GEC 880
Service Manual
Version: 1.2/0111
PRODUCT MANUAL
ENGLISH

GEC 880 Service Manual
21.2/0111
Manufacturer’s Reference:
A Counter Intercom System consisting of GEC881/GEC882 and PA24W15V fulfils the requirements of the
EU-standard 89/336/EEC.
Application:
With regard to the CE mark, the Counter Intercom is suitable for the following types of application: residential
buildings, office and commercial premises, small businesses and industrial premises with public low-voltage mains
supply.
Therefore this equipment is CE-labelled.
Subject to change
The material in this document is for information only and subject to change without notice. While reasonable efforts
have been made in the preparation of this document to assure its accuracy, we assume no liability resulting from er-
rors or omissions in this document, or from the use of the information contained herein. We reserve the right to make
changes or revisions in the product design or the product manual without reservation and without obligation to notify
any person of such revisions and changes.
Cleaning the station
Use a damp cloth to clean the station when required. Do not use water, liquid detergent or paper towels to clean the
station!
PRECAUTIONS
To prevent defects, do not expose the station to rain or moisture. Do not open the station. Refer servicing to qualified
personnel only.
■ Do not connect ethernet devises! This can damage the operator staion and / or the enternet devices
■ Do not use the station near water, e.g. near a bathtub, pool, kitchen sink, laundry tub, swimming pool or in a wet
basement.
■ Do not place the station on an unstable cart, stand, or table. If the station falls, it can injure a person and cause
serious damage to the appliance.
■ Do not install the station in a location near heat sources such as radiators or air ducts, or in a place subject to direct
sunlight, or excessive dust or mechanical vibration or shock.
■ Mounting and installation of the Counter Intercom GEC 880 and of the equipment may be carried out by authorised
service personnel only when the power supply is unplugged.
■ The counter intercom GEC 880 may be opened only in electrostatic protected areas.
On the bottom of the station a label displays the station type and serial number for reference.
Please keep this description in safe custody!
Please do not give users / operators access to this manual. This will prevent “de-parametrisation“ by the
customer and may you some on-site service lookups.
GEC 880
Version: 1.2/0111
Number of Pages: 13

GEC 880 Service Manual
1.2/0111 3
Content
General 4
The Stations 4
Extent of supply 4
Operation 4
Technical Data 5
Installation 7
Components and cabling 7
Power supply and wall socket 7
Mounting of the client side 8
Microphone client side 8
Positioning of the client side micophon 9
Loudspeaker client side 10
Positioning of the client side loudspeaker 10
SERVICE MODE 11
Parameter Reset 12
Examples 12
Technical Support 13

General GEC 880 Service Manual
41.2/0111
General
Digital desktop counter intercom systems fulfill the widest variety of requirements – from security
solutions in banks to ski-lift stations and ticket counters to isolation wards in hospitals.
The modular construction of the system allows any number of desktop counter intercom systems to
be combined into one system. The basic unit is a digital intercom station, which is available in two
different versions (with and without gooseneck). Therefore it is very simple to select the optimum
station for every counter requirement.
The Stations
GEC 881
Digital desktop counter call station with plastic reinforced silicon keypad and
built-in microphone with omnidirectional characteristic for unrestricted
speech. Keypad with 15 keys, printed with easily understood pictograms.
Extent of supply:
Wall mounting box for surface mounting
3 m connection cable.
Further accessories must be ordered separately.
GEC 882
Digital desktop counter call station with plastic reinforced silicon keypad,
antitilt device and cardioid type goose neck microphone. Keypad with 15
keys, printed with easily understood non-verbal pictograms.
Extent of supply:
Wall mounting box for surface mounting
3 m connection cable.
Further accessories must be ordered separately.
Extent of supply
Counter Intercom system including:
Inside station GEC 881 or GEC 882
Modular outlet for surface or flush mounting
3 m (9.8 feet) connection cable ASKKAT6-3 from operator station to wall outlet
Manual and quick installation guide
Operation
See GEC 880 User Manual.

GEC 880 Service Manual Technical Data
1.2/0111 5
Technical Data
Technical Data GEC 881 / GEC 882
IP-rating: IP 30
MTBF: 1.37 mio. h
Loudspeakers: Internal: 8 Ohm
External: connection possibility for
loudspeaker(s) 4 – 16 Ohm
Internal microphone GEC 881: omnidirectional electret microphone
GEC 882: gooseneck cardioid electret microphone
both with adjustable speaking zone
Amplifier: outside: built-in amplifier with 10/15 W
inside: built-in amplifier with 0.6/0.8 W
Power supply: 12 – 18 VDC, 1.2 A
Cabling: 10-wires (8 signal + 2 power supply)
Connection: RJ 10 socket (for headset/handset)
RJ45 socket (for outside microphone, outside loudspeaker,
proximity switch or bell button, AUX output)
Frequency range: 500 Hz – 15 kHz
Operating temperature range: 0° C to +50° C
(32° F to 122° F)
Storage temperature range: –20° C to +60° C
(–4° F to 140° F)
Relative humidity: 20% to 80%
Measurements: GEC 881: 66 x 55 x 230 mm (2.6 x 2.2 x 9.1 in)
GEC 882: 179 x 280 x 230 mm (7.1 x 11 x 9.1 in)
length of gooseneck: 422 mm (16.6 in)
Weight incl. package: GEC 881: 280 g (0.6 lbs)
GEC 882: 440 g (1 lb)
Technical Data Q400
Directivity: cardioid to the front
Directivity: 15 mV / Pa
Frequency range: 100 Hz – 8 kHz
Temperature range: –25°C to +70°C (–13° F to 158° F)
Cable length: 2.8 m (9.2 ft) shielded
Measurements: W 24 x H 42 x D 13 mm (1.69 x 0.83 x 0.51 in)
Colour: Black
Technical Data MIC 480
Type: Back electret condenser microphone
Directivity: omnidirectional
Sensitivity: 5.6 mV / Pa
Frequency range: 20 Hz – 16 kHz
IP rating: IP 53 (only if installed correctly)
Temperature range: –20°C to +60°C (–4° F to 140° F)
Colour: black
Measurements: ø 14 x D 20 mm (0.55 x 0.79 in)
Types: MIC480: 4 m (13.1 ft) shielded
MIC480S-10: 10 m (32.8 ft) shielded

Technical Data GEC 880 Service Manual
61.2/0111
Technical Data AL10-16
Load rating / music power: 12/15 W
Impedance: 16 Ohm
Sound Pressure Level: 94 dB/W/m
Max. Sound Pressure Level: 110 dB (1 m)
Transmission range (–3 dB): 220 - 16 000 Hz
Transmission angle (–6 dB): Horizontal (3 m): 1/4/8 kHz: 220°/60°/60°
Vertical (3 m): 1/4/8 kHz: 140°/100°/30°
Material: housing: plastic, grille: metal
Net weight: 1,600 g
Connection: 2-core cable (50 cm)
Accessories (included): U-type mounting bracket
Dimensions (including brackets): W 100 mm, H 300 mm, D 98 mm
(3.9“ x 11.8“ x 3.9“)
Colours: Black (AL10-16S), White (AL10-16W)
Technical Data PA 24W15V
Primary: 90 – 264 VAC (47 - 63 Hz)
Secondary: 14,5 – 15,5 VDC, 1,6 ADC, 24 W
Efficiency: 75 – 85%
Temperature range: –5° C bis +40° C (23°F 104°F)
Measurements: W 54 mm x H 110 mm x D 38 mm
(2.12 x 4.33 x 1.49 in)
Weight: approx. 175 g
Colour: black
Cable length: 1.5 m (4.9 ft)
Technical Data Power Cable
Types: KAB-C13-AU (Australia)
KAB-C13-EU (Europe)
KAB-C13-UK (Great Britain)
KAB-C13-US (USA)
Cable length: 1.5 m (4.9 ft)
Technical Data KABJTAG3
Weight: approx. 73 g
Cable length: 150 cm (60 in)

GEC 880 Service Manual Installation
1.2/0111 7
Installation
Components and cabling
Power supply and wall socket
Power supply unit
24 W high-efficiency switched-mode power supply. The power cable must be ordered seperately
Power supply:
PA24W15V
Power Cable:
KAB-C13-AU (Australia)
KAB-C13-EU (Europe)
KAB-C13-UK (Great Britain)
KAB-C13-US (USA)
Please use only DC power supplies with 12 to 18 V sec. and 1.2 A min. The Counter Intercom station is
not qualified for AC supply or DC supply exceeding 18 V.
Wall socket
The operator station must be connected to the wall socket via the supplied cable (CAT6, straight, not
crossed).
The outside loudspeaker, microphone and bell button are connected to the wall socket. Pin assignment
see ”Components and cabling” above.
Attention: Do not mis-connect the wires of the outside microphone. Polarity must be observed.
However, polarity of the outside loudspeaker is not relevant.
Attention: If you connect a crossed-out RJ45 cable, irreparable damage to the Intercom station may
occur!
GEC 882
AL10-16
Q400
PA24W15V
KAB-C13-**
Option:
Headset
ASKKAT6-3, 3 m*
Cable length 2.8 m (9.2 ft)
Operator side
Client side
glass, wall, etc.
communication hatch
Cable length 1.5 m (4.9 ft)
wall
socket *
* ...Included in extent of supply
**...Depending on the country-specific
version (AU/EU/UK/US)
LS+
LS–
IN+
AUX+
AUX–
IN–
MIC+
MIC–
1
2
3
4
5
6
7
8
zur GEC 881/
GEC 882
Measurements wall mount box:
88 x 88 x 30 (3.5 x 3.5 x 1.2)
50 (1.97)
50 (1.97)

Mounting of the client side GEC 880 Service Manual
81.2/0111
Mounting of the client side
The loudspeaker must be mounted at least 1 m / 40 inches away from the microphone. If possible, the
loudspeaker should not face the microphone directly because this leads to an echo of the operator
voice at the inside station.
1. Mounting version A: Loudspeaker at the top (best for acoustic separation of multiple queues)
2. Mounting version B: Loudspeaker at the side in level of ears (best for single queue situations)
If possible, the microphone should be mounted at the bottom of the counter, in direction to the client.
If this is not possible, the microphone has to be mounted aside in direction to the client. The closer the
microphone is mounted to the clients mouth, the lower the volume required at the operator station.
3. Mounting version A: Microphone mounted in the middle of the counter
4. Mounting version B: Build-in microphone at the side
Microphone client side
The outside microphone should not be mounted nearby the outside loudspeaker and, most notably, it
should not face the sound beam of the speaker(s). The call station will try to suppress audible feedback
at any time and therefore will reduce the outside volume level at situations with high acoustic coupling.
If the outside microphone is installed very near to the outside speaker, maximum outside volume level
will not be possible.
Mouse Microphone Q400
This microphone has a special directional characteristic as shown in the picture. It should be mounted
in such a way, that the speech of the client enters the microphone in direction of the arrows. The
microphone can also be used for outdoor mounting, but it must be protected against rain and moisture.
Technical data see page 5.
Build-in Microphone MIC 480
The build-in microphone is designed to fit panels up to 10 mm (0.4 inch) thick. Technical data see page 5 .
Note: To fullfill the IP53-classification the opening of the microphone must face to the bottom.
1
2
1
4
3
Bore-hole
Mounting
Opening
to the bottom
max. 10 mm (0.39 in)
1.5 mm
(0.06 in)
8 mm
(0.32 in)

GEC 880 Service Manual Mounting of the client side
1.2/0111 9
Positioning of the client side micophon
When mounting the client side microphone a minimum distance (l) between client side and service side
opening must be insured.
If the distance is too small, the audio quality decreases. The two most common cases are shown in the
following figures.
Situation 1
Situation 2
Settings
For a the optimal audio quality don‘t change the parameters SZE, AEC, NLP. Normaly with the default
value SZE = 5, AEC = 3 and NLP = 3 you get the best quality (paramters see page 11).
service side
service si
d
e
client side
MIC Q 400
l= min. 25cm
MIC Q 480
l= min. 35cm
l
l
MIC
service side
s
ervice si
d
e
client side
MIC Q 400
l= min. 25cm
l
l
MIC

Mounting of the client side GEC 880 Service Manual
10 1.2/0111
Loudspeaker client side
The outside loudspeaker must have 4 to 16 ohms impedance and shall not be mounted to far from the
wall socket, because otherwise a larger cable diameter is required. For greater distances a 16 Ohm
loudspeaker is preferable. This loudspeaker allows a line length up to 4 times as large as compared to
a 4 ohm loudspeaker.
Connection of multiple loudspeakers in series or parallel is allowed as long as the impedance of the
entire circuit does not drop below 4 ohms.
AL10-16
For ”Technical Data” see page 5.
When using line arrays (like e.g. AL10-16) the directivity of the array should be used to address only
the parts of the outside area, in which the customer is situated. Depending on the building construction
the line array is positioned in horizontally or vertically (see ”Mounting of the client side” on page 8).
Positioning of the client side loudspeaker
Settings
If operating more than one call stations GEC 882 side by side, feature “AHC” (via parameter “NLP” in
service mode) has to be switched on (value 3 = already active in standard), to compensate for the
acoustic coupling between the call stations (see page 11).
Example for a single counter: Example for multiple counters:
In this setup the speech of the
operator is audible in the entire
Example how to utilize the directivity of a speaker line array
(e.g. AL10-16) for separately addressing individual queues via
horizontal mounting above the counter.
area in front of the counter.

GEC 880 Service Manual SERVICE MODE
1.2/0111 11
SERVICE MODE
The call station is in USER MODE after booting. Via a special key combination unknown to operators
you can enter the so-called SERVICE MODE, where more settings than in USER MODE can be
applied. All settings are entered via the keyboard.
Via the key combination + + (press simultaneously with key first – easily to be remembered
– because situated in a diagonal row) you can switch to SERVICE MODE and back to USER MODE.
As long as the call station is in service mode, each of the 6 digits of the display will show a dot (e.g.
S.T.D.B.Y. instead of STDBY).
With the key it is possible to scroll through the list of parameters. With the keys andthe value
of the individual parameters can be changed.
Parameter Description Value
range
Default
value
ACK Acknowledgement tones ON/OFF (“keypad tones”) 0 = OFF
1 = ON
0
AEC Noise surpression 0 = service side OFF, client side OFF
1 = service side ON, client side OFF
2 = service side OFF, client side ON
3 = service side ON, client side ON
3
ALM Sabotage alarm 0
ANK Automatic switch off
time
0= OFF
1-30 = automatic swich off time (s)
0
BEL Ring tone for contact 0 = OFF
1 = make
2 = break (contact)
1
GNG Call gong 0 = OFF
1 = ON
1
LCD Adjustment of LCdisplay contrast 1...10 5
LED Brightness of the LED 1...10 5
MAX Mode of the AUX output 0 = AUX OFF
1 = AUX reflect service side
2 = AUX reflect user side
3 = AUX reflect both sides
0
MEX Amplification outside microphone Increase in 0.5 dB steps
0...127
MIC 480 90
Q400 v2.0 (AGK) 90
Q400 v1.0 (Peiker) 102
X-MIC 473 (Schwanenhals) 96
MHS Amplification headset microphone 75
NLP NLP (Non-linear Processor) + AHC (Anti-howling control) 0 = NLP OFF; AHC OFF
1 = NLP ON; AHC OFF
2 = NLP OFFs; AHC ON
3 = NLP ON, AHC ON
3
(may not be
changed)
SZE Size of speaking zone of external microphone 0 = limit OFF
1 = limit approx. 2,5m (8.2 ft)
9 = limit approx. 25 cm (9.8 in)
5
SZI Size of speaking zone of internal microphone 5
VAX Volume AUX-output* 0...10 10
VCE Volume of the tones in the outside zone (call gong, alarm tone) 0...10 5
VCI Volume of the tones at the inside station (keypad tones, ring
tone, alarm tone)
1...10 5
VEB Volume of external speaker in BOOST Mode 1...13 8
VEX Volume of external speaker 1...13 8
* for connection to Audiocom

SERVICE MODE GEC 880 Service Manual
12 1.2/0111
Parameter Reset
It is possible to reset all parameters to the factory presets. For this the following procedure is carried
out:
Unplug the power supply
Press and hold down the following buttons + + 
Reconnect the power supply
The display shows RESET for one second.
Examples
Examples for setting the correct values:
Situation:
The internal microphone of the GEC 881 / GEC 882 is picking up too much noise from distant sources.
A characteristic which is more noise cancelling is desired.
Remedy: Increase the value of parameter SZI. Be careful: the speaker has to reduce the distance from
his mouth to the internal microphone now.
Situation: Bad sound quality during communication.
Remedy A: Enter Service Mode and check if all parameters are set to their default values. The default
values provide the best sound quality and should only be changed on special demand. Use the
”Parameter Reset” if required.
Remedy B: Check if all cabling is correct. Most importantly the GND connection (shield-GND
connected to pin 8 of the modular socket) and if the RJ45-cable is plugged in the station securely.

GEC 880 Service Manual Technical Support
1.2/0111 13
Technical Support
For more information about our products and services please visit:
www.software-manuals.com
