Cocraft HMS 210-L Series User manual

ENGLISHSVENSKANORSKSUOMIDEUTSCH
Important!
Read the entire instruction manual
carefully and make sure that you fully
understand it before you use the
equipment. Keep the manual for future
reference.
Viktig information:
Läs hela bruksanvisningen noggrant och
försäkra dig om att du har förstått den
innan du använder utrustningen. Spara
bruksanvisningen för framtida bruk.
Viktig informasjon:
Les disse anvisningene nøye og forsikre
deg om at du forstår dem, før du tar
produktet i bruk. Ta vare på anvisningene
for seinere bruk.
Tärkeää tietoa:
Lue nämä ohjeet huolellisesti ja varmista
että olet ymmärtänyt ne, ennen kuin
alat käyttää laitetta. Säilytä ohjeet
myöhempää tarvetta varten.
Wichtiger Hinweis:
Vor Inbetriebnahme die komplette
Bedienungsanleitung sorgfältig
durchlesen und aufbewahren.
HMS 210-L
STEPLESS 0-45° MITRE ANGLE SETTINGS
1450 W
18-3602 ∙41-1072
SLIDING MITRE SAW
KAP- OCH GERINGSSÅG
KAPP- OG GJÆRESAG
KATKAISU- JA JIIRISAHA
KAPP- UND GEHRUNGSSÄGE
Ver. 20180430
Original instructions
Bruksanvisning i original
Originalbruksanvisning
Alkuperäinen käyttöohje
Original Bedienungsanleitung
Art.no Model
18-3602 M1YL-4DF-216JA
41-1072 M1YL-4DF-216JA

ENGLISH
3
Sliding Mitre Saw
Art.no 18-3602, 41-1072 Model M1YL-4DF-216JA
Please read theentire instruction manual before using theproduct and then save
it for future reference. We reserve theright for any errors in text or images and any
necessary changes made to technical data. In theevent of technical problems or other
queries, please contact our Customer Services (see address details on theback).
Safety
Warning!
When using this tool all basic safety precautions must be followed to avoid therisk of
fire, electrocution and personal injury. Read these instructions carefully before using
theproduct and keep them for future reference.
• Keep theworking area tidy. Cluttered surfaces and benches invite accidents.
• Take stock of your working environment. Do not expose thetool to rain.
• Do not use thetool in moist or wet areas. Keep theworking area well lit. Never
operate thetool near flammable liquid or gas.
• Avoid electric shocks. Avoid body contact with earthed objects, such as pipes,
radiators, ovens or refrigerators.
• Keep other people at asafe distance. Do not allow anyone not involved in thework
process to touch thetool or its electric cable, especially children. Keep all bystanders
at adistance.
• Store thetool in asafe place. When your tools are not in use, keep them in
alocked, dry area, away from children.
• Do not overload thetool. Thecorrect feed rate makes thework better and safer.
• Use thecorrect tool for thejob. Do not try to use small tools to perform jobs
requiring more powerful tools. Do not use atool for apurpose for which it was not
designed, e.g. using acircular saw for lopping branches off trees.
• Wear suitable clothing. Do not wear loose-fitting clothing or jewellery; they could
be caught in moving parts. Non-slip shoes are recommended for outdoor work.
• Wear ahairnet or similar if you have long hair.
• Always use safetywear. Wear safety glasses. Use adust mask or dust filter when
working in dusty environments.
• Use dust extractors. If thetool is equipped with or connected to adust extractor/
collector, make sure that it is turned on and used correctly.
• Do not abuse thelead. Do not jerk thelead, grip theplug itself when
disconnecting thepower. Make sure that themains lead does not come into
contact with heat, oil, or sharp edges.

ENGLISH
4
• Firmly secure theworkpiece. If possible use vices or clamps to hold
theworkpiece in place. This is much safer than holding theworkpiece in one hand.
• Do not overreach. Make sure that you stand steady and balanced all times.
• Look after your tools. Make sure that they are clean and that theedges are
sharp for maximum effect and best results. Follow themanual’s recommendations
regarding lubrication and replacement of accessories.
• Inspect themains lead regularly. If it is damaged it should be replaced by
aqualified service technician. Inspect all leads and cables regularly to check for
any damage. Make sure that themachine’s handles and controls are clean, dry
and free from oil and grease.
• Turn thepower off. Pull out theplug and push in theemergency stop button
before servicing or changing any blades, drill bits, cutters or sanding discs.
• Remove all spanners and repair tools. Make ahabit of checking to make sure
that themachine is free of all spanners and tools before turning thepower on.
• Avoid accidental starts. Do not walk around with your finger on thetrigger of
apower tool if it is plugged in. Make sure that theon/off switch is set to OFF
before plugging in any power tool.
• Use thecorrect extension leads. If you use extension leads outdoors, only
use those designed for outdoor use. Only use extension leads with thick enough
diameter core wires and roll out thewhole lead.
• Use common sense and be careful. Think before carrying out any task, so that
it is carried out safely. Never operate machines/power tools when you are tired or
under theinfluence of medicine.
• Check thefollowing before turning thetool on:
- That all guards and other parts are whole and in working order.
- That moving parts are free and correctly aligned.
- That no moving parts can get caught.
- That there are no visible defects.
- Other factors that can influence work execution.
• Use only recommended accessories. Theuse of non-recommended
accessories can cause accidents and personal injury.
• Should only be repaired by aqualified technician. This tool conforms to current
safety requirements. Repairs to thetool should only be carried out by atradesman
using original spares; otherwise thetool could cause accidents and personal injury.

ENGLISH
5
Additional safety rules for compound mitre saws
• Never use cracked or damaged saw blades.
• Replace thekerf plate when it is worn.
• Use only saw blades recommended by themanufacturer.
• Never use blades made of high speed steel (HSS).
• Select thecorrect blade for thematerial to be cut.
• Never saw material other than that for which thesaw blade is intended.
• Observe themaximum speed marked on thesaw blade.
• When moving themitre saw, hold it by thehandle.
• Do not operate themachine without theguard in position, or if theguard does not
function or is not maintained properly.
• Keep thesurrounding work area free of loose chips and offcuts.
• Use only those spacers and spindle adaptors approved for your saw.
• If thesaw is fitted with alaser, it must not be replaced by adifferent type. If damaged,
have thelaser repaired by themanufacturer or anauthorised repair agent.
• Do not remove any offcuts or jammed material from around theblade area until
theblade has stopped.
• Before sawing, make sure that thesaw is stable and secure. When possible,
always mount themachine to abench.
• When sawing, always secure theworkpiece using clamps or avice if possible.
• Use atable, roller stand, or similar to support long workpieces.
In spite of theapplication of therelevant safety rules and theimplementation of
safety devices, certain residual risks cannot be avoided. Thefollowing hazards
are inherent to theuse of mitre saws:
• Contact with uncovered parts of therotating saw blade.
• Contact with rotating saw blade (cuts).
• Workpiece or parts of it can be ejected back towards theuser (kickback).
• Shattered saw blade.
• Flying metal particles if thecarbide tips break off.
• Impairment of hearing if ear defenders are not worn.
• Health hazards caused by breathing dust in poorly ventilated work areas.

ENGLISH
6
1 19 18
4
5 6 7 8
9
10
11
12
14
15
16
3
2
13
17
Safety symbol guide
• Class 2 laser product (EN60825-1:2007).
• Never look into thelaserbeam.
• Never point thelaser beam into theeyes of people or animals.
Read theentire instruction manual.
Always use safety glasses, ear defenders and aface mask.
Product description
1. Side supports (2×)
2. Locking screws for
side supports (one for
each support)
3. Bevel angle scale
4. Dust bag
5. Dust extractor/bag
port
6. Saw blade cover
locking screw
7. Saw head
8. Handle
9. Motor
10. Saw blade cover
11. Mitre angle lock
12. Fence
13. Laser
14. Turntable
15. Turntable insert
(slotted plate)
16. Mitre angle lever
17. Allen key
18. Mitre angle scale
19. Holes for side supports

ENGLISH
7
20
21
22
23
24
26
25
2827
29 30 31
32
20. Saw blade
21. Spindle lock
22. Saw blade guard
release lever
23. Saw head lock
24. Workpiece clamp
25. Lock for workpiece clamp
(one on each side)
26. Mounting holes
(one in each corner)
27. [l/0 ] Laser line on/off switch
28. Saw blade power trigger
29. Slide rail locking knob
30. Bevel angle 0° adjustment screw
31. Bevel angle locking knob
32. Bevel angle 45° adjustment screw

ENGLISH
8
Before operating the machine
• Thesaw must be securely fastened to aworkbench or stand.
• All guards and safety devices must be properly fitted.
• Thesaw blade must be able to turn freely in all work settings.
• Make sure that there are no foreign objects (nails, screws) in theworkpiece to be sawn.
• Make sure that thesaw blade is correctly fitted and that all moving parts run smoothly.
Fitting the included dust bag
Squeeze thespring clamp on thebag and slide thebag onto thedust extraction port
(theport may also be used for connecting adust extractor).
Fitting the side supports
Slide therods of theside supports into
theholes (19) and lock them in place
using thelocking screws (2).
Installing the mitre angle lever
1. Swing out the lever so that
it lines up with the slotted
turntableinsert.
2. Fasten the lever using the 2 provided
set screws.

ENGLISH
9
When sawing narrow pieces of wood,
theslide function is not required and thesaw
head can be locked in therear position by
tightening theslide rail locking knob (29). For
sawing wide workpieces, first make sure that
theslide rail lock is released so that thesaw
head can move before you begin sawing.
1. Raise thesaw head (7) to its upper
position by first pressing thesaw head
down and then releasing thesaw head
lock (23). Note: Keep hold of thesaw
head when releasing thelock, otherwise it
will spring up automatically.
2. Move thesaw head backwards and
fix it in this position with a slide lock if
necessary (depending on thewidth of
theworkpiece).
3. Place theworkpiece on theturntable
(14) and hold it against thefence (12).
4. Secure theworkpiece using theclamp
(24) to prevent it from moving during
thecutting process.
5. Switch thelaser line on if necessary,
using theswitch (27).
6. Press in thepower trigger (28) to start
themotor, press in theblade guard
release lever (22) and carefully lower
thesaw head and let theblade cut
through theworkpiece.
7. To switch thesaw off, release thepower trigger whilst still maintaining full control
over thesaw head. When theblade has stopped, thesaw head can be moved
back to its upper position.
Warning: Theresetting springs in themachine automatically raise thesaw head after
cutting. Do not simply let go of thesaw head after cutting, hold onto thehandle and
let it come up slowly.
Operating instructions
Cross-cutting
Cross-cutting with the saw blade angled 0°

ENGLISH
10
Mitre cutting -45°/0°/+45°
1. Raise thesaw head (7) to its upper position by
releasing thelock (23).
2. Undo themitre angle lock (11) and set
thesaw to thedesired mitre angle using
thescale (18).
3. Tighten themitre angle lock and perform
cutting operations as described above.
Bevel cutting 0–45°
1. Undo thelocking knob (31) and tilt theblade
to thedesired angle with thehelp of thebevel
angle scale (3).
2. Tighten thelocking knob to lock thebevel angle.
Adjust the fence (see below fig.).
3. Cut as described above.
20 40 60 80 20 40 60 80
Important:
When sawing with theblade tilted at anangle, thefence must be moved out of theway
to prevent it from obstructing theblade.
Fine-adjusting the 0° and 45° bevel angle stops
1. Undo thelocking knob (31) and angle thesaw to 0°.
2. Check theangle between theblade and theturntable using a90° angle guide.
3. Adjust theend stop using theadjuster screw (30) by slackening thenut and turning
thescrew. Lock thescrew again afterwards by re-tightening thenut.
4. To adjust the45° end stop, do as above but use theother adjuster screw (32) and
a45° angle guide.
