Congratulations
Congratulations on the purchase of your state-of-the-art security system.
Reading this Owner’s Guide prior to using your system will help maxi-
mize the use of your system and its many features. For any additional
questions please contact your authorized Directed dealer or contact
Directed at 1-800-753-0600.
Important information
Government Regulations and Safety information
Read the Government Regulations and Warning! Safety
First sections of this manual prior to operating this system.
Warning! Failure to heed this information can result in
death, personal injury or property damage and may also
result in the illegal use of the system beyond its intended
purpose.
Optional Remote Controls
A choice of two optional remote controls with additional features is
also available for use with your system. These remote control choices
are: LED 2-way (P/N 7856) and LCD 2-way (P/N 7756). See your
authorized dealer for purchasing details. Once purchased, please
go online to our website (listed on the back cover) and use system
model number 3806 or 3706 respectively to search for the appropri-
ate owner’s guide, which provides instructions on how to use these
remote controls.

Replacement Remote Controls
Please see your authorized dealer or visit us at www.directedstore.
com to order additional remote controls , or the optional LED and LCD
remote controls. Remote control part numbers are found on the back
of the device.
Your Warranty
Your system comes with a warranty. The warranty terms are detailed at
the end of this guide. Make sure that you receive the proof of purchase
from your dealer, indicating the product was installed by an autho-
rized Directed dealer.

Contents
Getting Started.................................................................................................... 3
Keys to using this manual...................................................................... 3
Remote Control ................................................................................................... 4
Control Center .................................................................................................... 4
Using your System............................................................................................... 5
Commanding the system....................................................................... 5
Performing Commands ......................................................................... 5
Remote Control Command table ............................................................ 6
Basic Commands (Direct Access) .......................................................................... 7
Arm ................................................................................................... 7
Disarm ............................................................................................... 7
Remote Start/Aux 1/Aux 4................................................................... 8
AUX/Trunk.......................................................................................... 8
Advanced Commands: (Level 1) ........................................................................... 9
Silent Arm........................................................................................... 9
AUX 1................................................................................................ 9
Advanced Commands: (Level 2) ......................................................................... 10
Sensor Bypass ................................................................................... 10
Remote Valet .................................................................................... 10
AUX 2.............................................................................................. 10
Advanced Commands: (Level 3) ......................................................................... 11
Sensor Silent Arm .............................................................................. 11
AUX 3.............................................................................................. 11
Advanced Commands: (Level 4) ......................................................................... 12
Full Silent Arm ................................................................................... 12
AUX 4.............................................................................................. 12
Remote Control Configuration ............................................................................ 13
Remote Programming ......................................................................... 13
Remote Pairing ................................................................................. 13
Remote Features ............................................................................... 14
Sensor Adjust .................................................................................... 15
Alarm Features ................................................................................................. 16
Normal Arm Protection....................................................................... 16
Sensor Silent Arm protection ............................................................... 16
Sensor Warn-away output .................................................................. 17
Full Trigger output .............................................................................. 17
Emergency Override .......................................................................... 17
Trigger Zone Fault Report.................................................................... 17
Alarm Report..................................................................................... 18
Nuisance Prevention (NPC)................................................................. 18
Remote and System Operations.......................................................................... 19
Passive Arming.................................................................................. 19

Auto Re-arming.................................................................................. 19
Valet Mode ....................................................................................... 20
Power Save....................................................................................... 20
Rapid Resume ................................................................................... 20
Car Select......................................................................................... 20
System Expansion Options................................................................................. 21
Battery Information............................................................................................ 23
Low Battery Alerts .............................................................................. 23
Battery Replacement........................................................................... 23
Battery Disposal ................................................................................ 23
Patent Information ............................................................................................. 24
Glossary of Terms.............................................................................................. 25
Government Regulations .................................................................................... 26
Warning! Safety First......................................................................................... 28
Installation ........................................................................................ 28
Interference....................................................................................... 28
Upgrades ......................................................................................... 28
Water/Heat Resistance ...................................................................... 28
Limited lifetime consumer warranty ..................................................................... 29

3
© 2013 Directed. All rights reserved.
Getting Started
Keys to using this manual
Specific actions (in bold type) and style conventions are used consis-
tently throughout this manual, they are as follows:
• Press: implies pushing in and releasing a button.
• Hold: is used after Press actions when a button needs to be held
in position for an extended period of time, typically several sec-
onds.
• Italicized words denote section/sub headings in this guide and
can be located through the table of contents.
• An asterisk (*) when used after a word or phrase denotes that
additional details can be found in related sections usually noted
at the bottom of the page or end of the section.

4© 2013 Directed. All rights reserved.
Remote Control
Feature Description
Internal Antenna Used for transmitting information
Transmit LED Active when transmitting information
Command buttons (4)
A U X
Used to perform arming, disarming, and auxiliary channel
commands
Function button Used to access function levels for commands, configuration
menus for programming and Car Selection
Control Center
Control CenterLED Button
The Control Center, typically located on the upper part of the front
windshield. It consists of:
• The In-vehicle system antenna.
• The Status LED, as a visual indicator of the system’s status.
• The Control button, for placing the system into Valet Mode* and
to perform the Emergency Override** operation.
* See “Remote and System Operations” on page 19 for details.
** See “Alarm Features” on page 16 for more details.

5
© 2013 Directed. All rights reserved.
Using your System
Commanding the system
Commands, Basic or Advanced, are used to activate system features
and are performed by pressing one of the Command buttons. Basic
commands control the most often used security and remote start fea-
tures while Advanced commands control more specialized features.
Confirmations for Basic or Advanced commands are indicated
by siren chirps and parking light flashes. A description of each feature
confirmation is found in the following Basic command and Advanced
command sections.
Performing Commands
Perform Basic commands by pressing a Command button.
Perform Advanced Commands by first accessing Levels 1-4 using the
button and then by pressing a Command button while within a
level.
Advanced command example: Silent Arm
1. Press the button once to access Function Level 1, The trans-
mit LED single flashes for 3 seconds.
2. Press the button while the transmit LED is still flashing to
perform the Silent Arm command.
3. The system will arm, lock the doors and flash the parking lights
without siren chirps.

6© 2013 Directed. All rights reserved.
Remote Control Command table
Button
Level Direct Access x 1
LEVEL 1
x 2
LEVEL 2
x 3
LEVEL 3
x 4
LEVEL 4
Arm/Lock
(Panic)
Silent Arm Sensor
Bypass
Sensor Silent
Arm
Full Silent
Arm
Disarm/Unlock Silent Disarm Remote Valet Car Finder
Remote Start*/
Aux 1/4**
AUX Aux/Trunk AUX 1 AUX 2 AUX 3 AUX 4
Advance Level,
Enter program-
ming (8 sec)
* Available only with optional Remote Start module installation
** This button can command either Aux 1 or Aux 4 if turned on by
an authorized Directed dealer.

7
© 2013 Directed. All rights reserved.
Basic Commands (Direct Access)
Arm
Press and release
The alarm arms, doors lock (if connected), and the siren chirps and
parking lights flash once. If Valet mode* is On, the doors lock without
siren chirps, the alarm is disabled. Exit Valet mode to arm the alarm
normally.
If a trigger zone fault is detected the siren chirps once again and the
control center LED generates a Trigger Zone Fault report**.
To Arm and Panic
Press and hold
The alarm Arms (or Locks in Valet) and, after two seconds, sounds
the siren and flashes the parking lights. Press the or button
to stop the output.
Disarm
Press and release
The alarm disarms, doors unlock (if connected), and the siren chirps
and parking lights flash twice.
An Alarm Report** alert of four or five siren chirps will replace the
normal disarm chirps if the alarm was triggered.

8© 2013 Directed. All rights reserved.
Remote Start/Aux 1/Aux 4
Press and release
Remote Start ***
Activates (or if On, deactivates) the remote starter. The engine and
parking lights turn On, or the engine and parking lights turn Off ac-
cordingly.
AUX1/AUX4 ****
Activates (or if on, deactivates) the aux 1or aux 4 output..
AUX/Trunk
Press and hold AUX
The Trunk opens (if connected) when this button is pressed for 2 sec-
onds.
* See “Remote and System Operations” on page 19.
** See “Alarm Features” on page 16 for more details.
*** Available only with optional Remote Start module installation.
**** This feature must be turned on by an authorized Directed dealer.

9
© 2013 Directed. All rights reserved.
Advanced Commands: (Level 1)
Press and release the button one time first, before pressing one of
the following command buttons. The transmit LED illuminates in sets of
single flashes to indicate Level 1.
Silent Arm
Press and release
The alarm arms, doors lock (if connected), and the parking lights flash
once.
Silent Disarm
Press and release
The alarm disarms, doors unlock (if connected), and the parking lights
flash twice. The Silent Disarm output may be replaced by the Alarm
Report*
AUX 1
Press and release AUX
Activates (or if On, deactivates) the Aux 1 output.
* See Alarm Features for details.

10 © 2013 Directed. All rights reserved.
Advanced Commands: (Level 2)
Press and release the button two times first, before pressing one of
the following command buttons. The transmit LED illuminates in sets of
double flashes to indicate Level 2.
Sensor Bypass
Press and release
Performing the Sensor Bypass command will incrementally bypass sen-
sor operations and be confirmed as follows:
• Warn-away bypass: The Parking lights flash two times. Sensors
will be activated for Full Trigger levels of impact only.
• Warn-away & Full trigger bypass: The Parking lights flash three
times. Sensors will not be activated for any level of impact.
• Sensor Bypass off: The Parking lights flash 1 time. Sensors are
fully operational.
Note System needs to be armed to perform Sensor Bypass.
Perform arm command any time to turn Sensor Bypass Off.
Remote Valet
Press and release
Enters (or if On, exits) Valet Mode. The Control Center LED turns on
and off accordingly.
AUX 2
Press and release AUX
Activates (or if On, deactivates) the Aux 2 output.

11
© 2013 Directed. All rights reserved.
Advanced Commands: (Level 3)
Press and release the button three times first, before pressing one
of the following command buttons. The transmit LED illuminates in sets
of triple flashes to indicate Level 3.
Sensor Silent Arm*
Press and release
The alarm arms, doors lock, and the siren chirps and parking lights
flash three times.
Car finder
Press and release
The siren emits one long chirp and the parking lights flash for 10 sec-
onds. The parking light flashes stop if armed or disarmed while Car
Finder is in progress.
AUX 3
Press and release AUX
Activates (or if On, deactivates) the Aux 3 output.
* See “Alarm Features” on page 16 for more details.

12 © 2013 Directed. All rights reserved.
Advanced Commands: (Level 4)
Press and release the button four times first, before pressing one of
the following command buttons. The transmit LED illuminates in sets of
quadruple flashes to indicate Level 4.
Full Silent Arm*
Press and release
The alarm arms, doors lock, and the siren chirps and parking lights
flash four times.
AUX 4
Press and release AUX
Activates (or if On, deactivates) the Aux 4 output.
* See “Alarm Features” on page 16 for more details.

13
© 2013 Directed. All rights reserved.
Remote Control Configuration
The remote controls have operations that can be configured to a user’s
personal preferences. The following instruction directs you through the
available programming options for both remote controls.
Remote Programming
To Enter Programming: Press and hold the button for eight sec-
onds, the transmit LED turns on to indicate the Main Menu is accessed.
To Exit Programming: Press and release the button once then press
and hold the button again until the transmit LED shuts off.
Remote Pairing
The following instruction will step you through the remote pairing op-
eration.
Prepare the vehicle system for pairing:
1. Open at least one of the vehicle’s doors.
2. Turn the key to the ON position.
3. Within five seconds press and release one time the Control but-
ton on the Control Center.
4. Within five seconds, press and hold the Control button. The sta-
tus LED will flash one time and the siren will chirp once to confirm
the system is ready for remote pairing.
5. Release the Control button and proceed to next step.
Prepare the remote control for pairing:
6. Enter programming to access the Main Menu as explained previ-
ously.
7. Press and hold the button for 1 second, 3 transmit LED flash-
es indicate the remote control is ready to pair.

14 © 2013 Directed. All rights reserved.
8. Press the button.
9. Wait several seconds as the remote generates a security encryp-
tion and sends it to the Control Center. The siren chirps to indi-
cate Pairing is complete.
If pairing is not successful press and release the button once
and then repeat steps 7 and 8.
Pairing will exit if:
• Step 7 is not completed within 60 seconds
• The doors are closed
• The ignition is turned off.
Remote Features
Enter programming to access the main menu as previously explained,
then from the main menu, press and hold the button to access the
remote operation features, two transmit LED flashes indicate the remote
features menu is accessed. Press the buttons indicated in the tables
below to set the feature option.
The remote control will flash the Transmit LED to indicate the setting.
Feature Button Press Single Flash Double Flash
Keypad Lock Auto Off *
Button Beeps On* Off
Car 2 Car 2 On Car 2 Off *
* Indicates default setting.

15
© 2013 Directed. All rights reserved.
Keypad Lock
Options: Off, Auto
When Off, the buttons do not lock and always perform a com-
mand when pressed. When set to Auto, the remote buttons lock
after a 20 second lapse between button presses to prevent unin-
tentional operations.
To unlock the buttons, press the button followed by the
button.
Note If a button is pressed when locked, a fault tone plays as an
alert. To unlock the buttons, press the button followed
by the button, tones are emitted to confirm unlocking.
Car 2
Options: Off, On
The remote controls can control two systems independently.
When set to Off, the Car Select feature is not available. When
set to On the Car Select feature is enabled. See Car Select (un-
der Remote and System Operations) for detail on using a remote
with two systems.
Sensor Adjust
To avoid unintended alarm triggers; it is recommenced that an autho-
rized Directed dealer performs all sensor adjustments.

16 © 2013 Directed. All rights reserved.
Alarm Features
Normal Arm Protection
Status LED: The Control Center Status LED flashes as a visual indicator
that your vehicle’s security system is active.
Starter Kill: The Failsafe starter kill relay prevents the engine from
starting
Note May require additional parts and installation
Sensor triggers: The shock sensor can distinguish minor impacts from
major impacts to the vehicle exterior. Minor impacts causes the system
to emit a Warn-away output. Major impacts caused for example by a
forcible entry attempt, results in a Full Trigger output.
Point of entry triggers: Opening the hood or trunk causes a Full Trig-
ger output, while opening a Door or turning on the Ignition causes
the the siren to chirp three seconds before beginning the Full Trigger
output. This three second delay allows time to disarm and silence the
siren in case of accidental trigger.
Sensor Silent Arm protection
Sensor Warn-away and Sensor Full Trigger activations are defeated.
Point of entry triggers will activate the Full Trigger output.
Full Silent Arm Protection
Sensor Warn-away, Sensor Full Trigger and Point of Entry activations
are defeated. Only the Ignition input will activate the Full Trigger out-
put.

17
© 2013 Directed. All rights reserved.
Sensor Warn-away output
When the system sensors detect a Warn-away trigger the siren chirps
and parking lights flash for 3 seconds.
Full Trigger output
An alarm Full Trigger will sound the siren and flash the parking lights
for 30 seconds.
Emergency Override
The following procedure disarms the system when a programmed re-
mote is not available. Number of presses__________
1. Turn the ignition On.
2. Press the control button on the Control Center the correct
number of times (the default is one press).
3. After a few seconds the siren output ceases and the system
is disarmed.
Note As a precaution, if programmed for Passive Arming or Auto
re-arming the system should be placed into Valet Mode until
a remote is available .
Trigger Zone Fault Report
When armed by remote command the system runs a status check of
the alarm trigger zones. Faulty zones (usually caused by dome light
delay or open trunk) are bypassed and reported via the control center
LED, while all other trigger zones remain active and are monitored to
protect the vehicle. Should a faulty zone self correct (dome light turns
off) it becomes active and is then monitored normally.
The siren chirps once again a few seconds following the arming
chirps as an audible alert, the control center LED flashes in groups to
indicate the zone number.
