Chauvet SCORPION LR-1510 User manual

LR-1510
Scorpion™ R
USER MANUAL
CHAUVET, 3000 N 29th Ct, Hollywood, FL 33020 U.S.A
[phone] – [phone]
FAX [phone]
www.chauvetlighting.com

TABLE OF CONTENT
BEFORE YOU BEGIN........................................................................................................................................................... 3
WHAT IS INCLUDED................................................................................................................................................................................3
UNPACKING INSTRUCTIONS....................................................................................................................................................................3
ACPOWER...........................................................................................................................................................................................3
SAFETY INSTRUCTIONS..........................................................................................................................................................................4
INTRODUCTION ................................................................................................................................................................... 5
FEATURES............................................................................................................................................................................................5
PRODUCT OVERVIEW ............................................................................................................................................................................5
GENERAL INSTRUCTIONS .......................................................................................................................................................................5
COMPLIANCE STATEMENT................................................................................................................................................ 6
LASER SAFETY AND COMPLIANCE INFORMATION......................................................................................................................................6
PROPER USAGE....................................................................................................................................................................................7
APPENDIX............................................................................................................................................................................. 7
GENERAL MAINTENANCE .......................................................................................................................................................................7
RETURNS PROCEDURE..........................................................................................................................................................................8
CLAIMS ................................................................................................................................................................................................8
TECHNICAL SPECIFICATIONS ..................................................................................................................................................................8
LR-1510 User Manual 2 11/14/2007/18:54

BEFORE YOU BEGIN
What is included
¾1 x Scorpion™ R
¾Warranty Card ¾User Manual ¾Power Adapter
Unpacking Instructions
Immediately upon receiving a fixture, carefully unpack the carton, check the contents to ensure that
all parts are present, and have been received in good condition. Notify the shipper immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture
must be returned to the factory, it is important that the fixture be returned in the original factory box
and packing.
AC Power
To determine the power requirements for a particular fixture, see the label affixed to the back plate of
the fixture or refer to the fixture’s specifications chart. A fixture’s listed current rating is its average
current draw under normal conditions. All fixtures must be powered directly off a switched circuit and
cannot be run off a rheostat (variable resistor) or dimmer circuit, even if the rheostat or dimmer
channel is used solely for a 0% to 100% switch. Before applying power to a
fixture, check that the source voltage matches the fixture’s requirement.
Check the fixture or device carefully to make sure that if a voltage selection
switch exists that it is set to the correct line voltage you will use.
Figure 1 - AC Voltage Switch
Not all fixtures have a voltage
select switch. Please be sure to
connect to the proper voltage.
Warning! Verify that the power select switch on your unit matches the
line voltage applied. All fixtures must be connected to circuits
with a suitable Earth Ground.
LR-1510 User Manual 3 11/14/2007/18:54

Introduction
Safety Instructions
Please read these instructions carefully, which
includes important information about the installation,
usa
g
e and maintenance?
•Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that
they also receive this instruction booklet.
•Always make sure that you are connecting to the proper voltage and that the line voltage you are
connecting to is not higher than that stated on decal or rear panel of the fixture.
•This product is intended for indoor use only!
•To prevent risk of fire or shock, do not expose fixture to rain or moisture. Make sure there are no
flammable materials close to the unit while operating.
•The unit must be installed in a location with adequate ventilation, at least 50cm from adjacent
surfaces. Be sure that no ventilation slots are blocked.
•Always disconnect from power source before servicing or replacing lamp or fuse and be sure to
replace with same lamp source.
•Secure fixture to fastening device using a safety chain. Never carry the fixture solely by its head. Use
its carrying handles.
•Maximum ambient temperature is Ta: 40°. Do not operate fixture at temperatures higher than this.
•In the event of serious operating problem, stop using the unit immediately. Never try to repair the unit
by yourself. Repairs carried out by unskilled people can lead to damage or malfunction. Please
contact the nearest authorized technical assistance center. Always use the same type spare parts.
•Don’t connect the device to a dimmer pack.
•Make sure power cord is never crimped or damaged.
•Never disconnect power cord by pulling or tugging on the cord.
•Avoid direct eye exposure to lamp while it is on.
Caution! There are no user serviceable parts inside the unit. Do not open the housing or
attempt any repairs yourself. In the unlikely event your unit may require service,
please contact CHAUVET.
LR-1510 User Manual 4 11/14/2007/18:54

INTRODUCTION
Thank you for purchasing this laser product. You can be assured that you have made an investment
into the highest quality laser products available today. This product has been designed by the
development team at CHAUVET.
You can be confident that our quality and after sales service is equal to our status of being the global
leader in entertainment lighting and laser products.
Features
•Red laser
•16 preset patterns
•Sound activated mode
•Auto and Manual modes
•User selectable patterns and speed of rotation in manual mode
Product Overview
AC Power Connection:
The unit is supplied with a power pack appropriate to its voltage and destination. It is imperative that
the correct power pack suitable for this unit be used at all times. If any other type of supply is provide
to this unit then it is likel
y
to render the unit non-o
p
erational.
General Instructions
This lighting effect has been designed to function on a 9V DC power and has been supplied with a
suitable AC power pack for use with your local voltage. Check the label on the unit and the power
plug for the correct voltage. When connected to the mains power supply via the power pack and
switched on the unit should illuminate and shoot a <4.95mW single laser. Warning: Do not aim
towards eye.
This unit provides three modes of operation accessible via the functions switch (Fig 1). The three
modes are as follows: Sound Activation, Auto Mode and Manual. In the sound and automatic modes,
the laser will change through sixteen preset patterns. In manual mode, the user can select the pattern
and speed of rotation.
LR-1510 User Manual 5 11/14/2007/18:54

COMPLIANCE STATEMENT
Your LR-1510 has been designed to comply with FDA and IEC Standards for its classification. A
special optic design regulates the output of the projector so that when properly used the output
remains at levels government agencies have determined to be appropriate for the products function.
Laser Safety and Compliance Information
This product is manufactured to comply with the IEC 60825-1 and in accordance with U.S. Food and
Drug Administrations (FDA) Standards listed under FDA Document 21 CFR 1040 and subsequent
laser notices.
Product Classification and Manufacturing Label Identification
Laser Classification Class IIIa
Laser Medium LB05R Semiconductor Diode 650nm
Cooling Fan Cooled
Output 4.95mW
Beam Divergence Optically adjusted for compliance
There is only one
laser aperture on
this product.
CAUTION: AVOID EXPOSURE
TO BEAM: Avoid direct eye
contact with laser light. Never
intentionally expose your eyes or
others to direct laser radiation.
Non-Interlocked Housing Warning Labels. This unit
contains an embedded laser device that exceeds the output
of the intended class internally. Exposure to unsafe levels
of laser radiation when opened.
Additionally there are no user serviceable parts inside. Tampering or
removing warranty seals will void your products limited warranty.
LR-1510 User Manual 6 11/14/2007/18:54

Proper Usage
APPENDIX
This unit has been designed to be hung. It is recommended that, for safety
purposes, your lighting effect are properly mounted using a suitable
hanging clamp and safety cable. CHAUVET offers a range of items, which
are ideal for safe mounting.
It is the responsibility of the manufacturer to provide useful instruction on
the proper use of this product.
According to FDA Regulations you should operate the product in the
fashion illustrated below.
CAUTION: Use of controls, adjustments, or performance of
procedures other than what is specified herein may result in
hazardous radiation exposure
General Maintenance
To maintain optimum performance and minimize wear fixtures should be cleaned frequently. Usage
and environment are contributing factors in determining frequency. As a general rule, fixtures should
be cleaned at least twice a month. Dust build up reduces light output performance and can cause
overheating. This can lead to reduced lamp life and increased mechanical wear. Be sure to power off
fixture before conducting maintenance.
Unplug fixture from power. Use a vacuum or air compressor and a soft brush to remove dust
collected on external vents and internal components. Clean all glass when the fixture is cold with a
mild solution of glass cleaner or Isopropyl Alcohol and a soft lint free cotton cloth or lens tissue. Apply
solution to the cloth or tissue and drag dirt and grime to the outside of the lens. Gently polish optical
surfaces until they are free of haze and lint.
The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to
optimize light output. Cleaning frequency depends on the environment in which the fixture operates:
damp, smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s
optics. Clean with soft cloth using normal glass cleaning fluid. - Always dry the parts carefully. - Clean
the external optics at least every 20 days. Clean the internal optics at least every 30/60 days.
LR-1510 User Manual 7 11/14/2007/18:54

Appendix
Returns Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Merchandise Authorization Number (RA #). Products
returned without an RA # will be refused. Call CHAUVET and request RA # prior to shipping the
fixture. Be prepared to provide the model number, serial number and a brief description of the cause
for the return. Be sure to properly pack fixture, any shipping damage resulting from inadequate
packaging is the customer’s responsibility. CHAUVET reserves the right to use its own discretion to
repair or replace product(s). As a suggestion, proper UPS packing or double-boxing is always a safe
method to use.
Claims
Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise. It is the customer's responsibility to notify and
submit claims with the shipper in the event that a fixture is damaged due to shipping. Any other claim
for items such as missing component/part, damage not related to shipping, and concealed damage,
must be made within seven (7) days of receiving merchandise.
Technical Specifications
WEIGHT & DIMENSIONS
Length........................................................................................................................... 143 mm (5.63 in)
Width .............................................................................................................................. 188 mm (7.4 in)
Height........................................................................................................................... 131 mm (5.16 in)
Weight ...........................................................................................................................0.4 Kg (0.88 lbs)
POWER
Power adapter...................................................................................................................DC 9V 800mA
LASER
Diode (LR-1510)............................................................................................... 1 x 4.8 ~ 5 mW red laser
Wavelength...................................................................................................................................650 nm
Part No ..................................................................................................................................4.9mW Red
THERMAL
Maximum ambient temperature.......................................................................................... 40°C(104° F)
ORDERING INFORMATION
Scorpion R..................................................................................................................................LR-1510
LR-1510 User Manual 8 11/14/2007/18:54
