ComAp InteliLite 4 MRS16 Manual

Copyright © 2021 ComAp a.s.
Written by Jan Liptak
Prague, Czech Republic
ComAp a.s., U Uranie 1612/14a,
170 00 Prague 7, Czech Republic
Tel: [phone]
E-mail: [e-mail], www.comap-
control.com Operator Guide
InteliLite 4
MRS16
Controller for single gen-set
applications
1 Front panel elements 2
2 Display screens and pages structure 4
3 Browsing alarms 17
4 Login 19
5 Logout 22
6 Production mode 24
7 Information screen 26
8 Language selection 28
9 Display contrast adjustment 30

InteliLite 4 MRS16 Operator Guide 2
1 Front panel elements
Image 1.1 Operator interface of InteliLite 4 MRS16
Control buttons
Position Picture Description
LEFT button. Use this button to move left or to change the mode. The button
can change the mode only if the main screen with the indicator of currently
selected mode is displayed.
Note: This button will not change the mode if the controller mode is forced by
one of binary inputs listed in the Reference Guide – "Operating modes"
chapter.
RIGHT button. Use this button to move right or to change the mode. The
button can change the mode only if the main screen with the indicator of
currently selected mode is displayed.
Note: This button will not change the mode if the controller mode is forced by
one of binary inputs listed in the Reference Guide – "Operating modes"
chapter.
HORN RESET button. Use this button to deactivate the horn output without
acknowledging the alarms.
FAULT RESET button. Use this button to acknowledge alarms and
deactivate the horn output. Inactive alarms will disappear immediately and
status of active alarms will be changed to "confirmed" so they will disappear
as soon as their reasons dismiss.

InteliLite 4 MRS16 Operator Guide 3
UP button. Use this button to move up or increase value.
PAGE button. Use this button to switch over display pages.
DOWN button. Use this button to move down or decrease value.
ENTER button. Use this button to finish editing a setpoint or moving right in
the history page.
START button. Works in MAN mode only. Press this button to initiate the
start sequence of the engine.
STOP button. Works in MAN mode only. Press this button to initiate the stop
sequence of the Gen-set. Repeated pressing of button will cancel current
phase of stop sequence (like cooling) and next phase will continue.
GCB button. Works in MAN mode only. Press this button to open or close the
GCB.
Indicators and others
Position Description
GENERATOR status indicator. There are two states – Gen-set OK (indicator is green) and
Gen-set failure (indicator is red). Green LED is on if the generator voltage and frequency is
present and within limits. Red LED starts flashing when Gen-set failure occurs. After
FAULT RESET button is pressed, Red LED goes to steady light (if an alarm is still active)
or is off (if no alarm is active).
Graphic B/W display, 132 × 64px.
LOAD. Green LED is ON if load is supplied by generator. It means, that Gen-set is OK and
proper circuit breaker is closed.
GCB Status. Consists of 3 green LEDs. The middle green LED is on if GCB is closed. It is
driven by GCB CLOSE/OPEN output or by GCB feedback signal. Side green LEDs are on
in case the generator status indicator is ok.

InteliLite 4 MRS16 Operator Guide 4
2 Display screens and pages
structure
The displayed information is structured into "pages" and "screens". Use PAGE button to switch over the pages.
The page Measurement consists of screens which display measured values like voltages, current, oil
pressure etc., computed values like i.e. gen-set power, statistic data and the alarm list on the last screen.
The page Setpoints contains all setpoints organized to groups and also a special group for entering
password.
The page History log shows the history log in the order that the last record is displayed first.
2.1 Main Screen
2.1.1 Symbols
Padlock – active when LBI ACCESS LOCK is active
R – active when there is active remote connection to controller
Exclamation mark – active when there is any alarm in alarmlist
2.1.2 Optional
Value can be chosen via setpoints Main Screen Line 1 (page 1) and Main Screen Line 2 (page 1).
Posibilities are: RPM, PF, Run Hours, ATT, AIN1

InteliLite 4 MRS16 Operator Guide 5
2.2 Measurement Screens
Note: Use Up and Down button to move between measurement pages.
Note: Use Up and Down button to move between measurement pages.
Note: Use Up and Down button to move between measurement pages.
Note: Use Up and Down button to move between measurement pages.

InteliLite 4 MRS16 Operator Guide 6
Note: Use Up and Down button to move between measurement pages.
Note: Use Up and Down button to move between measurement pages.
Note: Use Up and Down button to move between measurement pages.
Note: Use Up and Down button to move between measurement pages.

InteliLite 4 MRS16 Operator Guide 7
Note: Use Up and Down button to move between measurement pages.
Note: Use Up and Down button to move between measurement pages.
Note: Available only with plug-in module.
Note: Use Up and Down button to move between measurement pages.
Note: Available only with plug-in module.
Note: Use Up and Down button to move between measurement pages.

InteliLite 4 MRS16 Operator Guide 8
Note: Use Up and Down button to move between measurement pages.
Note: Use Up and Down button to move between measurement pages.
Note: Use Up and Down button to move between measurement pages.
Note: Use Up and Down button to move between measurement pages.
Note: Available only with plug-in module.

InteliLite 4 MRS16 Operator Guide 9
Note: Use Up and Down button to move between measurement pages.
Note: Available only with plug-in module.
Note: Use Up and Down button to move between measurement pages.
Note: Available only with plug-in module.
Note: Use Up and Down button to move between measurement pages.
Note: Available only with plug-in module.

InteliLite 4 MRS16 Operator Guide 10
Note: Use Up and Down button to move between measurement pages.
Note: Available only with ECU supported by TIER4F
Note: Use Up and Down button to move between measurement pages.
Note: Use Up and Down button to move between measurement pages.
Note: From all of these pages it is possible to switch seamlessly to the setpoint group page by pressing Page
button.
Note: There can be some additional screens and also some screens can be hidden. Screen’s visibility
depends on actual configuration (usage of extension or communication modules, ECU etc.).

InteliLite 4 MRS16 Operator Guide 11
2.3 Setpoint Screens
Note: From all measurement pages we can fluently go to the setpoint group page by pressing Page button.
Note: Use Up and
Down button to
select required
setpoint group.
Note: Use Enter button to enter selected setpoint group.
Note: Use Up and
Down button to
select required
setpoint.
Note: Use Left and Right button to select required setpoint.
Note: Use Enter button to enter selected setpoint.

InteliLite 4 MRS16 Operator Guide 12
Note: Use Up and
Down button to set
required value of
selected setpoint.
Note: Use Enter button to confirm adjusted value of setpoint.
Note: Use Page button to discard changes, to set setpoint to previous value and to return to the list of
setpoints of selected group.
2.4 History Log
Note: From all measurement pages we can fluently go to the setpoint group page by pressing Page button.
Note: From setpoint group page we can fluently go to the history log pages by pressing Page button.

InteliLite 4 MRS16 Operator Guide 13
Note: Use Up and
Down button to
select required
alarm reason.
Note: Use Enter button to move to the next page of history log.
Note: Use Up and
Down button to
select required
alarm reason.
Note: Use Enter button to move to the next page of history log.
Note: Use Up and
Down button to
select required
alarm reason.
Note: Use Enter button to move to the next page of history log.
Note: Use Up and
Down button to
select required
alarm reason.
Note: Use Enter button to move to the next page of history log.

InteliLite 4 MRS16 Operator Guide 14
Note: Use Up and
Down button to
select required
alarm reason.
Note: Use Enter button to move to the next page of history log.
Note: Use Up and
Down button to
select required
alarm reason.
Note: Use Enter button to move to the next page of history log.
Note: Use Up and
Down button to
select required
alarm reason.
Note: Use Enter button to move to the next page of history log.
Note: Use Up and
Down button to
select required
alarm reason.
Note: Use Enter button to move to the next page of history log.

InteliLite 4 MRS16 Operator Guide 15
Note: Use Up and
Down button to
select required
alarm reason.
Note: Use Enter button to move to the next page of history log.
Note: Use Up and
Down button to
select required
alarm reason.
Note: Use Enter button to move to the next page of history log.
Note: Use Up and
Down button to
select required
alarm reason.
Note: Use Enter button to move to the next page of history log.
Note: Use Up and
Down button to
select required
alarm reason.
Note: Use Enter button to move to the first page of history log.
IMPORTANT: The records are numbered in reverse order, i.e. the latest (newest) record is "0" and
older records have "-1", "-2" etc.

InteliLite 4 MRS16 Operator Guide 16
Note: This is only basic history record. There can be some additional screens in case that in controller is
extension module or ECU is configured. Also it depends on connection type.
6back to Display screens and pages structure

InteliLite 4 MRS16 Operator Guide 17
3 Browsing alarms
Note: Use Up button to move to alarmlist from main measurement screen.
Active alarms are displayed as white text on black background. It means the alarm is still active, i.e. the
appropriate alarm conditions are still present.
Inactive alarms are displayed as black text on white background. It means the alarm is no more active, i.e.
the appropriate alarm conditions are gone.
Not confirmed alarms are displayed with an asterisk. It means the alarm is still not acknowledged
(confirmed).
ECU alarms: SPN/FMI/OC/SC
SPN – Suspect parameter number
FMI – type of protection
OC – number of errors
SC – source of error

InteliLite 4 MRS16 Operator Guide 18
3.1 User access management alarms
The controller comes to the customer with turned on Production mode, the default administrator password and
with no filled email address for password reset. Due to the security reasons following user access management
alarms appear. Detailed description of situation when the alarms are active are described below:
Wrn Production Mode is present in the alarm list all the time while production mode is turned on. To turn
off the Production mode go to User management and uncheck the checkbox Production mode or go to
Production Mode display screen and select disable.
Wrn Default Password appears in alarmlist when the default administrator password is set and
communication module is plugged in the controller. The purpose of alarm is to inform that the controller might
be or is connected to the untrusted interface and cybersecurity rules are not fulfilled due to default
administrator password.
Wrn Password reset e-mail addr is not set appears in alarmlist when there is no email address set and
the administrator password is not the default one. The purpose of alarm is to inform that there is possibility
that the controller might not be accessible by administrator password due to forgotten password reason.
Password reset procedure cannot be performed without filled email address. To fill out email address, the
administrator password is required.
6back to Browsing alarms

InteliLite 4 MRS16 Operator Guide 19
4 Login
Note: From all measurement pages we can fluently go to the setpoint group page by pressing Page button.
Note: Use Up and
Down button to
select setpoint group
Login.
Note: Use Enter button to enter setpoint group Login.
Note: Use Up and
Down Button to
select Login.
Note: Use Enter button to enter Login.

InteliLite 4 MRS16 Operator Guide 20
Note: Use Up and
Down Button to
change the digit.
Note: Use Left and Right button to move between digits.
UserID Edit
Note: Use Enter button to confirm the UserID or Page button to cancel entering Login.
PIN Edit
Note: Use Up and
Down Button to
change the digit.
Note: Use Left and Right button to move between digits.
