Chauvet Scorpion Storm RGX User manual

LASER LIGHT
AVOID DIRECT EYE EXPOSURE
CLASS 3R LASER PRODUCT
CLASSIFIED PER EN/IEC 60825-1:2007
Complies with FDA performance standards for
laser products except for deviations pursuant
to Laser Notice No. 50, dated June 24, 2007.

Scorpion™ Storm RGX User Manual 2 8/18/2011
TABLE OF CONTENTS
1.BEFORE YOU BEGIN ................................................................................................................................................................................................3
WHAT IS INCLUDED.................................................................................................................................................................................................3
UNPACKING INSTRUCTIONS......................................................................................................................................................................................3
CLAIMS..................................................................................................................................................................................................................3
MANUAL CONVENTIONS...........................................................................................................................................................................................3
ICONS....................................................................................................................................................................................................................3
SAFETY INSTRUCTIONS............................................................................................................................................................................................4
NON INTERLOCKEDHOUSING WARNING....................................................................................................................................................................5
LASER SAFETY NOTES ............................................................................................................................................................................................5
LASER SAFETY LABEL REPRODUCTION.....................................................................................................................................................................6
LASER EMISSION DATA............................................................................................................................................................................................7
LASER COMPLIANCE STATEMENT .............................................................................................................................................................................7
2.INTRODUCTION.........................................................................................................................................................................................................8
PRODUCT OVERVIEW ..............................................................................................................................................................................................8
PRODUCT DIMENSIONS............................................................................................................................................................................................8
PROPER USAGE......................................................................................................................................................................................................9
3.SETUP...................................................................................................................................................................................................................10
ACPOWER ..........................................................................................................................................................................................................10
FUSE REPLACEMENT.............................................................................................................................................................................................10
MOUNTING ...........................................................................................................................................................................................................10
Orientation................................................................................................................................................................................................................................... 10
Rigging........................................................................................................................................................................................................................................ 10
FIXTURE LINKING ..................................................................................................................................................................................................11
Data Cabling ............................................................................................................................................................................................................................... 12
DMX Data Cable......................................................................................................................................................................................................................... 12
Cable Connectors.......................................................................................................................................................................................................................12
3-Pin to 5-Pin Conversion Chart................................................................................................................................................................................................. 13
SETTING UP A DMSSERIAL DATA LINK..................................................................................................................................................................13
MASTER/SLAVE FIXTURE LINKING ..........................................................................................................................................................................13
4.OPERATING INSTRUCTIONS.....................................................................................................................................................................................14
NAVIGATING THE CONTROL PANEL .........................................................................................................................................................................14
Menu Functions........................................................................................................................................................................................................................... 14
DMXCHANNEL SUMMARY.....................................................................................................................................................................................14
DMXCHANNEL VALUES........................................................................................................................................................................................15
Setting the Starting Address....................................................................................................................................................................................................... 15
GENERAL TROUBLESHOOTING................................................................................................................................................................................16
TECHNICAL SUPPORT............................................................................................................................................................................................16
5.APPENDIX .............................................................................................................................................................................................................17
DMXPRIMER.......................................................................................................................................................................................................17
RETURNS PROCEDURE..........................................................................................................................................................................................17
TECHNICAL SPECIFICATIONS..................................................................................................................................................................................18
Contact Information
WorldHeadquartersUnitedKingdom&Ireland
CHAUVET®CHAUVET®EuropeLtd.
GeneralInformation
Address:5200NW108thAvenue
Sunrise,FL33351
Voice: (954)929‐1115
Fax: (954)929‐5560
Tollfree: (800)762‐1084
TechnicalSupport
Voice: (954)929‐1115(Press4)
Fax: (954)756‐8015
GeneralInformation
Address: Unit1C
BrookhillRoad
Pinxton,Nottingham,UK
NG166NT
Voice: +44(0)1773511115
Fax: +44(0)1773511110
Email:[email protected]

WorldWideWeb:www.chauvetlighting.com WorldWideWeb:www.chauvetlighting.co.uk

Scorpion™ Storm RGX User Manual 3 8/18/2011
1.BEFORE YOU BEGIN
What Is Included
1 x Scorpion™ Storm RGX
1 x Power Cord
1 x Warranty Card
1 x User Manual
Unpacking Instructions
Immediately upon receipt, carefully unpack this product and check the container to make
sure you have received all the parts indicated above in good condition.
Claims
If the container or the material inside the container (this product and any other accessory
included) appears damaged from shipping, or shows signs of mishandling, notify the carrier
immediately, not CHAUVET®, upon receipt of the damaged merchandise. Failure to do so in
a timely manner may invalidate your claim with the carrier. In addition, retain the container
and all the packing material for inspection.
For other issues such as missing components or parts, damage not related to shipping, or
concealed damage, file a claim with CHAUVET® within seven (7) days of receiving the
merchandise.
Manual Conventions
CHAUVET® manuals use the following conventions to differentiate certain types of
information from the regular text.
Convention MEANING
<Menu> A key to be pressed on the product’s control panel
1~512 A range of values
50/60 A set of values of which only one can be chosen
Settings A menu option not to be modified (for example, showing the
operating mode/current status)
MENU >
Settings A sequence of menu options to be followed
ON A value to be entered or selected
Icons
This manual uses the following icons to indicate information that requires special attention
on the part of the user.
Icons MEANING
This paragraph contains critical installation, configuration or
operation information. Failure to comply with this information
may render the product partially or completely inoperative,
cause damage to the product or cause harm to the user.
This paragraph contains important installation or configuration
information. Failure to comply with this information may
prevent the product from functioning correctly.
This paragraph reminds you of useful, although not critical,
information.

Scorpion™ Storm RGX User Manual 4 8/18/2011
Safety Instructions
Please read the following notes carefully because they include important safety
information about the installation, usage, and maintenance of this product.
Keep this User Manual for future consultation. If you sell this product to another user,
be sure that they also receive this document.
Always make sure that the voltage of the outlet to which you are connecting this
product is within the range stated on the decal or rear panel of the product.
This product is for indoor use only! To prevent risk of fire or shock, do not expose this
product to rain or moisture.
Make sure there are no flammable materials close to the unit while operating.
Always install this product in a location with adequate ventilation, at least 20 in (50 cm)
from adjacent surfaces. Be sure that no ventilation slots are blocked.
Always disconnect this product from the power source before cleaning it or replacing
fuse.
Make sure to replace the fuse with another of the same type and rating.
If mounting it overhead, always secure this product to a fastening device using a
safety chain.
The maximum ambient temperature (Ta) is 104° F (40° C). Do not operate this product
at higher temperatures.
In the event of a serious operating problem, stop using the unit immediately. Never try
to repair the unit. Repairs carried out by unskilled people can lead to damage or
malfunction. Please contact the nearest authorized technical assistance center.
Never connect this product to a dimmer pack.
Make sure the power cord is not crimped or damaged.
Never disconnect the power cord by pulling or tugging on the cord.
Never carry a product from the power cord or any moving part. Always use the
hanging/mounting bracket or the handles.
Always avoid direct eye exposure to the light source when this product is on.
Lasers can be hazardous and have unique safety considerations. Permanent eye
injury and blindness is possible if lasers are used incorrectly. Pay close attention to
each safety REMARK and WARNING statement in this user manual. Read all
instructions carefully BEFORE operating this device.
Avoid direct eye contact with laser light. Never intentionally expose your eyes or
others to direct laser light.
This laser product can potentially cause instant eye injury or blindness if laser
light directly strikes the eyes.
It is illegal and dangerous to shine this laser into audience areas, where the
audience or other personnel could get direct laser beams or bright reflections
into their eyes.
It is a US Federal offense to shine any laser at aircraft.
Use of controls or adjustments or performance of procedures other than those
specified herein may result in hazardous radiation exposure.
There are no user serviceable parts inside the unit. Do not open the housing or
attempt any repairs yourself. In the unlikely event your unit may require service,
please contact the dealer nearest to you.
Avoid direct eye contact with laser light. Never intentionally expose your eyes or
others to direct laser light.

Scorpion™ Storm RGX User Manual 5 8/18/2011
Non Interlocked Housing Warning
This unit contains high power laser devices internally.
Do not open the laser housing, due to potential exposure to unsafe levels of laser
radiation.
The laser power levels, accessible if the unit is opened, can cause instant blindness,
skin burns, and fires.
Laser Safety Notes
STOP AND READ ALL THE LASER SAFETY NOTES BELOW
Laser Light is different from any other light sources with which you may be familiar. The light
from this product can potentially cause eye injury if not set up and used properly. Laser light
is thousands of times more concentrated than light from any other kind of light source. This
concentration of light can cause instant eye injuries, primarily by burning the retina (the light
sensitive portion at the back of the eye). Even if you cannot feel “heat” from a laser beam, it
can still potentially injure or blind you or your audience. Even very small amounts of laser light
are potentially hazardous even at long distances. Laser eye injuries can happen quicker than
you can blink.
It is incorrect to think that because these laser entertainment products split the laser into
hundreds of beams that the laser beam is scanned out in high speed, that an individual laser
beam is safe for eye exposure. This laser product uses dozens of milliwatts of laser power
(Class 3B levels internally) before it splits into multiple beams (Class 3R levels). Many of the
individual beams are potentially hazardous to the eyes.
It is also incorrect to assume that because the laser light is moving, it is safe. This is not true.
Nor, do the laser beams always move. Since eye injuries can occur instantly, it is critical to
prevent the possibility of any direct eye exposure. In the laser safety regulation, it is not legal
to aim Class 3R lasers in areas which people can get exposed. This is true even if it is aimed
below people’s faces, such as on a dance floor.
Do not operate the laser without first reading and understanding all safety and technical
data in this manual.
Always set up and install all laser effects so that all laser light is at least 3 meters (9.8
feet) above the floor on which people can stand. See “Proper Usage” section later in this
manual.
After set up, and prior to public use, test laser to ensure proper function. Do not use if any
defect is detected. Do not use if laser emits only one or two laser beams rather than
dozens/hundreds, as this could indicate damage to the diffraction grating optic, and could
allow emission of higher laser levels above Class 3R.
Do not point lasers at people or animals.
Never look into the laser aperture or laser beams.
Do not point lasers in areas in which people can potentially get exposed, such as
uncontrolled balconies, etc.
Do not point lasers at highly reflective surfaces, such as windows, mirrors and shiny
metal. Even laser reflections can be hazardous.
Never point a laser at aircraft, this is a federal offense.
Never point un-terminated laser beams into the sky.
Do not expose the output optic (aperture) to cleaning chemicals.
Do not use laser if the laser appears to be emitting only one or two beams.
Do not use the laser if the housing is damaged, open, or if the optics appear damaged in
any way.
Never open the laser housing. The high laser power levels inside of the protective
housing can start fires, burn skin and will cause instant eye injury.
Never leave this device running unattended.
The operation of a class 3R laser show is only allowed if the show is controlled by a
skilled and well-trained operator, familiar with the data included in this manual.
The legal requirements for using laser entertainment products vary from country to
country. The user is responsible for the legal requirements at the location/country of use.
Always use appropriate lighting safety cables when hanging lights and effects overhead.

Scorpion™ Storm RGX User Manual 6 8/18/2011
Laser Safety Label Reproduction
LASER HAZARD WARNING LABEL
LASER APERTURE LABEL
EXPLANATORY, MANUFACTURER’S
ID & CERTIFICATION LABEL
NON INTERLOCKED HOUSING
LABEL

Scorpion™ Storm RGX User Manual 7 8/18/2011
Laser light - Avoid direct eye contact!
Further guidelines and safety programs for safe use of lasers can be found in the ANSI
Z136.1 Standard “For Safe Use of Lasers”, available from the Laser Institute of America:
www.laserinstitute.org. Many local governments, corporations, agencies, military and
others, require all lasers to be used under the guidelines of ANSI Z136.1. Laser Display
guidance can be obtained via the International Laser Display Association:
www.laserist.org.
Laser Emission Data
Laser Classification Class 3R
Green Laser Medium DPSS Nd:YVO4, 532nm
Red Laser Medium LD GaAlAs 650nm, typical
Beam Diameter <5mm at aperture
Pulse Data All pulses < 4Hz (>0.25sec)
Divergence (each beam) <2 mrad
Divergence (total light) <160 degrees
Laser Power of Each
Beam from Aperture* <5mW
* As measured under IEC measurement conditions for classification.
Laser Compliance Statement
This laser product complies with EN/IEC 60825-1 Ed 2, 2007-03, and US FDA/CDRH
FLPPS via the terms of Laser Notice No. 50 dated June 24, 2007. This laser device
is classified 3R. (Class 3R is the international equivalent of US Class IIIa). No
maintenance is required to keep this product in compliance with laser performance
standards.
LASER EXPOSURE

Scorpion™ Storm RGX User Manual 8 8/18/2011
2.INTRODUCTION
Product Overview
Power LED
Hanging
bracket
Bracket
adjustment
knob (1 of 2)
Audio LED
Laser Aperture

Scorpion™ Storm RGX User Manual 9 8/18/2011
Product Dimensions

Scorpion™ Storm RGX User Manual 10 8/18/2011
Hanging Clamp
Note!
Clamp is sold separatel
y
.
The fuse is located
inside this
compartment.
Remove using a flat
head screwdriver.
3.SETUP
AC Power
This product has an auto-switching power supply that can accommodate a wide range of input
voltages. The only thing necessary to do before powering on the unit is to make sure the line
voltage you are applying is within the range of accepted voltages. This product will accommodate
between 100V and 240V AC 50-60 Hz. All products must be powered directly off a switched circuit
and cannot be run off a rheostat (variable resistor) or dimmer circuit, even if the rheostat or dimmer
channel is used solely for a 0% to 100% switch.
Always connect the product to a switched circuit. Never connect the product to a rheostat
(variable resistor) or dimmer circuit, even if the rheostat or dimmer channel is used only as a 0 to
100% switch.
Fuse Replacement
With a flat head screwdriver, wedge the fuse holder
out of its housing. Remove the damaged fuse from
its holder and replace with exact same type fuse.
Insert the fuse holder back in its place and
reconnect power.
Disconnect the power cord before replacing a fuse and always replace with the same type fuse.
Mounting
Orientation This product may be mounted in any safe position, provided there is adequate room for ventilation.
Rigging It is important never to obstruct the fan or vents pathway. Mount the
product using, a suitable “C” or “O” type clamp. Adjust the angle of
the product by loosening both knobs and tilting the product. After finding the
desired position, retighten both knobs.
When selecting installation location, take into consideration
access and routine maintenance.
Safety cables must always be used.
Never mount in places where the product will be
exposed to rain, high humidity, extreme temperature
changes or restricted ventilation.

Scorpion™ Storm RGX User Manual 11 8/18/2011
Proper Usage
This product is for overhead mounting only. For safety purposes, CHAUVET®
recommends mounting your lighting effect products on steady elevated platforms or
sturdy overhead supports using suitable hanging clamps. In all cases, you must use
safety cables. You can obtain appropriate mounting hardware from your lighting
vendor.
International laser safety regulations require that laser products must be operated in
the fashion illustrated below, with a minimum of 3 meters (9.8 ft) of vertical separation
between the floor and the lowest laser light vertically. Additionally, 3 meters of
horizontal separation is required between laser light and audience or other public
spaces.
CAUTION - USE OF CONTROLS OR
A
DJUSTMENTS OR PERFORMANCE
OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT
IN HAZARDOUS RADIATION EXPOSURE

Scorpion™ Storm RGX User Manual 12 8/18/2011
Fixture Linking
You will need a serial data link to run light shows of one or more products using a DMX-512
controller or to run synchronized shows on two or more products set to a master/slave operating
mode. The combined number of channels required by all the products on a serial data link
determines the number of products the data link can support.
Fixtures on a serial data link must be daisy chained in one single line. To comply with the
EIA-485 standard no more than 32 fixtures should be connected on one data link.
Connecting more than 32 fixtures on one serial data link without the use of a DMX
optically-isolated splitter may result in deterioration of the digital DMX signal.
Maximum recommended serial data link distance: 500 meters (1640 ft.)
Maximum recommended number of products on a serial data link: 32 products
Data Cabling
To link products together you must obtain data cables. You can purchase CHAUVET-certified DMX
cables directly from a dealer/distributor or construct your own cable. If you choose to create your
own cable please use data-grade cables that can carry a high quality signal and are less prone to
electromagnetic interference.
DMX Data Cable
Use a Belden© 9841 or equivalent cable which meets the specifications for EIA RS-485
applications. Standard microphone cables cannot transmit DMX data reliably over long distances.
The cable will have the following characteristics:
2-conductor twisted pair plus a shield
Maximum capacitance between conductors – 30 pF/ft.
Maximum capacitance between conductor and shield – 55 pF/ft.
Maximum resistance of 20 ohms / 1000 ft.
Nominal impedance 100 – 140 ohms
Cable Connectors
Cabling must have a male XLR connector on one end and a female XLR connector on the other
end.
Do not allow contact between the common and the fixture’s chassis ground. Grounding
the common can cause a ground loop, and your fixture may perform erratically. Test
cables with an ohmmeter to verify correct polarity and to make sure the pins are not
grounded or shorted to the shield or each other.
COMMON
DMX
+
DMX -
INPUT OUTPUT
1
3
2
1
3
2
1
3
2
Resistance 120
ohm 1/4w between
pin 2 (DMX -) and
pin 3 (DMX +) of
the last product.
Termination reduces signal errors. To
avoid signal transmission problems
and interference, it is always
advisable to connect a DMX signal
terminator.
DMX connector configuration

Scorpion™ Storm RGX User Manual 13 8/18/2011
This drawing provides a
general illustration of the
DMX Input/Output panel
of a lighting product.
Universal DMX Controller
Continue the link
MasterSlaveSlave
Often, the setup for Master-Slave and
Standalone operation requires that the
first product in the chain be initialized
for this purpose via either settings in the
control panel or DIP-switches.
Secondarily, the products that follow
may also require a slave setting. Please
consult the “Operating Instructions”
section in this manual for complete
instructions for this type of setup and
configuration.
3-Pin to 5-Pin Conversion Chart
If you use a controller with a 5-pin DMX output connector, you will need to use a 5-pin to 3-
pin adapter. CHAUVET Model No: DMX5M, or DMX5F.
The chart below details a proper cable conversion.
3PIN TO 5PIN CONVERSION CHART
Conductor 3 Pin Female (output) 5 Pin Male (Input)
Ground/Shield Pin 1 Pin 1
Data ( - ) signal Pin 2 Pin 2
Data ( + ) signal Pin 3 Pin 3
Do not use Do not use
Do not use Do not use
Setting Up a DMS Serial Data Link
1. Connect the (male) 3 pin connector side of the DMX cable to the output (female) 3 pin connector of the
controller.
2. Connect the end of the cable coming from the controller
which will have a (female) 3 pin connector to the input
connector of the next product consisting of a (male) 3 pin
connector.
3. Then, proceed to connect from the output as stated
above to the input of the following product and so on.
CHAUVET Certified DMX Data Cables
Order Code Description
DMX1.5 DMX Cable 1.5m/4.9ft
DMX4.5 DMX Cable 4.5m/14.8ft
DMX10 DMX Cable 10m/32.8ft
Master/Slave Fixture Linking
1. Connect the (male) 3 pin connector side of the DMX
cable to the output (female) 3 pin connector of the first
product.
2. Connect the end of the cable coming from the first product which will have a (female) 3 pin connector to the
input connector of the next product consisting of a (male) 3 pin connector. Then, proceed to connect from
the output as stated above to the input of the following product and so on.

Scorpion™ Storm RGX User Manual 14 8/18/2011
4. OPERATING INSTRUCTIONS
Navigating the Control Panel
Access control panel functions using the four panel buttons located directly underneath the LED
Display.
The Control Panel LED Display shows the menu items you select from the menu map on page #.
When a menu function is selected, the display will show immediately the first available option for
the selected menu function. To select a menu item, press <ENTER>.
Use the <UP> and <DOWN> buttons to navigate the menu map and menu options. Press the
<ENTER> button to access the menu function currently displayed or to enable a menu option. To
return to the previous option or menu without changing the value, press the <MODE> button.
Menu Functions
MAIN FUNCTION SELECTION DESCRIPTION/VALUES
DMX mode 001 001 - 509 DMX starting address assignment
Stand-alone
modes
AFr Automatic fast (red)
ASr Automatic slow (red)
AFG Automatic fast (green)
ASG Automatic slow (green)
AFB Automatic fast (red & green)
ASB Automatic slow (red & green)
SrD Sound (red)
SGr Sound (green)
SrG Sound (red & green)
rDM Random
Slave SL
A
Slave mode
DMX Channel Summary
CHANNEL FUNCTION
1 Control Mode
2 Color selection
3 Strobe
4 Rotation
Button Function
<MODE> Used to access the menu or to return to
a previous menu option
<UP> Scrolls through menu options in
ascending order
<DOWN> Scrolls through menu options in
descending order
<ENTER> Used to select and store the current
menu or option within a menu
MODE UP DOWN ENTER

Scorpion™ Storm RGX User Manual 15 8/18/2011
DMX Channel Values
CHANNEL VALUE FUNCTION
1
000 019
020 039
040 059
060 079
080 099
100 119
120 139
140 159
160 179
180 199
200 255
Control Mode
DMX Mode
Automatic fast (red)
Automatic slow (red)
Automatic fast (green)
Automatic slow (green)
Automatic fast (red & green)
Automatic slow (red & green)
Sound (red)
Sound (green)
Sound (red & green)
Random
2
000 004
005 028
029 056
057 084
085 112
113 140
141 168
169 197
198 224
225 255
Color selection
Blackout
Red
Green
Red & Green
Green strobing
Red strobing
Red on & Green strobing
Green on & Red strobing
Red & Green strobing
Red & green (alternate strobing)
3
000 004
005 254
255 255
Strobe
No function
Strobe (slow fast)
Strobe to sound
4
000 004
005 127
128 133
134 255
Rotation
No rotation
Clockwise rotation (slow fast)
Stop
Counterclockwise rotation (slow fast)
Setting the Starting Address
This DMX mode enables the use of a universal DMX controller device. Each product requires a "start
address" from 1 to 512. A product requiring one or more channels for control begins to read the data on the
channel indicated by the start address. For example, a product that uses 6 DMX channels and was
addressed to start on DMX channel 100, would read data from channels: 100, 101, 102, 103, 104, and 105.
Choose start addresses so that the channels used do not overlap, and note the start address selected for
future reference.
If this is your first time addressing a product using the DMX-512 control protocol, we suggest jumping to the
Appendix Section and reading the heading “DMX Primer”. It contains very useful information that will help
you understand its use.

Scorpion™ Storm RGX User Manual 16 8/18/2011
General Troubleshooting
Symptom Solution(s)
Applies to
Lights Foggers & Snow Controllers Dimmers & Chaser
Auto shut off Check fan thermal switch reset 
Beam is very dim or
not bright Clean optical system or replace lamp Check 220/110v switch for proper setting 
Breaker/Fuse keeps
blowing Check total load placed on device 
Chase is too slow Check users manual for speed adjustment 
Device has no power Check for power on Mains.
Check device’s fuse. (internal and/or external) 
Fixture is not
responding Check DMX Dip switch settings for correct addressing Check DMX cables
Check polarity switch settings

Fixture is on but
there is no
movement to the
audio
Make sure you have the correct audio mode on the
control switches. If audio provided via ¼” jack, make
sure a live audio signal exists
Adjust sound sensitivity knob
 
Light will not come
on after power failure Some discharge lamps require a cooling off period before the electronics in the product can kick start it
again, wait 5 to 10 minutes before powering up

Loss of signal Use only DMX cables
Install terminator
Note: Keep DMX cables separated from power cables
or black lights.

Moves slow Check 220/110v switch for proper setting 
No flash Re-install bulb, may have shifted in shipping 
No laser output Bounce mirror motor may have shifted during shipping,
readjust 
If you still have a problem after trying the above solutions, please contact CHAUVET Technical Support.
Technical Support
Address: Service Dept.
5200 NW 108th Avenue, Sunrise, FL 33351 (U.S.A.)
Support (Email): [email protected]om
Telephone: [phone] - (Press 4)
Fax: [phone] (Attention: Service)
Website: http://www.chauvetlighting.com

Scorpion™ Storm RGX User Manual 17 8/18/2011
5.APPENDIX
DMX Primer
There are 512 channels in a DMX-512 connection. Channels may be assigned in any manner. A
product capable of receiving DMX 512 will require one or a number of sequential channels. The
user must assign a starting address on the product that indicates the first channel reserved in the
controller. There are many different types of DMX controllable products and they all may vary in the
total number of channels required. Choosing a start address should be planned in advance.
Channels should never overlap. If they do, this will result in erratic operation of the products whose
starting address is set incorrectly. You can however, control multiple products of the same type
using the same starting address as long as the intended result is that of unison movement or
operation. In other words, the products will be slaved together and all respond exactly the same.
DMX products are designed to receive data through a serial Daisy Chain. A Daisy Chain
connection is where the DATA OUT of one product connects to the DATA IN of the next product.
The order in which the products are connected is not important and has no effect on how a
controller communicates to each product. Use an order that provides for the easiest and most
direct cabling. Connect products using shielded two conductor twisted pair cable with three pin XLR
male to female connectors. The shield connection is pin 1, while pin 2 is Data Negative (S-) and pin
3 is Data positive (S+). CHAUVET carries 3-pin XLR DMX compliant cables, DMX-10 (33’), DMX-
4.5 (15’) and DMX-1.5 (5’)
Returns Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be
issued. Package must be clearly labeled with a Return Merchandise Authorization Number (RMA
#). Products returned without an RMA # will be refused. Call CHAUVET and request RMA # prior to
shipping the product. Be prepared to provide the model number, serial number and a brief
description of the cause for the return. Be sure to properly pack product, any shipping damage
resulting from inadequate packaging is the customer’s responsibility. CHAUVET reserves the right
to use its own discretion to repair or replace product(s). As a suggestion, proper UPS packing or
double-boxing is always a safe method to use.
If you are given an RMA #, please include the following information on a piece of paper
inside the box:
Your name
Your address
Your phone number
The RMA #
A brief description of the symptoms

Scorpion™ Storm RGX User Manual 18 8/18/2011
Technical Specifications
WEIGHT & DIMENSIONS
Length..............................................................................................................................11 in (276 mm)
Width .............................................................................................................................. 9.3 in (235 mm)
Height.............................................................................................................................8.5 in (216 mm)
Weight ..............................................................................................................................4.6 lbs (2.1 kg)
POWER
Autoswitching ........................................................................................................100-240VAC 50/60Hz
Fuse........................................................................................................................1.5A 250V slow-blow
Power Consumption........................................................................................ 11W (0.1A) max @ 120V
Inrush Power ......................................................................................................................0.4A @ 120V
Power Output.........................................................................................................75 units max @ 120V
LASER
Green diode......................................................................................................................532 nm 30mW
Red Diode.........................................................................................................................650 nm 80mW
Laser Type......................................................................................................................................DPSS
Cooling ..................................................................................................................................Fan Cooled
RANGE
Coverage Angle................................................................................................................................114°
THERMAL
Maximum ambient temperature.......................................................................................... 104°F (40°C)
CONTROL & PROGRAMMING
Data input................................................................................................locking 3-pin XLR male socket
Data output...........................................................................................locking 3-pin XLR female socket
Data pin configuration...............................................................................pin 1 shield, pin 2 (-), pin 3 (+)
Protocols........................................................................................................................DMX-512 USITT
DMX Channels .......................................................................................................................................4
ORDERING INFORMATION
Scorpion™ Storm RGX ....................................................................................SCORPIONSTORMRGX
WARRANTY INFORMATION
Warranty..............................................................................................................2-year limited warranty
