Quick Reference Guide

LED Followspot 75ST QRG
Page 2 of 8
About this
Guide
The LED Followspot 75ST Quick Reference Guide (QRG) contains the
product
’s connection and mounting information as well as the menu options
and the DMX values.
Disclaimer
•This Quick Reference Guide DOES NOT replace the product’s user
manual, which you can download from the CHAUVET® Web site
(www.chauvetlighting.com).
•
You must read ALL the disclaimers and safety notes in this document as
well as those in the product’s user manual before installing, operating, or
maintaining this product.
Safety Notes
Please read the following notes carefully before starting to work with this
product. They include important safety information about its
installation,
usage, and maintenance.
•Always connect this product to a grounded circuit to avoid the risk of
electrocution.
•Always disconnect this product from the power source before cleaning it
or replacing the fuse.
•Avoid direct eye exposure to the light source while the fixture is on.
•Make sure the power cord is not crimped or damaged.
•Make sure there are no flammable materials close to the unit while
operating.
•Do not touch this product’s housing when operating because it may be
very hot.
•Always make sure that the voltage of the outlet to which you are
connecting this product is within the range stated on the decal or rear
panel of the fixture.
•This product is for indoor use only! (IP20) To prevent risk of fire or
shock, do not expose this fixture to rain or moisture.
•Never connect this product to a dimmer pack.
•Make sure to replace the fuse with another of the same type and rating.
•Never carry this product from the power cord or any moving part.
Always use the hanging/mounting bracket or the handles.
•The maximum ambient temperature (Ta) is 104° F (40° C). Do not
operate this product at higher temperatures.
•In the event of a serious operating problem, stop using the unit
immediately.
•Never try to repair this product. Repairs carried out by unskilled people
can lead to damage or malfunction. Please contact the nearest authorized
technical assistance center.

LED Followspot 75ST QRG
Page 3 of 8
What is
Included
•LED Followspot 75ST
•Power Cord
•Tripod
•Warranty Card
•Quick Reference Guide
Before You
Begin
Prior to using your LED Followspot 75ST, ensure that you have received all
parts indicated above in good condition. If the container or material inside
appear damaged or show signs of mishandling, notify the carrier
immediately, not CHAUVET®.
Product
Description
The LED Followspot 75ST is a portable, LED-powered fixture that offers
DMX or manual controls to suit a variety of needs. Super smooth LED
dimming and an extremely fast electronic strobe makes it a fantastic beam
for any performance.

LED Followspot 75ST QRG
Page 4 of 8
Product Overview
Focus Lens Adjustment Knobs
DMX In/Out
Power In
Button Menu
Control Panel
Iris Adjustment
Bracket Adjustment Knob
Mounting Bracket
On/Off Switch

LED Followspot 75ST QRG
Page 5 of 8
AC Power
This product has a switchable power supply that can work with an input
voltage of 115 VAC or 230 VAC, 50/60 Hz.
Fuse
Replacement
1. Disconnect this product from power.
2. Using a Phillips #2 head screwdriver, unscrew the fuse holder cap from
the housing.
3. Remove the blown fuse.
4. Replace with a good fuse of the same type and rating.
5. Screw the fuse holder cap back in place and reconnect power.
Programming
For details on how to program this product, please refer to the product’s user
manual.
Control Panel
Description
Button Function
<POWER SWITCH>
Turns power on and off.
<DIMMER MAX>
Opens dimmer to a maximum of 100% (hold to
raise percentage).
<DIMMER MIN>
Closes dimmer to a maximum of 0% (hold to
lower percentage).
<SHUTTER ON>
Turns LED on (default setting).
<BLACK OUT>
Turns LED off.
<ORANGE>
Projects orange color.
<CYAN>
Projects cyan color.
<RED>
Projects red color.
<GREEN>
Projects green color.
<MAGENTA>
Projects magenta color.
<YELLOW>
Projects yellow color.
<BLUE>
Projects blue color.
<WHITE>
Projects white light.
<FUNCTION SELECT>
Selects Manual or DMX Mode.
<UP>
In DMX Mode, moves channel number up.
<DOWN>
In DMX Mode, moves channel number down.
Menu Options
Main Level Programming Levels Description
1. Manual Mode
NAn
Selects Manual Mode.
2. DMX Address
001
001~512
Sets the DMX starting address

LED Followspot 75ST QRG
Page 6 of 8
DMX Linking
The LED Followspot 75ST can work with a DMX controller when linked
using a regular DMX serial connection.
If you are not familiar with the DMX standard, please download the
DMX
Primer document from www.chauvetlighting.com.
DMX Connection
The LED Followspot 75ST uses a regular DMX data connection for its 3-
channel DMX personality.
Download the LED Followspot 75ST user manual and refer to the Setup
chapter to learn how to connect this fixture for DMX operation, and the
Operation Instructions chapter to learn in detail how to configure this fixture
for DMX operation.
Start Address
To ensure full access to all channels in each DMX mode, the highest
recommended DMX address is 510.
Master/Slave
Connection
The LED Followspot 75ST uses the DMX data connection for its
Master/Slave mode.
Download the LED Followspot 75ST user manual and refer to the Setup
chapter to learn how to connect this fixture for Master/Slave operation, and
the Operation chapter to learn in detail how to configure this fixture for
Master/Slave operation.
DMX Values
3-CH
Channel
Function
Value
Percent/Setting
1
Dimmer
000 255
0~100%
2
Color
000 031
White
032 063
Dark Blue
064 095
Yellow
096 127
Purple
128 159
Green
160 191
Red
192 223
Light Blue
224 255
Orange
3
Strobe
000 255
0~100%

LED Followspot 75ST QRG
Page 7 of 8
Mounting
Before mounting this product, read the safety notes at the beginning of this
guide and i
n the product’s user manual. Then, follow the mounting
procedure indicated in the Setup chapter of the user manual.
Product
Mounting
Diagram

LED Followspot 75ST QRG
Page 8 of 8
Contact Us
World Headquarters
CHAUVET®
General Information
Address: 5200 NW 108th Avenue
Sunrise, FL 33351
Voice: [phone]
Fax: [phone]
Toll free: [phone]
United Kingdom and Ireland
CHAUVET® Europe Ltd.
General Information
Address: Unit 1C
Brookhill Road Industrial Estate
Pinxton, Nottingham, UK
NG16 6NT
Voice: [phone]
Fax: [phone]
Technical Support
Voice: [phone] (Press 4)
Fax: [phone]
Email: [e-mail]
Technical Support
Email: [e-mail]
World Wide Web
www.chauvetlighting.com
World Wide Web
www.chauvetlighting.co.uk
Outside the U.S., United Kingdom, or Ireland, contact your distributor of
record. Follow their instructions to request support or to return a product.
Visit our Web site for contact details.
LED Followspot 75ST QRG – Rev. 3
