Conel xr5i sl User manual

Router XR5i and XR5i SL
USER’S GUIDE
Declared system
ISO 9001:2009
WWW.INFOPULSAS.LT
[email protected]

OBSAH
2
Contents
1. Safety instruction 5
2. Description of the router 6
2.1. Introduction 6
2.2. Delivery Identification 6
2.3. Power Supply 7
2.4. Technical parameters 8
2.5. Control microcomputer 8
2.6. User interfaces (Connectors) 8
2.6.1. Connection of the PWR Supply Connector 10
2.6.2. Connection of the XPORT Connector – ETH 11
2.6.3. Connection of the ETH Connector 11
2.6.4. Connection of the I/O Connector 12
2.6.5. Connection of the Connector USB 12
2.7. Technical specification of I/O port 13
2.8. Technical specification of expansion ETH XPORT 13
2.9. Modem status indication 14
2.10. Putting into operation 14
2.11. Mechanical external dimensions and mounting recommendations 15
3. Expansion port mounting 18
3.1. Expansion port mounting for XR5i 18
3.2. Expansion port mounting for XR5i SL 20
4. Configuration setting over web browser 22
4.1. Network Status 23
4.2. DHCP Status 24
4.3. IPsec status 24
4.4. DynDNS status 24
4.5. System Log 25
4.6. LAN Configuration 25
4.7. VRRP Configuration 31
4.8. PPPoE Configuration 32
4.9. Firewall Configuration 33
4.10. NAT Configuration 34
4.11. OpenVPN Tunnel Configuration 38
4.12. IPSec Tunnel Configuration 42
4.13. GRE Tunnels Configuration 44
4.14. L2TP Configuration 46
4.15. DynDNS Client Configuration 48
4.16. NTP Client Configuration 49
4.17. SNMP Configuration 50
4.18. SMTP Configuration 52
4.19. Expansion Port Configuration 53
4.20. USB Port Configuration 54
4.21. Startup Script 56
4.21.1. 802.1d Ethernet Bridging setting-up 56
4.21.2. IO program 57
4.21.3. Controlling USR LED 57
4.22. Up/Down Script 58
4.23. Automatic update configuration 58

CONTENTS
3 - 3 - 11.5.2011
4.24. Change profile 59
4.25. Change password 60
4.26. Set real time clock 60
4.27. Backup Configuration 60
4.28. Restore Configuration 60
4.29. Update firmware 61
4.30. Reboot 61
4.31. Default settings 62
4.31.1. LAN Configuration 62
4.31.2. VRRP Configuration 63
4.31.3. Firewall Configuration 63
4.31.4. NAT Configuration 64
4.31.5. OpenVPN Tunnel Configuration 64
4.31.6. IPsec Tunnel Configuration 66
4.31.7. GRE Tunnels Configuration 67
4.31.8. L2TP Tunnel Configuration 67
4.31.9. DynDNS Configuration 68
4.31.10. NTP Configuration 68
4.31.11. SNMP Configuration 68
4.31.12. Expansion Port Configuration 69
4.31.13. USB Port Configuration 69
4.31.14. Startup script 70
4.31.15. Up/Down script 71
4.31.16. Automatic update 71
5. Configuration setting over Telnet 72
6. Possible problems 73
7. FAQ 73
8. Customers support 74
9. Product disposal instructions 74
10. Guarantee Claim Guidelines 75
11. Guarantee certificate 78

CONTENTS
4 - 4 - 11.5.2011
Symbols used
Danger – important notice, which may have an influence on the user’s safety or the function
of the device.
Attention – notice on possible problems, which can arise to in specific cases.
Information, notice – information, which contains useful advices or special interest.
GPL licence
Source codes under GPL licence are available free of charge by sending email
on [email protected].
Conel s.r.o., Sokolska 71, 562 04 Usti nad Orlici, Czech Republic
Issued in CZ, 5/11/2011

SAFETY INSTRUCTION
5
1. Safety instruction
Please, observe the following instructions:
•The communication router must be used in compliance with all applicable international and
national laws and in compliance with any special restrictions regulating the utilization of the
communication router in prescribed applications and environments.
•To prevent possible injury to health and damage to appliances and to ensure that all
the relevant provisions have been complied with, use only the original accessories.
Unauthorised modifications or utilization of accessories that have not been approved may
result in damage to the communication router and in a breach of applicable regulations.
Unauthorized modifications or utilization of accessories that have not been approved may
result in the termination of the validity of the guarantee.
•Do not open the communication router cover.
•Voltage at the power connector of the communication router must not be exceeded.
•Do not expose the communication router to extreme ambient conditions. Protect
the communication router against dust, moisture and high temperature.
•It is recommended that the communication router should not be used at petrol stations.
•Switch off the communication router when travelling by airplane. Utilization
of the communication router in a airplane may endanger the operation of the airplane
or interfere with the mobile telephone network, and may be unlawful. Failure to observe
these instructions may result in the suspension or cancellation of telephone services for
the respective client, or, it may result in legal sanctions; it may also result in both
eventualities.
•When using the communication router in the close proximity of personal medical devices,
such as cardiac pacemakers or hearing aids, you must proceed with heightened caution.
•If it is in the proximity of TV sets, radio receivers and personal computers, the telephone
may cause interference.
•It is recommended that you should create an appropriate copy or backup
of all the important settings that are stored in the memory of the device.

DESCRIPTION
6
2. Description of the router
2.1. Introduction
The ethernet router is a compact electronic device which enables data transfer. In
addition, the router is equipped with a two USB 1.1 Host interfaces which is designed only for
connection to a USB device.
The ethernet router has two versions. The first version is basic XR5i and the second
version is XR5i SL in the aluminum box.
Examples of Possible Applications
•security system
•remote monitoring
•vending and dispatcher machines
2.2. Delivery Identification
Specimen Label:
Trade name
Type name Other
XR5i XR-5i Basic version
XR5i SL XR-5i-SL Version in the aluminum box

DESCRIPTION
7
Example of expansion port XPORT:
Trade name Type name Power supply
Expansion port ETH XC-ETH Internal power supply
Basic delivered set of router includes:
•ethernet router,
•power supply,
•crossover UTP cable,
•plastic clips for the DIN rail with fixing screws,
•installation CD containing instructions.
The router standard is designed for:
•possibility to be put on a work surface,
•for mounting onto a DIN rail, the plastic clips are included.
2.3. Power Supply
The router requires +10 V DC to +30 V DC supply. Protection against reversed polarity
without signaling is built into the router.
The peak power consumption when USB port used is 15 W. For correct operation it is
necessary that the power source is able to supply a peak current of 1.3 A.

DESCRIPTION
8
2.4. Technical parameters
UMTS/HSDPA/HSUPA/EDGE/GPRS/GSM module
Complies with standards ETSI EN 301 489-1 V1.8.1,
EN 60950-1:06 ed.2
Temperature range Function
Storage -30
o
C to +60
o
C
-40
o
C to +85
o
C
Protection Freely
In switch board IP20 IP56
Supply voltage 10 to 30 V DC
Consumption to 3 W
Dimensions 42x86x94 mm (DIN rail 35 mm)
Weight 250 g
User interface ETH
USB
XPORT
Ethernet (10/100 Mbit/s)
2x USB 1.1 type A host
Second ETH port
2.5. Control microcomputer
The core of the router is a 32-bit microprocessor with 64 MB RAM, 32 MB FLASH
EEPROM, serial interface RS-232 and an Ethernet interface 10/100 Mbit/s. Towards to the
user it is connected on the Ethernet interface.
The software is built on the Linux operating system.
The router support services like DHCP, NAT, GRE, IPsec tunnels, etc.
The modem settings are saved in the FLASH EEPROM memory. All modem
configurations can be done through a web interface (HTTP), which is protected by security
password.
Actual firmware version: 2.1.0 (22.4.2011)
2.6. User interfaces (Connectors)
On the back panel of router the following connectors are located:
•one RJ12 or MRT9 connector (PWR) – for connection of the power supply adapter,
•one RJ45 connector (ETH) – for connection into the local area network(LAN),
•one RJ45 connector (optional XPORT) – for connection of the local any arrangement,
•one MRT9 (I/O) – interface with one binary input and with one binary output
(only version XR5i SL)
•two USB-A Host connectors (USB) – for connection of the devices to the router, USB’s
supports equipments with PL-2303 and FTDI USB/RS232 converter.

DESCRIPTION
9
Front panel XR5i
Rear panel XR5i
Front panel XR5i SL
Rear panel XR5i SL

DESCRIPTION
10
2.6.1. Connection of the PWR Supply Connector
Panel socket RJ12.
Pin
number Signal mark Description
1 +UN Positive pole of DC supply voltage (+10 to +30 V)
2 NC Signal not connected
3 NC Signal not connected
4 +UN Positive pole of DC supply voltage (+10 to +30 V)
5 GND Negative pole of DC supply voltage
6 GND Negative pole of DC supply voltage
Circuit example:
•Panel socket MRT9.
Pin
number Signal mark Description
1 +UN Positive pole of DC supply voltage (+10 to +30 VDC)
2 GND Negative pole of DC supply voltage
Circuit example:
The positive pole +UN is marked by a red socket on the power supply.
Pin 1 – +UN
Pin 2 – NC
Pin 3 – NC
Pin 4 – +UN
Pin 5 – GND
Pin 6
–
GND
Router
DC
+
Pin 1 – +UN
Pin 2 – GND
Router
DC
+

DESCRIPTION
11
2.6.2. Connection of the XPORT Connector – ETH
Panel socket RJ45.
Pin
number Signal mark
Description Data flow direction
1 TXD+ Transmit Data – positive pole Input/Output
2 TXD- Transmit Data – negative pole Input/Output
3 RXD+ Receive Data – positive pole Input/Output
4 --- ---
5 --- ---
6 RXD- Receive Data – negative pole Input/Output
7 --- ---
8 --- ---
ATTENTION! Port ETH is not POE (Power Over Ethernet) compatible!
Example of the ETH router connection:
2.6.3. Connection of the ETH Connector
Panel socket RJ45.
Pin
number Signal mark
Description Data flow direction
1 TXD+ Transmit Data – positive pole Input/Output
2 TXD- Transmit Data – negative pole Input/Output
3 RXD+ Receive Data – positive pole Input/Output
4 --- ---
5 --- ---
6 RXD- Receive Data – negative pole Input/Output
7 --- ---
8 --- ---
ATTENTION! Port ETH is not POE (Power Over Ethernet) compatible!
Router
USB
ETH
XPORT
PWR
UTP cable
Switch

DESCRIPTION
12
Example of the ETH router connection:
2.6.4. Connection of the I/O Connector
Pin
number Signal mark
Description Data flow direction
1 BIN Binary input Input
2 GND Signal ground
3 OUT Binary output Output
The user interface I/O is for processing of binary input signal and to control (settings)
of binary output signal.
Example of the I/O router connection:
I/O port is part of the XR5i SL version only.
2.6.5. Connection of the Connector USB
Panel socket USB-A.
Pin
number Signal mark
Description Data flow direction
1 VCC Positive pole of 5V DC supply voltage
2 USB data - USB data signal – negative pole Input/Output
3 USB data + USB data signal – positive pole Input/Output
4 GND Negative pole of DC supply voltage
Router
Pin 1 - BIN
Pin 2 - GND
Pin 3 - OUT
+12 V
Router
USB
ETH
XPORT
PWR
UTP cable
Switch

DESCRIPTION
13
Example of the USB router connection:
2.7. Technical specification of I/O port
Port IO
Environment Operating temperature -20 .. +55 °C
Binary input reed contact
with trigger level 1,3 up to 1,4 V
Input/Output
Binary output 120 mA/max. 30 V
I/O port is part of the XR5i SL version only.
2.8. Technical specification of expansion ETH XPORT
Expansion port ETH
Power supply Internal ....
Operating temperature -20 .. +55 °CEnvironment
Storage temperature -20 .. +85 °C
Emission EN 55022/B
Immunity ETS 300 342
Standards
Safety EN 60950
Max. bit rate 100 MbpsEthernet
(IEEE 802.3)
Max. total cable length
(300Bd, 200nF/km) 100 m
Router
USB
ETH
XPORT
PWR
USB cable
USB device

DESCRIPTION
14
2.9. Modem status indication
On the front and back panel of the modem there are altogether four LED indicators,
which inform on the modem status.
Panel Color Description
Description
Green PWR Permanently on ……….. starting of the router
Blinking 1:9 ................... router is active
Front Yellow USR Defined by user’s firmware
Green – On ...................... selected 100 Mbit/s
Off ...................... selected 10 Mbit/s
Back Green – On........................ the network cable is connected
Blinking ……….... data transmission
Off ....................... the network cable is not connected
2.10. Putting into operation
Before putting the XR5i or XR5i SL router into operation it is necessary to connect all
components needed for the operation of your applications.
The router is put into operation by connection of the power supply to the router.
The behavior of the router can be modified by using the web interface which is described
in the following chapter.

DESCRIPTION
15
2.11. Mechanical external dimensions and mounting recommendations

DESCRIPTION
16
For the majority of applications with a built-in router in a switch board it is possible to
recognize two sorts of environments:
• no public and industry environment of low voltage with high interference,
• public environment of low voltage without high interference.
For both of these environments it is possible to mount routers to switch board,
the following it is not need have no examination immunity or issues in connection with EMC
according to EN 60439-1 ed.2:00 + A1:04.
For compliance of EN 60439-1 ed.2:00 + A1:04 specifications it is necessary observe
next assembly of the router to the switch - board:
• for single cables we recommend to bind the bunch according to the following picture,
for this use we recommend:
 length of the bunch (combination of power supply and data cables) can
be maximum 1,5 m, if length of data cables exceeds 1,5 m or in the
event of, the cable leads towards the switch - board, we recommend to
use fit over - voltage protectors (surge suppressors),
 with data cables they mustn't carry cables with reticular tension
~ 230 V/50 Hz,
 all signals to sensors must be twisted pairs.
• sufficient space must be left before individual connectors for handling of cables,
• for correct function of the router we recommend to use in switch - board earth-
bonding distribution frame for grounding of power supply of router and data cables,

DESCRIPTION
17
• the circuit diagram of the XR5i router is on the following pictures,
• the circuit diagram of the XR5i SL router is on the following pictures.

EXPANSION PORT MOUNTING
18
3. Expansion port mounting
3.1. Expansion port mounting for XR5i
Attention! Expansion port XPORT include when the router XR5i is switch off.
After unscrewed two screws (position 8) on box bottom part (position 3) and carried
out box top part (position 2) the expansion port XPORT (position 6) connect to connector J3
(see below) of the router B-UR-5i motherboard (position 1) from TOP side. Expansion port is
mounted to motherboard by the help of three distant columns (position 7). After expansion
port mounting the box is screwed by the help three screws (position 8).
Connector J3

EXPANSION PORT MOUNTING
19
Parts list and description
Part
Description Number
1 Router motherboard 1
2 Box top part 1
3 Box bottom part 1
4 Rear head 1
5 Front head 1
6 Expansion port 1
7 Distant columns for expansion port XPORT mounting to motherboard 3
8 Screw for box completion 2

EXPANSION PORT MOUNTING
20
3.2. Expansion port mounting for XR5i SL
Attention! Expansion port XPORT include when the router XR5i SL is switch off.
After unscrewing four screws (position 10) on the rear panel (position 5)
and removing it is possible to take out the B-UR-5i motherboard (position 1). The expansion
port XPORT (position 2) is connected to connector J3 (see below) of the router B-UR-5
motherboard (position 1) from TOP side. The expansion port is mounted to the motherboard
by the help of three spacers (position 9). After mounting the expansion port the box is
screwed together by the help of four screws.
C
onnector J3
