Comnet FVT10 User manual

INS_FVT10_REV–
12/03/10
PAGE 1
INSTALLATION AND OPERATION MANUAL
FVT10
VIDEO TRANSMITTER
The FVT10 single channel transmitter supports one independent AM video
signal on one independent multimode optical fiber. The FVT10 video transmitter
is compatible with the FVR10, FVR10M, FVR11, FVR11M, FVR21 and FVR22
receivers. Plug-and-play design ensures ease of installation requiring no
electrical or optical adjustments. The FVT10 is interchangeable between stand-
alone or card mount configurations.
See Figure A for mounting instructions.

INS_FVT10_REV–
12/03/10
PAGE 2
NOTE: Remove Electrical Connector for Rack Mount Units
FIGURE 2 – FVT10 TRANSMITTER
FIGURE 1 – FVT10 TRANSMITTER
INSTALLATION AND OPERATION MANUAL FVT10
REAR PANELFRONT PANEL
TECH SUPPORT: 1.888.678.9427
OPTICAL FIBER
BLACK
BLACK WITH WHITE STRIPE
Power Supply:
Surface Mount: 8–15 VDC @ 80mA
Rack Mount: From Rack
FIGURE 3 – LED INDICATOR
VIDEO PRESENT
GREEN A Video signal is
present.
RED No Video signal is
present.
OFF Unit not powered up.

INS_FVT10_REV–
12/03/10
PAGE 3
© 2010 Communications Networks Corporation. All Rights Reserved. “ComNet” and the “ComNet Logo” are registered trademarks of Communication Networks, LLC.
3 CORPORATE DRIVE | DANBURY, CT 06810 | USA
T: 203.796.5300 | F: 203.796.5303 | TECH SUPPORT: 1.888.678.9427 | [e-mail]
8 TURNBERRY PARK ROAD | GILDERSOME | MORLEY | LEEDS, UK LS27 7LE
T: [phone] | F: [phone] | [e-mail]
INSTALLATION CONSIDERATIONS
This fiber-optic link is supplied as a Standalone/Rack module. Units
should be installed in dry locations protected from extremes of
temperature and humidity.
C1-US, C1-EU, C1-AU OR C1-CH CARD CAGE RACKS
CAUTION: Although the units are hot-swappable and may be installed
without turning power off to the rack, ComNet recommends that
the power supply be turned off and that the rack power supply
is disconnected from any power source. Note: Remove electrical
connector before installing in card cage rack.
1. Make sure that the card is oriented right side up, and slide it into
the card guides in the rack until the edge connector at the back
of the card seats in the corresponding slot in the rack’s connector
panel. Seating may require thumb pressure on the top and bottom
of the card’s front panel.
CAUTION: Take care not to press on any of the LEDs.
2. Tighten the two thumb screws on the card until the front panel of
the card is seated against the front of the rack.
WARNING: Unit is to be used with a Listed Class 2 or LPS power supply rated
8-15 VDC @ 80mA.
IMPORTANT SAFEGUARDS:
A) Elevated Operating Ambient - If installed in a closed or multi-unit rack
assembly, the operating ambient temperature of the rack environment may
be greater than room ambient. Therefore, consideration should be given to
installing the equipment in an environment compatible with the maximum
ambient temperature (Tma) specified by the manufacturer.
B) Reduced Air Flow - Installation of the equipment in a rack should be such
that the amount of air flow required for safe operation of the equipment is
not compromised.
MECHANICAL INSTALLATION INSTRUCTIONS
FIGURE A
Dimensions are for a standard ComNet one slot module
.156 [3.96 mm]
.313 [7.95 mm]
