Clarke CSR450 Series User manual

ASSEMBLY INSTRUCTIONS
GC0815
4-SHELF BOLTLESS SHELVING UNITS
MODEL NO: CSR450
PART NO: SEE TABLE PAGE 2

2
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
INTRODUCTION
Thank you for purchasing this CLARKE Shelving Unit.
Before attempting to use this product, please read this manual thoroughly and
follow the instructions carefully. In doing so you will ensure the safety of yourself
and that of others around you, and you can look forward to your purchase
giving you long and satisfactory service.
SCOPE
These instructions cover the following models
Description Model Part Number
4-Shelf 50kg Boltless Shelving (Light Grey) CSR450LG 6600680
4-Shelf 50kg Boltless Shelving (Blue) CSR450B 6600682
4-Shelf 50kg Boltless Shelving (Galvanised CSR450GALV 6600684

3
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
INVENTORY
No Description Quantity
APost 8
B Shelf (metal) 4
C Post Joining Insert 4
D Plastic End Cap 8

4
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
ASSEMBLY ADVICE
1. Assemble on a strong, level surface. Avoid assembly on a domestic carpet.
2. Use a cloth or softwood block to protect the surface finish of the product
when using a mallet. Strike the flat surface of each beam to prevent
damage to the beam.
3. Always ensure that the rivets sit at the bottom of the slots.
4. Always wear protective gloves when assembling the shelf unit.
5. The shelving unit is not recommended for outdoor use.
ASSEMBLY INSTRUCTIONS
TOOLS REQUIRED
• Rubber mallet or hammer
• Protective cloth/wood block
The tabs of the shelves will often
enter the slots in the posts fully using
just firm hand pressure but if they are
too tight, you may require a rubber
mallet to assist. If so, always use a
cloth to protect the product finish.
Tap gently with the mallet to drive the
tabs of the shelves fully into the slots
in the post. Always strike the edge
close to the post.
1. Fit the shelves (B) to the front and
rear posts as in Fig 1.
2. Ensure that the posts are the right
way up as shown in the detail.
3. Repeat this again with the
remaining posts ensuring each
shelf is at the same height at each
corner.
4. Add the next shelf to the posts to
create a structure.

5
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
5. Fit post joining inserts (C) into the
posts (A), ensuring that the inserts
are fitted with their slots to match
those of the corner posts.
6. Add the upper posts to the post
inserts (C) before adding the
remaining shelves as previously to
complete the assembly.
• Remember that the top shelf
should be fitted at the highest
possible position.
7. Insert the plastic end caps (D) into
the end of each post (A).
We recommend that the racking be secured to an adjacent wall using typical
wall insert plugs and screws (not supplied) aligned with the assembly slots in
the posts.

6
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
GENERAL SAFETY RULES
1. Always maintain equipment in good condition for the best/safest
performance.
2. Never exceed the maximum load for these shelving units as stated in the
specification.
3. Never use these units if they are damaged.
4. Always load small, stable items on the top shelves, heavier and bulky items
should be stored on the lower shelves.
5. Always distribute heavy loads evenly across the shelves.
Please keep these instructions in a safe place for future reference.
SPECIFICATIONS
GUARANTEE
This product is guaranteed against faulty manufacture for a period of 12
months from the date of purchase. Please keep your receipt which will be
required as proof of purchase.
This guarantee is invalid if the product is found to have been abused or
tampered with in any way, or not used for the purpose for which it was
intended.
Faulty goods should be returned to their place of purchase, no product can
be returned to us without prior permission.
This guarantee does not effect your statutory rights.
Model Dimensions
(W x D x H)
Weight
(Empty)
Load per shelf
(evenly distributed)
CRS450 Units 750 x 300 x 1500 mm 6.8 kg 50 kg

7
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
ENVIRONMENTAL PROTECTION
Do not dispose of old products or damaged parts with general household
waste. All tools, accessories and packaging no longer required should be
sorted, taken to a recycling centre and disposed of appropriately.
