Collomix Xo 1 R User manual

Original Operating Instructions Electronic Hand-Mixer
EN
110 volts UK-plug
Xo 1 R Xo 4 R Xo 6 R

WK 120
WK 140
MK 120
MK 140
MK 160
KR 120
KR 140
KR 160
LX 120
DLX 120
DLX 152
↓
↑
↑
↔
↓
Xo 1 R Xo 4 R Xo 6 R
WK 120 • •
WK 140 • •
MK 120 • •
MK 140 • •
MK 160 •
KR 120 • •
KR 140 • •
KR 160 •
LX 120 • •
DLX 120 • •
DLX 152 • •

1
2
3
4
5
6
7
8
9
10
A
B
C
5/8" x 16 UNF
SW 13 (mm)
Art.nr. 49529
M-14 5/8" x 16 UNF
Art.nr. 49582-000

Machine components
Noise/vibraon levels
1 Release buon for ON/OFF switch
2 ON/OFF switch
3 Gear selecon switch (for Xo 4 R/Xo 6 R only)
4 Handle frame with rubber buer
5 Handles
6 Venlaon slits
7 Neck of the machine
8 Mixing sha
9 HEXAFIX adapter / size M14 adapter
10 Mixing tool
Xo 1 R Xo 4 R Xo 6 R
Rated power/Current consumpon: 1010W 1300W 1600W
Power supply: 110-125 volts AC 110-125 volts AC 110-125 volts AC
Frequency: 50/60 hz 50/60 hz 50/60 hz
No-load speed, rst gear - 900 min-1 - 660 min-1 - 660 min-1
second gear - 920 min-1 - 920 min-1
Rpm under load, rst gear - 650 min-1 - 450 min-1 - 410 min-1
second gear - 620 min-1 - 580 min-1
Threaded spindle mixing sha: 5/8“x16 UN 5/8“x16 UN 5/8“x16 UN
Maximum mixing tool diameter: 120 mm 140 (150*) mm 160 mm
Weight w/o mixing tool: 4,5 kg 5,4 kg 5,4 kg
Protecon class: q/ II q/ II q/ II
Measured values determined in accordance with EN
62841. The A-weighted noise level of the machine is
typically:
Sound pressure level
LpA [dB(A)]
Sound power level
LWA [dB(A)]
Xo 1 R 81 dB(a) 92 dB(A)
Xo 4 R 88 dB(a) 99 dB(A)
Xo 6 R 88 dB(a) 99 dB(A)
Uncertainty K = 3 dB
Overall vibraon level (for mixing of mineral
materials)
Emission level an[m/s2]
Xo 1 R 2,5 m/s2
2,9 m/s2
2,9 m/s2
Xo 4 R
Xo 6 R
Uncertainty K = 1,5 m/s2
LWARNING:
The measured values which are provided apply to new
machines. Noise and vibraon levels change with day-to-
day use.
NOTE
The vibraon level given in these instrucons was
measured in accordance with a standardized method of
measurement as dened in EN 62841 and can be used
for the purposes of comparing electrical tools with each
other. It is also suitable for a preliminary esmaon
of vibraon strain. The vibraon level which is given
represents vibraon level for the primary use of the
electrical tool. If, however, the electrical tool is used for
any other purposes, with dierent plug-in tools or with
insucient maintenance, the vibraon level may vary.
This can result in a signicantly higher level of vibraon
strain over the work period as a whole.
For a precise esmaon of the vibraon strain the mes
when the machine is switched o have to be taken into
account as well, as do the mes when it is running but is
not actually being used. This can result in a signicantly
reduced level of vibraon strain over the work period as
a whole.
EU - Declaraon of Conformity
We declare, with sole responsibility, that this product
complies with the following standards or normave
products: EN 55014-1:2017, EN 55014-2:2015, EN 61000-
3-2:2014, 61000-3-3:2013, EN 62841-1:2015 + AC:2015,
EN 62841-2-10:2017 in accordance with the provisions
of direcves 2014/30/EC, 2006/42 EC, 2011/65/EC.
.
Gaimersheim, 2019-05-28
Alexander Essing
Managing Director
Technical documentaon can be requested from:
Collomix GmbH
Abt. Technische Entwicklung
Daimlerstr. 9, 85080 Gaimersheim, Germany
Technical data

►Do not wind cables or leads around any parts of your
body.
►Do not use the machine with a damaged cable. Do
not touch the cable and pull out the power plug im-
mediately. There is an increased risk of electric shock
from damaged cables. If the mains power cable has to
be replaced (because of damage or similar), ensure
that it is replaced by the manufacturer or an autho-
rized representative of the manufacturer (electrician)
in order to avoid any risk to safety.
►Hold the machine by the insulated grip surfaces
when carrying out work where it may be possible for
the plug-in tool to come into contact with concealed
power cables or the machine’s own mains power
cable. Contact with a live cable may make metal com-
ponents of the machine live as well and could cause
an electric shock.
►Before starting up, check that the mixing rod is se-
curely attached and rotates without a hitch.
►Only operate the machine and the mixing tool in
perfect condition. Do not use damaged, bent or worn
paddles.
►If the sound pressure level should exceed 85 dB (A)
where you are working, use ear protection!
►We recommend that you wear work gloves and pro-
tective goggles when using the mixer. Regulations
require that you wear close-fitting clothing.
►Always connect machines via a residual current de-
vice (RCD) with a rated residual current of 30 mA or
less.
LWARNING: Read all safety warnings, instruc-
ons, illustraons and specicaons provided with this
power tool. Failure to follow all instrucons listed below
may result in electric shock, re and/or serious injury.
Save all warnings and instrucons for future reference.
The term “power tool” in the warnings refers to your
mains-operated (corded) power tool or baery-operated
(cordless) power tool.
To be able to use the machine safely it is essenal that
you read the operang instrucons and the safety
instrucons thoroughly and comply with all of them.
The machine is to be used only by persons who have
read the operang instrucons and who are acquainted
with the occupaonal safety and accident prevenon
regulaons in force in your country.
LIn addition, you must also comply with the general
safety instructions also included with the machine.
►Take care to ensure that the mains power supply
corresponds to the specifications on the rating plate.
►Hold the power tool with both hands by the handles
provided. Loss of control may result in injury.
►To avoid a dangerous atmosphere, ensure adequate
ventilation when mixing flammable substances.
Vapours formed may be inhaled or ignited by sparks
generated by the power tool.
►Do not stir any food. Power tools and their insert
tools are not designed for processing food.
►Keep the power cord away from the working area.
The mains cable may get caught in the stirring basket.
►Ensure that the mixing bucket is firmly and safely
positioned. An improperly secured bucket may move
unexpectedly.
►Make sure that no liquid splashes against the hous-
ing of the power tool. Liquid entering the power tool
can cause damage and electric shock.
►Follow the instructions and safety instructions for
the material to be mixed. The material to be mixed
may be harmful to health.
►If the power tool falls into the material to be mixed,
immediately unplug the power plug and have the
power tool checked by qualified personnel. Reach-
ing into the bucket with the power tool still hanging
from the socket inside it can lead to an electric shock.
►Do not reach into the stirring container with your
hands or insert any other objects while stirring. Con-
tact with the paddle can cause serious injury.
►Only let the power tool run on and off in the stirring
bucket. The paddle can spin around or bend in an
uncontrolled manner.
►Further safety instructions:
Machine-specic safety instrucons
Read and observe the operang
instrucons for the machine before you
start it up!
Always wear protecve goggles and ear
protecon while working.
It is advisable to wear a dust mask
whenever working with materials which
generate large amounts of dust.
Always wear protecve gloves while
working.

Proper use
The machine is designed for mixing liquid and powder-
based building products such as paints, mortar,
adhesives, plaster and similar substances. Use the right
mixing tool for the consistency of the material and the
quanty to be mixed.
Please refer to the informaon in the technical data
when choosing the size of mixing tool (diameter/
mixing acon). If the wrong mixing acon or mixing tool
diameter is selected, this may cause the machine/gear
unit to become overloaded and lead to damage as a
result. Please remember that a mixing tool with a mixing
acon from the top down puts a greater strain on the
electrical tool than one with the reverse mixing acon.
Given the high torque levels generated by the machine, it
must not be used as a power drill.
The machine must not be used for the preparaon of
foodstus.
The machine is not suitable for mixing materials
containing graphite dust, brine or slurry. Mixing of
these materials or substances may damage the machine
beyond repair.
Assembly
Operaon
►Always pull the power plug out of the socket outlet
before carrying out any work on the machine.
Depending on the model, either a HEXAFIX adapter or
an adapter with M-14 thread connection is included with
the machine.
Fing the mixing tool mount:
Take the HEXAFIX coupling or size M14 adapter supplied
with the packaging and screw it to the male thread of the
mixing sha.
Fing the mixing tool / tool change-over:
HEXAFIX (Fig. A)
Insert the mixing tool with the HEXAFIX mount in
the coupling unl it locks. To release or change the
mixing tools, simply pull back the handle-collar
on the coupling and this releases the mixing tool.
(Fig. C)
M14 (Fig. B)
Screw the mixing tool with a size M14 male thread into
the M14 adapter on the mixing sha. The mixing tool
ghtens itself during operaon.
To release the mixing tool you will need one SW 22
and one SW 24 open-ended wrench. Place the one
open-ended wrench on the adapter and the other on
the hexagonal holding xture and turn them both in
opposite direcons to one another unl the mixing tool
is released.
► Check that the power supply shown on the rating
plate is the same as the mains power supply.
Always hold the machine with both hands.
Press the starng lockout
buon (1).
Press the ON/OFF switch (2).
The more pressure you apply to
the ON/OFF switch,
the faster the machine will run.
The ON/OFF switch cannot be
locked!
Always work with the ON/OFF switch fully pressed.
To stop working, release the ON/OFF switch.
Machines with 2-speed gear
units (Xo4R/Xo6) have two
maximum speeds available (First
gear: Slow / Second gear: Fast).
To change from one gear to the
other, turn the gear selecon
lever through 180°.
Only ever actuate it when the
machine is at a standsll.
LWARNING
Tips for safe working:
Always reduce the speed when submerging the mixing
tool in the mixing material or liing it out. Once the
mixing tool is fully submerged, increase the speed again
to ensure that the motor is adequately cooled.
During mixing you should guide the machine around
the mixing container. Connue mixing unl all of the
mixing material is completely mixed. Please follow the
processing instrucons of the manufacturer of the
material.
You work beer and safer when the mixing tool used is
clean, free of material residues and in perfect condion.
The greater the viscosity of the material, the greater
the impact of the torque forces on the machine, so you
should be prepared for this when you carry out your
work.
If the mixing tool comes into contact with a surface (e.g.
the boom of the tub) while running, it may kick back.
Set the machine down resng on the guard handle aer
you have nished your mixing work.
For transportaon purposes the HEXFIX mixing tool can
be inserted through the hexagon punch-hole provided in
the handle frame.
1.
2.

Manufacturer:
Collomix GmbH
Daimlerstrasse 9
85080 Gaimersheim
Germany
Care and maintenance Warranty
Content
LWARNING
►Before you carry out any operations on the machi-
ne, and especially when changing the mixing tool,
always pull out the power plug out first!
Clean the machine and the mixing tool immediately aer
use. We recommend that you use the Collomix MIXER
CLEAN cleaning bucket for cleaning.
Keep the HEXAFIX coupling clean
and freely moving at all mes.
Take the mixing tool out of the
coupling aer you have nished
your work.
Grease the hexagon mount of the
coupling at regular intervals with
suitable grease.
Keep the venlaon slits clean and clear at all mes
so that the machine can be properly cooled. Blocked
venlaon slits will lead to irreparable damage to the
machine.
Make sure that the ON/OFF switch moves and releases
smoothly at all mes.
The machine is equipped with self-deacvang carbon
brushes. This means that the machine will shut itself
down once a certain level of wear is reached. The carbon
brushes can be replaced by the authorized customer
service center or by the Collomix Service center.
Have repairs carried out only by an approved workshop
or by your Collomix Service.
Only use original Collomix accessories and replacement
parts.
For exploded drawings, lists of replacement parts
and the form for repair orders, please refer to:
hp://www.collomix.com
The manufacturer provides a warranty within the
framework of his terms and condions of delivery in
accordance with the requirements of statutory/country-
specic provisions. Should you need to make a claim
under the warranty, please provide us with your invoice
or delivery note.
On no account will any warranty claims be accepted if
any repairs are carried out by third pares. In the event
of any irregularies, please send the machine to us.
Complaints can only be accepted if the device is sent to
the Collomix Service center undismantled.
The warranty does not apply to damages caused
by normal wear, overloading, improper handling,
unsuitable accessories or inadequate maintenance.
Any structural or funconal modicaons to the
machine which are made without our agreement shall
render the warranty and the Declaraon of Conformity
null and void.
Subject to change.
Disposal
The device, accessories and packaging should all be
consigned for environment-friendly recycling.
Electrical tools which have come to the end of their
service lives must be made unusable by removing the
mains power cable.
Do not dispose of electrical tools with household waste.
Fett
Grease
Graisse
Smar
1x Mixing machine
1x Mixing paddle
1x Hexax adapter
1x Manual
1x General safety notes

Copyright by Collomix GmbH - BA XoR 10V UK - Rev. 03 - 0920- 21436
Collomix GmbH
Daimlerstraße 9
85080 Gaimersheim, Germany
[e-mail]
www.collomix.com
