Clarke CPSB200B Instruction Manual

OPERATION & MAINTENANCE
INSTRUCTIONS
ORIGINAL INSTRUCTIONS GC0218 ISS 1
PRESSURISED SANDBLASTER
MODEL NO: CPSB200B
PART NO: 7640134

2
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
INTRODUCTION
Thank you for purchasing this CLARKE Pressurised Sandblaster.
Before attempting to use this product, please read this manual thoroughly and
follow the instructions carefully. In doing so you will ensure the safety of yourself
and that of others around you, and you can look forward to your purchase
giving you long and satisfactory service.
GUARANTEE
This product is guaranteed against faulty manufacture for a period of 12
months from the date of purchase. Please keep your receipt which will be
required as proof of purchase.
This guarantee is invalid if the product is found to have been abused or
tampered with in any way, or not used for the purpose for which it was
intended. Faulty goods should be returned to their place of purchase, no
product can be returned to us without prior permission.
This guarantee does not effect your statutory rights.
CARTON CONTENTS
The following items should be supplied in the carton.
If any parts are missing or damaged, please see your Clarke dealer.
• 1 x Tank Assembly • 1 x Front Leg
• 2 x Handlebars • 1 x Gun Assembly
• 2 x Wheels • 2 x Wheel Covers
• 1 x Fixings Kit • 1 x Axle
• 1 x Media Hose • 1 x Funnel
• 1 x Sand Sieve • 1 x Roll Teflon Tape
• 1 x Protective Mask/Hood • 1 x Spare Gun Closing Block
• 4 x Nozzles - nominal diameters: 2.0 mm, 2.5 mm, 3.0 mm, 3.5 mm

3
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
GENERAL SAFETY RULES
1. Read this instruction manual before connecting the sandblaster to your
compressor.
2. Do not use any silica based abrasives with this tool. Silica based abrasives
have been linked to severe respiratory disease. Always use recommended
abrasives. Abrasives used in this sandblaster may be covered by COSHH
Regulations.
3. Read this manual carefully, Learn the sandblaster applications and
limitations, as well as potential hazards specific to it.
4. Do not expose to moisture. Don't use this product in damp or wet locations,
Keep out of rain.
5. Keep work area clean and well lit. Cluttered or dark work areas invite
accidents.
6. Keep children away. All children should be kept away from the work area.
Never let a child handle tools without strict adult supervision.
7. Do not operate this product if under the influence of alcohol or drugs.
Read warning labels on prescriptions to determine if your judgment or
reflexes are impaired while taking medication. If there is any doubt, do not
attempt to operate.
8. Use safety equipment. Dust mask, non-skid safety shoes, hard hat, or
hearing protection should be used in appropriate conditions.
9. Don't overreach, Keep proper footing and balance at all times when
operating this product.
10. Always disconnect the sandblaster from the air supply and release pressure
from the tank before storing, servicing, or changing accessories.
11. Use clamps or other practical means to secure and support the work piece
to a stable platform. Do not hold the work by hand or against your body.
12. Do not point the sandblaster at anyone or at any objects other than the
intended work object.
13. Check your sandblaster regularly for damage, If any part is damaged it
should be carefully inspected to make sure that it can perform its intended
function correctly. If in doubt, the part should be repaired. Refer all
servicing to a qualified technician. Consult your dealer for advice.
WARNING: COMPRESSED AIR CAN BE DANGEROUS. ENSURE THAT YOU
ARE THOROUGHLY FAMILIAR WITH ALL PRECAUTIONS RELATING TO THE
USE OF COMPRESSORS AND COMPRESSED AIR SUPPLY.

4
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
14. Do not attempt to operate this product near flammable materials or
combustibles. Failure to comply may cause serious injury.
15. Always make sure that the trigger is not on before connecting the
sandblaster to the air supply.
16. Store idle equipment out of the reach of children and untrained persons.
Tools may be dangerous in the hands of untrained users.
17. Drain the water trap periodically during use, Do not allow moisture to fill
more than 1/2 of the water trap bowl. Do not leave water standing in the
water trap when storing the sandblaster.
18. Do not allow the sandblaster to sit pressurized while unattended or not in
use.
19. Periodically check the abrasive medium delivery components. Valves,
hoses and nozzles that carry the abrasive medium after it leaves the
pressure tank are subjected to the abrasive blasting action so will wear out
more quickly than other components.
20. Release the air pressure in the tank before opening. See “Releasing
Pressure from the Tank” section, Make sure pressure gauge reads “0”
before opening the tank. Do not attempt any maintenance on the
sandblaster until the pressure gauge reads “0” and it has been
disconnected from the air supply.
21. Maintain the correct air pressure whenever working. Do not allow working
pressure to exceed 125 psi. If the safety valve does not release excess air
pressure, stop all work and release pressure from the tank (see “Releasing
Pressure from the Tank” section).
22. ALWAYS make sure there is adequate ventilation. Do not work in confined
areas.
23. In the case of injury seek expert medical advice immediately.
24. Use clamps or a vice to hold the work if it is small or of light weight rather
than using your hands. This frees both hands to operate the nozzle.
ENVIRONMENTAL PROTECTION
Recycle unwanted materials instead of disposing of them as waste.
All tools, accessories and packaging should be sorted, taken to a
recycling centre and disposed of in a manner which is compatible
with the environment.

5
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
ASSEMBLY
FIT THE PRESSURE GAUGE TO THE TANK
1. Screw the pressure gauge onto
the sandblaster as shown in Fig 1.
FIT THE HANDLE BARS TO THE TANK
1. Lay the tank on a flat level surface
such as a workbench, with the
handlebar mounting brackets
facing up, as shown in Fig 2.
2. Align the holes in the left
handlebar with the handlebar
mounting brackets on the left side
of the tank.
3. Fit a washer to each of the
handlebar mounting screws. Insert
a screw through each hole in the handlebar and mounting brackets.
4. Fit a nut onto each of the screws and firmly tighten with a wrench.
5. Repeat steps 2-4 for the right handlebar.
ASSEMBLE THE AXLE
1. Slide the axle through the holes at
the bottom of the handlebars, see
Fig 3.
2. Slide a washer onto each end of
the axle.
Fig 1
Fig 2
Fig 3

6
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
3. Slide a wheel onto each end of
the axle followed by another
washer.
4. Use the circlip provided to secure
the wheel, see Fig 4.
5. Press the wheel cover onto the
wheel as shown in Fig 5.
ATTACH THE FRONT LEG
1. Roll the tank over so that handlebars
are now facing down.
2. Align the holes of the front leg
with the holes in the leg mounting
on the front side of the tank, see
Fig 6.
3. Insert a split pin through the holes
and bend it so the front leg
cannot slide off the leg mount.
ATTACH THE MEDIA HOSE
1. Slide the hose onto the outlet at
the bottom of the sandblaster as
shown in Fig 7.
2. Tighten the clip shown to secure
the hose.
Fig 4
Fig 5
Fig 6
Fig 7

7
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
3. Connect the sandblasting gun to
the other end of the hose in a
similar manner. Ensure the inlet
connector is tightly fitted to the
gun.
• A spare gun closing block is
supplied for future use.
OPERATION
SAFETY AND HEALTH CONSIDERATIONS
• Before opening tank make sure that it is not pressurized. Ensure the
gauge reads “0”. If it does not, release pressure from the tank (See
page 10).
• Disconnect the compressor before opening the tank. Protect
yourself and those around you from “over-spray”. Remember that
your sandblaster is shooting a powerful spray of abrasive material.
Do not point it at yourself or anyone around you.
• Wear protective clothing including hood (30), and heavy gloves
when using this sandblaster.
• Wear a dust mask over your mouth and nose when using this
sandblaster. You will create a cloud of abrasive material and debris
which is dangerous to inhale.
• Protect anything around you that may be damaged from the spray
of abrasive particles. Nothing subject to contamination damage or
with a fine surface should be near your sandblaster work area.
WARNING: ALWAYS WEAR YOUR HOOD, DUST MASK AND HEAVY DUTY
CANVAS GLOVES WHEN OPERATING THE SANDBLASTER.
WARNING: BEFORE OPERATING YOUR SANDBLASTER, INSPECT EACH
CONNECTION, DOUBLE CHECKING TO MAKE SURE THAT ALL ARE TIGHT
AND PROPERLY SEALED.
WARNING: THIS SANDBLASTER IS NOT INTENDED FOR USE WITH SILICA
BASED ABRASIVES. WHICH HAVE BEEN LINKED TO SEVERE RESPIRATORY
DISEASE. ALWAYS USE SILICA SUBSTITUTES (SUCH AS CLARKE GLASS BEAD
ABRASIVE.
Fig 8

8
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
ABRASIVE SELECTION
The type of abrasive you choose will greatly influence the amount of time
needed to clean a given surface area.
Suitable Abrasives available from your clarke stockist
LOADING THE ABRASIVE
• To prevent clogging, ensure that the abrasive you use is dry.
• While you may re-use abrasive but remember that abrasive grit/
material does wear out. After use, abrasive becomes smoother and
rounder, thus reducing its effectiveness.
NOTE: Re-using abrasive may also cause clogging due to fine debris
contained in the mixture from prior use.
1. Close the air supply valve by
turning it to the closed position,
see Fig 9.
2. Squeeze the trigger to release any
pressure from the tank.
• Make sure the pressure gauge
reads “0”.
3. Remove the filler cap.
4. Using the sieve and funnel
supplied, pour the selected
abrasive material into the tank,
see Fig 10.
• Do not fill the tank more than ¾
full.
• If humidity in your region is 90%
or more, only fill the tank ½full
and check the water trap more
frequently.
Aluminium Oxide
Powder
60 60-80 60-80 80 80-120 120
22kg 20kg 7.5kg 22kg 7.5kg 22kg
3052070 3052110 3052100 3052075 3052105 3052080
Glass Bead Abrasive 3052095 20kg
Soda Blast Abrasive 3052805 7.5kg 3052800 22kg
Garnett Abrasive 3052090 22kg
Fig 9
Fig 10

9
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
5. Replace the filler cap ensuring the O-ring is in place.
NOTE: Place your air compressor in another room to prevent damage
from the intake of abrasive dust laden air.
TO START BLASTING
NOTE: Start with all valves in the closed position. Following the instructions
below will help prevent clogging in the delivery hose, outlet
manifold and in the gun.
1. Connect the compressor to the
inlet connector.
2. Start the compressor and open
the air supply valve, see Fig 11.
• The tank will start to pressurise.
3. Test the safety valve by pulling up
on the valve as shown in Fig 12.
• Air will hiss out when the valve is
pulled.
•
•
•
•
4. Open the throttle valve, Fig 13.
5. Check for leaks at the filler cap
and along all hoses and fittings as
the system pressurises. If leaks are
observed, release the pressure
from the tank and repair any leaks
immediately.
6. Press and hold the trigger until air
is flowing through the gun.
Fig 11
Fig 12
Fig 13

10
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
7. With the trigger open, slowly open
the abrasive control valve as
shown in Fig 14 until abrasive
material begins to flow out of the
gun.
8. Adjust the abrasive control valve
until the desired amount of
abrasive material is flowing
through the gun.
9. Begin blasting.
ABRASIVE FLOW ADJUSTMENT
• Choose a larger nozzle for a broader spray pattern. Choose a
smaller nozzle for more focused spray.
• Adjust air pressure with the throttle valve. Adjust abrasive flow with
the abrasive control valve.
• Watch for abrasive clogging. Release pressure from the tank if
necessary and replace the abrasive with drier or cleaner abrasive.
TO STOP BLASTING
1. While continuing to press and hold the trigger, turn the abrasive control
valve to the closed position, see Fig 14.
2. When you notice only air (no abrasive) is coming out of the nozzle, you can
stop the air flow by releasing the trigger. By doing this you are ensuring a
clean manifold, hose and gun.
3. ALWAYS clean the gun thoroughly after use.
RELEASING PRESSURE FROM THE TANK
1. When finished blasting, close the
abrasive control valve, see Fig 15.
2. Press and hold the trigger to expel
any remaining abrasive material
from the abrasive hose and gun.
Fig 14
Fig 15

11
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
3. When you notice only air (no
abrasive material) is coming out
of the gun, release the trigger and
close the Air Supply Valve, see Fig
16.
4. Ensure the throttle valve is open,
see Fig 17.
5. Point the gun in a safe direction.
6. Press the trigger until air stops
flowing and pressure gauge reads
“0”.
7. Disconnect air supply hose from
the supply valve.
MAINTENANCE
1. Keep your sandblaster clean and protect it from damage.
2. When initially pressurising, check for leaks at the top of the tank and at all
hoses and fittings.
3. Leaking joints maybe repaired by replacing worn or damaged parts or
using teflon tape.
4. Check for worn abrasive hose and fittings.
5. Watch for leaks, blistering, bulging or thinning of the hose.
6. Replace any parts which appear worn.
WARNING: DISCONNECT THE SANDBLASTER FROM THE AIR SUPPLY AND
RELEASE ANY PRESSURE IN THE TANK AND HOSE BEFORE CHANGING
ACCESSORIES, ATTEMPTING TO MOVE THE SANDBLASTER OR
PERFORMING ANY MAINTENANCE.
Fig 16
Fig 17

12
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
AIR FILTER
DRAINING
Condensation will collect in the air
filter which must be drained manually.
1. Drain the air filter by pulling down
on the drain plug until all the water
comes out, see Fig 18.
CLEANING/REPLACING
1. Press the release catch and
unscrew the condensation
chamber, see Fig 19.
2. Unscrew the filter as shown in Fig
20 and wipe clean.
NOTE: Do not use harsh or abrasive
chemicals when cleaning
the condensation chamber.
3. Refit the condensation chamber.
REPLACING THE NOZZLE
After l0-l2 hours of blasting time the nozzle should be checked for wear. The
nozzle will wear out over time and should be replaced when the hole is no
longer round or the abrasive media does not flow smoothly through. To
replace the nozzle:
NOTE: Refer to page 14 for the following replacement parts.
1. Disconnect the sandblasting gun from the air hose.
2. Unscrew the nozzle adapter (38), located at the front of the gun.
3. Remove the old nozzle (37) and insert the new one.
• A pack of 4 replacement nozzles are available from your Clarke
dealer Part number 7640132.
Replace the nozzle adapter (38) and firmly screw it onto sandblasting gun.
Fig 18
Fig 19
Fig 20

13
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
SPECIFICATIONS
DECLARATION OF CONFORMITY
Sand Grade Type Recommended 80-100 grit
Abrasive Material Aluminium Oxide, Sand,
Garnet, Glass Beads
Tank Capacity (working) 63 Litres (13.86 Gallons)
Operating Pressure 65 - 125 PSI (4.4 - 8.6 Bar)
Flow Rate Required 169-707 l/min (6-25 cfm)
Min Compressor Size Required 2-10 HP (dependant on setting)
Nozzle Sizes 2, 2.5, 3, 3.5 mm
Dimensions (L x W x H) 445 x 780 x 920 mm
Product Weight (empty) 28.1 kg

14
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
EXPLODED DIAGRAM

15
Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]
PARTS LIST
NO DESCRIPTION NO DESCRIPTION
1 Tank 29 Funnel
2 Wheel 30 Hood
3 Circlip 30A Lens for Hood
4 Front Foot 31 Upper Gun Body
5 Axle 32 Lower Gun Body
6 Handle Bar 33 Metal Pipe
7 Handle Grip 34 Inlet Connector
8 Pan Head Screw 35 Adapter
9 Hex Nut 36 O-Ring
10 Safety Valve 37 Ceramic Nozzle
11 0-Ring 38 Rubber Adapter
12 Tank Filler Cap 39 Nozzle Cap Nut
13 Connecting Pipe 40 Screw ST 4.2 x 16
14 Intake Manifold 41 Screw ST 4.2 x 12
15 Pressure Gauge 42 On/Off Control Lever
16 3/8” Connector 43 Spring Pin
17 Water Trap Filter 44 Spring
18 3/8” Brass Air Supply Valve 45 Rubber Pad
18A 3/8” Brass Throttle Valve 46 Screw M3 x 25
18B 3/8” Steel Abrasive Control Valve 47 Hard Alloy Pad
19 Inlet Connector 48 Nut M3
20 Connector 49 Hose Adapter
21 Air Hose 50 Washer
22 Abrasive Outlet Manifold 51 Washer
23 Hose Clamps 52 Wheel Cover
24 Abrasive Hose
