Classic Exhibits visionary DESIGNS MOD-1109 Manual

© 2018
Order #XXXXX
*
Completed Assembly
Shelf
Infill
Infill
Infill Counter Top
Puck Light
Literature
Holder
Plex Counter
Screw
Cap
3
7A 45A
1
2
5
Door
6
7
7
Item
1
2
3
4
5,5A
6,6A
7,7A
Qty.
1
1
1
1
1,1
1,1
2,2
Description
38” RSG560 Vertical Extrusion w/ Door Stop
42” RSG530 Vertical Extrusion
42” RSG530 Vertical Extrusion
38” RSG560 Vertical Extrusion w/ S44
41.5” Z45 Curved Horizontal Extrusion
41.5” Z45 Curved Horizontal Extrusion
16” Z45 Horizontal Extrusion
Shelf
Support
Extrusions [1] [2] [7] and
[7A] stay assembled for
packing.
Extrusions [3] [4] [7] and
[7A] stay assembled for
packing.
*
*
*
7A
6A
Connector
Literature Holder Attachment
Locks
Literature
Holder
Attach angled end of connector to
literature holder. Attach flat end of
connector to vertical [2]. Tighten
locks to secure.
*
2
Door
Hinge
Hinge
Pin
Slide pin into
hinge attached
to vertical.
Slide door
hinge over pin.
Door Connection
*
*
*
Screw
Cap
Align hole with pin Rotate pin. Spring
will push pin into hole.
Counter Top Lock
12
*
Pin
Hole
Steps:
1) Assemble back panel by connecting verticals [1] and [4] with horizontals [5] and [5A].
2) Assemble front panel by connecting verticals [2] and [3] to curved horizontals [6] and [6A],
placing infill between, making sure Velcro faces inside counter.
3) Connect front and back panels together with horizontals [7] and [7A],
placing infill between.
4) Attach shelf supports to Velcro inside infills, then place shelf on top.
5) Connect door to vertical [3]. See Door Connection detail.
6) Slide counter top over verticals [2] and [3]. See Counter Top Lock detail.
7) Attach plex counter to verticals [2] and [3], using screw caps.
8) Attach literature holders to vertical [2]. See Literature Holder Attachment detail.
9) Connect puck light cord to power.
MOD-1109 Counter
SETUP INSTRUCTIONS
If you would like to tell us about your experience with your setup instructions please email us at [email protected]

© 2018
Case 1 of 1
Order #XXXXX Case Packing
Setup Hardware
Top View of Each Level
Level 1 Level 2 Level 3 Level 4 Level 5 Level 6
Counter Top Shelf
5,5A
6,6A
Door
Infill
Assembled
Side
Assembled
Side
Plex
Counter
