and IT
Overvoltage category III

8
English
Pollution degree 3
Electromagnetic compatibility Environment B
Operating temperatures -35°C to +45°C
Altitude 0 m to 2000 m
IP code IP55
IK code IK10
Mechanical resistance High
Dimensions (W x D x H) 367 x 159 x 405 mm
Weight 10 kg
Characteristics of power supply and
output
AC EV supply equipment connected
to AC supply network, permanently
connected.
External design and method of
mounting
Enclosed wall-mounted surface type:
- surface mounted on walls
- stationary ground and floor mounted
installation with accessory Charge
Amps Pole mount
Type of construction Fixed
Intended use and location type By ordinary persons, indoor and
outdoor installation with non-
restricted access

9
English
RFID Type: ISO/IEC 14443 Typ A 13.56MHz
Mifare
Range: 13.553 – 13.567 MHz
Output: 31 dBm
Wi-Fi Type: 802.11 b/g/n
Range: 2400 – 2500 MHz
Max output: 20/17/14 dB[email protected]
b/g/n
Communication protocol OCPP 1.6J
Cellular netoworks communication
(only applies to 131293).
Type: GSM, GPRS, EDGE, UMTS/
HSPA+, LTE
Range: 698 – 960 / 1710 – 2690 MHz
Max. output: 33 dBm@GSM, 24 dBm@
WCDMA, 23 dBm@LTE
SIM Card: Standard SIM (25mm x
15mm)

10
English
3 Product overview
A RFID reader
B RFID light
C EV socket
D Socket light
C
B
A
D
E
E Cylinder lock
F Back cover
G Front cover
H Cable slide: data and power cable in/out
F
G
H

11
English
3.1 Package contents
1
Cable slide Cable fitting Plugs M32 insert Screws
RFID tag Cylinder key Wago jumper
2

12
English
1 Charge Amps Aura
2 Accessories:
• Cable slide
• Cable fitting for power (M32): 13 - 17.5 mm and 17 - 25 mm
• Cable fitting for data (M12): 4 -8 mm
• Plugs for non-used cover entries.
• M32 insert only
• Screws
• 2x RFID tags
• 2x Cylinder lock keys
• Wago jumper for IT network connection (MPN: 2016-433)
Additional contents:
• Document with serial number and password
• Quick Guide User

13
English
4 Before installation
N.B: This Installation Manual is only applicable to Charge
Amps Aura with product number 131293 and 131294.
4.1 Recommended tools
• 3.5 mm flat head screwdriver
• Drill
• Multimeter
• Laser/spirit level
• Wire stripper for cabling
• Mobile phone, tablet or computer
4.2 Materials provided by installer
• 4 x M6x30 mm or longer, flat head stainless screws type A2 or
A4 with associated washers type A2 or A4 having a maximum
outer diameter of 20 mm and plugs (if required, depending on
wall conditions)
• Installation cable, according to the charging capability of the
selected product
• Ethernet cable

14
English
4.3 Mounting requirements
• If possible, do not mount the Charge Amps Aura in direct
sunlight.
• Make sure the wall can support a weight of 10 kg and the
tractive force from the inserted cabling.
• Do not install Charge Amps Aura in confined spaces.
• Use screws and plugs (if required) suitable for the wall material.
• Charge Amps Aura must be mounted upright.
• Permissable mounting height 900 -1450 mm, measured from
the ground to the bottom of Charge Amps Aura.
• For alternative mounting requirements for a pole mount, contact
Charge Amps Support.

15
English
4.4 Electric requirements
N.B: Local regulations might add additional requirements for
the electrical installation and must always be met.
• Charge Amps Aura must be earthed through a permanent
electrical installation.
• Only insert the power cable through the specified cable entry.
Cables must not be passed through the rear housing.
4.4.1 Short circuit safety
Make sure the installation for Charge Amps Aura is properly fused
up to 63 A with one of the following:
• B- or C-curve MCB* with energy limiting class 3.
• D-type fuse category gG.
• NH blade fuse category gG.
*MCB = Miniature Circuit Breaker, B Curve MCBs trip at 3–5 times the rated
current and C Curve MCBs trip at 5–10 times the rated current.
4.4.2 Residual current safety
Following is integrated to Charge Amps Aura for each socket:
• Type A RCBO complying with EN 61009-1 and EN 61009-2-1.
• Separate DC fault current protection.

16
English
4.5 Internet access
Both Wi-Fi, LAN, and 4G-LTE (only available for Charge Amps
Aura with product number 131293) connection is available for
Charge Amps Aura.
4.5.1 Wi-Fi
Once the power is switched on, Charge Amps Aura will provide a
Wi-Fi access point which is available for 10 minutes. Use the Wi-Fi
access point to connect Charge Amps Aura to the Wi-Fi network
of the facility.
N.B: The Charge Amps Aura Wi-Fi access point is deactivated
if the RJ45 port is connected.
Before installing Charge Amps Aura, make sure the Wi-Fi network
of the facility is supported:
Supported networks:
• Wi-Fi 2,4 GHz according to 802.11b/g/n.
Recommendation for network security and encryption:
• WPA using TKIP: supported but not recommended.
• WPA2 using AES: recommended.
• WPA3: not supported.

17
English
4.5.2 4G-LTE
N.B: Only applicable to Charge Amps Aura with product
number 131293.
N.B: If you wish to use the Charge Amps Aura Wi-Fi
access point to configure Charge Amps Aura via the local
managemen interface, make sure to disconnect the 4G-LTE
modem from the RJ45 port.
The Charge Amps Aura 4G-LTE model comes with the 4G-LTE
modem connected to one of the RJ45 ports on the main card.
Once the power is on, and a SIM card is inserted, Charge Amps
Aura will automatically connect to the 4G-LTE network.
• 4G-LTE modem model: Teltonika TRB 140 (if you wish to log in
to the 4G-LTE modem, see the TRB 140 User Manual to find the
default password and other information).
4.5.3 LAN
It is possible to connect Charge Amps Aura via a network cable. A
cat5 cable, or better, is required.
4.5.4 Network daisy chain of Charge Amps Aura
N.B: There’s a dependency between upstream and
downstream chargers in the chain, therefore the
recommended best practice is to connect a maximum of 4
Charge Amps Aura 4G-LTE, or Charge Amps Aura with LAN
connection, in series.
It is possible to daisy chain the network connection of several
Charge Amps Aura 4G-LTE or Charge Amps Aura with LAN
connection. For Charge Amps Aura 4G-LTE, use a separate
router or an Aura 4G-LTE as an uplink. It is not possible to use one
Charge Amps Aura with Wi-Fi as an uplink.

18
English
5 Installation
5.1 Mounting
N.B: Mounting shall only be performed by an qualified
electrician.
1. Unpack Charge Amps Aura. Make sure that Charge Amps Aura
is in a good condition and that all cables are properly seated.
Do not place the face plate directly on to the ground.
2. Mark the mounting holes on the wall according to the
dimensions in the drawing below*.
*Not to scale, [mm].

19
English
3. Unlock the cylinder lock. Rotate the front cover upwards and
suspend the front.
4. Remove the cable slide by unscrewing the two M6 screws.

20
English
5. Attach the cable fittings for power and data (NOTE: cable
fitting for data is only applicable for Charge Amps Aura with
LAN connection).
Important! Make sure to cover non used cable entries with
suitable plugs from the accessories.
6. Reattach the cable slide to the back cover by securing the two
M6 screws.
Data cable entry
Power cable entry
A
B
A
AB B
