Clarke GMS23SS User manual

ASSEMBLY INSTRUCTIONS
ORIGINAL INSTRUCTIONS GC1218 - ISS 1
CORNER MODULAR SYSTEM

2
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
INTRODUCTION
Thank you for purchasing this CLARKE corner module unit.
Before attempting to use this product, please read this manual thoroughly and
follow the instructions carefully. In doing so you will ensure the safety of yourself
and that of others around you, and you can look forward to your purchase
giving you long and satisfactory service.
GUARANTEE
This product is guaranteed against faulty manufacture for a period of 12
months from the date of purchase. Please keep your receipt which will be
required as proof of purchase.
This guarantee is invalid if the product is found to have been abused or
tampered with in any way, or not used for the purpose for which it was
intended.
Faulty goods should be returned to their place of purchase, no product can
be returned to us without prior permission.
This guarantee does not effect your statutory rights.

3
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
SAFETY WARNINGS
1. Ensure Health & Safety, local authority, and general workshop practice
regulations are adhered to when using this storage system.
2. Locate in a suitable work area.
3. Keep the work area clean, uncluttered and ensure there is adequate
lighting.
4. Use storage on level and solid ground, preferably concrete.
5. Keep the storage system clean and tidy in accordance with good
workshop practice.
6. Keep children and unauthorised persons away from the work area.
7. DO NOT use the storage system for any purpose other than that for which it
is designed.
8. DO NOT use the storage system outdoors.
9. DO NOT place the storage system in a damp or wet location or an area
where there is condensation.
10. DO NOT clean the storage system with any solvents which may damage
the surfaces or the protective coating.
11. DO NOT move the storage system when there are items placed inside.
12. DO NOT step on the shelves.
13. DO NOT overload the storage system.
ASSEMBLY INSTRUCTIONS
1. Place all parts in a clear area and arrange them on the ground in front of
you. Check for completeness and for any transport damage
2. Remove all packaging materials and place them back in the box. Do not
dispose of the packaging materials until assembly is complete.
3. Erect your cabinet on a level surface.
4. DO NOT use bleach, alkaline or harsh detergents for cleaning. Soap and
warm water are recommended.
WARNING: READ ALL SAFETY INSTRUCTIONS TO REDUCE THE RISK OF
INJURY. RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.
