Cocraft PRO Series User manual

ENGLISHSVENSKANORSKSUOMIDEUTSCH
Important!
Read the entire instruction manual
carefully and make sure that you fully
understand it before you use the
equipment. Keep the manual for future
reference.
Viktig information:
Läs hela bruksanvisningen noggrant och
försäkra dig om att du har förstått den
innan du använder utrustningen. Spara
bruksanvisningen för framtida bruk.
Viktig informasjon:
Les disse anvisningene nøye og forsikre
deg om at du forstår dem, før du tar
produktet i bruk. Ta vare på anvisningene
for seinere bruk.
Tärkeää tietoa:
Lue nämä ohjeet huolellisesti ja varmista
että olet ymmärtänyt ne, ennen kuin
alat käyttää laitetta. Säilytä ohjeet
myöhempää tarvetta varten.
Wichtiger Hinweis:
Vor Inbetriebnahme die komplette
Bedienungsanleitung sorgfältig
durchlesen und aufbewahren.
PROEDITION
Ver. 20170403
Original instructions
Bruksanvisning i original
Originalbruksanvisning
Alkuperäinen käyttöohje
Original Bedienungsanleitung
Art.no Model
40-9931 HM1028R
PRO ML10-DB
SLIDING MITRE SAW 1200 W
40-9931
KAP- OCH GERINGSSÅG
KAPP- OG GJÆRESAG
KATKAISU- JA JIIRISAHA
KAPP- UND GEHRUNGSSÄGE

ENGLISH
2
Sliding Mitre Saw
Art.no 40-9931 Mode HM1028R
Please read theentire instruction manual before using theproduct and then save
it for future reference. We reserve theright for any errors in text or images and any
necessary changes made to technical data. In theevent of technical problems or other
queries, please contact our Customer Services (see address details on theback).
Safety
Warning!
When using this tool all basic safety precautions must be followed to avoid the risk of
fire, electrocution and personal injury. Read these instructions carefully before using
the product and keep them for future reference.
• Keep the working area tidy. Cluttered surfaces and benches invite accidents.
• Take stock of your working environment. Do not expose the tool to rain.
• Do not use the tool in moist or wet areas. Keep the working area well lit. Never
operate the tool near flammable liquid or gas.
• Avoid electric shocks. Avoid body contact with earthed objects, such as pipes,
radiators, ovens or refrigerators.
• Keep other people at a safe distance. Do not allow anyone not involved in the
work process to touch the tool or its electric cable, especially children. Keep all
bystanders at a distance.
• Store the tool in a safe place. When your tools are not in use, keep them in a
locked, dry area, away from children.
• Do not overload the tool. The correct feed rate makes the work better and safer.
• Use the correct tool for the job. Do not try to use small tools to perform jobs
requiring more powerful tools. Do not use a tool for a purpose for which it was not
designed, e.g. using a circular saw for lopping branches off trees.
• Wear suitable clothing. Do not wear loose-fitting clothing or jewellery; they could
be caught in moving parts. Non-slip shoes are recommended for outdoor work.
• Wear a hairnet or similar if you have long hair.
• Always use safetywear. Wear safety glasses. Use a dust mask or dust filter when
working in dusty environments.
• Use dust extractors. If the tool is equipped with or connected to a dust extractor/
collector, make sure that it is turned on and used correctly.
• Do not abuse the lead. Do not jerk the lead, grip the plug itself when discon-
necting the power. Make sure that the mains lead does not come into contact with
heat, oil, or sharp edges.

ENGLISH
3
• Firmly secure the workpiece. If possible use vices or clamps to hold the work-
piece in place. This is much safer than holding the workpiece in one hand.
• Do not overreach. Make sure that you stand steady and balanced all times.
• Look after you tools. Make sure that they are clean and that the edges are sharp
for maximum effect and best results. Follow the manual’s recommendations regar-
ding lubrication and replacement of accessories. Inspect the mains lead regularly.
If it is damaged it should be replaced by a qualified service technician. Inspect all
leads and cables regularly to check for any damage. Make sure that the machine’s
handles and controls are clean, dry and free from oil and grease.
• Turn the power off. Pull out the plug and push in the emergency stop button
before servicing or changing any blades, drill bits, cutters or sanding discs.
• Remove all spanners and repair tools. Make a habit of checking to make sure
that the machine is free of all spanners and tools before turning the power on.
• Avoid accidental starts. Do not walk around with your finger on the trigger of a
power tool if it is plugged in. Make sure that the on/off switch is set to OFF before
plugging in any power tool.
• Use the correct extension leads. If you use extension leads outdoors, only use
those designed for outdoor use. Only use extension leads with thick enough dia-
meter core wires and roll out the whole lead.
• Use common sense and be careful. Think before carrying out any task, so that
it is carried out safely. Never operate machines/power tools when you are tired or
under the influence of medicine.
• Check the following before turning the tool on:
- That all guards and other parts are whole and in working order.
- That moving parts are free and correctly aligned.
- That no moving parts can get caught.
- That there are no visible defects.
- Other factors that can influence work execution.
• Use only recommended accessories. The use of non-recommended accesso-
ries can cause accidents and personal injury.
• Should only be repaired by a qualified technician. This tool conforms to current
safety requirements. Repairs to the tool should only be carried out by a tradesman
using original spares; otherwise the tool could cause accidents and personal injury.

ENGLISH
4
Additional safety rules for compound mitre saws
• Never use cracked or damaged saw blades.
• Replace the kerf plate when it is worn.
• Use only saw blades recommended by the manufacturer.
• Never use blades made of high speed steel (HSS).
• Select the correct blade for the material to be cut.
• Never saw material other than that for which the saw blade is intended.
• Observe the maximum speed marked on the saw blade.
• When moving the mitre saw, hold it by the handle.
• Do not operate the machine without the guard in position, or if the guard does not
function or is not maintained properly.
• Keep the surrounding work area free of loose chips and offcuts.
• Use only those spacers and spindle adaptors approved for your saw.
• If the laser is fitted with a laser, it must not be replaced by a different type. If damaged,
have the laser repaired by the manufacturer or an authorised repair agent.
• Do not remove any offcuts or jammed material from around the blade area until the
blade has stopped.
• Before sawing, make sure that the saw is stable and secure. When possible,
always mount the machine to a bench.
• When sawing, always secure the workpiece using clamps or a vice if possible.
• Use a table, roller stand, or similar to support long workpieces.
In spite of the application of the relevant safety rules and the implementation of
safety devices, certain residual risks cannot be avoided. The following hazards
are inherent to the use of mitre saws:
• Contact with uncovered parts of the rotating saw blade.
• Contact with rotating saw blade (cuts).
• Workpiece or parts of it can be ejected back towards the user (kickback).
• Shattered saw blade.
• Flying metal particles if the carbide tips break off.
• Impairment of hearing if ear defenders are not worn.
• Health hazards caused by breathing dust in poorly ventilated work areas.

ENGLISH
5
Safety symbol guide
• Class 2 laser product (EN60825-1:2007).
• Never look into thelaserbeam.
• Never point thelaser beam into theeyes of people or animals.
Read theentire instruction manual.
Always use safety glasses, ear defenders and aface mask.

ENGLISH
6
12
3
4
5
6
7
8
9
10 11 16 15
14
13
12
17
18
19
20
21
Product description

ENGLISH
7
22
23
24
25
26
1. Handle
2. Power trigger
3. Laser line switch
4. Cutting depth adjuster
5. Saw head lock
6. Material clamp
7. Turntable
8. Work support
9. End stop
10. Material clamp adjuster
11. Work support locking screw
12. Dust bag
13. Fence
14. Fence adjustment knob
15. Slide rail locking wing nut
16. Bevel angle 0° adjuster
17. Safety lever
18. Spindle lock
19. Blade guard
20. Locking knob
21. Fixed setting locking lever
22. Carbon brush plug
23. Bevel scale
24. Bevel locking lever
25. Bevel angle 45° adjuster
26. Saw head

ENGLISH
8
5
Before operating the machine
• Thesaw must be securely fastened to aworkbench or stand.
• All guards and safety devices must be properly fitted.
• Thesaw blade must be able to turn freely in all work settings.
• Make sure that there are no foreign objects (nails, screws) in theworkpiece to be sawn.
• Make sure that thesaw blade is correctly fitted and that all moving parts run smoothly.
Operating instructions
Work support
1. Undo thework support locking
screw (11).
2. Extend thework support.
3. Tighten thelocking screw again.
Cutting operations
Cross-cutting with the saw head at 0˚
Thesaw can cross-cut workpieces up to 120mm wide without using theslide function
and thesaw can be fixed in therearmost setting using theslide rail lock nut (15). If
theworkpiece is wider than 120mm, make sure that theslide rail lock nut is undone and
that thesaw head (26) is able to slide back and forth before beginning to cut.
1. Raise thesaw head to its upper
position by releasing thelock (5).
2. Move thesaw head backwards
using handle (1) and fix it in this
position if necessary (depending on
thewidth of theworkpiece) using
theslide rail lock nut.
3. Place theworkpiece against
thefence (13) on theturntable (7).
4. Secure theworkpiece using
theclamp (6) to prevent it from
moving during thecutting process.

ENGLISH
9
16
25
24
5. Switch thelaser line on if necessary, using theswitch (3).
6. Press in thepower trigger (2) to start themotor, press in thesafety lever (17) and
carefully lower thesaw head and let theblade cut through theworkpiece.
7. To switch thesaw off, release thepower trigger whilst still maintaining full control
over thesaw head. When theblade has stopped, thesaw head can be moved
back to its upper position.
Warning: Theresetting springs in themachine automatically raise thesaw head after
cutting. Do not simply let go of thesaw head after cutting, hold onto thehandle and
let it come up slowly.
Bevel cutting 0–45°
1. Undo thelocking lever (24) and tilt
theblade to thedesired angle with
thehelp of thebevel scale (23).
2. Tighten thelocking lever to lock
thebevel angle.
3. Cut as described above.
Fine-adjusting the 0° and 45° bevel angle stops
1. Undo thelocking knob (24) and
angle thesaw to 0°.
2. Check theangle between theblade
and theturntable using a90° angle
guide.
3. Adjust theend stop using
theadjuster screw (16) by
slackening thenut and turning
thescrew. Lock thescrew again
afterwards by re-tightening thenut.
4. To adjust the45° end stop, do as
above but use theother adjuster
screw (25) and a45° angle guide.

ENGLISH
10
Mitre cutting -45°/0°/+45°
1. Raise thesaw head (26) to its upper position by releasing thelock (5).
2. Undo thelocking knob (20), lift thelocking lever (21) and set thesaw to thedesired
mitre angle using thescale on thebase.
3. Tighten thelocking knob and perform cutting operations as described above.
Sawing bowed workpieces
Correct Incorrect
If the workpiece is bowed, turn it as shown in the figure to prevent it from pinching
the blade towards the end of the cut.
Care and maintenance
Dust bag
Thesaw is fitted with adust bag (12) which can be emptied by opening thezip on
thebottom. Adust extractor can also be attached to theoutlet instead of thedust
bag.
Changing the blade
Note: Wear gloves whenever handling theblade, it is very sharp.
1. Unplug themains lead from thewall
socket.
2. Raise thesaw head to its upper
position by releasing thelock (5).
3. Alter theposition of theblade
guard alittle so that you can undo
thescrew in thehole as shown in
thefigure.
Note: Do not remove thescrew, just
slacken it.
