ASSEMBLY INSTRUCTIONS
GC0811
Chrome Boltless Wire Shelving
Model Nos: CS330, CS430 & CS530
PART NOs: 6600550, 6600555 & 6600560

2
Parts & Service: 020 8988 7400/E-mail:Part[email protected] or [email protected]
INTRODUCTION
Thank you for purchasing this CLARKE shelf unit. This units requires no screws or
fixings for assembly, providing easy and rapid installation and re-
configuration when required. The frame allows for shelf height adjustment,
providing excellent versatility.
Before using this product, please read this manual & follow the instructions
carefully. Thoroughly familiarise yourself with this product in order to ensure
the safety of yourself and others around you. In so doing, you can look
forward to the product giving you long and satisfactory service.
SPECIFICATION
COMPONENT PARTS
Lower post with adjustable
foot fitted.
Upper post shown with
threaded coupling fitted.
Split Collets
Shelves
)HxWxL(snoisnemiD thgieW flehSrePdaoLxaM
033SC 539x553x019gk2.7gk03
034SC 0221x043x047gk7.8gk03
035SC 2261x243x5011gk4.31gk03

3
Parts & Service: 020 8988 7400/E-mail:Part[email protected] or [email protected]
ASSEMBLY
Note; The CS330 does not require upper posts or
threaded couplings.
1. Take one of the lower posts, and clip a pair of the
plastic split collets to a groove on each of the posts.
Note: The collets are slightly narrower at one end, the
narrow end should be at the top. The collets are
also marked “TOP”.
2. Repeat the process with the remaining 3
lower posts. positioning the collets at the
same height on each post.
3. Slide the shelf down over the collets,
pushing down on each corner of the shelf
to clip it into place.
4. If not alredy fitted to CS430 & 530 versions,
screw the threaded coupling into the
upper post.
5. Screw the upper posts to the lower posts.
6. Using the collets as above, attach the remaining shelves.
7. Adjust each foot as required to level the shelving unit on
uneven ground.
Note: It is recommended that the unit be securely anchored
to a wall to prevent overturning when loaded.
This product is guaranteed against faulty manufacture for a period of 12
months from the date of purchase. Please keep your receipt which will be
required as proof of purchase. This guarantee is invalid if the product is found
to have been abused or tampered with in any way, or not used for it’s
intended purpose.
Faulty goods should be returned to their place of purchase, no product can
be returned to us without prior permission. This guarantee does not effect
your statutory rights.
