Clarke CSM5265 User manual

ASSEMBLY INSTRUCTIONS
ORIGINAL INSTRUCTIONS GC0817
5-SHELF BOLTLESS SHELVING UNITS
MODEL NO: CSM5265
PART NO: SEE TABLE PAGE 2

2
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
INTRODUCTION
Thank you for purchasing this CLARKE Shelving Unit.
Before attempting to use this product, please read this manual thoroughly and
follow the instructions carefully. In doing so you will ensure the safety of yourself
and that of others around you, and you can look forward to your purchase
giving you long and satisfactory service.
Please keep these instructions in a safe place for future reference.
SCOPE
These instructions cover the following models
SPECIFICATIONS
Description Model Part Number
5-Shelf Boltless Shelving (Light Grey) CSM5265/30LG 6600762
5-Shelf Boltless Shelving (Light Grey) CSM5265/60LG 6600764
5-Shelf Boltless Shelving (Light Grey) CSM5265/40LG 6600766
Model Dimensions
(W x D x H)
Weight
(Empty)
Load per
shelf (evenly
distributed)
CSM5265/30LG 900 x 300 x 1800 mm 17.5 kg 265 kg
CSM5265/40LG 1200 x 400 x 1800 mm 28 kg 265 kg
CSM5265/60LG 900 x 600 x 1800 mm 26.3 kg 265 kg

3
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
INVENTORY
No Description Quantity
ACornerPost 8
B Shelf 5
C Long Beam 10
D Short Beam 10
E Centre Beam 5
F Post Joining Insert 4
G Plastic End Cap 8

4
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
ASSEMBLY ADVICE
1. Assemble on a strong, level surface. Avoid assembly on a domestic carpet.
2. Use a cloth or softwood block to protect the surface finish of the product
when using a mallet. Strike the flat surface of each beam to prevent
damage to the beam.
3. Always ensure that the rivets sit at the bottom of the keyhole slots.
4. It is recommended that the assembly should be done by two persons.
5. Always wear protective gloves when asssmbling this shelving.
6. The shelving unit is not recommended for outdoor use.
ASSEMBLY INSTRUCTIONS
TOOLS REQUIRED
• Rubber mallet or hammer
• Protective cloth/wood block
The tabs of the beams will often enter
the slots fully using just firm hand
pressure but if they are too tight, you
may require a rubber mallet to assist.
If so, always use a cloth to protect
the product paint finish.
Tap gently with the mallet to drive the
tabs of the beams fully into the slots in
the corner post. Always strike the
edge close to the post.
1. Use the short beams (D) to
connect the front and rear posts
together.
NOTE: The edge with the wider
flange should be installed
uppermost to support the
shelf.
• Repeat this again to create the
other end assembly, making sure
that the corresponding beams
are at the same height.

5
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
2. Ensure the posts are the right way
up with the upper ends as shown in
the detail.
3. Join the two end assemblies
together with the long beams (C)
as shown.
4. Connect the support beams (E) to
the long beams (C). First bend the
tabs 90 degrees to pass them
through the slots in the long
beams.
• The tab initially lays flat against the
long beam (C).
5. Next, bend the tab back through
180 degrees to grip the long
beam.
• Use a screwdriver or similar tool to
bend the tabs.
6. Finally bend the tab again through
90 degrees the opposite way, to
seat tightly against the support
beam (E).
7. Ensure there is no movement
between the beams.

6
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
8. Fit post joining inserts (F) into the
posts (A), ensuring that the inserts
are fitted with their keyholes to
match those of the posts.
9. Construct the upper end
assemblies onto the post inserts (F)
before adding more long beams
and support beams as previously
to complete the framework.
10. Lay the shelf panels (B) into
position.
• Always fit the top shelf at the
highest position.
11. Insert the plastic end caps (G) into
the end of each post (A).
12. We recommend that the shelvng
be secured to an adjacent wall
using typical wall insert plugs and
screws (not supplied) aligned with
the assembly slots in the posts.

7
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
GENERAL SAFETY RULES
1. Always maintain equipment in good condition for the best/safest usage.
2. Never exceed the maximum load for these shelving units as stated in the
specification.
3. Never use these units if they are damaged.
4. Always load small, stable items on the top shelves, heavier and bulky items
should be stored on the lower shelves.
5. Always distribute heavy loads evenly across the shelves.
GUARANTEE
This product is guaranteed against faulty manufacture for a period of 12
months from the date of purchase. Please keep your receipt which will be
required as proof of purchase.
This guarantee is invalid if the product is found to have been abused or
tampered with in any way, or not used for the purpose for which it was
intended.
Faulty goods should be returned to their place of purchase, no product can
be returned to us without prior permission.
This guarantee does not effect your statutory rights.
ENVIRONMENTAL PROTECTION
Do not dispose of old products or damaged parts with general household
waste. All tools, accessories and packaging no longer required should be
sorted, taken to a recycling centre and disposed of appropriately.
