Clarke CSB34 Instruction Manual

OPERATION & MAINTENANCE
INSTRUCTIONS
LS0513
SIPHON FEED SANDBLASTER
MODEL NO: CSB34
PART NO: 7640120

2
INTRODUCTION
Thank you for purchasing this Clarke Siphon Feed Sandblaster.
Before you try to use this product, read this manual and follow the instructions
carefully. In doing so you will ensure your safety and the safety of others
around you. You can also look forward to a purchase that gives you long and
satisfactory service.
GUARANTEE
This product is guaranteed against faulty manufacture for a period of 12
months from the date of purchase. Please keep your receipt which will be
required as proof of purchase.
This guarantee is invalid if the product is found to have been abused or
tampered with in any way, or not used for the purpose for which it was
intended.
Faulty goods should be returned to their place of purchase, no product can
be returned to us without prior permission.
This guarantee does not effect your statutory rights.
CONSUMABLES
Please be aware that certain parts of this sandblaster will wear, requiring
replacement and that these parts may not be covered by your guarantee.
The wear on certain parts depends on the abrasiveness of the materials used.
Replacement parts are available from your nearest Clarke International
dealer.

3
GENERAL SAFETY RULES
1. Read this instruction manual before connecting the sandblaster to a compressor.
2. Do not use any silica based abrasives with this sandblaster. Silica based abrasives
have been linked to severe respiratory disease. Always use recommended
abrasives. Abrasives used in this sandblaster may be covered by COSHH
Regulations.
3. Safety glasses, hood, long-sleeve shirt, gloves and a respirator should be worn during
operation and clean up.
4. During operation, do not expose the hands or skin to the blasted material, keep
hands away from the nozzle.
5. Everyone in the blasting area must also wear personal protective equipment.
6. Check the condition of hoses and air lines before each use.
7. Make sure all connections are secure before use.
8. Abrasives used in this unit may be covered by COSHH Regulations.
9. ALWAYS make sure there is adequate ventilation. Do not spray in confined areas.
10. ALWAYS disconnect the gun from the air supply when the sandblaster is not in use.
11. ALWAYS clean the gun thoroughly after use. See ‘Maintenance’.
12. ALWAYS turn off the compressor and expel all air from the air hose and gun before
disconnecting the sandblasting gun.
13. ALWAYS use appropriate air hoses and couplings and ensure that they are in good
condition. If any parts are worn or damaged, they should be replaced immediately.
14. ALWAYS hold the tool firmly and maintain good balance.
15. NEVER carry the gun by the hose. Keep hoses away from heat, oil and sharp edges.
16. NEVER use wet or even damp grit. Ensure the grit is completely dry,
17. In the case of injury seek expert medical advice immediately.
18. NEVER allow children to use or play with the sandblaster.
Warning: Compressed air can be dangerous. Ensure that you are
thoroughly familiar with all precautions relating to the use of
compressors and compressed air supplies.
Warning: Disconnect the sandblaster from the air supply before
changing accessories, attempting to move the sandblaster or perform
any maintenance.
Warning: Do not point the sandblaster gun at anyone or objects other
than the intended work object.

4
UNPACKING
Unpack your sand blaster and its accessories and make sure that the following
items are present. Should there be any damage caused during transit contact
your Clarke dealer immediately.
Drum Assembly
Lower Frame
2 x Wheels
Upper Frame
Sandblasting Gun
Delivery Hose
Axle
Leg/Prop Stand
Combination
Mesh Filter
Ceramic nozzles
Hood & Mask
(HTCSB3401)
(HTCSB3404)
(HTCSB3402)
(HTCSB3410)
(HTCSB3403)
(HTCSB3406) (HTCSB3408)
(HTCSB3409)
(HTCSB3407)
(HTCSB3405)
Available from your Clarke
1 x Fixings Pack
(HTCSB3411)
Dealer: Part no: 7640122
Please dispose of any packaging responsibly. The cardboard packaging can
be recycled.

5
ASSEMBLY
1.
Upper Frame
Axle
Lower Frame
Slide the axle through the upper
frame and lower frame as shown
on the right.
2.
Split Pin
Washer
Wheel
Spacer
Slide the spacer (5) onto the axle
followed by the wheel, then the
thin washer (6), and secure in
place using the split pin (2).
3. Repeat on the other end of the
axle.
4. Attach the drum to the upper
frame and secure in place using 2
bolts (4), 4 washers (3) and 2 nuts
(7) to secure into place.

6
5. Fit the leg/prop stand to the drum
and secure in place using 2 short
bolts (1), 4 washers (3) and 2 nuts
(7).
6. Secure in leg/prop stand to the
lower frame using the long bolt
(9), 2 washer (3) and 1 nut (7).
7. Place a jubilee clip (8) onto each
end of the hose.
8. Firmly push the end of the hose
onto the abrasive inlet on the
sandblasting gun.
9. Slide one of the jubilee clips so
that it is overlapping both the
hose and the abrasive inlet.
10. Tighten the jubilee clip with a
screwdriver.
11. Firmly push the opposite end of
the hose onto the abrasive outlet,
located at the base of the drum.
NOTE: there is an air hole in the
abrasive outlet - do not
cover this air hole with the
abrasive hose.
12. Position the remaining jubilee clip
so that it is overlapping both the
hose and the abrasive outlet of
the drum.
13. Tighten the jubilee clip with a screwdriver.

7
OPERATION
USING YOUR SANDBLASTER
Connect your sandblasting gun to a compressor (minimum 3hp capable of
supplying a minimum of 10 CFM of air) via the 3/8” hose adaptor located at
the base of the handle.
Set the working pressure on your air compressor to 6 - 8 bar (87 - 116 psi).
1. Connect an air hose (sold
separately) from your compressor,
to the hose fitting on the
sandblasting gun.
2. Make sure air hole located on the
base of the abrasive tank is not
covered.
3. Place the mesh filter on top of the
drum and pour the blasting
medium through the filter into the
drum.
4. Start compressor according to the
manufacturers instructions.
5. Check for leaks along all hoses
and fittings. if leaks are found, turn off the compressor, disconnect the hose
and repair immediately.
6. Point the sandblasting gun in a safe direction away from people, pets or
anything around you that may be damaged by direct or indirect abrasive
spray.
7. Press and hold the sandblasting gun trigger until abrasive medium is flowing
through the nozzle.
TO STOP BLASTING
1. Release the trigger on the sandblasting gun.

8
MAINTENANCE
REPLACING THE NOZZLE
After 10-12 hours of blasting time the nozzle should be checked for wear. The
nozzle will wear out overtime and should be replaced when the hole is no longer
round or the abrasive media does not flow smoothly through it. To replace the
nozzle:
1. Disconnect the sandblasting gun from the air hose.
2.
Nozzle
Unscrew the nozzle adaptor,
located at the front of the
sandblasting gun.
3. Remove the old nozzle.
4. Insert new nozzle.
• Replacement nozzles are
available from your Clarke
dealer Part number 7640122
5. Replace the nozzle adapter and
firmly screw it onto sandblasting gun.
• Keep your sandblaster clean and protect it from damage.
• Check for worn abrasive hose and fittings. Watch for leaks, blistering,
bulging or thinning of the hose.
• Replace any parts which appear worn.
PARTS AND SERVICING
For Parts & Servicing, please contact your nearest dealer, or
CLARKE International, on one of the following numbers.
PARTS & SERVICE TEL: [phone]
PARTS & SERVICE FAX: [phone]
or e-mail as follows:
PARTS: [email protected]
SERVICE: [e-mail]

9
SPECIFICATIONS
CSB34
Sand Grade Type Up to 60 Grit (Clarke AOP60)
Abrasive Material Aluminium Oxide, Garnet Powder,
Glass Bead
Drum Capacity: 34 Litres (7.5 UK gallons)
Sand Capacity: (kg/lbs) 22.6/50
Working Pressure: 6 - 8 bar (87 - 116 psi)
Flow Rate Required: (cfm) 10 - 16
Compressor Size Hp: (Minimum) 3
Gun Inlet Size: 3/8” hose adaptor fitted
Air Inlet Hose Diameter: 3/8” (10mm)
Nozzle Sizes: (mm) 4, 5, 6, 7 (Ceramic)
Dimensions (Length x Width x Height) 490 mm x 430 mm x 895 mm
Weight 8.5 Kg
