Cima Plus 42 Troubleshooting guide

OPERATION AND
MAINTENANCE INSTRUCTIONS
R
PLUS
atomizzatori e impolveratori
Babsbfhngkdlkdm,skhgfhdgdddgdg
sfdmkhkygulhdgdgdgdgdgdddj
tfykfygvjyl,,j,.ffgddddgdgdgt
Babsbfhngkdlkdm,sk
sfdmkhkygulhj
tfykfygvjyl,,j,.ffgdddt
Babsbfhngkdlkdm,sk
sfdmkhkygulhj
tfykfygvjyl,,j,.ffgdddt
Babsbfhngkdlkdm,sk
Babsbfhngkdlkdm,sk
Babsbfhngkdlkdm,sk

Dear Customer, thank you very much!
We want to congratulate with you, for having
®
chosen a sprayer.
Your choice shows the wisdom of the well-informed
Purchaser, aware of the fact, that the required
features of quality, technique and reliability must
be satisfied at the right price!
Our continuous engagement in R&D and in testing
our machines allows us to realize products able to
offer the best performances, a high reliability and
a great easiness of use at the same time !
Our first goal, is to get our Customers happy for
having met us!
The “Spare parts catalogue” of this sprayer/sprayhead is
available in the ‘“restricted area” on website www.cima.it.
In order to accede, use:
User name: sprayer
Password: 844719KE

LOW- VOLUME
SPRAYING ATOMISER CARRIED
27040 Montù Beccaria - Loc. Molino Quaroni - (PV) - ITALIA
Tel. [phone] r.a. - Fax [phone]
http://www.cimaitalia.com
S.p.A.
OPERATING AND
MAINTENANCE INSTRUCTIONS
Plus 42-45
Plus 50-55-55S-55E
Serial Number: ...................................................

III
Plus 42 - 45 - 50 - 55 - 55S - 55E 11-2000
LISTING OF VALID PAGES
This publication consists of 59 pages, subdivided as follows:
N° OF PAGE REVISION BASE
from I to VI 01 November 2000
from 1 to 53 01 November 2000
ADDITIONAL RECORDS AND VARIANTS
REVISION DESCRIPTION
00 First Edition, June 2000
01 Second Edition, November 2000
02
03
04
05
06
07
08

IV
Plus 42 - 45 - 50 - 55 - 55S - 55E 11-2000
GENERAL INDEX
1 FOREWORD .......................................................................................................................... 1
1.1 PUBLICATION IDENTIFICATION......................................................................................... 1
1.2 CONNECTED PUBLICATIONS ............................................................................................ 1
1.3 PURPOSE OF PUBLICATION .............................................................................................. 1
1.4 REFERENCE TO REGULATIONS ....................................................................................... 1
1.5 USING THE MANUAL ............................................................................................................1
1.6 UPDATES ...............................................................................................................................2
2 GLOSSARY ........................................................................................................................... 3
2.1 TERMINOLOGY .................................................................................................................... 3
2.2 UNITS OF MEASURE - CODES ........................................................................................... 3
2.3 DECALS .................................................................................................................................. 3
3 GENERAL NOTES ................................................................................................................ 7
3.1 MACHINE IDENTIFICATION ................................................................................................ 7
3.2 TECHNICAL ASSISTANCE ................................................................................................... 7
3.3 SAFETY INSTRUCTIONS ..................................................................................................... 7
3.4 SAFETY SYSTEMS ................................................................................................................ 8
3.5 MANAGING AGRO-CHEMICALS ......................................................................................... 9
3.5.1 STORAGE .............................................................................................................................. 9
3.5.2 SPECIFIC TOOLS ................................................................................................................. 9
3.5.3 DISPOSAL OF EMPTY CONTAINERS AND AGRO-CHEMICAL RESIDUES ................... 9
3.5.4 PERSONAL MEANS OF PROTECTION ............................................................................ 10
4 MACHINE STRUCTURAL ANALYSIS .............................................................................. 11
4.1 FRAME ................................................................................................................................. 12
4.2 SERVO-AMPLIFIER - FAN .................................................................................................. 13
4.3 HYDRAULIC CIRCUIT COMPONENTS ............................................................................. 14
4.4 TECHNICAL DATA ..............................................................................................................21
4.4.1 Dimensions and weights of the spray atomisers ................................................................ 21
4.4.2 Technical specifications of fans - pump .............................................................................. 21
5 COUPLING MODALITIES .................................................................................................. 23
5.1 CONNECTION TO THE TRACTOR .................................................................................. 23
5.2 TRANSMISSION SHAFT ASSEMBLING ............................................................................ 24
5.3 INSTALLATION OF REMOTE CONTROLS ...................................................................... 24
5.3.1 Manual 2-tap distributor - P10 .............................................................................................. 24

V
Plus 42 - 45 - 50 - 55 - 55S - 55E 11-2000
5.3.2 Electrical control panel - E10 ............................................................................................... 25
6 DISTRIBUTION DEVICES .................................................................................................. 26
6. IDENTIFICATION TYPES AND CODES ............................................................................ 26
6.2 POSITIONING OF FAN-GUARD ........................................................................................ 27
6.3 DISTRIBUTION DEVICES ELBOW FITTINGS .................................................................. 27
7 ACCESSORIES .................................................................................................................... 28
7.1 FILLER PIPE ......................................................................................................................... 28
7.2 PAIR OF WHEELS ............................................................................................................... 28
7.3 CRANK-CONTROLLED REVOLVING DEVICE ................................................................. 29
7.4 ELECTRICALLY-CONTROLLED REVOLVING DEVICE .................................................. 29
8 FILLING MODALITY ........................................................................................................... 30
8.1 FOREWORD – USE OF THE FAN RELEASE ................................................................... 30
8.1.a Fan release ........................................................................................................................... 30
8.1.b Fan engagement to start the treatment ............................................................................... 31
8.2 FILLING THROUGH POURING FROM THE TOP ........................................................... 31
8.3 FILLING THROUGH THE SPECIFIC PIPE ........................................................................ 32
9 SHAKING OF MIXTURE ..................................................................................................... 35
10 HYDRAULIC CIRCUIT DISCHARGING ............................................................................ 36
11 OPERATING PROCEDURES ............................................................................................. 36
11.1 PRELIMINARY OPERATIONS TO TREATMENT .............................................................. 36
11.2 PREPARATORY OPERATIONS TO TREATMENT ........................................................... 36
11.3 THE TREATMENT ............................................................................................................... 38
11.4 END OF TREATMENT - STORAGE .................................................................................. 38
11.4.1 Daily ...................................................................................................................................... 38
11.4.2 End of seasonal cycle .......................................................................................................... 39
12 LIFTING AND TRANSPORT .............................................................................................. 40
13 MAINTENANCE OPERATIONS ......................................................................................... 41
13.1 LUBRICATION ..................................................................................................................... 41
13.2 CLEANING OF FILTER CARTRIDGE ................................................................................ 42
13.3 PURGING OF RESIDUES FROM FILTER ........................................................................ 42
13.4 CLEANING OF THE FAN .................................................................................................... 42
13.5 FAN BELT TENSIONER ...................................................................................................... 43

VI
Plus 42 - 45 - 50 - 55 - 55S - 55E 11-2000
13.6 PUMP BELT TENSIONER ................................................................................................... 43
13.7 TANK REMOVAL OR REPLACEMENT .............................................................................. 44
13.8 TABLE OF MAINTENANCE OPERATIONS ....................................................................... 45
14 FAULT FINDING ................................................................................................................. 46
15 REPAIRS ALLOWED .......................................................................................................... 48
15.1 ASSEMBLING OF PUMP CONTROL BELT ....................................................................... 48
15.2 REPLACEMENT OF ELECTRICAL PANEL FUSES .......................................................... 49
16 INTEGRATIVE DIAGRAMS ................................................................................................ 50
16.1 HYDRO-PNEUMATIC DIAGRAM ....................................................................................... 50
16.2 ELECTRICAL CONNECTIONS ........................................................................................... 51
17 AERIAL NOISE .................................................................................................................... 52
18 WARRANTY ......................................................................................................................... 52
19 ATTACHMENT : COMPLIANCE DECLARATION ........................................................... 53

1
Plus 42 - 45 - 50 - 55 - 55S - 55E 11-2000
1 FOREWORD 1
1.1 - PUBLICATION IDENTIFICATION
The “OPERATIVE INSTRUCTIONS AND MAINTENANCE” manual is an integral part of the spray atomiser.
It is identified by a Publication No. located on the third cover page, and through which the document
can be identified, traced and/or subsequently referred to.
The information elements contained herein are updated as at the date of publication. C.I.M.A. S.p.A.
reserves the right to modify its machines without notice, with the purpose of applying technical
enhancements, and it declines all responsibility for possible omissions from the publication.
1.2 - ATTACHED PUBLICATIONS
— Spare parts catalogue;
— Distribution devices, “Operative and maintenance instructions” for
— Distribution devices, “Spare parts catalogue”
— “Low Volume” Machine adjustment instructions”
— “Modalities for filling through the specific pipe” diagram
— “Modalities for filling through pouring from the top” diagram
1.3 - PURPOSE OF PUBLICATION
All indications contained in this manual are aimed at the user of the spray atomiser.
The duration of the machine and its operation, the operator’s safety and the respect for the environment
are dependent upon scrupulous observance of the stated norms.
Before making use of the spray atomiser, the user must read, understand and abide by all regulations
listed in this manual.
1.4 - REFERENCE TO REGULATIONS
This manual was set out conforming to the regulations contained in:
— Attachment “I” to Directive 89/392/C and subsequent modifications (letters “b”, “c” of point 1.1.2
and point 1.7.4);
— UNI EN 292/2 - 1992, point 5.5;
— UNI EN 907 - 1997.
1.5 - USING THE MANUAL
Read every part of this manual, paying attention to the meaning of the WARNING and of DANGER
indications contained in the text and displayed on the signs applied to the machine or on the parts that
make it up. All operations suggested by the manual will have to be followed with the utmost care and
only after having understood the negative consequences of their wrong interpretation and execution.
The following “symbols “ are utilised within the text in order to highlight and visually identify the

2
Plus 42 - 45 - 50 - 55 - 55S - 55E 11-2000
importance of the various types of information:
Indicates important complementary information
The non observance of the relative indications can cause damage of an even irreparable nature
to the spray atomiser.
Highlights possibly dangerous situations to persons.
The manual, with relevant attachment and possible integrating issues, must be kept with the utmost
care and must always be complete, integer and legible in every part. Should it be mislaid it is imperative
to immediately request a duplicate from C.I.M.A. S.p.A. Should the decals originally applied on the
machine be mislaid, damaged or become incomprehensible, they should be
promptly replaced.
For every type of distribution device (Head) delivered with the spray atomiser, a specific user and
maintenance manual is attached. All the head manuals must always accompany the one of the machine.
- The manual must always be kept for the spray atomiser’s whole operational life.
- Any modification received must be permanently inserted in this publication.
- The manual must be ceded with the spray atomiser should this be sold.
1.6 - UPDATES
Possible updates that C.I.M.A. S.p.A. will provide the owner of the spray atomiser will be accompanied
by instructions to insert them in this publication.
Should the machine be sold, the owner must inform the new purchaser that he should notify C.I.M.A
S.p.A. of his address in order to receive possible future integrating issues and/or updates.
2 GLOSSARY 2

3
Plus 42 - 45 - 50 - 55 - 55S - 55E 11-2000
2.1 - TERMINOLOGY
The terms FRONT, REAR, RIGHT and LEFT utilised in this publication refer to the spray atomiser as seen
by an operator from behind the operative unit along the drive line and facing it: the rear part of the
machine is that closest to the operator, and is where the distribution device (Head) is mounted - and
the front part is the one that gets attached to the tractor.
2.2 - ABBREVIATIONS
g.................................................................................................................................................. grams
g/1'.............................................................................................................................. revs per minute
h.................................................................................................................................................... hour
ha............................................................................................................................................. hectare
ha/h .......................................................................................................................... hectare per hour
l..................................................................................................................................................... litres
l/h ................................................................................................................................... litres per hour
l/ha ............................................................................................................................ litres per hectare
kg ............................................................................................................................................ kilogram
kg/cm2..................................................................... kilograms per square centimetre (atmosphere)
km.......................................................................................................................................... kilometre
km/h .................................................................................................................... kilometres per hour
Lm............................................................................................................................... width in metres
m................................................................................................................................................. metre
Mesh .................................................................................................... N° of meshes per linear inch
Micron ................................................................................................................. 1/1000 of millimetre
PTO .............................................................................................................................. power take-off
s.............................................................................................................................................. seconds
2.3 - DECALS
The decals relative to the safety and the use/maintenance of the machine are applied to the machine
and their meaning is described in the following paragraph.
Every decal is marked with its identification code, to be used for the necessary purchasing.
Safety
1 - 95001 - STOP THE ENGINE AND REMOVE THE KEY FROM THE TRACTOR’S CONTROL PANEL
BEFORE CARRYING OUT ALL MAINTENANCE OR REPAIR OPERATIONS
-Positioned on the left-hand side of the tank in the forward part of the machine.
2 - 95004 - DANGER OF CONTAMINATION BY CONTACT OR POISONOUS PRODUCTS INHALA-
TION
- Positioned above the tank, in the forward part, next to the filler spout.
3 - 95005 - DANGER, PARTS IN MOTION. BEFORE REMOVING PROTECTION GUARDS, STOP
THE TRACTOR, REMOVE THE KEY FROM THE TRACTOR’S CONTROL PANEL AND
ENSURE THAT ALL MOVING PARTS HAVE STOPPED

4
Plus 42 - 45 - 50 - 55 - 55S - 55E 11-2000
- Positioned on the fan casing next to the outflow vent.
4 - 95015 - BEFORE UTILISING THE RELEASE DEVICE, STOP THE TRACTOR, REMOVE THE KEY
FROM THE TRACTOR’S CONTROL PANEL AND ENSURE THAT THE FAN HAS
STOPPED
- Positioned on the tank in the forward part of the machine, on the mobile protection cover
of the access to the release device.
5 -95010 - MAXIMUM OPERATING SPEED OF THE DRIVE OUTLET (P.d.P): 540 REVS A MINUTE
- Positioned on the forward part of the machine, on the lower part of the tank and close
to the drive outlet.
6 - 95007 - DANGER OF SPRAYS: KEEP AT A SAFE DISTANCE
- Positioned on the upper part of the fan casing.
7 - 95006 - WARNING: CONSULT THE USER AND MAINTENANCE MANUAL BEFORE USING OR
INTERVENING ON THE MACHINE
-Positioned on the left-hand side of the tank, in the forward part of the machine.
8 - 95009 - DANGER: GLOVES MUST BE USED TO EMPTY THE TANK
- Positioned on the right hand side and lower part of the tank.
9 - 95012 - DANGER: MOUNT THE WHEELS AFTER HAVING HITCHED THE MACHINE TO THE
HOISTER AND DISMANTLE THEM BEFORE UNHITCHING THE MACHINE FROM THE
HOISTER
- Positioned on the right hand side and lower part of the tank.
Utilisation and maintenance
10 - 95059 - HOOKING POINT FOR THE LIFTING OF THE MACHINE
-Positioned on the frame, above the fan’s casing.
11 - 95052 - GREASE EVERY 20 HOURS: FAN SHAFT BEARINGS
- Positioned on the rear of the frame, in the lower left-hand part.
12 - 95053 - GREASE EVERY 50 HOURS: FAN BELT-TENSIONER SUPPORT
- Positioned on the rear of the frame, in the lower left-hand part.
13 - 95054 - GREASE EVERY 200 HOURS: FREE WHEEL AND WHEEL HUBS
- Positioned on the front lower part of the tank, next to the power take-off (PTO.).
- Positioned on the wheel (accessory).
14 - 95067 - OIL EVERY 50 HOURS: PUMP BEARINGS
- Positioned on the left-hand side of the machine, on the frame, behind the pump.
15 - 95057 - HAND WASHING TANK TAP
- Positioned on the right-hand side of the tank, next to the tap.
16 - 95065 - WARNING: NEVER OPERATE THE SPRAY ATOMISER WITHOUT LIQUID IN THE TANK
- Positioned on the forward part of the tank, above the gauge.
17 - 95069 - INDICATIONS FOR THE USE AND MAINTENANCE OF THE SOLENOID VALVES
- Positioned on the tank, on the side of the electrical distributor.
18 - 95060 - INDICATION OF THE WHEELS OPERATING PRESSURE (ACCESSORY)
95056 - Positioned on the wheel (accessory).
19 - 95058 - INDICATION ON THE OPERATION OF THE 3-WAY TAP (P5)
- Positioned on the left-hand side of the tank, above the pump..
Positioning of the safety, utilisation and maintenance decals
* Safety decals

5
Plus 42 - 45 - 50 - 55 - 55S - 55E 11-2000
* Operation and maintenance decals
00129
17
8
00184
3
6
00128
00011
350
300
250
200
150
100
50
6
15
12
10
2
6
19
10
14 11
13
16
5
13
7
1
4
00130
18
OPTONAL

6
Plus 42 - 45 - 50 - 55 - 55S - 55E 11-2000
3 GENERAL INFORMATION 3
1 95001
00042
2 95004 3 95005
00043
00044
4 95015 5 95010 6 95007 7 95006
8 95009 9 95012
00045 00046 00047 00048
00049
00050
11 95052 12 95053 13 95054
14 95076
15 95057 16 95065 17 95069
18 95056
18 95060
10 95059
00062
00063 00064
0006500068
00069
00067
00127
2,50 atm
3,30 atm
A
POSIZIONE LAVORO
WORK POSITION
POSITION DU TRAVAIL
POSICION DE TRABAJO
MANUTENZIONE FILTRO
FILTER MAINTENANCE
COMPLAINTE DU FILTRE
MANTENIM. DEL FILTRO
COLLEGAMENTO / SCOLLEGAMENTO TUBO RIEMP .
CONNECTION / DISCONNECTION FILLING PIPE
CONNEXION / DECONNEXION TUYAU DE REMPL.
CONEXION / DESCONEXION TUBO DE CARGA
C
MISCELAZIONE POLVERI
POWDER M IXING
MEZCLA DE LOS POLVOS
MELANGE DE LA POUDRE
BD
95058
19 95058

7
Plus 42 - 45 - 50 - 55 - 55S - 55E 11-2000
3.1 - IDENTIFICATION OF THE MACHINE
3.2 - TECHNICAL ASSISTANCE
C.I.M.A. S.p.A. is at the complete disposal of customers for any type of intervention. The names and
addresses of its service network, both in Italy and in foreign countries, can be requested from:
C.I.M.A. S.p.A. - 27040 Montù Beccaria - Loc. Molino Quaroni (PV) - ITALIA
tel. [phone] - fax [phone]
dall'estero tel. [phone] - fax [phone]
e.mail [email protected]
3.3 - SAFETY NOTICES
All the preparation, utilisation, maintenance, moving and transporting operations must be carried out
only after having acquired a perfect knowledge of the regulations contained in this publication and the
ability to appropriately interpret the symbols of the decals applied to the machine.
IT IS FORBIDDEN TO UTILISE THE SPRAY ATOMISER FOR PURPOSES OTHER THAN FOR
ITS INTENDED USE, SINCE IT WAS MANUFACTURED ONLY FOR DUSTING AGRICULTURAL
CROPS WITH ANTI-PARASITIC PRODUCTS.
It is necessary to scrupulously abide by the following general norms:
— always stop the tractor’s engine before carrying out any operation on the spray atomiser;
— check that the weight and power of the tractor are compatible with the spray atomiser to be
deployed;
— before utilisation, check the correct tightening and securing of the machine’s various components,
paying particular attention to the safety protections and to the moving parts;
— only utilise protected drive couplings provided with CE conformity certification.
Carry out the assembly only if the drive outlets of both tractor and spray atomiser are equipped
with the protection counter-guard;
— check that the drive coupling is blocked by the appropriate anti-rotation chains;
— keep people and animals away from the machine before starting it up;
— don’t wear articles of clothing that might get caught in moving parts;
— keep to a low speed while negotiating humps or crossing ditches.
00128
00070 Identification nameplate

8
Plus 42 - 45 - 50 - 55 - 55S - 55E 11-2000
- All maintenance and repair operations must be carried out only after having
washed the hydraulic circuit with clean water.
- Before operating within the tank it is necessary to wash it thoroughly with clean
water.
- It is forbidden to perform welding operations if ammonium salts were previously
used.
- It is forbidden to use the machine within a potentially explosive environment.
-The application of paints and/or solvents, the washing of closed environments
and machinery as well as the utilisation of the air flow for purposes other than
those expressly concerning the spraying of agro-chemicalsare not permitted.
- It is forbidden to enter the tank.
3.4 - SAFETY SYSTEMS
All machine moving parts are suitably protected by guards and highlighted through the use of warning
decals.
- It is forbidden to use the machine with these guards removed.
- Before removing the protection, stop the tractor’s engine and remove the key
from the control panel.
The Pictures illustrate the machine’s guarded parts:
:
THE OWNER AND/OR THE OPERATOR OF THE SPRAY ATOMISER ARE NOT PERMITTED
TO MODIFY THE STRUCTURE OR THE SPECIFIC OPERATION OF THE SPRAY ATOMISER
ITSELF. ANY INTERVENTION NOT SPECIFICALLY AUTHORISED BY C.I.M.A. S.p.A.
IMMEDIATELY VOIDS ANY KIND OF WARRANTY AND CLEARS C.I.M.A. S.p.A. OF ANY
CONSEQUENT AND/OR IMPLIED RESPONSIBILITY.
350
300
250
200
150
100
50
REMOVABLE PROTECTION COVER
FOR THE FAN
SWITCHING-OFF DEVICE
FAN
PROTECTION
GRILL
00130
00131

9
Plus 42 - 45 - 50 - 55 - 55S - 55E 11-2000
3.5 - HANDLING OF AGRO-CHEMICALS
The operator could become contaminated due to accidental sprays, contact or inhalation of products
or crop-dusting mixtures.
The environment could become polluted by mixture over-spills, puncturing of containers, uncon-
trolled storage of used and unwashed containers or spillage into waterworks.
In order to avoid these risks the preparation and filling operations must be carried out in suitably
appointed and adequately equipped sites.
3.5.1 - Storage
Fixed / stationary: the site used must be well ventilated and secured by lockable doors in order to
prevent even accidental access by children or unauthorised persons.
Mobile: the carrier equipment must be properly lockable and kept under conditions whereby access
by children or unauthorised persons can be prevented during the absence of the operator. All full or
partially utilised containers must be secured against tipping, falling or breakage during transportation.
Both types of storage must:
— have a suitable container for the storing of empty packaging materials should a specific storage
area not be available;
— have a clean water supply readily available for washing, by means of a specific container or
through connection to the waterworks system;
— have the use of fire extinguishers, should flammable products and substances be stored..
- All packages, whether whole or partially utilised, must be stored in their original
packing and with the warning instructions clearly displayed and legible.
- The storage indications must always be scrupulously adhered to, as well as their
utilisation and possible disposal as suggested on the product’s original packag-
ing.
3.5.2 - Specific equipment
The site at which the preparation and filling out will take place must provide for:
— all the equipment necessary to the precise measuring of both the water quantity and the dose of
product to be mixed in the tank at every filling;
— all the equipment and means useful to the preparation of the mixture and for the cleaning of the
operator in case of contamination;
— all tools necessary to facilitate the direct introduction of the agro-chemicals in the tank;
— the allocation of clothing and specific equipment in order to avoid contamination by contact or
inhalation during the whole operative phase of the intervention;
— the availability of proper equipment able to stop the uncontrolled spilling and flowing of the mixture;
— a retaining valve on the feed pipe when the filling of the tank takes place directly from the
waterworks system.
3.5.3 - Disposal of empty containers and agro-chemicals residues
Agro-chemicals are classified as “special” waste and their disposal must take place separately from
“urban” wastes.

10
Plus 42 - 45 - 50 - 55 - 55S - 55E 11-2000
Empty packaging and contaminated containers to be done away with cannot be
dispersed, burned or buried.
The washing water for the cisterns and the tools utilised for the preparation of
mixtures cannot be emptied on the ground, spilled into the sewerage system or
in water courses and rivers.
The disposal of special wastes is regulated by specific norms. In order to perform this operation it is
necessary to obtain the relevant information from the Local Offices specifically appointed to rule on
this subject. The non compliance with these regulations can cause considerable damage to persons
and animals as well as polluting the environment.
3.5.4 - Personal means of protection
The toxicity of agro-chemicals forces persons working with them to wear adequate protective clothing
and accessories in order to avoid risks of contamination by contact or inhalation.
In each of the following work stages:
— filling of tanks and adding of the agro-chemical,
— dusting and spraying,
— adjusting of the spray atomiser,
— emptying and cleaning of the tank,
— replacement of the agro-chemical,
— maintenance interventions,
it is necessary to wear personal protection clothing and accessories.
The following must be worn:
— Polyethylene or polyvinyl gloves.
— Full, waterproof cotton overalls, in order to
guarantee transpiration, fitted with polypro-
pylene side flaps.
In commerce, one-time ‘tyvek’ overalls are
available which, after use (see Picture), must
be disposed of according to the modalities
applicable to toxic waste.
— A protective half-mask in polychloroprene
rubber with 1 or 2 filters. Filters for gasses
and organic fumes, of European A1-class
vapours, are envisaged and these can be
combined with anti-dust models of P1 Euro-
pean class, for harmful mists and powders,
or P2, for harmful and toxic mists and pow-
ders.
The filters must be replaced:
- when the smell/taste of agro-chemicals can be detected, and that of active A1-
class carbons;
- when difficulty in breathing is experienced for the anti-dust filters of class P1 and
P2.
In any case it is necessary to make use of all personal means of protection as
suggested by the manufacturers.
00073

11
Plus 42 - 45 - 50 - 55 - 55S - 55E 11-2000
4 MACHINE’S STRUCTURAL ANALYSIS 4
The pictures indicate the position of the main components of the spray atomiser.
CENTRIFUGAL
FAN
TANK DISTRIBUTION
DEVICE
(HEAD)
JOINING
ELBOW
ROTATING DISC
REGULATOR
MAIN FILLER (BP)
FRAME HEAD
PROTECTION
RING
00129
PUMP
00132
DELIVERY
FILTER

12
Plus 42 - 45 - 50 - 55 - 55S - 55E 11-2000
350
300
250
200
150
100
50
50 Plus
2000
2000
4.1 - FRAME
Frames of series Plus 42 and 45 can be coupled to category “1” hydraulic hoists.
The plugs diameter is 22 mm. The diameter of the third-point plug is 19 mm.
Frames of series Plus 50, 55, 55S and 55E can be coupled to category “2” hydraulic hoists.
The plugs diameter is 28.5 mm. The diameter of the third-point plug is 25 mm.
In order to limit the shifting of the centre of gravity and to implement a functional
coupling, ALL frames allow for the double positioning of plugs
— The tank-securing bracket is mounted by means of 2 screws on the front, below the 3rd point.
— A tie-rod through the tank’s upper tunnel connects the front part of the frame to the rear. This must
be dismantled should the tank be removed and it must be repositioned after having re-assembled
the tank.
This operation is carried out from the front, below the 3rd point connection, by means of a spanner
supplied with the machine.
— In the forward part, below the 3rd point connection, the removable protection cover of the fan
release device is secured by means of a screw.
The application of a ring onto the frames in order to protect the distribution devices is envisaged. This
must be mounted in the most effective position, according to the operating conditions and in keeping
with the type of heads utilised.
A chain with hooks, fixed to the front part of the frame, allows the support of the transmission joint
when the machine is coupled to the tractor.
All frames are pre-set with axles for the application, on request, of a pair of wheels (please refer to
the installation accessories for the assembly, Paragraph 7.2).
HAND WASHING TANK
(incorporated with the tank)
LEVEL
INDICATOR
GAUGE
PLUNGER
TAP
POWER TAKE-OFF
(PTO)
00133
SECONDARY
FILLER (BS)
CONNECTION
TIE ROD
TANK
DRAINAGE
TAP
MAIN FILLER (BP)
HAND WASHING
TANK TAP
PRESSURE
REGULATOR
MANUAL
DISTRIBUTOR
