ank you for purchasing a CITIZEN watch. To ensure correct use, please read these instructions carefully.
Please conrm that the CITIZEN International Guarantee Card is included for your possible claim.
Vielen Dank für den Kauf dieser CITIZEN Uhr. Bitte lesen Sie diese Anleitung durch, um mit den
Funktionen dieser Uhr vertraut zu werden. Überprüfen Sie bitte in Ihrem eigenen Interesse, ob der Uhr
die internationale CITIZEN Garantiekarte beigelegt ist.
Nous vous remercions d’avoir porté votre choix sur une montre CITIZEN. Pour assurer une utilisation
correcte, veuillez lire les instructions attentivement. Veuillez vous assurer que la carte de garantie
internationale CITIZEN est fournie pour toute réclamation éventuelle.
Muchas gracias por la compra de este reloj CITIZEN. Para asegurar un uso correcto, lea detenidamente
estas instrucciones. Verique de que la tarjeta de Garantía Internacional de CITIZEN le sea suministrada
con el reloj en el momento de la compra, de esta manera, podrá reclamar servicios de acuerdo con los
términos de garantía.
Grazie per aver scelto un orologio CITIZEN. Per la sicurezza di un uso corretto, si prega di leggere
attentamente le istruzioni. Inoltre abbiate la cortesia di assicurarvi che la carta di garanzia internazionale
CITIZEN sia inclusa in caso di un eventuale reclamo.
Muito obrigado por adquirir um relógio CITIZEN. Para garantir uma utilização correcta, por favor leia
estas instruções atentamente Conrme também se o Cartão Internacional de Garantia da CITIZEN
acompanha o relógio. Ele será necessário no caso de uma possível reclamação.
承蒙購買CITIZEN錶，為確保正確的使用，敬請仔細閱讀此使用指南。請確認同附的CITIZEN國際保證卡，以
享受免費修理之權利。
承蒙惠购CITIZEN表，谨致谢意。为确保正确使用，敬请仔细阅读此使用指南。请确认随附的CITIZEN国际保证
卡，以享受免费修理的权利。
このたびは、シチズンウオッチをお買い上げいただきましてありがとうございます。この取扱説明書をよくお読みの上、
正しくお使いくださいますようお願い申し上げます。また、万一故障した場合に必要な国際保証書が同梱されていることを
ご確認いただきますようお願い申し上げます。

3
English
The movement number of this watch is “8712”.
Thank you for your purchase of this Citizen watch.
Before using the watch, read this instruction manual carefully to ensure
correct use.
After reading, be sure to store this manual in a safe place should it be
needed for future reference.
✳The case has different features depending on the model.
Details of model specific features may not be outlined in this manual. See
“ http://www.citizenwatch.jp ”.

4
5
English
■ Important instructions are categorized and depicted in this manual as follows:This manual may contain certain safety advisories. Your watch should be used
in accordance with these advisories at all times to ensure optimal enjoyment of
your watch and to prevent injury to yourself, other persons and/or damage to
property.
■ Safety advisories are categorized and depicted in this manual as follows:
Highly likely to cause death or serious injury
May cause serious injury or death
May or will cause minor or moderate injury or damage
Warning (caution) symbol followed by instructions that should be
followed and/or precautions that should be observed.
Warning (caution) symbol followed by prohibited use and/or
operation advisory.
Safety Precautions Safety Precautions
DANGER
WARNING
CAUTION

6
7
English
Notes Before Use
◆About protective stickers
Please be sure to peel off protective stickers before wearing the watch if glass
and metal parts of the watch (case, metal band, and metal parts of the clasp)
are covered with the stickers. Perspiration or moisture may enter the gaps
between the stickers and the parts, which may result in a skin rash and/or
corrosion of the metal parts.
◆About band adjustment
Do not attempt to adjust the watchband (including the metal and rubber type)
by yourself (except watches with accessory tool for band adjustment). Doing
so may result in dropping the watch or injury during the adjustment. Please
contact your dealer or Citizen Customer Support Center for adjustment of the
band; otherwise, adjustment may not be possible or not be free of charge.
Notes Before Use
◆How to use screw down crown
Some models use screw down system for the crown.
Accidental operations can be prevented when the watch is not being operated
by locking the crown. To operate the watch, release the lock.
* If your watch does not have a screw down crown, operations can be
performed without locking or unlocking the crown.
Before operation After operation
When the screw lock
is released, the crown
extends to the normal
position.
Unlock the crown
Rotate the crown to the
left (counterclockwise).
Lock the crown
Press the crown and
rotate it to the right
(clockwise) to tighten
the screw lock.

8
9
English
Notes Before Use ……………………………………………………… 6
Features ………………………………………………………………… 9
Notes on Charging Your Watch …………………………………… 10
Guide to Charging Time …………………………………………… 12
Component identication ………………………………………… 13
Setting the Time …………………………………………………… 14
Setting the Calendar ……………………………………………… 16
Setting the Moon Age ……………………………………………… 18
Eco-Drive (solar powered) Watch Handling Precautions………… 20
Water resistance …………………………………………………… 24
Precautions and usage limitations ………………………………… 27
Maintenance ………………………………………………………… 33
Information ………………………………………………………… 34
Specications ……………………………………………………… 35
Table of contents
◆Eco-Drive (solar powered) watch
The watch operates by converting sunlight and other light into electrical energy. Once the
rechargeable cell is fully charged, the watch will function for approximately 6 months.
◆Insufficient charge warning
If the power becomes very low, the second hand advances
at 2-second intervals, indicating that charging is necessary.
When the second hand starts to advance at 2-second
intervals, expose the watch to light until it is fully charged.
◆Quick start function
When the stopped watch is exposed to light, it starts operating again.
Features
If the watch is not exposed to light within approximately 4 days aer the insucient
charge warning starts, the watch will stop.
Aer quick start, expose the watch to light until it is fully charged. Set the correct time
before using the watch.

10
11
English
This watch has a rechargeable cell which
is charged by exposing the side surface of
the watch to light, such as direct sunlight
or fluorescent lamps. After taking off the
watch, place it in a location where the side
surface is exposed to bright light, such as
by a window.
Placing the watch exposing the side surface
(9 o'clock position) to light as shown in the
figure on the right could charge it more
efficiently.
Notes on Charging Your Watch Notes on Charging Your Watch
• When the watch is regularly covered with long sleeves, it may not be charged
suciently. Try to keep the watch exposed to light sucient for charging.
• Do not charge the watch at a high temperature (about 60ºC/140˚F or higher).
For optimal performance, perform the following:
• Expose the watch with the side surface facing towards direct sunlight for five to
six hours at least once a month.
• Do not store the watch in a dark place with no light for a prolonged period
of time.

12
13
English
Guide to Charging Time
Below are the approximate times needed for charging when exposing the watch
dial to light continuously. Please use this table as a reference only.
Environment
Illuminance
(Lx)
Charging time (approximate)
To keep working
normally for one day
To start working normally when
the rechargeable cell is empty
To charge fully when the
rechargeable cell is empty
Outdoors
(sunny sky) 100,000 7 minutes 3.5 hours 25 hours
Outdoors
(cloudy sky) 10,000 30 minutes 14 hours 100 hours
20 cm under
a uorescent
lamp (30 W) 3,000 1 hour 30 hours 220 hours
Interior
lighting 500 4 hours 150 hours —
＊To charge the rechargeable cell fully, it is recommended to expose the watch to direct
sunlight. A uorescent lamp or interior lighting does not have sucient illumination to
charge the rechargeable cell fully.
is watch will run for approximately 6 months from a full charge without further exposure to light.
Component identification
Minute hand
Crown
* The illustrations in this instruction manual may dier from the actual appearance of your watch.
Hour hand
Second hand Moon age
Date hand

14
15
English
Setting the Time
Pull the crown out to
position 2.
Rotate the crown to
set the time.
Pull out the crown just as the
second hand is at the 0 second
position in order to accurately
align to the second.
For more accurate adjustment, rst
set the minute hand forward by ve
minutes and then return it to the
correct time.
e date changes around midnight.
Make sure not to confuse AM and
PM.
1 2
Setting the Time
Press the crown back into
its normal position.
Refer the time signal and push the
crown to set the time.
Be sure to secure if the watch has a
screw down crown.
Water may enter your watch.
3

16
17
English
Setting the Calendar
Pull the crown
out to position 1.
1
•
Avoid adjusting the calendar when the
hands indicate around 9:00 p.m. to 1:00 a.m..
The calendar may not be changed correctly.
•
The date starts being changed around 10:00
p.m.. It takes the date approximately 2 hours
to be changed.
Setting the Calendar
Press the crown
back into its
normal position.
Rotate the crown
counterclockwise to set the date.
Be sure to secure
if the watch has a
screw down crown.
Water may enter
your watch.
32

18
19
English
Setting the Moon Age
Pull the crown
out to position 1.
1Rotate the crown clockwise to
set the moon age.
2
Setting the Moon Age
Moon age
Guide to the
moon shape
Look in a newspaper to find out the moon age for the day, and then set the shadow part
while referring to the moon age reference chart shown below.
<How to see the moon age>
New moon
Moon age: 0
(Spring)
First quarter
Moon age:
approx. 7
(Neap)
Full moon
Moon age: approx.
15
(Spring)
Last quarter
Moon age approx.:
22
(Neap)
New moon
Moon age: 0
(Spring)
*The indication of moon age is shown to indicate the age of the moon and not its shape. It
can be used as a general indicator of moon age.
Moon age can be set more accurately by setting the moon age either during a new moon/
the first lunar day (moon age: 0) or during a full moon (moon age: 15)

20
21
English
Eco-Drive (solar powered) Watch Handling Precautions
<Always be Sure to Expose Your Watch to Light Regularly>
• Your watch enjoys regular exposure to light. Wearing in situations that
prevent light exposure such as long shirt or coat sleeves will prevent your
watch from receiving light sufficient for charging. In these instances,
supplemental charging may be needed.
• When you take your watch off, try and place it in a bright location. This will
ensure your watch receives light for charging and will continue to operate
properly. Storing your watch in dark places for extended periods of time may
cause the stored energy to become depleted and your watch to stop.
CAUTION Recharging Precautions
• Do not charge your watch at high temperatures (60°C/140°F) as
this may cause damage to sensitive components and the watch to
malfunction.
Examples:
• Charging the watch too close to a light source which generates
a large amount of heat such as an incandescent lamp or
halogen lamp.
* When charging your watch under an incandescent lamp,
be sure to leave 50 cm (19-11/16 inches) distance between
the lamp and the watch to avoid excessive heat. Never use a
halogen lamp for recharging as these generate excessive heat.
• Charging the watch in a location where the temperature may become extremely high such as on
the dashboard of a vehicle.
Eco-Drive (solar powered) Watch Handling Precautions

22
23
English
<Replacement of Rechargeable Cell>
• Your watch features a cell that does not need regular replacement.
However, after an extended period of time, power consumption may increase due to deterioration
of lubrication in the movement. This may result in shorter than expected run time. Be sure to have
your watch regularly inspected by an Authorized Service Center.
Note: Regular maintenance is not covered under the terms of the warranty.
WARNING Handling of Rechargeable Cell
• The rechargeable cell should never be removed from the watch.
If for any reason it becomes necessary to remove the rechargeable cell from the watch, keep out of
the reach of children to prevent accidental swallowing.
If the rechargeable cell is accidentally swallowed, consult a doctor immediately.
• Do not dispose of the rechargeable cell with ordinary garbage. Please follow the instructions of
your municipality regarding collection of batteries to prevent the risk of fire or environmental
contamination.
Eco-Drive (solar powered) Watch Handling Precautions
WARNING Use Only the Specified Rechargeable Cell
• Never install a conventional battery in your watch. Only use the specified rechargeable cell.
Your watch is designed to operate only with the original type of rechargeable cell. It is not designed
to run or be used with a conventional type of battery. Installing such a battery may result in
overcharging which may cause the battery to burst. This can cause damage to the watch and injury
to the wearer.
If for any reason the rechargeable cell needs replacement, be sure to use only the original type
rechargeable cell. We recommend contacting your nearest Authorized Service Center for this
service.
Eco-Drive (solar powered) Watch Handling Precautions

24
25
English
Water resistance
WARNING Water Resistance
• Refer to the watch dial and the case back for the indication of the water resistance of your watch.
The following chart provides examples of use for reference to ensure that your watch is used
properly.
(The unit “1bar” is roughly equal to 1 atmosphere.)
• WATER RESIST(ANT) ××bar may also be indicated as W.R.××bar.
Water-related use
Minor exposure
to water (washing
face, rain, etc.)
Swimming and
general washing work
Skin diving,
marine sports
Scuba diving
using an air tank
Operate the crown
or button when the
watch is wet
Name Indication Specification
Dial or Case back
Non-water resistant Non-water resistant NO NO NO NO NO
Everyday-use
water resistant watch WATER RESIST(ANT) Water-resistant to
3 atmospheres OK NO NO NO NO
Upgraded everyday use
water-resistant watch
WATER RESIST(ANT)
5 bar
Water-resistant to
5 atmospheres OK OK NO NO NO
WATER RESIST(ANT)
10/20 bar
Water-resistant to
10 or 20 atmospheres OK OK OK NO NO
Water resistance

26
27
English
• Non-water resistant watches cannot be used underwater or in environments in contact with water.
• Water-resistance for daily use (to 3 atmospheres) means that the watch may be worn while washing
your face or in the rain, but is not to be immersed in water.
• Upgraded water-resistance for daily use (to 5 atmospheres) means that the watch may be worn
while swimming, but is not to worn while skin diving.
• Upgraded water-resistance for daily use (to 10/20 atmospheres) means that the watch may be worn
while skin diving, but not while scuba or saturated diving using helium gas.
• For a metallic, plastic or rubber watchband, wash any dirt off with water. Remove the small
amounts of dirt trapped between the crevices of the metallic band with a soft brush. If your watch
is not water resistant, be sure not to get the case of the watch wet.
Water resistance Precautions and usage limitations
CAUTION To Avoid Injury
• Be particularly careful when wearing your watch while holding a small child, to avoid injury.
• Be particularly careful when engaged in strenuous exercise or work, to avoid injury to yourself and
others.
• DO NOT wear your watch while in a sauna, jacuzzi or other location where it may become
excessively hot. This may result in burns to the wearer and/or malfunction of your watch.
• Be careful when putting on or taking off your watch since there is a risk of pinching your skin or
damaging your fingernails depending on the manner in which the band is fastened.
• Do not go to bed wearing the watch to prevent from unexpected injury or rash.

28
29
English
CAUTION Precautions
• Always wear your watch with the crown pushed in to the normal position. If your crown is a screw
down type, be sure it is properly screwed down (locked) to the case.
• Do not operate the crown or any buttons when the watch is wet. This may allow the entrance of
moisture and cause damage to sensitive components.
• If water enters the watch or the watch fogs up and does not clear up even after a long time, consult
Authorized Service Center for inspection and/or repair.
• If a watch of upgraded water resistance for daily use is immersed in sea water or subjected to
excessive perspiration, thoroughly rinse with fresh water and wipe completely dry with a soft cloth.
•
If seawater enters the watch, place the watch in a box or plastic bag and immediately take it in for repair.
Otherwise, pressure inside the watch will increase, and parts (crystal, crown, buttons, etc.) may come off.
• Do not splash water from the faucet directly on the watch. The water pressure may be too high for the
watch.
• Do not take a bath wearing the watch. The deterioration of packing, etc may be promoted even if the
watch is water-resistant.
Precautions and usage limitations
CAUTION When Wearing Your Watch
<Band>
• The durability of a leather, cloth, or natural skin strap may be affected by moisture and
perspiration. Moreover, wet leather may cause a rash. Be sure to keep your strap dry and clean.
• It is recommended to take off the watch if it gets wet, even if the watch itself is water-resistant.
• Perspiration or accumulated dirt may cause the leather or rubber band to deteriorate. Be sure to
replace it regularly.
• Note that exposing to light for an extended period of time may cause discoloration of the leather
band whose surface finish is minimized to keep the original texture of the leather.
• A rubber type strap may become stained by dyes or soils found in clothing and other accessories.
Since these stains may become permanent, take caution when wearing your watch with items that
may transfer color (articles of clothing, purses, dyed bracelets, etc.).
• Solvents, moisture and perspiration may cause the strap to deteriorate. Be sure to replace a strap
that has become dried, brittle, or cracked to prevent loss due to strap failure.
• Accumulated dirt between the metal band pieces may cause rash or corrosion of metal leading to
rust.
• Do not wear your watch too tightly. Try to leave enough space between the watch and your skin to
allow adequate ventilation.
Precautions and usage limitations

30
31
English
Precautions and usage limitations
• Please ask immediately for the band adjustment and repair in the following cases.
The band is found to be abnormal due to corrosion of metal, etc.
The pin comes out of the band.
<Temperature>
• The watch may stop or the function of the watch may be impaired in extremely high or low
temperature. Do not use the watch in places where the temperature is outside the operating
temperature range as stated in the specifications.
<Static Electricity>
• The integrated circuits (IC) used in quartz watches are sensitive to static electricity. Please note that
the watch may malfunction if exposed to intense static electricity.
<Magnetism>
• Analog type quartz watches are powered by a motor that utilizes a small magnet. The operation
of this motor can be disturbed if the watch is subjected to magnetic items resulting in the
malfunction of the watch. Do not allow the watch to come into close proximity to magnetic items
such as “health” bracelets or necklaces, coin trays, latches found in cabinets and refrigerators,
certain clasps of handbags and cell phone pouches, cell phone speakers, certain sporting
accessories, MRI equipment, etc.
<Strong Shock>
• Avoid dropping the watch or subjecting it to other strong impact. It may cause malfunctions and/
or performance deterioration as well as damage to the case and bracelet.
<Chemicals, Corrosive Gasses and Mercury>
• If paint thinner, benzene or other solvents or products containing these solvents (including
gasoline, nail-polish remover, cresol, bathroom cleaners and adhesives, water repellent, etc.)
are allowed to come in contact with the watch, they may cause discoloration, deterioration and
damage materials of the watch. Be careful when handling these chemicals. Contact with mercury
such as that used in thermometers may also cause discoloration of the band and case.
CAUTION Always Keep Your Watch Clean
• Rotate the crown while it is pressed in fully and press the buttons periodically so they do not
become stuck due to accumulations of foreign matter.
Note: Do not operate the crown or any buttons when the watch is wet.
• The case and band of the watch come into direct contact with the skin in the same manner as
undergarments. Corrosion of the metal or unnoticed soiling such as that caused by perspiration
and dirt can soil sleeves and other portions of clothing. Keep your watch clean at all times.
Precautions and usage limitations

32
33
English
• The case and band of the watch come in to direct contact with the skin. This may result in
unnoticed accumulations of dirt and foreign matter caused by normal wear. Accumulated matter
may cause rust, discoloration, and premature wear. Be sure to regularly clean your watch with
a soft cloth. If severe accumulations occur, you may need to have your case and/or bracelet
professionally cleaned.
• In some instances, accumulations of dirt and foreign matter may cause skin reactions. This may
also occur due to certain allergies beyond our control. For the metal band and case, use a brush
with neutral detergent to remove dirt and perspiration. For the leather or rubber band, wipe off
dirt with a dry cloth. If a serious problem occurs, immediately discontinue use of your watch and
consult your physician.
• Leather, cloth, and other natural skin straps may become discolored or brittle from moisture,
perspiration and/or accumulated dirt. To maximize the life of your strap, be sure to keep your
leather band clean and dry by wiping it with a soft cloth each day.
CAUTION Caring for Your Watch
• Wipe any dirt or moisture such as perspiration from the case and crystal with a soft cloth.
• If you will not be using your watch for an extended period of time, carefully wipe off any
perspiration, dirt or moisture and store in a proper location, avoiding locations subject to
excessively high or low temperatures and high humidity.
Precautions and usage limitations Maintenance
Daily maintenance
• Rotate the crown while it is pressed in fully and press the buttons periodically so they do not
become stuck due to accumulations of foreign matter.
• Wipe off dirt, perspiration, and water from the case and glass with a clean soft cloth occasionally.
• To clean a metal, plastic, or rubber watchband, wash away dirt with water. Use a soft brush to
remove dust and dirt stuck in the gaps in a metal band.
• Wipe off dirt from the leather or rubber band with a dry cloth.
• Do not use a polishing type of cloth as this may damage the surface and certain treatments.
• Do not use solvents (thinner, benzine, etc.), as they may damage the finish.
Periodical inspections
Your watch needs an inspection once every two or three years for safety and longer usage. To keep
your watch water-resistant, the gaskets and other components need to be replaced regularly. Other
parts need to be inspected and replaced if necessary.
Always ask for genuine Citizen parts upon replacement.

34
35
English
Information
About the Watch with Luminous Paint
Your watch may feature luminous treatment to the dial and hands to aid you in reading the watch
in dimly lit environments. This luminous treatment stores light from both natural and artificial
sources. It is free from any radioactive substance or any other material that may be harmful to the
environment or human body.
• The light emission of the luminous material gradually decreases as time passes.
• The duration and amount of light emitted will vary depending on the brightness, type of and
distance from the light source, exposure time and amount/size of luminous treatment.
• When not exposed to a light source, light emission from the luminous treatment will start off
bright and gradually diminish over a period of hours. The duration of visible light emission will
vary with type of and duration of light exposure as well as size of luminous features of your watch.
Model 8712 Type Analog solar-powered watch
Timekeeping
accuracy
Within ±15 seconds per month when worn at normal operation
temperatures (between +5˚C/41˚F and +35˚C/95˚F)
Operating
temperature
range
−10˚C/14˚F to +60˚C/140˚F
Display
functions
• Time: Hour, minute, second
• Calendar: Date, Moon age
Additional
functions
• Solar power function
• Overcharging prevention function
•
Insufficient charge warning function (2-second interval movement)
Continuous
operation
times
• Fully charged to fully discharged:
Approx. 6 months (Normal use condition)
• From insufficient charge warning display until stop: Approx. 4 days
Battery Rechargeable cell (lithium button cell), 1pc.
Specifications
