CLEAR DESIGN BLDLS User manual

BLDLS
STORAGE–
SUPPORTED
WORKSTATION
LOW OPEN-SHELF LATERAL
LOW BOX/FILE LATERAL
MERGING TOP
Includes Add-Ons: A1 | A2 | A3 | A4
General Installation Guide

TABLE OF CONTENTS
EDITION CODE
BLLBFV2 :: Low Open-Shelf Lateral.................................1
BLLOSV2 :: Low Box/File Lateral.....................................9
GBLLT2 :: Merging Top....................................................... 13
BLDLS :: L-Shape with Storage ....................................... 19
ADD-ONS
A1 :: Surface-Mount Cable Management Tray........... 25
A2 :: Modesty Panel............................................................. 29
A3 :: Laminate Inset End Panels..................................... 33
A4 :: Steel Inset End Panels ............................................. 37

LOW OPEN-SHELF LATERAL
OVERVIEW
Storage-Supported Workstation
All parts listed are for a single low open-shelf
lateral; additional parts will be needed for additional
low open-shelf laterals.
1

2
LOW OPEN-SHELF LATERAL
CODE QTY DESCRIPTION
BLLOSV2
1Top Panel*
1Bottom Panel
1Fixed Shelf Panel
2End Panels
1Back Panel
4Corner Feet
*If installing a merging topper, disregard top panel item.
PARTS LIST

3
LOW OPEN-SHELF LATERAL
1 | SCREW CAM PINS INTO BOTTOM PANEL
Requires 6 cam pins.
2 | INSERT HARDWARE INTO END PANELS
Requires 4 wooden dowels, 4 cam locks, and 4 cam pins.
Cam Lock
Wooden Dowel
Cam Pin
Cam Pin

4
LOW OPEN-SHELF LATERAL
3 | INSERT HARDWARE INTO BACK PANEL
Requires 2 cam pins and 8 cam locks.
4 | INSERT CAM LOCKS INTO FIXED SHELF
Requires 6 cam locks.
Cam Lock
Cam Lock
Cam Pin

5
LOW OPEN-SHELF LATERAL
5 | SECURE FIXED SHELF TO BACK PANEL
Align the cam pins so they sit inside of open cam locks. Use a screwdriver to turn
cam locks clockwise and lock into place.
6 | SECURE END PANELS
If working with a surface 72” or longer, use 10 wood screws to install
support bar under the surface.
Tighten Cams
Tighten Cams

6
LOW OPEN-SHELF LATERAL
7 | SECURE BOTTOM PANEL
Align the cam pins so they sit inside of open cam locks. Use a screwdriver to turn
cam locks clockwise and lock into place.
8 | SECURE TOP PANEL
Note: DO NOT Install top panel if you are merging storage.
Align the cam pins so that they sit inside of open cam locks. Use a screwdriver
to turn cam locks clockwise and lock into place.
Tighten Cams
Tighten Cams

7
LOW OPEN-SHELF LATERAL
9 | SECURE FEET TO BOTTOM PANEL
Attach corner feet to the bottom panel with 4 wood screws per foot.

8
END OF LOW OPEN-SHELF LATERAL SECTION

LOW BOX/FILE LATERAL
OVERVIEW
Storage-Supported Workstation
All parts listed are for a single low box/file
lateral; additional parts will be needed for additional
low box/file laterals.
9

10
LOW BOX/FILE LATERAL
CODE QTY DESCRIPTION
BLLBFV2
1Low Box/File Lateral
2Handles
4Corner Feet
PARTS LIST

11
LOW BOX/FILE LATERAL
1 | SECURE FEET TO STORAGE AND FLIP
Flip storage piece so it is laying on its back; secure foot to each corner using 4
wood screws.
2 | ATTACH HANDLES
Using 2 bolts each, attach handles to front of drawers.

12
END OF LOW BOX/FILE LATERAL SECTION

MERGING TOP
OVERVIEW
Surface-Supported Workstation
All parts listed are for a single merging top;
additional parts will be needed for additional
merging tops.
13

14
MERGING TOP
CODE QTY DESCRIPTION
BLLBFV2 1Low Box/File Lateral
BLLOSV2 1Low Open-Shelf Lateral
GBLLT2 1Laminate Merging Top
PLB.1 12 Laminate Storage L-Bracket
WD.2 24 Wood Screws
PARTS LIST

15
MERGING TOP
2 | REMOVE STORAGE TOP
Locate the 6 cam locks across top edge on the inside of the storage piece. Then,
use a screwdriver to turn cam locks counterclockwise to unlock. Carefully lift top
from storage.
1 | REMOVE DRAWERS FROM LOW BOX/FILE LATERAL
15

16
MERGING TOP
4 | ATTACH TOP TO STORAGE
Set storage side-by-side then align top panel so it is flush with sides, back, and
front of storage. Secure the 12 laminate storage L-brackets to top panel using
wood screws.
3 | CONNECT BRACKETS TO TOP PANEL
Attach 12 laminate storage L-brackets to inside of storage using wood screws in
the places shown below.
Top View

17
MERGING TOP
5 | INSERT DRAWERS
17
