Clear-Com BP410 User manual

Quick Reference Guide
BP410
1. Battery
2. Increase Volume button (▲)
3. Decrease Volume button (▼)
4. PWR (Power) button
5. Headset cable connector
6. Battery-release latch
7. Power/Mode lights
8. Channel A (Intercom 1) button - Includes 2-wire and
4-wire connections
9. ISO (Isolate) button - To All Wireless Headsets and
Beltpacks, Base, ISO Relay and AUX OUT
(if activated)
10. Channel B (Intercom 2) button - Includes 2-wire
and 4-wire connections
The Beltpack Beltpack Setup
7 78 9 10
21 64 3 5
Part Number: 399G214 Rev A
Date: 12/5/16
Copyright © 2016 Clear-Com, LLC, an HM Electronics, Inc. company. All rights reserved.
Clear-Com, the Clear-Com logo and Clear-Com Concert are trademarks or registered trademarks of HM Electronics, Inc.
Battery RELEASE BATTERY button
Belt clip
Headset
cable plug
¾Insert a fully charged battery in each Beltpack with the
metal contacts inserted rst. Slide it in until it snaps.
NOTE: The battery will not slide in if inserted
incorrectly. Excessive force should not be necessary.
¾Plug the Beltpack’s headset cable connector into each
Beltpack.
BP410 Beltpack Settings
To Set: All functions are from an off state. Press the Power button and release with the
appropriate buttons below.
ISO restrict On A button
ISO restrict Off A button and ISO buttons
Handsfree On selected button(s) A button and/or B button and/or ISO and Volume up button (▲)
Handsfree Off selected button(s) A button and/or B button and/or ISO and Volume down button (▼)
Listen-Only mode On Volume down button (▼)
Listen-Only mode Off Volume up button (▲)
To Set: With the power already on...
Increase mic gain (15 steps) Press the B button while repeatedly pressing the Volume up button (▲)
Decrease mic gain (15 steps) Press the B button while repeatedly pressing the Volume down button (▼)
Increase sidetone level (5 steps) Press the A button while repeatedly pressing the Volume up button (▲)
Decrease sidetone level (5 steps) Press the A button while repeatedly pressing the Volume down button (▼)

Register Beltpack
¾Make certain the Beltpack is turned Off.
¾Press REG button on base station.
– STATUS display on the base station shows “o” for registration mode.
¾On the Beltpack, press and hold ISO while pressing POWER and then release all buttons.
– The power lights blink red, then green and then turn off. One power light remains green.
– The registration number will appear on the base station STATUS display.
AUTO NULL Adjustment (only if using 2-wire interface)
If echo is heard in wireless Beltpacks on A or B:
¾Use pointed object (e.g. pen) to press and hold the A or B AUTO NULL button for 2 seconds.
CAUTION: Before pressing an AUTO NULL button, be certain there are no open microphones on the wired
system. Notify wired system users that a loud noise may occur in their headsets during the auto null adjustment.
The system may be out of operation for approximately 50 seconds during this adjustment.
Local Headset Communication
¾SEL button selects communication with A, Bor ISO.
– A, Bor ISO lights indicate selection.
¾TALK button
– Press and release quickly to “latch on” for open communication.
– Press and hold while talking for momentary communication – release when nished.
¾VOLUME control adjusts the audio level in local headset ear piece.
¾MIC LEVEL control adjusts the audio level going out from local headset microphone.
Power Switch
STATUS AUTO NULLREG
Beltpack
Registration
Audio Channel and
Auto-Null Controls
Local Headset
Controls
The DX410 Console
Technical Support
In The Americas and Asia – Tel: [phone] or 1.800.462.4357 Menu option 1 • Hours: 8:00am-5:00pm Pacic Time • Web: www.clearcom.com
In Europe, Middle East and Africa – Tel: [phone] • Hours: 8:00am-5:00pm GMT • Email: [email protected]
General Use
Beltpack Sidetone Adjustment:
¾Press and hold the A button while you repeatedly press up (▲) to increase or press down (▼) to decrease
audio levels.
Changing the battery:
¾When a Beltpack battery becomes weak, a headset voice prompt will say “Change battery.”
¾Press the RELEASE BATTERY button on the belt clip of the pouch, and use your thumb to slide the battery
from the belt-pac.
¾When charging the battery using the AC50 Battery Charger, the charging time is about 2.5 hours.
