Clarke CSP520 User manual

ASSEMBLY INSTRUCTIONS
Model No:CSP520
Part No:6600532
GC1010
5-TIER SHELVING RACK

2
INTRODUCTION
Thank you for purchasing this CLARKE Shelving Rack.
Before attempting to use the product, it is essential that you read this manual
thoroughly and carefully follow all instructions given. In doing so you will
ensure the safety of yourself and that of others around you, and you can also
look forward to the product giving you long and satisfactory service.
GUARANTEE
This product is guaranteed against faulty manufacture for a period of 12
months from the date of purchase. Please keep your receipt which will be
required as proof of purchase.
This guarantee is invalid if the product is found to have been abused or
tampered with in any way, or not used for its intended purpose.
Faulty goods should be returned to their place of purchase, no product can
be returned to us without prior permission. This guarantee does not effect
your statutory rights.
ENVIRONMENTAL PROTECTION
Do not dispose of this product with general household waste. All
equipment, accessories and packaging should be sorted, taken to a
recycling centre and disposed of appropriately.
SPECIFICATION & CONTENTS
Dimensions (L x W x H) 610 x 305 x 1730 mm
Product Weight 5.4 kg
Max Load per Shelf 20 kg (evenly distributed)
Shelf Height 370 mm
When unpacking, check for damage and/or shortages etc. Any found
should be reported to your CLARKE dealer where the product was
purchased. This shelving rack should include the following:
4 x Feet 16 x Supporting Legs 4 x Top Caps
5 x Shelf Panels 4 x Wall Fixing Brackets 8 x Wall Plugs
8 x Screws 1 x Assembly Instructions (this document)
Caution: This product is not intended to come into contact with cleaning
agents/corrosive chemicals or sources of heat e.g. naked flames etc.
Please keep these instructions in a safe place for future reference.

3
GENERAL SAFETY GUIDELINES
1. ALWAYS maintain this product in good condition for greater safety.
2. NEVER exceed the maximum recommended load for this product.
3. NEVER use this product if damaged.
4. ALWAYS store small, stable items on the top shelves, heavier and bulky
items should be stored on the lower shelves.
5. ALWAYS secure the shelf rack to a wall using the fixings supplied before
loading.
ASSEMBLY TIPS
Assemble the product on a firm, level surface rather than a soft surface.
1. Take the feet and push them onto the underside of one shelf as in Fig 1.
2. Insert the supporting legs, narrow end downwards through the shelf
corner sockets and into the feet from the upper side of the shelf, trapping
the shelf between the foot and leg.
3. Turn the assembly over the right way up and add the next shelf panel and
continue until all the legs and shelf panels are assembled. Ensure the
supporting legs are connected with the narrow end downwards to lock
the parts together.
4. Insert the top caps into the holes in the top shelf as shown in Fig 2.
5. Finally, secure the shelving rack to a wall using the brackets and fixings
supplied. Use a masonry drill to install the wall plugs, positioning at
sufficient height to provide good support for the shelving rack as in Fig 3.
Fig 2
Fig 1 Fig 3
