Claypaky TAMBORA LINEAR 100 User manual

IN TRUCTION MANUAL
Congratulations on choosing a Claypaky product!
We thank you for your custom.
Please note that this product, as all the others in the
rich Claypaky range, has been designed and made with
total quality to ensure excellent performance and best
meet your expectations and requirements.
INDEX
ENGLI H
Page Contents
2 1. afety information
3 2. Unpacking and preparation
3 3 Installation and start-up
3 3.1 Fixture overview
4 3.2 nstalling the fixture
5 3.3 Connecting to mains supply
5 3.4 Connecting the control signal line: DMX / Art-Net
6 3.5 Switching on the fixture and basic SetUp
7 4. Maintenance
7 4.1 Fuses replacing
8 4.2 Periodical cleaning & Caution
9 4.3 Battery removal
10 5. pecifications
10 6. Cause and solution of problems
CL2019
TAMBORA LINEAR 100

2
TAMBORA LINEAR 100
EN
IT
DE
E
FR
RU
AFETY INFORMATION
MPORTANT: Claypaky recommends you carefully read and keep the safety information on this product, also
available in digital format at the following link:
www.claypaky.com
Ref: F S02C – Safety nformation Tambora Linear 100
INFORMAZIONI DI ICUREZZA
MPORTANTE: Claypaky raccomanda di leggere accuratamente e conservare le informazioni di sicurezza relative
a questo prodotto, sempre reperibili in versione digitale al seguente link:
www.claypaky.com
Rif: F S02C – Safety nformation Tambora Linear 100
INFORMATIONEN ZUR ICHERHEIT
W CHT G: Claypaky empfiehlt, die Sicherheitsinformationen bezüglich dieses Produkts genau zu lesen und
aufzubewahren. Sie sind in Digitalversion immer unter folgendem Link auffindbar:
www.claypaky.com
Ref: F S02C – Safety nformation Tambora Linear 100
INFORMACIONE DE EGURIDAD
MPORTANTE: Claypaky recomienda leer detenidamente y conservar la información de seguridad relativa a este
producto. Además, está disponible una versión digital de la misma en el siguiente enlace:
www.claypaky.com
Ref: F S02C – Safety nformation Tambora Linear 100
CON IGNE DE ÉCURITÉ
MPORTANT: Claypaky recommande de lire attentivement et de conserver les informations de sécurité relatives
à ce produit, disponibles en version digitale au lien suivant:
www.claypaky.com
Réf. : F S02C – Safety nformation Tambora Linear 100
ИНСТРУКЦИЮ ПО ТЕХНИКЕ БЕЗОПАСНОСТИ
ВАЖНО: Claypaky рекоменд ет внимательно прочитать и сохранить инстр кцию по технике безопасности
данного изделия, которая всегда дост пна в электронном формате по след ющей ссылке:
www.claypaky.com
Наименование: F S02C - Safety nformation Tambora Linear 100
1. AFETY INFORMATION

3
TAMBORA LINEAR 100
1
Packing contents - Fig. 1
2. UNPACKING AND PREPARATION
Neutrik PowerCON
TRUE1 (IN/OUT)
LCD Display
User buttons
Safety loop
5pin DMX IN/THRU
Ethernet
Fuse
Fan
Fan
Handle
Fan
Fan
2
3. IN TALLATION AND TART-UP
3.1 Fixture overview
Continue ‘

4
TAMBORA LINEAR 100
1
1
2
3
Projector installation - Fig. 3
The projector can be installed on the floor resting on specific rubber feet, on a truss, on the ceiling or wall.
WARNING: the safety chain must be installed except when the projector rests on the floor. (Code 105041-003 available upon request).
This must be secured to the projector support structure and then hooked to the fastening point at the centre of the fixture.
3.2 Installing the fixture

5
TAMBORA LINEAR 100
Continue ‘
Connections to the power mains - Fig. 5
Power
Supply
1
2
3
2
1
Connecting and disconnecting the power cord - Fig. 4
4
5
DMX 512
SIGNAL
SCREEN
DMX 512
5 PIN
1
2
3
4
5
SIGNAL
Ethernet
Connections to the control signal line (DMX) - Fig. 6
Use a cable conforming to specifications E A RS-485: 2-pole twisted, shielded, 120Ω characteristic impedance, 22-24 AWG, low capacity. Do not use
microphone cable or other cable with characteristics differing from those specified. End connections must be made using XLR type 5-pin male/female
connectors. A terminating plug must be inserted on the last projector with a resistance of 120 (minimum 1/4 W) between terminals 2 and 3.
IMPORTANT: The wires must not make contact with each other or with the metal casing of the connectors. The casing must be connected to the
shield braid and pin 1 of the connectors.
NB: connecting one
Tambora Linear 100 to the mains,
it is possible to connect up to a maximum
of 5 @200-240Vac - 1 @100-120Vac
Tambora Linear 100 in parallel
at the same time Max 2400W.
6
3.3 Connecting to mains supply
3.4 Connecting the control signal line: DMX / Art-Net

TAMBORA LINEAR 100
6
witching on the projector - Fig. 7
Switch-on the fixture. The projector starts resetting the effects. At the same time, the following information scrolls on the display:
Model Firmware Dmx Address xxx ystem errors
Tambora Version X.X.X .........................
Linear 100 Date - Hour .........................
The control panel (Fig. 7) has a display and buttons for the complete programming and management of the projector menu. The display can be in one
of two conditions: rest status and setting status. When it is in the rest status, the display shows the projector’s DMX address.
During menu setting status, after a wait time (about 30 seconds) without any key having been pressed, the display automatically returns to rest status.
t should be noted than when this condition occurs, any possible value that has been modified but not yet confirmed with the
F
key will be cancelled.
1
Dmx Address
War ning Message
7
3.5 witching on the fixture and basic etUp
28
28
Reversal of the display - Fig. 8
To activate this function, press UP
B
and DOWN
C
keys simultaneously while the display is in the rest mode. This status will be memorised and
maintained even for the next time it will be switched on. To return to the initial state, repeat the operation all over again.
etting the projector starting address
On each projector, the starting address must be set for the control signal (addresses from 1 to 512).
The address can also be set with the projector switched off.
8
Functions of the buttons - Using the menu
Confirms the displayed value, or activates the displayed function, or enters the successive
menu.
Decreases the value displayed (with auto-repetitions) or passes to the next item in the menu.
ncreases the value displayed (with auto-repetitions) or passes to the previous item in a menu.
Return to the top level
Enters the successive menu
F
C
DOWN
B
UP
D
LEFT
E
R GHT

7
TAMBORA LINEAR 100
Fuse replacing - Fig. 9
Each Tambora Linear 100 has 1 fuse 10AT 250V, associated with the main power cord connection.
1
10AT 250V
9
Continue ‘
4. MAINTENANCE
4.1 Fuses replacing
etting addresses and options with the projector disconnected
The projector’s DMX address, as well as other possible operating options, can also be set when the appliance is disconnected from the electricity
supply. All that is needed is to press
R GHT
E
to momentarily activate the display and thus access the settings. Once the required operations have
been carried out, the display will switch off again after a wait time of 30 seconds.
U ING THE MENU:
1) Press LEFT
D
once – “Main Menu” appears on the display.
2) Use the UP
B
and DOWN
C
keys to select the menu to be used:
• Setup (Setup Menu): To set the setting options.
• Option (Option Menu): To set the operating options
• nformations ( nformations Menu): To read the counters, software version and other information.
• Manual Control (Manual control Menu): To trigger the test and manual control functions.
• Test (Test Menu): To check the proper functionning of effects
• Advanced (Advanced Menu): Access to the "Advanced menu" is recommended for a trained technical personnel.
3) Press
F
to display the first item in the selected menu.
4) Use the UP
B
and DOWN
C
keys to select the MENU items.

WARNING:
no alcohol
8
TAMBORA LINEAR 100
10
CAUTION:
•To ensure optimal operation and performance for a long time it is essential to periodically clean the parts subject to dust and grease deposits. The
frequency with which the following operations are to be carried out depends on various factors, such as the amount of the effects and the quality
of the working environment (air humidity, presence of dust, salinity, etc.).
t is recommended that the projector undergoes an annual service by a qualified technician for special maintenance involving at least the
following operations:
- General cleaning of internal parts.
- General visual check of the internal components, cabling, mechanical parts, etc.
- Electrical, photometric and functional checks; eventual repairs.
Cleaning the LED cover
Only use neutral soap and water to clean the LED cover, then dry it carefully with a soft, non-abrasive cloth. (WARN NG: the use of alcohol or any other
detergent could damage the LED cover).
4.2 Periodical cleaning & Caution
Parts requiring frequent cleaning.
Light collimation system
This product contains internal light
collimation system. Avoid intense
light from any angle.

9
TAMBORA LINEAR 100
This product contains a rechargeable battery. To preserve the environment, please dispose the battery at the end of its life according to the
regulation in force.
11
4.3 Battery removal

74
(2.91")
Rotating angle
1000
(39.37")
172
(6.77")
180°
5. DIMEN ION
10
TAMBORA LINEAR 100
THE PROJECTOR W LL NOT SW TCH ON
TROUBLE
ELECTRON CS NON-OPERAT ONAL
DEFECT VE PROJECT ON
REDUCED LUM NOS TY
POSSIBLE CAUSES CHECKS AND REMEDIES
No power supply.
LED burnt out or defective.
Signal transmission cable faulty or disconnected.
ncorrect addressing.
Fault in the electronic circuits.
Optic fault.
Dust or grease deposits.
Check the power supply voltage.
Call an authorised technician.
Replace the cables.
Check addresses (see instructions).
Call an authorised technician.
Call an authorised technician.
Clean (see instructions).
6. CAU E AND OLUTION OF PROBLEM

11
TAMBORA LINEAR 100

ST02M – EN - Rev.0 11/2022
CLAYPAKY .p.A. - Via Pastrengo, 3/b - 24068 Seriate (BG) taly - Tel. [phone] - www.claypaky.com
