Conel CR10 v2 SL User manual

CDMA router CR10 v2
USER’S MANUAL

USED SYMBOLS
Used symbols
Danger – important notice, which may have an influence on the user’s safety or the function
of the device.
Attention – notice on possible problems, which can arise in specific cases.
Information, notice – information, which contains useful advice or special interest.
GPL license
Source codes under GPL license are available free of charge by sending an email to:
[email protected].
Conel s.r.o., Sokolska 71, 562 04 Usti nad Orlici, Czech Republic
Manual issued in CZ, June 3, 2013
i

CONTENTS
Contents
1 Safety instruction 1
2 Product disposal instructions 2
3 Router description 3
4 Contents of package 4
5 Router design 5
5.1 Routerversions.................................... 5
5.2 Deliveryidentification ................................ 6
5.3 Versionoffirmwaremodule ............................. 7
5.4 Orderingcodes.................................... 8
5.4.1 Basicversion................................. 8
5.4.2 Fullversion .................................. 8
5.5 Basic dimensions of plastic box . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
5.6 Basic dimensions of metal box . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
5.7 Mechanical dimensions and mounting recommendations . . . . . . . . . . . . . 10
5.8 Removing from the DIN rail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
5.9 Description of the front panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
5.9.1 Statusindication ............................... 14
5.9.2 PowerconnectorPWR............................ 15
5.9.3 Antenna connector ANT, DIV (alternatively WIFI or WMBUS) . . . . . . 16
5.9.4 SIMcardreader ............................... 17
5.9.5 Ethernetport ................................. 17
5.9.6 PORT1 .................................... 19
5.9.7 PORT2 .................................... 19
5.9.8 USBPort ................................... 20
5.9.9 I/OPort .................................... 21
5.9.10Reset ..................................... 23
6 First use 24
6.1 Connecting the router before first use . . . . . . . . . . . . . . . . . . . . . . . 24
6.2 Start.......................................... 25
6.3 Configuration ..................................... 25
6.3.1 Configuration over web browser . . . . . . . . . . . . . . . . . . . . . . . 25
6.3.2 Configuration over Telnet . . . . . . . . . . . . . . . . . . . . . . . . . . 25
7 Technical parameters 26
ii

CONTENTS
7.1 Technical parameters of router . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
7.2 Technical parameters of module . . . . . . . . . . . . . . . . . . . . . . . . . . 26
7.3 Technical parameters of processor . . . . . . . . . . . . . . . . . . . . . . . . . 27
7.4 Technical parameters I/O port . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
7.5 Technical parameters of expansion port . . . . . . . . . . . . . . . . . . . . . . 27
8 Recommended literature 28
9 Possible problems 29
10 FAQ 30
11 Customers support 32
iii

LIST OF FIGURES
List of Figures
1 Contentsofpackage................................. 4
2 FrontpanelCR10v2B ................................ 5
3 FrontpanelCR10v2F ................................ 5
4 FrontpanelCR10v2BSL .............................. 5
5 FrontpanelCR10v2FSL .............................. 5
6 LabelCR10v2B ................................... 6
7 LabelCR10v2BSL ................................. 6
8 LabelCR10v2F ................................... 6
9 LabelCR10v2FSL ................................. 6
10 Basic dimensions of plastic box . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
11 Basic dimensions of metal box . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
12 Spacearoundantennas ............................... 10
13 Space around antennas for SL . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
14 Cablerouting ..................................... 11
15 Cable routing for SL version . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
16 Space in front of connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
17 Space in front of connectors – SL . . . . . . . . . . . . . . . . . . . . . . . . . . 11
18 Default position of DIN holder . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
19 RemovingfromtheDINrail ............................. 12
20 FrontpanelCR10v2FSL .............................. 13
21 Powerconnector ................................... 15
22 Connection of power supply connector . . . . . . . . . . . . . . . . . . . . . . . 15
23 Connection of power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
24 Externalantenna................................... 16
25 Connectingoftheantenna.............................. 16
26 EjectedSIMholder.................................. 17
27 Ethernetconnector.................................. 18
28 Connection of ethernet cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
29 Example of router connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
30 PORT1cableconnection .............................. 19
31 PORT2cableconnection .............................. 20
32 USBconnector .................................... 20
33 Connection PLC to the router . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
34 Connection flash memory to the router . . . . . . . . . . . . . . . . . . . . . . . 21
35 I/Oconnector..................................... 21
36 ConnectionofI/Ocable ............................... 22
37 Connection of input and output to the router . . . . . . . . . . . . . . . . . . . . 22
38 Routerreset...................................... 23
40 Routerconnection .................................. 24
iv

LIST OF TABLES
List of Tables
1 Routerversions.................................... 5
2 Deliveryidentification ................................ 6
3 Versionoffirmwaremodule ............................. 7
4 Ordering codes of basic version . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
5 Ordering codes of full version . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
6 Frontpaneldescription................................ 13
7 Routerstatusindication ............................... 14
8 Connection of power connector . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
9 Connection of Ethernet connector . . . . . . . . . . . . . . . . . . . . . . . . . . 17
10 Connection of USB connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
11 ConnectionofI/Oport ................................ 21
12 Description of reset and restart router . . . . . . . . . . . . . . . . . . . . . . . 23
12 Technical parameters of router . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
13 Technical parameters of module . . . . . . . . . . . . . . . . . . . . . . . . . . 26
14 Technical parameters of processor . . . . . . . . . . . . . . . . . . . . . . . . . 27
15 Technical parameters I/O port . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
v

1. SAFETY INSTRUCTION
1. Safety instruction
Please, observe the following instructions:
•The router must be used in compliance with all applicable international and national laws
and in compliance with any special restrictions regulating the utilization of the router in
prescribed applications and environments.
•To prevent possible injury to health and damage to appliances and to ensure that all
the relevant provisions have been complied with, use only the original accessories.
Unauthorised modifications or utilization of accessories that have not been approved
may result in damage to the router and in a breach of applicable regulations. Unautho-
rized modifications or utilization of accessories that have not been approved may result
in the termination of the validity of the guarantee.
•The router can not be opened.
•Before handling of the SIM card turn off the router and disconnect it from power supply.
•Caution! The SIM card could be swallowed by small children.
•It must not be exceeded by the maximum voltage 30 V DC power connector on the router.
•Do not expose the router to extreme ambient conditions. Protect the router against dust,
moisture and high temperature.
•The router should not be used at petrol stations of flammable and explosive materials.
We remind the users of the duty to observe the restrictions concerning the utilization
of radio devices at petrol stations, in chemical plants, or in the course of blasting works
in which explosives are used.
•Switch off the router when travelling by plane. Utilization of the router in a plane may
endanger the operation of the plane or interfere with the mobile telephone network, and
may be unlawful. Failure to observe these instructions may result in the suspension
or cancellation of telephone services for the respective client, or, it may result in legal
sanctions; it may also result in both eventualities.
•When using the router in the close proximity of personal medical devices, such as cardiac
pacemakers or hearing aids, you must proceed with heightened caution.
•If it is in the proximity of TV sets, radio receivers and personal computers, the telephone
may cause interference.
•It is recommended that you should create an appropriate copy or backup of all the im-
portant settings that are stored in the memory of the device.
1

2. PRODUCT DISPOSAL INSTRUCTIONS
2. Product disposal instructions
The WEEE (Waste Electrical and Electronic Equipment: 2002/96/EC) directive has been
introduced to ensure that electrical/electronic products are recycled using the best available
recovery techniques to minimize the impact on the environment. This product contains high
quality materials and components which can be recycled. At the end of it’s life this product
MUST NOT be mixed with other commercial waste for disposal. Check the terms and condi-
tions of your supplier for disposal information.
2

3. ROUTER DESCRIPTION
3. Router description
CDMA wireless router CR10 v2 is used to wirelessly connect various equipments and de-
vices via Ethernet interface 10/100 to the Internet or intranet. Thanks to high data transfer
speed of up to 14.7 Mbit/s (download) and upload speed up to 5.4 Mbit/s it is an ideal wire-
less solution for traffic and security camera systems, individual computers, LAN networks,
automatic teller machines (ATM) and other self-service terminals, etc.
As a standard, this exceptionally CR10 v2 wireless router is equipped with one Ethernet
10/100, one USB Host port, one binary Input/output (I/O) port and one SIM card. To save
and backup communication data a version with two SIM cards is available. The wide range of
interface options of the CDMA router further expands Port1 and Port2 expansion ports, which
are selected by the customer. For Port1 are available: Ethernet port 10/100, serial interface
ports RS232/RS485/RS422/MBUS or inputs/outputs (I/O – CNT). Port2 may be equipped with
serial interfaces RS232/RS485/RS422/MBUS, wireless interfaces WIFI/WMBUS, SDH expan-
sion port or inputs/outputs (I/O – CNT). Both of ports can be fitted with internal switch SWITCH.
This 3G wireless router is supplied either in a plastic or metal casing, based on the require-
ments of the customer.
Configuration is done via web interface protected by password. The 3G CDMA router sup-
ports creation of VPN tunnels using technologies IPsec, OpenVPN and L2TP to ensure safe
communication. Web interface provides detail statistics about the 3G router activities, signal
strength, detailed log, etc. Cellular router supports functions: DHCP, NAT, NAT-T, DynDNS,
NTP, VRRP, control by SMS and many other functions.
Other diagnostic functions ensuring continuous communication include automatic inspec-
tion of PPP connection offering an automatic restart feature – in case of connection losses,
or hardware watchdog which monitors the status of the router. With the help of a special
window (start up script window) you may insert Linux scripts for various actions. For some ap-
plications the key option to create several different configurations for one 3G wireless router,
the so-called profiles (maximum of 4), and the option to switch between them (for example
via SMS, binary input status, etc.) is essential. Cellular wireless routers may automatically
upgrade configuration and firmware from server. This allows mass reconfiguration of many
routers in one time.
For easy use additional software may be used - communication VPN server Digicluster
and software for router monitoring R-SeeNet.
Examples of possible applications
•mobile office
•fleet management
•security system
•telematic
•telemetric
•remote monitoring
•vending and dispatcher machines
3

4. CONTENTS OF PACKAGE
4. Contents of package
Basic delivered set of router includes:
•router,
•power supply,
•crossover UTP cable,
•two external antennas,
•clip for the DIN rail,
•installation CD containing instructions,
•paper start guide.
Figure 1: Contents of package
Note: The router box and DIN mount are supplied in a metal case in the SL version.
The router can also be supplied as expansion accessories:
•One (Basic version) or two (Full version) expansion ports: RS232, RS485/422, MBUS,
ETHERNET, CNT, SWITCH, WIFI, WMBUS or SDH. Separation columns for mounting
expansion boards are included.
4

5. ROUTER DESIGN
5. Router design
5.1 Router versions
CR10 v2 router is supplied in the following versions:
Box SIM1 SIM2 I/O USB PORT1 PORT2 ETH
CR10 v2B Plastic     
CR10 v2B SL Metal     
CR10 v2F Plastic       
CR10 v2F SL Metal       
Table 1: Router versions
Figure 2: Front panel CR10 v2B
Figure 3: Front panel CR10 v2F
Figure 4: Front panel CR10 v2B SL
Figure 5: Front panel CR10 v2F SL
5

5. ROUTER DESIGN
5.2 Delivery identification
Trade name Type name Other
CR10 v2B CR-10-v2 Basic version
CR10 v2B SL CR-10-v2 Basic version in the metal box
CR10 v2F CR-10-v2 Full version
CR10 v2F SL CR-10-v2 Full version in the metal box
Table 2: Delivery identification
Figure 6: Label CR10 v2B
Figure 7: Label CR10 v2B SL
Figure 8: Label CR10 v2F
Figure 9: Label CR10 v2F SL
6

5. ROUTER DESIGN
5.3 Version of firmware module
Each operator can have another CDMA network, so it is necessary to generate a special
firmware for each operator. Version of the firmware is indicated by two-digit code in the name
of the product.
Operator Code
Poland Orange 01
Poland Plus 02
Czech Republic O2 03
Germany Inet 04
Sweden Net.1 05
Norway Net.1 06
Russia Skylink 07
Table 3: Version of firmware module
Example of trade name: CR10 v2B-01
Example of type name: CR-10-v2B ver. 01
7

5. ROUTER DESIGN
5.4 Ordering codes
Order codes are given for the Polish operator Orange. Another operator can be selected
by changing two digits according to Table 3 Version of firmware module on page 7.
5.4.1 Basic version
Expansion port Ordering code
Version without expansion port CR10 v2B-01 set
Version with Ethernet expansion port CR10 v2B-01 ETH set
Version with RS232 expansion port CR10 v2B-01 RS232 set
Version with RS485 expansion port CR10 v2B-01 RS458 set
Version with MBUS expansion port CR10 v2B-01 MBUS set
Version with CNT expansion port CR10 v2B-01 CNT set
Table 4: Ordering codes of basic version
5.4.2 Full version
Expansion port Possible participation Ordering code
Version without expansion port CR10 v2F-01 set
Version with Ethernet exp. port PORT1 CR10 v2F-01 ETH set
Version with RS232 exp. port PORT1 a PORT2 CR10 v2F-01 RS232 set
Version with RS485 exp.port PORT1 a PORT2 CR10 v2F-01 RS458 set
Version with MBUS exp. port PORT1 a PORT2 CR10 v2F-01 MBUS set
Version with CNT exp. port PORT1 CR10 v2F-01 CNT set
Version with SWITCH exp. port PORT1 + PORT2 CR10 v2F-01 SWITCH set
Version with WIFI exp. port PORT2 CR10 v2F-01 WIFI set
Version with WMBUS exp. port PORT2 CR10 v2F-01 WMBUS set
Version with SDH exp. port PORT2 CR10 v2F-01 SDH set
Table 5: Ordering codes of full version
Second expansion port is written after first expansion port in the ordering code.
Example:
•Full version with Ethernet and RS232 port: CR10 v2F-01 ETH RS232 set.
•Full version with Ethernet and RS232 port in metal cover:
CR10 v2F-01 ETH RS232 SL set.
8

5. ROUTER DESIGN
5.5 Basic dimensions of plastic box
Figure 10: Basic dimensions of plastic box
5.6 Basic dimensions of metal box
Figure 11: Basic dimensions of metal box
9

5. ROUTER DESIGN
5.7 Mechanical dimensions and mounting recommendations
Mounting recommendations:
•possibility to be put on a work surface,
•DIN rail with clips CKD2 (ELPAC clip SL for metal version) are included.
For the most of applications with a built-in router in a switch board it is possible to recognize
two kinds of environments:
•no public and industry environment of low voltage with high interference,
•public environment of low voltage without high interference.
For both of these environments it is possible to mount router to a switch board, the following
there is no need to have examination immunity or issues in connection with EMC according to
EN 60439-1 ed.2:00 + A1:04.
For compliance of EN 60439-1 ed.2:00 + A1:04 specification it is necessary to observe next
assembly of the router to the switch – board:
•for whip antennas we recommend to observe a distance of 6 cm from cables and metal
surfaces on every side according to the next picture due to the elimination of interfer-
ence, while using an external antenna except for the switch-board it is necessary to fit a
lightening conductor,
•before mounting a router on sheet-steel we recommend using an external antenna,
Figure 12: Space around antennas Figure 13: Space around antennas for SL
10

5. ROUTER DESIGN
•For every cables we recommend to bind the bunch according to the following picture, we
recommend for this use:
–Length of the bunch (combination of power supply and data cables) can be max-
imum 1,5 m. If the length of data cables exceeds 1,5 m or in the event of, the
cable leads towards the switch – board. We recommend installing over – voltage
protectors (surge suppressors).
–With data cables they mustn’t carry cables with reticular tension ∼230 V/50 Hz.
–All signals to sensors must be twisted pairs.
Figure 14: Cable routing Figure 15: Cable routing for SL version
•Sufficient space must be left before individual connectors for handling of cables,
Figure 16: Space in front of connectors Figure 17: Space in front of connectors – SL
•For correct function of the router we recommend to use in the switch-board earth-bonding
distribution frame for grounding of power supply of router, data cables and antenna.
11

5. ROUTER DESIGN
5.8 Removing from the DIN rail
Default position of CPD2 holder (or CKD2 holder for SL version), which is used for
mounting the router on a DIN rail, is shown in the following figure:
Figure 18: Default position of DIN holder
For removing from the DIN rail it is necessary to lightly push upward the router so that
the top part of the CPD2 holder (or CKD2 for SL version) hitched to the DIN rail get out
of this rail and then fold out the top part of the router away from the DIN rail.
Figure 19: Removing from the DIN rail
12

5. ROUTER DESIGN
5.9 Description of the front panel
On the front panel is located:
Caption Connector Description
PWR 2-pin Connector for the power supply adapter.
ETH RJ45 Connector for connection into the local computer network.
PORT1 RJ45 Connector for expansion port RS232, RS458/422, MBUS,
ETHERNET, CNT or SWITCH.
PORT2 RJ45 Connector for expansion port RS232, RS485/422, MBUS,
SWITCH, WIFI, WMBUS or SDH (only FULL version).
ANT SMA Connector for main antenna.
DIV SMA Connector for diversity antenna.
WIFI R-SMA Connector for WIFI antenna. Only when router is equipped
with an expansion port WIFI.
WMBUS SMA Connector for WMBUS antenna. Only when it is equipped
with an expansion port WMBUS.
USB USB-A Host Connector for connection of USB devices to the router. Sup-
ports devices with PL-2303 and FTDI USB/RS232 converters.
I/O 3-pin Connector for connection of the binary input and output.
SIM1 — Holder for the first SIM card.
SIM2 — Holder for the second SIM card (only FULL version).
Table 6: Front panel description
Figure 20: Front panel CR10 v2F SL
13

5. ROUTER DESIGN
5.9.1 Status indication
About router status inform eight led indicators on the front panel and on every port are two
LED indicators, which inform about port status.
Caption Color State Description
PWR Green Blinking
On
Fast blinking
Router is ready
Starting of the router
Updating firmware
DAT Red Blinking Communication in progress on radio channel
WAN Yellow 1x flash per second
2x flash per second
3x flash per second
Signal strength is from –50 dBm to –69 dBm
Signal strength is from –70 dBm to –89 dBm or differ-
ence between neighbours cells is exactly 3 dBm
Signal strength is from –90 dBm to –113 dBm or differ-
ence between neighbours cells is smaller than 3 dBm
USR Yellow Function selected by user
OUT Green On Binary output active
IN Green On Binary input active
ETH Green On
Off
Selected 100 Mbit/s
Selected 10 Mbit/s
ETH Yellow On
Blinking
Off
The network cable is connected
Data transmission
The network cable is not connected
PORT Green Depends on the expansion port (see user’s guide of used port)
PORT Yellow Depends on the expansion port (see user’s guide of used port)
SIM1 Yellow On SIM card 1 is active
SIM2 Yellow On SIM card 2 is active
Table 7: Router status indication
State indication of WAN LED is updated every 10 seconds.
14
