Coca-Cola Freestyle 7000 User manual

© 2020 The Coca-Cola Company | Coca-Cola Freestyle® 7000 User Guide | Confidential information of The Coca-Cola Company | 20200821 | 1
7OOO User Guide

Coca-Cola Freestyle® 7OOO utilizes micro-dosing technology and stores all
beverage components separately until the moment the drink is poured, ensuring
a fresh, great tasting beverage every time.
This guide provides general tips and
proper maintenance procedures for your
Coca-Cola Freestyle® 7000 dispenser.

© 2020 The Coca-Cola Company | Coca-Cola Freestyle® 7000 User Guide | Confidential information of The Coca-Cola Company | 20200821 | 1
contents
maintenanceequipment
external components ••••••••••••••••••••••2
internal and under the counter components ••••••••3
equipment
operations
product replacement
maintenance
For crew training videos, visit
iLearnCoca-ColaFreestyle.com
cleaning nozzle, injector ring, and ice chute •••••••• 15
cleaning drain and exterior surfaces •••••••••••• 16
cleaning and filling ice bin •••••••••••••••••• 17
small parts and cleaning tips ••••••••••••••••• 18
daily, weekly, and monthly checklist •••••••••••• 19
manager lock mode ••••••••••••••••••••••20
activate calorie counter display feature •••••••••• 21
ingredient cartridge overview •••••••••••••••••8
when to replace an ingredient cartridge •••••••••••9
how to replace an ingredient cartridge •••••••••••10
HFCS (sweetener) dashboard reset ••••••••••••• 11
replacing sweeteners (HFCS & NNS) ••••••••••••• 12
Coca-Cola Freestyle Boost •••••••••••••••••• 13
pouring a drink ••••••••••••••••••••••••••4
(standard and ADA interface)
mobile pour ••••••••••••••••••••••••••••5
accessing the crew dashboard •••••••••••••••••6
using the freestyle operating system •••••••••••••7resources
Crew Connect •••••••••••••••••••••••••••22

2| © 2020 The Coca-Cola Company | Coca-Cola Freestyle® 7000 User Guide | Confidential information of The Coca-Cola Company | 20200821
external components
Ice bin lid*
Cartridge access door
Key (access door)
Touch screen
Nozzle and injector ring
Beverage dispense lever
Ice chute
Ice dispense lever
ADA interface
Cup rest and drain pan
The cartridge area is accessible
by unlocking the key lock
(pictured in the diagram).
• For several reasons, including food
safety, it’s important to keep this
area locked at all times and the key
kept with a manager or in a secured
location (such as a locked oce).
• Additional keys can be ordered
through the Coca-Cola Small Parts
Program at no-cost.
• Should you misplace your key
or experience trouble with
accessing the cartridge area, call
Coca-Cola Phone-Fix®for support at
1-800-241-COKE (2653).
* Not applicable with top mounted ice maker.
equipment

The dispenser is
equipped with two
stand-by modes:
1. Power Saver Mode
If the dispenser is inactive for
20-minutes the touchscreen
will go dark. Simply tap the
touchscreen anywhere to
wake it up.
2. Locked Mode
Lock the dispenser by
pressing the lock icon in the
top right corner of the crew
dashboard. This mode locks
the touch screen and prohibits
dispensing during non-
operating hours. Choose to
lock manually or set an
automated time window.
Power Switch
The power (on/o) switch is
located on the right-hand side
underneath a square plastic
flap. CAUTION! DO NOT
POWER OFF unless instructed
to do so by a Coca-Cola
technician.
© 2020 The Coca-Cola Company | Coca-Cola Freestyle® 7000 User Guide | Confidential information of The Coca-Cola Company | 20200821 | 3
internal and under the counter components
Ingredient cartridge
Cartridge tray
Brand identification strip
Power switch
HFCS 65
CO2tank
Power Switch
Cartridge Tray
equipment

4| © 2020 The Coca-Cola Company | Coca-Cola Freestyle® 7000 User Guide | Confidential information of The Coca-Cola Company | 20200821
pouring a drink
Step one
Place your cup under the ice chute and press
lever to dispense ice.
Step two
Find your favorite beverage using the touch
screen. Note the touch screen will time out after
10 seconds and return to the home screen.
Press to activate the ADA Interface
Press arrow to browse to the right
and press arrow to browse left
Press to pour beverage selected
NOTE: The ADA screen will revert back to
the standard home screen after one minute
of inactivity, or press “ADA Exit Button” in
the upper right corner.
ice dispense lever
pour lever
Select a brand to see all available flavor
options.
Pick your favorite flavor and then use the pour
lever to dispense your beverage.
Balance
what you eat, drink & do.
Small 10 fl oz 120 cal
Medium 12 fl oz 150 cal
Large 20 fl oz 240 cal
Natural flavors.
cherry orange cherry
vanilla
lime vanilla
raspberry
lemon
O
R
I
G
I
N
A
L
T
A
S
T
E
operations
Using the ADA interface
The ADA interface allows people with reach challenges (such as
those in wheelchairs) to use the Coca-Cola Freestyle® dispenser
without having to reach the touch screen.
Assisting Guests with the
Coca-Cola Freestyle Dispenser
Some guests may need a little extra help choosing
and dispensing his/her drink if you have the
Coca-Cola Freestyle dispenser.
If someone looks like they might need assistance
(e.g., he/she is visually impaired or height/reach
challenged), tell your guest that you have the
Coca-Cola Freestyle dispenser and that you would
be happy to assist with his/her beverage choice.
It is up to you to determine whether the above satisfies
your legal and operational obligations.

© 2020 The Coca-Cola Company | Coca-Cola Freestyle® 7000 User Guide | Confidential information of The Coca-Cola Company | 20200821 | 5
Push lever for
ice and place
cup in dispenser
Scan QR code
on dispenser
using your
smart phone
camera. Be sure
to hold your
phone in front
of the QR code,
DO NOT hold it
lower than the
dispenser
screen
Select desired
brand and drink
Press “hold to
pour” button
and release it to
stop. Keep
button pressed
until cup is full.
operations
mobile pour
Mobile Pour allows customers to use their mobile phones to dispense their favorite
Coca-Cola Freestyle beverages without downloading a special app or membership.

6| © 2020 The Coca-Cola Company | Coca-Cola Freestyle® 7000 User Guide | Confidential information of The Coca-Cola Company | 20200821
operations
Crew Dashboard
There are two ways to access the crew dashboard:
Secret Handshake
Opening the cartridge access door.
accessing the crew dashboard
Secret handshake
On the all brands consumer screen, place your
index finger on the lower left of the screen
between the water icon and the red all drinks
button. Hold for 5-6 seconds to launch the crew
dashboard.

© 2020 The Coca-Cola Company | Coca-Cola Freestyle® 7000 User Guide | Confidential information of The Coca-Cola Company | 20200821 | 7
operations
Bold alerts provide clear direction when
maintenance is required.
Improve cartridge change-out management
and reduce product waste, by reading each
ingredient cartridge’s color-coded fuel
gauge displaying the remaining product
percentage and enjoy by date.
Keep in mind, the percentage remaining and
time before changing the ingredient
cartridge may vary significantly. For
example, a flavor cartridge with 6% may
have several days remaining, while a heavily
used ingredient cartridge, like Coca-Cola,
may last only a few hours with 6%.
The time remaining feature provides an
accurate reading when each cartridge will
likely run out. This new feature is calculated
using the dispensers consumption activity
and daypart data to deliver a dynamic and
precise reading throughout the day.
using the freestyle operating system

8| © 2020 The Coca-Cola Company | Coca-Cola Freestyle® 7000 User Guide | Confidential information of The Coca-Cola Company | 20200821
ingredient cartridge overview
product replacement
SmartPAK™ (paperboard) cartridges replace your BIB packaging,
except for HFCS (sweetener) BIB. HFCS will be the only
ingredient located outside of the Coca-Cola Freestyle®
dispenser.
• Always remove and replace ONE CARTRIDGE at a time to avoid inserting it into the
incorrect slot.
• Black plastic cartridge trays should be “hand washed” only using dish soap and
Kay-5 sanitizer or an approved equivalent and NEVER PLACED IN A
DISHWASHER. Placing trays in a dishwasher may warp the trays over time.
• Staging of ingredient cartridges and plastic trays for your most popular brands
and flavors will make the cartridge change-out process more ecient and avoid
delays during peak periods.
• Never stack cartridges more than six (6) high.
• Always ensure ingredient cartridges are organized by “enjoy by dates” to
eectively manage inventory.
• Always use your oldest ingredient cartridges on hand first,
i.e. “FIRST-IN ~ FIRST-OUT”.
• Avoid placing cartridges near any heat source, standing water,
or cleaning solutions.
Proper handling of the ingredient cartridges and plastic
trays is extremely important to ensure proper operation
of the Coca-Cola Freestyle® 7000 dispenser.

© 2020 The Coca-Cola Company | Coca-Cola Freestyle® 7000 User Guide | Confidential information of The Coca-Cola Company | 20200821 | 9
when to replace an ingredient cartridge
The example above shows the Hi-C ingredient
cartridge is empty, as a result the flavor icon is
grayed out and will say “Not Available” when
selected.
Access the crew dashboard
to view the color-coded fuel
gauge displaying the
remaining product percentage.
Keep in mind, the percentage
remaining and time before changing the ingredient
cartridge may vary significantly. For example,
a flavor cartridge with 6% may have several
days remaining while a heavily used ingredient
cartridge, like Coca-Cola, may last only a few
hours with 6%.
NOTE: Time remaining is an estimate based on the
dispensers consumption activity and daypart data.
Replacing ingredient cartridges
starts with knowing when a
cartridge is empty or unavailable.
1 hour
Fanta
remaining
2%
Enjoy by 04/05/19
Cartridge prime procedure.
Priming an ingredient cartridge simply removes
any trapped air in the line and ensures guests
receive a consistent, quality beverage. After
replacing an empty cartridge, follow the on-
screen messages outlined below:
Confirm the cartridge was inserted into
the correct slot and prime by pressing the
orange box on the crew dashboard or press
“Prime All” to prime multiple cartridges.
REMINDER: The prime process lasts
approximately 5-10 seconds. The process should
NEVER be interrupted.
When priming is complete, press exit at the
upper right of the screen. Follow subsequent
prompt on the screen to return to the main
screen.
NOTE: Only press the “Prime All” button ONCE!
Pressing it more than once will needlessly repeat
the prime process.
Navigate to Consumer Interface
Are you sure you want to navigate to the consumer interface now?
ContinueCancel
product replacement

10 | © 2020 The Coca-Cola Company | Coca-Cola Freestyle® 7000 User Guide | Confidential information of The Coca-Cola Company | 20200821
product replacement
Remove the empty ingredient cartridge from
the plastic tray and clean with dish soap,
followed by approved sanitizer solution
(Kay-5).
Dip a clean cloth in approved sanitizer solution,
wipe the probes (that insert into cartridges),
then dip a new clean cloth into the sanitizer
solution and wipe the probes again to sanitize.
Open new cartridge using perforated cartridge
opening flap.
Remove (outer) white dust-cap prior to placing
cartridge into plastic tray.
Always place the ingredient cartridge into
plastic tray and ensure plastic fitment from
cartridge pouch aligns with tray.
Ensure the ingredient cartridge is aligned with
the slot found on the plastic tray.
Remove foil safety seal prior to inserting into
the dispenser.
Insert cartridge into appropriate slot.
Close the dispenser door and follow on-screen
instructions to complete the cartridge prime
process (instructions on page 9).
Remove cartridge and tray from dispenser and separate cartridge
from plastic tray and recycle the outer paperboard box.
Reminder: always replace any missing
or damaged plastic cartridge trays
immediately to prevent dispensing
issues. Replacement trays can be ordered by
calling 1-800-241-COKE (2653) through the
Coca-Cola Freestyle Small Parts Program at
no charge (up to $25/order).
how to replace an ingredient cartridge

© 2020 The Coca-Cola Company | Coca-Cola Freestyle® 7000 User Guide | Confidential information of The Coca-Cola Company | 20200821 | 11
HFCS (sweetener) dashboard reset
When the HFCS BIB is empty, you will need to
replace it and RESET the HFCS module following
these steps:
Ensure HFCS is empty, check the crew dashboard to see if the HFCS
indicator has turned red and says “HFCS Sold out.”
Replace the HFCS (instructions on page 12).
Once the new HFCS box is installed, touch the red HFCS
box to reset and the prime function will automatically follow.
The HFCS BIB indicator changes to a green dot when successfully reset.
NOTE: When the HFCS BIB is empty, all full calorie beverage icons on
the home screen will GRAY OUT.
product replacement
The red square on the crew dashboard
indicates when the HFCS BIB is empty
and needs to be replaced.
24 hours
Coca-Cola
remaining
90%
Enjoy by 02/05/19
24 hours
Fanta
remaining
90%
Enjoy by 02/05/19
3 days
Cherry
remaining
43%
Enjoy by
02/05/19
2 days
Grape
remaining
40%
Enjoy by
02/05/19
1 hour
Raspberry
remaining
3%
Enjoy by
02/05/19
18 days
Orange
remaining
88%
Enjoy by
02/05/19
24 days
Strawberry
remaining
98%
Enjoy by
02/05/19
1 hour
Vanilla
remaining
15%
Enjoy by
02/05/19
11 days
Lemon
remaining
100%
Enjoy by
02/05/19
4 days
Lime
remaining
88%
Enjoy by
02/05/19
10 days
Dasani
Sparkling
remaining
84%
Enjoy by
02/05/19
2 days
Dasani
remaining
62%
Enjoy by
02/05/19
3 hours
Peach
remaining
2%
Enjoy by
02/05/19
2 hours
Lime
Ginger
remaining
2%
Enjoy by
02/05/19
3 days
Coca-Cola Zero
remaining
60%
Enjoy by 02/08/19
21 days
Fanta Zero
remaining
76%
Enjoy by 02/08/19
16 hours
Sprite
remaining
19%
Enjoy by 02/05/19
24 hours
Diet Coke
remaining
90%
Enjoy by 02/05/19
32 days
Powerade
remaining
95%
Enjoy by 02/05/19
3 hours
Diet Coke Caeine Free
remaining
5%
Enjoy by 02/05/19
2 days
Powerade Zero
remaining
56%
Enjoy by 02/05/19
17 hours
Pibb Xtra
remaining
56%
Enjoy by 02/05/19
41 days
Barq’s
remaining
20%
Enjoy by 02/05/19
15 hours
Diet Pibb Xtra
remaining
20%
Enjoy by 02/05/19
HFCS
HFCS Sold out.
NNS
Soda Water
Water
Dashboard Notifications About
Login Door Lock Help Exit
Prime All
24 hours
Coca-Cola
remaining
90%
Enjoy by 02/05/19
24 hours
Fanta
remaining
90%
Enjoy by 02/05/19
3 days
Cherry
remaining
43%
Enjoy by
02/05/19
2 days
Grape
remaining
40%
Enjoy by
02/05/19
1 hour
Raspberry
remaining
3%
Enjoy by
02/05/19
18 days
Orange
remaining
88%
Enjoy by
02/05/19
24 days
Strawberry
remaining
98%
Enjoy by
02/05/19
1 hour
Vanilla
remaining
15%
Enjoy by
02/05/19
11 days
Lemon
remaining
100%
Enjoy by
02/05/19
4 days
Lime
remaining
88%
Enjoy by
02/05/19
10 days
Dasani
Sparkling
remaining
84%
Enjoy by
02/05/19
2 days
Dasani
remaining
62%
Enjoy by
02/05/19
3 hours
Peach
remaining
2%
Enjoy by
02/05/19
2 hours
Lime
Ginger
remaining
2%
Enjoy by
02/05/19
3 days
Coca-Cola Zero
remaining
60%
Enjoy by 02/08/19
21 days
Fanta Zero
remaining
76%
Enjoy by 02/08/19
16 hours
Sprite
remaining
19%
Enjoy by 02/05/19
24 hours
Diet Coke
remaining
90%
Enjoy by 02/05/19
32 days
Powerade
remaining
95%
Enjoy by 02/05/19
3 hours
Diet Coke Caeine Free
remaining
5%
Enjoy by 02/05/19
2 days
Powerade Zero
remaining
56%
Enjoy by 02/05/19
17 hours
Pibb Xtra
remaining
56%
Enjoy by 02/05/19
41 days
Barq ’s
remaining
20%
Enjoy by 02/05/19
15 hours
Diet Pibb Xtra
remaining
20%
Enjoy by 02/05/19
HFCS
HFCS Sold out.
NNS
Soda Water
Water
Dashboard Notifications About
Login Door Lock Help Exit
Prime All

12 | © 2020 The Coca-Cola Company | Coca-Cola Freestyle® 7000 User Guide | Confidential information of The Coca-Cola Company | 20200821
replacing sweeteners (HFCS & NNS)
product replacement
Coca-Cola Freestyle®7000
uses two sweetener sources
HFCS (High Fructose Corn Sweetener)
Used for all full-calorie beverages
• HFCS (sweetener) is delivered by your
local distributor in a 5-Gallon BIB.
• Replacement of the HFCS BIB is identical
to changing your BIB syrup boxes. HFCS
BIB will be located either underneath the
Coca-Cola Freestyle® 7100 dispenser or in
the back room.
• Always monitor your HFCS usage and
NEVER let it become completely empty.
NNS (Non-Nutritive Sweetener)
Used for all low/no-calorie beverages
• NNS will arrive in a SmartPAK™ cartridge
and is replaced just like other ingredient
cartridges (instructions on page 10).*
• NNS will always be in the number
one (1) or top slot in the cartridge
shelf (see the brand identification strip
on page 3).
Double check to see how
much product is left by
lifting the box.
Use a cloth to catch any
spills, and turn connector
counterclockwise
to loosen.
Remove connector and
replace with new HFCS
sweetener BIB.
Scrub connector using the
blunt end of the nozzle brush
(#149326) and soak in
approved sanitizer solution
(Kay-5). Wait two minutes and
repeat with clean sanitizer.
Open the box and pull out
the fitment.
CAUTION: DO NOT USE A
SHARP OBJECT TO OPEN
Attach the connector to the
fitment and turn clockwise to
tighten.
REMEMBER: Reset the HFCS
on the crew dashboard as
shown on page 11.
ENJOYBY:
MM/DD/YYYY
1234567890
ENJOYBY:
MM/DD/YYYY
1234567890
ENJOYBY:
MM/DD/YYYY
1234567890
ENJOYBY:
MM/DD/YYYY
1234567890
ENJOYBY:
MM/DD/YYYY
1234567890
ENJOYBY:
MM/DD/YYYY
1234567890
ENJOYBY:
MM/DD/YYYY
1234567890
ENJOYBY:
MM/DD/YYYY
1234567890
*NNS BIB will come with the dispenser in the event Coca-Cola Freestyle Boost is installed. For further instructions, refer to page 14.
Procedure to replace BIB
(including HFCS sweetener BIB or product BIB)

© 2020 The Coca-Cola Company | Coca-Cola Freestyle® 7000 User Guide | Confidential information of The Coca-Cola Company | 20200821 | 13
Coca-Cola Freestyle Boost (optional equipment)
product replacement
How to replace a Coca-Cola Freestyle® Boost BIB
When a Boost BIB package is sold-out, it will appear in a similar manner as
sold-out cartridges.
Replace the Boost BIB package, manually.
Once the BIB is replaced, tap on the ingredient location to reset.
Once successfully reset, the Boost BIB indicator will change to a green dot.
A red square on the crew dashboard indicates
Boost BIB is empty and needs to be replaced.
Successful reset
and healthy
status icon.
BIB pump
CCFS Boost TRAY
Add additional brands to your 7000 dispenser
with Coca-Cola Freestyle Boost
Brands currently available:
• Barq’s Olde Style Root Beer
• Minute Maid Lemonade w/ Real Sugar
• Blue Sky Lemonade
• vitaminwater XXX
• vitaminwater XXX Zero
NOTE: Brands which are available in cartridges are not eligible to be
used on Boost.
Equipment
how to replace Boost BIB

14 | © 2020 The Coca-Cola Company | Coca-Cola Freestyle® 7000 User Guide | Confidential information of The Coca-Cola Company | 20200821
Coca-Cola Freestyle Boost (optional equipment)
product replacement
Changing the NNS
(Under the Counter)
NNS (Non-Nutritive Sweetener) is a BIB ingredient
located under the counter for each Freestyle
dispenser. When NNS is empty, the dispenser it
serves will be unable to pour diet or low calorie
beverages and those brands will display as gray outs
on the touch screen.
To ensure a BIB is empty, check the Crew
Dashboard to see if the NNS indicator has
turned red with a “Sold Out” alert.
Open the cabinet under the counter and replace
the NNS using a new box from your storage
area. (Follow procedures as shown.)
Once the new NNS box is installed, return to the
Crew Dashboard and press the red “Sold Out”
alert to prime and reset.
NOTE: NNS indicator displays a green dot when
successfully reset.
Release by moving
locking lever to the
left. Double check to
ensure the box is
empty and remove.
Remove collar. Clean
collar, probe and
compartment with
cloth dipped in
approved sanitizer
solution (Kay-5). Wait
2 minutes and repeat
with fresh sanitizer
solution then allow to
air dry.
Reinstall the collar. Open
the new box, pull out the
fitment and remove cap.
CAUTION: Do not use a
sharp object to open
Place box onto tray
with the arrows on the
package facing up. Align
fitment to connector, then
move lever to the right to
lock.
NOTE: Small bubbles indicate it’s installed correctly.
Procedure To Replace NNS BIB Ingredients Under the Counter
how to replace under the counter NNS BIB

© 2020 The Coca-Cola Company | Coca-Cola Freestyle® 7000 User Guide | Confidential information of The Coca-Cola Company | 20200821 | 15
How to properly clean
the nozzle and injector ring
Locate the nozzle. Using a clean cloth to
protect your fingers, twist nozzle counter-
clockwise, and then pull down to remove.
Scrub the nozzle at a 45° angle with dish soap
using the blunt end of the nozzle brush (small
parts #149326).
Rinse nozzle in warm, clean, drinkable water.
Place nozzle in approved sanitizer solution
(Kay-5). Shake nozzle when submerging to
remove any air bubbles and soak the nozzle for
a minimum of 2 minutes. CAUTION: DO NOT
SOAK NOZZLES OVERNIGHT!
Dip the pointed end of the nozzle brush (small
parts #149326) in sanitizer solution and scrub
the injector ring at a 45° angle. Focus on the
small holes where ingredient comes out and the
area where the nozzle was connected (inner
ring). To access the interior surfaces of the inner
ring, use the wire handle nozzle brush (small parts #16586). Wipe injector ring with a clean
cloth and sanitizer and allow to sit for 2 minutes. Then repeat with fresh sanitizer solution.
Allow the nozzle and injector ring area to “AIR DRY”, then use a clean cloth to reinstall nozzle
and lock into place turning clockwise.
NOTE: Take extra care to ensure the nozzle is inserted completely and locked into place. Test by pouring
a sparkling beverage.
How to properly clean
the ice chute
Turn o power using green
power button.
Use the ice chute brush
(small parts #143257) and
approved sanitizer solution
(Kay-5) to clean inside the
ice chute.
Wait two minutes to allow
to air dry, then repeat
step 2 with fresh sanitizer
solution.
Wipe the outside of the ice chute tip using a clean cloth
and fresh sanitizer solution.
Allow time for the ice chute and ice chute tip to air dry.
Return to normal operation.
maintenance
cleaning nozzle, injector ring, and ice chute
ice chute brush
#143257

16 | © 2020 The Coca-Cola Company | Coca-Cola Freestyle® 7000 User Guide | Confidential information of The Coca-Cola Company | 20200821
cleaning drain and exterior surfaces
How to properly clean the exterior
NOTE: Reinforce with crew to always clean the touch
screen, levers, and ADA interface area periodically
throughout the day.
Remove the cup rest. Clean and sanitize the cup rest and
drain pan in an approved sanitizer solution using a clean
cloth. Then allow to air dry.
Pour remaining sanitizer solution slowly down the
dispenser drain. Ensure the drain empties properly.
Replace the cup rest in the drain pan.
Using a clean cloth and approved sanitizer solution, wipe
all exterior surfaces including the cartridge access door,
touch screen, levers and ADA interface area.
How to properly clean
the drain
Prepare 1 packet of approved
sanitizer solution (Kay-5) with
2.5 gallons of water.
Remove the cup rest. Clean and
sanitize the cup rest in an approved
sanitizer solution using a clean cloth.
Use the drain brush (small parts
#144925) to scrub the dispenser
drain, then pour remaining sanitizer
solution slowly down drain. Ensure
the drain empties properly.
Replace the cup rest in the drain pan.
maintenance
drain brush
#144925

© 2020 The Coca-Cola Company | Coca-Cola Freestyle® 7000 User Guide | Confidential information of The Coca-Cola Company | 20200821 | 17
cleaning and lling ice bin
How to properly check/fill ice
Maintaining the proper ice level is critical
to ensuring your guest receives a quality
beverage. If using a top-mount ice maker,
follow established procedures for checking ice
level. If you fill the ice manually, check to
ensure ice is at least 1/3 full at all times. Fill the
ice bin by following the steps illustrated below:
Fill a clean bucket with ice.
Safely lift and remove ice bin lid.
Dump the ice in the ice bin and fill until full.
(approximately 2" from the top – do not overfill)
Replace ice bin lid.
NOTE: Store bought or “bagged ice” SHOULD NEVER BE USED as it may
seriously damage the Coca-Cola Freestyle® 7000 dispenser ice bin.
/ full
/ full
full
Ice bin should NEVER be less
than one-third full
maintenance
Ice bin cleaning best practices
Remove ALL ice by using the ice dispense lever
(if a top mounted ice maker is installed, follow
manufacturer’s recommendation for cleaning).
Turn power o and unplug dispenser.
Remove ice bin lid.
Pour warm water slowly into the bin (not over
the ice chute) to melt the remaining ice on the
cold plate.
Spray approved sanitizer solution (Kay-5) onto
all internal surfaces of ice bin and both sides of
ice bin lid.
Clean areas within reach inside the bin with
either a clean cloth or an ice bin brush (small
parts #149322). Spray approved sanitizer
solution on all internal surfaces and lid again,
allow draining and air dry.
Return to normal operation.
NOTE: For complete disassembly instructions,
contact your Coke representative.

18 | © 2020 The Coca-Cola Company | Coca-Cola Freestyle® 7000 User Guide | Confidential information of The Coca-Cola Company | 20200821
small parts and cleaning tips
maintenance
Coca-Cola recommends
Kay-5®Sanitizer, or a
comparable food-grade
chlorine sanitizer.
If using Kay-5 brand, add 1 oz.
packets of Kay-5 to 2.5 gallons
of clean, warm water in a clean,
5-gallon bucket.
CAUTION: When using a chlorinated
detergent other than Kay-5, follow
the instructions to produce a 100
ppm chlorine sanitizer solution.
REMINDER: Kay-5 Sanitizer, cleaning
brush and replacement nozzle can
be ordered by calling
1-800-241-COKE (2653).
DO NOT use bleach,
or any unapproved
chemicals!
DO NOT soak any
parts overnight!
DO NOT use scouring
pads, steel wool or
any abrasive
material. It will
scratch the surface
and result in rusting/
pitting!
DO NOT use paper
towels. They may
break apart and clog
the drain!
DO NOT pour
hot liquids into
the drain!
(greater than 125˚F
– 51.6˚C)
CAUTION:
WHAT NOT TO DO...
nozzle tip
#144700
cartridge door key
#141343
Kay-5 sanitizer
#24041
nozzle brush
#149326
SmartPAK®
cartridge tray
#141103
wire handled nozzle
brush
#16586
microfiber cloth
#127723
ice chute brush
#143257
drain
cleaning brush
#144925
Customers may order up to $25 worth of the
following small parts per location.
Call The Coca-Cola service number 1-800-241-COKE (2653) and request a
small parts order.
NOTE: Shipping request other than standard ground transportation may be
charged to your outlet.
