Chauvet Q-Wash 436Z-LED User manual

Quick Reference Guide
English EN
Español ES
Français FR

Q-Wash™ 436Z-LED QRG EN
2
About this
Guide
The Q-Wash™ 436Z-LED Quick Reference Guide (QRG) has basic
product information such as connection, mounting, menu options, and
DMX values. Download the User Manual from www.chauvetpro.com
for
more details.
Disclaimer
The information and specifications contained in this QRG are subject to
change without notice.
Safety Notes
•DO NOT open this product. It contains no user-serviceable parts.
•DO NOT look at the light source when the product is on.
•CAUTION: This product’s housing may be hot when lights are
operating.
•Mount this product in a location with adequate ventilation, at least
20 in (50 cm) from adjacent surfaces.
•DO NOT leave any flammable material within 50 cm of this product
while operating or connected to power.
•USE a safety cable when mounting this product overhead.
•DO NOT operate this product outdoors or in any location where dust,
excessive heat, water, or humidity may affect it.
•DO NOT operate this product if the housing, lenses, or cables appear
damaged.
•DO NOT connect this product to a dimmer or rheostat.
•ONLY connect this product to a grounded and protected circuit.
•ONLY use the hanging/mounting bracket or the handles to carry this
product. Do not carry by the moving head.
•In the event of a serious operating problem, stop using immediately.
•The maximum ambient temperature is 104° F (40° C). Do not operate
this product at higher temperatures.
Contact
Outside the U.S., United Kingdom, or Ireland, contact your distributor to
request support or return a product. Visit www.chauvetpro.com
for contact
information.
What Is
Included
•Q-Wash™ 436Z-LED
•Power Input Cord
•2 Omega Brackets
•Safety Cable
•Warranty Card
•Quick Reference Guide
AC Power
This product has an auto-ranging power supply that can work with an input
voltage range of 100~240 VAC, 50/60 Hz.
Power Linking
You can link up to 2 Q-Wash™ 436Z-LED products at 120 VAC or 6 at
230 VAC. Never exceed this number. Power linking cords can be
purchased separately.
AC Plug
Connection
Wire (U.S.)
Wire (Europe)
Screw Color
AC Live
Black
Brown
Yellow/Brass
AC Neutral
White
Blue
Silver
AC Ground
Green/Yellow
Green/Yellow
Green
Replacing the
Fuse
1. Disconnect this product from power.
2. Using a Phillips #2 head screwdriver, unscrew the fuse holder cap
from the housing.
3. Remove blown fuse and replace with a good fuse of the same type and
rating.
4. Screw the fuse holder cap back in place and reconnect power.

EN Q-Wash™ 436Z-LED QRG
3
DMX Linking
The Q-Wash™ 436Z-LED will work with a DMX controller using a
regular DMX serial connection. A DMX Primer is available from
www.chauvetpro.com.
DMX Connection
The Q-Wash™ 436Z-LED uses a regular DMX data connection for its
DMX personalities: PERSON 1, PERSON 2, PERSON 3, PERSON 4,
and PERSON 5
. See the User Manual to connect and configure for DMX
operation.
Master/Slave
Connection
The Q-Wash™ 436Z-LED uses the DMX data connection for its
Master/Slave mode. See the User Manual to connect and configure for
Master/Slave operation.
Mounting
Product
Mounting
Diagram
Control Panel
Description
Button
Function
<MENU>
Exits from the current menu or function
<ENTER>
Enables the currently displayed menu or sets the currently
selected value into the selected function
<UP>
Navigates upwards through the menu list and increases the
numeric value when in a function
<DOWN>
Navigates downwards through the menu list and decreases
the numeric value when in a function
Password
After being prompted, enter the following password by pressing:
<UP>, <DOWN>, <UP>, <DOWN>, <ENTER>
This password cannot be changed and must be used whenever prompted.
Overhead Mounting
Floor Mounting
Safety
Cable
Clamp

Q-Wash™ 436Z-LED QRG EN
4
Menu Options
Main Level
Programming Levels
Description
ADDRESS
000~512
Sets the DMX starting address
PERSON
PERSON1
10-Channel mode
PERSON2
16-Channel mode
PERSON3
29-Channel mode
PERSON4
8-Channel mode
PERSON5
29-Channel mode
SETTINGS
WIRELESS
WDMX
ACTIVATE
OFF
Reserved for future use
ON
WDMX
RESET
NO
YES
PERFORM
FANS
SLOW
Selects the fan’s operation mode.
NORM
FAST
AUTO
PT SPEED
FAST
Defines the speed of the pan/tilt
SLOW
PAN INVERT
NORM
Defines the direction of the pan fader
INVERT
TILT INVERT
NORM
Defines the direction of the tilt fader
INVERT
OPTICS
SPEED
FAST
Defines the speed of the zoom
SLOW
BLACKOUT
DELAY
Activates the move-in black delay
(3 sec.)
INSTANT
DIMMER
DIM4
Slow (DIM4) to fast (DIM1) dimmer
curves
DIM3
DIM2
DIM1
OFF
Linear dimmer/no dimmer function

EN Q-Wash™ 436Z-LED QRG
5
Menu Options (cont.)
Main Level
Programming Levels
Description
SETTINGS
(cont.)
PERFORM
(cont.)
DIM INVERT
NORM
Defines the direction of the dimmer
fader
INVERT
DMX ERROR SAVE
Continues with last command upon loss
of DMX control
BLACK
Blacks out fixture upon loss of DMX
signal
DMX RESET
DMX
The DMX controller resets the product
DISPLAY
The control panel resets the product
DISPLAY ON
LONG
Determines how long the backlight of
the display will stay on after last
command button pressed
SHORT
ALWAYS
HOME
SCREEN
DMX
Displays DMX address
NAME
Displays what is programmed via
SERVICE > CONTENT level
DISPLAY
INVERT
NORM
Allows the display on the control panel
to be inverted
INVERT
RANGE
P.START
000~255
Sets the pan start point
(pan range)
P.END
Sets the pan end point
(pan range)
T.START
Sets the tilt start point
(tilt range)
T.END
Sets the tilt end point
(tilt range)
USE
NO
Activates the changes
YES
DISPLAY LOCK
OFF
Activates/deactivates the main level
password
ON
DEFAULT
NO
Resets fixture to factory default settings
YES
SEND
NO
Sends ALL settings of the 1st product
to all other Q-Wash™ 436Z-LEDs
connected to the DMX output
YES

Q-Wash™ 436Z-LED QRG EN
6
Menu Options (cont.)
Main Level
Programming Levels
Description
STAND ALONE
RUN
DMX 512
Selects DMX running mode
AUTO1
Selects the first automatic program
AUTO2
Selects the second automatic program
CUSTOM
Selects a user customizable program
TEST
Starts the product’s test sequence
SLAVE
Selects the Slave running mode
EDIT
STEP
01~49
Selects the program step
PAN
000~255
Selects the pan position
TILT
Selects the tilt position
RED
Combines red, green, blue, and white
to obtain a custom color
GREEN
BLUE
WHITE
DIMMER
Selects the dimmer value
STROBE
Selects the strobe frequency
ZOOM
Select the zoom position
TIME
Selects the step duration
USE
NO
Activates the changes
YES
SEND NO Sends CUSTOM settings of the 1st
product to all other Q-Wash™ 436Z-
LEDs connected to the DMX output
YES
INFO
SOFTWARE
V.X.X
Shows version of software installed
MANUAL RESET
ALL RESET
NO
Resets fixture to home settings
YES
PT.RESET
NO
Resets the Pan/Tilt to home settings
YES
OPTIC RESET
NO
Resets the Zoom to home settings
YES

EN Q-Wash™ 436Z-LED QRG
7
Menu Options (cont.)
Main Level
Programming Levels
Description
MANUAL
(cont.) MANUAL
PAN
000~255 Allows manual control of all settings
from control panel
TILT
RED
GREEN
BLUE
WHITE
DIMMER
STROBE
ZOOM
CONTROL
SERVICE
CALIB.M
PAN
000~255 Calibrates the start position of the
motors
TILT
ZOOM
CALIB.C
3200K
RED
000~255
Sets color temperature for White 1
GREEN
BLUE
3400K
RED
Sets color temperature for White 2
GREEN
BLUE
4200K
RED
Sets color temperature for White 3
GREEN
BLUE
4900K
RED
Sets color temperature for White 4
GREEN
BLUE

Q-Wash™ 436Z-LED QRG EN
8
Menu Options (cont.)
Main Level Programming Levels Description
SERVICE
(cont.)
CALIB.C
(cont.)
5600K
RED
000~255
Sets color temperature for White 5
GREEN
BLUE
5900K
RED
Sets color temperature for White 6
GREEN
BLUE
6500K
RED
Sets color temperature for White 7
GREEN
BLUE
7200K
RED
Sets color temperature for White 8
GREEN
BLUE
8000K
RED
Sets color temperature for White 9
GREEN
BLUE
8500K
RED
Sets color temperature for White 10
GREEN
BLUE
10000K
RED
Sets color temperature for White 11
GREEN
BLUE
ACCESS
SETTINGS
LOCK
OFF
Activates/deactivates the SETTINGS
main level password
ON
SERVICE
LOCK
OFF
Activates/deactivates the SERVICE
main level password
ON
WIRELESS
HIDE
HIDE
Shows/Hides the WIRELESS option in
the SETTINGS menu option
SHOW
CONTENT
DISPLAY1
*********
Allows 16 characters of text to be
displayed on control panel
DISPLAY2
*********
SEND NO
Sends CONTENT settings of the 1st
product to all other Q-Wash™ 436Z-
LEDs connected to the DMX output
YES

EN Q-Wash™ 436Z-LED QRG
9
DMX Values
PERSON 1
Channel
Function
Value
Percent/Setting
1
Pan
000 ó255
0~100%
2
Tilt
000 ó255
0~100%
3
Red
000 ó255
0~100%
4
Green
000 ó255
0~100%
5
Blue
000 ó255
0~100%
6
White
000 ó255
0~100%
7
Dimmer
000 ó255
0~100%
8 Strobe
000 ó009
010
ó
255
No Function
0~100%
9
Zoom
000 ó255
0~100%
10 Control
000 ó019
020 ó039
040 ó059
060 ó079
080 ó099
100 ó119
120 ó139
140 ó149
150 ó159
160 ó169
170 ó179
180 ó199
200 ó219
220 ó235
236 ó239
240 ó243
244 ó247
248 ó251
252 ó255
No Function
Pan/tilt black activation
Pan/tilt black deactivation
Automatic fan speed
Slow fan speed
Normal fan speed
High fan speed
Auto program 1 (3 s activation delay)
Auto program 2 (3 s activation delay)
Test (3 s activation delay)
Custom program (3 s activation delay)
No Function
Reset (3 s activation delay)
No Function
DIM0 (3 s activation delay)
DIM1 (3 s activation delay)
DIM2 (3 s activation delay)
DIM3 (3 s activation delay)
DIM4 (3 s activation delay)

Q-Wash™ 436Z-LED QRG EN
10
DMX Values (cont.)
PERSON 2
Channel
Function
Value
Percent/Setting
1
Pan
000 ó255
0~100%
2
Pan Fine
000 ó255
0~100%
3
Tilt
000 ó255
0~100%
4
Tilt Fine
000 ó255
0~100%
5
Pan/Tilt Speed
000 ó255
0~100%
6
Red
000 ó255
0~100%
7
Green
000 ó255
0~100%
8
Blue
000 ó255
0~100%
9
White
000 ó255
0~100%
10 Color/White Macro
000 ó010
011 ó030
031 ó050
051 ó070
071 ó090
091 ó110
111 ó130
131 ó150
151 ó170
171 ó200
201 ó205
206 ó210
211 ó215
216 ó220
221 ó225
226 ó230
231 ó235
236 ó240
241 ó245
246 ó250
251 ó255
No Function
R: 100% G: 0~100%B: 0
R: 100%~0G: 100% B: 0
R: 0 G: 100% B: 0~100%
R: 0 G: 100%~0B: 100%
R: 0~100%G: 0 B: 100%
R: 100% G: 0 B: 100%~0
R: 100% G: 0~100%B: 0~100%
R: 100%~0G: 100%~0B: 100%
R: 100% G: 100% B: 100% W:100%
White 1
White 2
White 3
White 4
White 5
White 6
White 7
White 8
White 9
White 10
White 11

EN Q-Wash™ 436Z-LED QRG
11
DMX Values (cont.)
PERSON 2
(cont.)
Channel
Function
Value
Percent/Setting
11 Auto Rings
000 ó009
010 ó019
020 ó029
030 ó039
040 ó049
050 ó059
060 ó069
070 ó079
080 ó089
090 ó099
100 ó109
110 ó119
120 ó129
130 ó139
140 ó149
150 ó159
160 ó169
170 ó179
180 ó189
190 ó199
200 ó209
210 ó219
220 ó229
230 ó239
240 ó249
250 ó255
No Function
Static Ring 1
Static Ring 2
Static Ring 3
Static Ring 4
Static Ring 5
Ring Effect 1
Ring Effect 2
Ring Effect 3
Ring Effect 4
Ring Effect 5
Ring Effect 6
Ring Effect 7
Ring Effect 8
Ring Effect 9
Ring Effect 10
Ring Effect 11
Ring Effect 12
Ring Effect 13
Ring Effect 14
Ring Effect 15
Ring Effect 16
Ring Effect 17
Ring Effect 18
Ring Effect 19
No Function
12
Auto Speed
000 ó255
0~100%
13
Dimmer
000 ó255
0~100%
14 Strobe
000 ó009
010 ó255
No Function
0~100%
15
Zoom
000 ó255
0~100%
16 Control
000 ó019
020 ó039
040 ó059
060 ó079
080 ó099
100 ó119
120 ó139
140 ó149
150 ó159
160 ó169
170 ó179
180 ó199
200 ó219
220 ó235
236 ó239
240 ó243
244 ó247
248 ó251
252 ó255
No Function
Pan/tilt black activation
Pan/tilt black deactivation
Automatic fan speed
Slow fan speed
Normal fan speed
High fan speed
Auto program 1 (3 s activation delay)
Auto program 2 (3 s activation delay)
Test (3 s activation delay)
Custom program (3 s activation delay)
No Function
Reset (3 s activation delay)
No Function
DIM0 (3 s activation delay)
DIM1 (3 s activation delay)
DIM2 (3 s activation delay)
DIM3 (3 s activation delay)
DIM4 (3 s activation delay)

Q-Wash™ 436Z-LED QRG EN
12
DMX Values (cont.)
PERSON 3
Channel
Function
Value
Percent/Setting
1
Pan
000 ó255
0~100%
2
Pan Fine
000 ó255
0~100%
3
Tilt
000 ó255
0~100%
4
Tilt Fine
000 ó255
0~100%
5
Pan/Tilt Speed
000 ó255
0~100%
6
Red 1
000 ó255
0~100%
7
Green 1
000 ó255
0~100%
8
Blue 1
000 ó255
0~100%
9
White 1
000 ó255
0~100%
10
Red 2
000 ó255
0~100%
11
Green 2
000 ó255
0~100%
12
Blue 2
000 ó255
0~100%
13
White 2
000 ó255
0~100%
14
Red 3
000 ó255
0~100%
15
Green 3
000 ó255
0~100%
16
Blue 3
000 ó255
0~100%
17
White 3
000 ó255
0~100%
18
Red 4
000 ó255
0~100%
19
Green 4
000 ó255
0~100%
20
Blue 4
000 ó255
0~100%
21
White 4
000 ó255
0~100%
22
Red 5
000 ó255
0~100%
23
Green 5
000 ó255
0~100%
24
Blue 5
000 ó255
0~100%
25
White 5
000 ó255
0~100%

EN Q-Wash™ 436Z-LED QRG
13
DMX Values (cont.)
PERSON 3
(cont.)
Channel
Function
Value
Percent/Setting
26
Dimmer
000 ó255
0~100%
27 Strobe
000 ó009
010 ó255
No Function
0~100%
28
Zoom
000 ó255
0~100%
29 Control
000 ó019
020 ó039
040 ó059
060 ó079
080 ó099
100 ó119
120 ó139
140 ó149
150 ó159
160 ó169
170 ó179
180 ó199
200 ó219
220 ó235
236 ó239
240 ó243
244 ó247
248 ó251
252
ó
255
No Function
Pan/tilt black activation
Pan/tilt black deactivation
Automatic fan speed
Slow fan speed
Normal fan speed
High fan speed
Auto program 1 (3 s activation delay)
Auto program 2 (3 s activation delay)
Test (3 s activation delay)
Custom program (3 s activation delay)
No Function
Reset (3 s activation delay)
No Function
DIM0 (3 s activation delay)
DIM1 (3 s activation delay)
DIM2 (3 s activation delay)
DIM3 (3 s activation delay)
DIM4 (3 s activation delay)

Q-Wash™ 436Z-LED QRG EN
14
DMX Values (cont.)
PERSON 4
Channel
Function
Value
Percent/Setting
1
Pan
000 ó255
0~100%
2
Tilt
000 ó255
0~100%
3
Hue
000 ó255
0~100%
4
Saturation
000 ó255
0~100%
5
Value
000 ó255
0~100%
6 Strobe
000 ó009
010
ó
255
No Function
0~100%
7
Zoom
000 ó255
0~100%
8 Control
000 ó019
020 ó039
040 ó059
060 ó079
080 ó099
100 ó119
120 ó139
140 ó149
150 ó159
160 ó169
170 ó179
180 ó199
200 ó219
220 ó235
236 ó239
240 ó243
244 ó247
248 ó251
252 ó255
No Function
Pan/tilt black activation
Pan/tilt black deactivation
Automatic fan speed
Slow fan speed
Normal fan speed
High fan speed
Auto program 1 (3 s activation delay)
Auto program 2 (3 s activation delay)
Test (3 s activation delay)
Custom program (3 s activation delay)
No Function
Reset (3 s activation delay)
No Function
DIM0 (3 s activation delay)
DIM1 (3 s activation delay)
DIM2 (3 s activation delay)
DIM3 (3 s activation delay)
DIM4 (3 s activation delay)

EN Q-Wash™ 436Z-LED QRG
15
DMX Values (cont.)
PERSON 5
Channel
Function
Value
Percent/Setting
1
Pan
000 ó255
0~100%
2
Pan Fine
000 ó255
0~100%
3
Tilt
000 ó255
0~100%
4
Tilt Fine
000 ó255
0~100%
5
Pan/Tilt Speed
000 ó255
0~100%
6
Dimmer
000 ó255
0~100%
7 Strobe
000 ó009
010
ó
255
No Function
0~100%
8
Zoom
000 ó255
0~100%
9 Control
000 ó019
020 ó039
040 ó059
060 ó079
080 ó099
100 ó119
120 ó139
140 ó149
150 ó159
160 ó169
170 ó179
180 ó199
200 ó219
220 ó235
236 ó239
240 ó243
244 ó247
248 ó251
252 ó255
No Function
Pan/tilt black activation
Pan/tilt black deactivation
Automatic fan speed
Slow fan speed
Normal fan speed
High fan speed
Auto program 1 (3 s activation delay)
Auto program 2 (3 s activation delay)
Test (3 s activation delay)
Custom program (3 s activation delay)
No Function
Reset (3 s activation delay)
No Function
DIM0 (3 s activation delay)
DIM1 (3 s activation delay)
DIM2 (3 s activation delay)
DIM3 (3 s activation delay)
DIM4 (3 s activation delay)

Q-Wash™ 436Z-LED QRG EN
16
DMX Values (cont.)
PERSON 5
(cont.)
Channel
Function
Value
Percent/Setting
10
Red 1
000 ó255
0~100%
11
Green 1
000 ó255
0~100%
12
Blue 1
000 ó255
0~100%
13
White 1
000 ó255
0~100%
14
Red 2
000 ó255
0~100%
15
Green 2
000 ó255
0~100%
16
Blue 2
000 ó255
0~100%
17
White 2
000 ó255
0~100%
18
Red 3
000 ó255
0~100%
19
Green 3
000 ó255
0~100%
20
Blue 3
000 ó255
0~100%
21
White 3
000 ó255
0~100%
22
Red 4
000 ó255
0~100%
23
Green 4
000 ó255
0~100%
24
Blue 4
000 ó255
0~100%
25
White 4
000 ó255
0~100%
26
Red 5
000 ó255
0~100%
27
Green 5
000 ó255
0~100%
28
Blue 5
000 ó255
0~100%
29
White 5
000 ó255
0~100%

ES Q-Wash™ 436Z-LED GRR
17
Acerca de Esta
Guía
La Guía de Referencia Rápida (GRR) del Q-Wash™ 436Z-LED contiene
información básica sobre el producto, como conexión, montaje, opciones de
menú y valores DMX. Descargue el manual de usuario de
www.chauvetpro.com para una información más detallada.
Exención de
Responsa-
bilidad
La información y especificaciones contenidas en esta GRR están sujetas a
cambio sin previo aviso.
Notas de
Seguridad
•NO abra este producto. No contiene piezas reparables por el usuario.
•NO mire a la fuente de luz cuando el producto esté encendido.
•¡CUIDADO! La carcasa de este producto está caliente cuando las
luces están en funcionamiento.
•Monte este producto en una ubicación con ventilación adecuada, al
menos a 20'' (50 cm) de superficies adyacentes.
•NO deje ningún material inflamable a menos de 50 cm de este
producto mientras esté funcionando o conectado a la alimentación.
•USE un cable de seguridad cuando monte este producto en lo alto.
•NO ponga en funcionamiento este producto en el exterior o en
cualquier ubicación en la que el polvo, calor excesivo, agua o
humedad puedan afectarlo.
•
NO ponga en funcionamiento este producto si sospecha que la carcasa,
lentes o cables están dañados.
•NO conecte este producto a un atenuador o reostato.
•Conecte este producto SOLO a un circuito con toma de tierra y
protegido.
•Use SOLAMENTE los soportes o las asas para mover este producto.
NO lo transporte sujetando por la cabeza móvil o el yugo.
•En caso de un problema grave de funcionamiento, deje de usarlo
inmediatamente.
•La máxima temperatura ambiente es de 104º F (40º C). No haga
funcionar este producto a temperaturas más altas.
Contacto
Fuera de EE.UU, Reino Unido o Irlanda, póngase en contacto con su
proveedor para solicitar asistencia o devolver el producto. Visite
www.chauvetpro.com para información de contacto.
¿Qué va
Incluido?
•Q-Wash™ 436Z-LED
•Cable de Alimentación
•2 Soportes Omega
•Cable de Seguridad
•Tarjeta de Garantía
•Guía de Referencia Rápida

Q-Wash™ 436Z-LED GRR ES
18
Corriente
Alterna
Este producto tiene una fuente de alimentación con detección automática
que puede funcionar con un rango de tensión de entrada de
100~240 VCA, 50/60 Hz.
Alimentación en
Cadena
Puede enlazar hasta 2 productos Q-Wash™ 436Z-LED a 120 VCA,
u 6
a 230 VCA. Los cables de alimentación en cadena se pueden adquirir
por separado.
Enchufe CA
Conexión
Cable (EE.UU)
Cable (Europa)
Color del Tornillo
CA Cargado
Negro
Marrón
Amarillo/Bronce
CA Neutro
Blanco
Azul
Plata
CA Tierra
Verde/Amarillo
Verde/Amarillo
Verde
Sustitución
del Fusible
1. Desconecte el producto de la toma de corriente.
2. Con un destornillador de estrella Nº2 desatornille la tapa del
portafusibles.
3. Quite el fusible fundido del portafusibles y sustitúyalo con otro del
mismo tipo y categoría.
4. Vuelva a atornillar la tapa del portafusibles en su sitio y conecte de
nuevo la alimentación.
Enlace DMX
El Q-Wash™ 436Z-LED funcionará con un controlador DMX usando una
conexión serie DMX normal. Hay un
Manual DMX disponible en
www.chauvetpro.com.
Conexión DMX
El Q-Wash™ 436Z-LED usa una conexión de datos DMX normal para sus
personalidades DMX: PERSON 1, PERSON 2, PERSON 3, PERSON 4
y PERSON 5. Vea el Manual de usuario para conectar y configurar para
funcionamiento DMX.
Conexión
Maestro/Esclavo
El Q-Wash™ 436Z-LED usa la conexión de datos DMX para su modo
Maestro/Esclavo Vea el Manual de usuario para conectar y configurar para
funcionamiento Maestro/Esclavo.

ES Q-Wash™ 436Z-LED GRR
19
Montaje
Diagrama
de Montaje
del Producto
Descripción del
Panel de
Control
Botón
Función
<MENU>
Sale del menú o función actual
<ENTER>
Habilita el menú actualmente en pantalla o configura el
valor seleccionado actualmente dentro de la función
seleccionada
<UP>
Navega hacia arriba por la lista de menú y aumenta el valor
numérico cuando está en una función
<DOWN>
Navega hacia abajo por la lista de menú y disminuye el
valor numérico cuando está en una función
Contraseña
Después de que se le solicite, introduzca la siguiente contraseña pulsando:
<UP>, <DOWN>, <UP>, <DOWN>, <ENTER>
Esta contraseña no se puede cambiar y se debe usar cuando se le solicite.
Montaje en Alto
Montaje de Suelo
Cable de
Segurida
Abrazaderas
de Montaje

Q-Wash™ 436Z-LED GRR ES
20
Opciones de Menú
Nivel Principal
Niveles de Programación
Descripción
ADDRESS
000~512
Configura la dirección inicial DMX
PERSON
PERSON1
Modo de 10 Canales
PERSON2
Modo de 16 Canales
PERSON3
Modo de 29 Canales
PERSON4
Modo de 8 Canales
PERSON5
Modo de 29 Canales
SETTINGS
WIRELESS
WDMX
ACTIVATE
OFF
Reservado para usos futuros
ON
WDMX
RESET
NO
YES
PERFORM
FANS
SLOW
Selecciona el modo de funcionamiento
de ventilador
NORM
FAST
AUTO
PT SPEED
FAST
Define la velocidad de desplazamiento
lateral/inclinación
SLOW
PAN INVERT
NORM
Define la dirección del deslizador de
desplazamiento lateral
INVERT
TILT INVERT
NORM
Define la dirección del deslizador de
inclinación
INVERT
OPTICS
SPEED
FAST
Define la velocidad del zoom
SLOW
BLACKOUT
DELAY
Activa el retardo del move-in black
(3 segundos)
INSTANT
DIMMER
DIM4
Curvas de atenuador de lento (DIM4) a
rápido (DIM1)
DIM3
DIM2
DIM1
OFF
Función Atenuador lineal/sin atenuador
