Contec CONPROSYS Reference manual

Introduction Guide
Cloud Data Service
CONTEC CO., LTD.

― 1 ―
Table of Contents
Handy Functions
Check Operation
Set the Controller
Check Communication
Set the Computer Network
Connect the Controller
Connector Positions for Setup
Items to Set Up
18
11
9
8
6
4
3
2
Web monitoring and task functions of the controller are described.?
How to check whether the controller is operating properly.
The setup procedure of the Integrated and the Configurable controllers on a DIN rail or on the wall.
How to check whether the computer and the controller are communicating properly.
The setup procedure of the computer IP address.
How to connect the computer, the controller, and the power unit.
The names and positions are illustrated.
The list of items to set up the CONPROSYS.
Before installation
Check
Communication
Setup
Appendix

― 2 ―
Items to Set Up (Integrated type)
Items to Set Up (Configurable type)
Controller
(CONPROSYS product)
Power cable
(This comes with the above recommended battery unit)
AC power cable
(Individually sold: IPC-ACCODE3 recommended)
LAN cable
(Cross cable)
Computer Battery unit
(Individually sold: CPS-PWD-15AW12-01 recommended)
The product requires the items listed below to set up. Have the followings ready.
The product requires the items listed below to set up. Have the following items ready.
Controller
(CONPROSYS product)
Power cable
(This comes with the above recommended battery unit)
AC power cable
(Individually sold: IPC-ACCODE3 recommended)
LAN cable
Cross cable
Computer Battery unit
(Individually sold: CPS-PWD-90AW24-01 recommended)

― 3 ―
Connector Positions for Setup (Integrated type)
Connector Positions for Setup (Configurable type)
LAN
Digital I/O
Power
See the positions to connect each cable.
Power
LAN Digital I/O
[Top]
[Front]
[Front]
[Bottom]
See the positions to connect each cable.
RESET
SW1
SD
Isolated RS-422A/485
SHUT
COM BUSB RS-232C
TERM MODE
SW2
DOWN
COM AAI1AI0DO1DO0DI/CNTLAN BLAN A
12-24VDC
A
B
SD
TX
R X
MCOM
DIO0
DIO1
DIO2
DIO3
N.C
PWR ST1 ST2 ERR
DIO
0
123
V +
V -
24VDC
SW1
ON
ID L
H
SD
A
A
This layout of the connectors is the example
of the multiple I/O model.Please see an
appropriate controller manual for your
model.

― 4 ―
Connect the Controller
（Integrated type）
Follow the instructions below to connect the computer, the controller, and the power unit.
1
Connect the power unit with AC plug, then turn on the computer.
* After connecting the power unit with AC plug, it takes a few minutes for the controller to complete
the start-up. (approx. 1-2 min)
2
AC plug
Controller
AC power cable
LAN cable
Computer
Battery unit
Connection diagram
Connect to
LAN A Connect to
the power
connector
AC
(L)
AC
(N)
AC
(G) -V +V
FG (Green)
GND (Black)
+12V (Red)
FG (Green)
N (白)
L (Black)
Power cable Power cable
AC power cable
AC power cable
FG
(Green)
GND
(Black)
+12V
(Red)
FG
(Green)
N
(White)
L
(Black)
AC
(L)
AC
(N)
FG
(G) -V +V

― 5 ―
Connect the Controller (Configurable type)
Follow the instructions below to connect the computer, the controller, and the power unit.
1
Connect the power unit with AC plug, then turn
on the computer.
* After connecting the power unit with AC plug,
it takes a few minutes for the controller to
complete the start-up. (approx. 1-2 min)
2
AC plug
Controller
AC power cable
LAN cable
Computer
Battery unit
Connection diagram
Connect to
the power
connector
Connect to
LAN A
＝Power cable
＝AC power cable
+ - -
N L
INPUT
AC100-240V
DC24V 3.8A
OUTPUT
DC_OK
FG
(Green)
GND
(Black)
+24V
(Red)
L
(Black)
N
(White)
FG
(Green)

― 6 ―
Set the Computer Network
Click [Network & Internet] on
[Windows Settings] screen.
1
Click [Change adapter options］ in
[Network status].
2
Double-click the appeared [Ethernet] .
3
Follow the “Computer Network Setting Procedure” described below and set the network to make the IP
addresses as shown.
The product must set a unique IP address for the bold part (200 or 101) that is not used by other devices on
your network.
Controller
* The factory default setting
Computer
IP address .10 1 1 200. .
Subnet mask .255 0 0 0. .
IP address .10 1 1 101. .
Subnet mask .255 0 0 0. .
Computer Network Setting Procedure (for Windows 10)
Go on to the
next page.

― 7 ―
Click [Property] in [Ethernet Status]
dialog box.
4
Double-click [Internet protocol version
4(TCP/IPv4)] in [Ethernet Properties]
dialog box.
5
In the [Internet protocol version 4
(TCP/IPv4) property], set IP address and
Subnet mask as shown below.
6
Click [OK] → [OK] → [Close] to close the dialog box and complete the network setting.
7
IP address .10 1 1 200. .
Subnet mask .255 0 0 0. .
Select

― 8 ―
Check Communication
* For an actual operation, change User name and Password in [User name and Password ] from the
Maintenance menu.
* After entering IP address and pressing [Enter]
key, the “Security certificate” might appear on
the screen. Choose “Continue to this website”.
Start the Internet Explorer 11 on your computer. Enter IP address (10.1.1.101) of the controller in the
address bar, then press [Enter] key.
The dialog box asking for the User name and Password appears, enter them and click [OK].
1
If [Status menu] of Web browser menu appears, it indicates the success of the communication
between the computer and the controller.
2
Status menu screen▶
10.1.1.101
User name :
[Default setting]
mc341
Password : mc341

― 9 ―
Set the Controller (Integrated type)
Pull down the two fixed hooks on the
bottom to unlock; preferably with a
slotted screwdriver.
1
(1)Hang the controller on the upper part
of a DIN rail, (2)and press the product to
the lower side of the DIN rail.
2
Mounting on a DIN Rail
Place the controller onto the wall
Push up the fixed hooks to lock on the
DIN rail.
3
Fixed hook
11
2
Appropriate screws (fit into φ3.5 hole) are required to set the product on the wall.
The screws can be purchased individually.

― 10 ―
Set the Controller (Configurable type)
Pull down the fixed hook on the bottom to unlock; preferably with a slotted screwdriver.
1
(1)Hang the controller on the upper part of a DIN rail, (2)and press the product to the lower side of
the DIN rail.
2
Mounting on a DIN Rail
Push up the hook to lock on the DIN rail.
3
1
2
Fixed hook
1
2

― 11 ―
Check Operation (Digital I/O of the Integrated type)
1 2 3 4 5 6 7 8 9 10
Connect the pin number 2 (DI0) and 7 (DO0+), then 6 (DI_MCOM) and 8 (DO0-) of the digital I/O
connector with the lead-wire to create the connector for operation check.
* The lead-wires are not included in the package. Please use the recommended wire, AWG28-16.
1
Place the operation check connector into the digital I/O connector of the controller.
2
Fasten the screws
with a driver to
secure the
lead-wires.
Lead-wires
Operation check connector
Go on to
the next page.
10
9
8
7
6
5
4
3
2
1
DO1-
DO1+
DO0-
DO0+
DI_MCOM
DI3/CNT1
DI2/CNT0
DI1
DI0
N.C.
Pin number
▼
Signal name
▼
This layout of connector pins is the example of the
multiple I/O model.
Please see an appropriate controller manual for
your model.
On your computer, start up Internet Explorer 11 and enter IP address (10.1.1.101) of the controller in
the address bar, then press [Enter].
The screen asking your user name and password appear. Enter them in the dialog box and click [OK]
to show Web browser menu.
3
10.1.1.101
User name
：
[Default setting]
mc341
Password
：mc341

― 12 ―
From Web browser menu, click [Monitoring view] in [Status menu] to show the screen for I/O check.
4
Click [DO0] in Digital Output on the I/O check screen of the controller to switch on/off. This turns
on/off the [DIO0] lamp of Digital Input.
This confirms that the controller is operating properly.
5
Lamp is offClick Lamp turns onON

― 13 ―
Check Operation (Digital I/O of the Configurable type)
Connect the pin number 2 (DIO0) and 3 (DIO1) of the digital I/O connector with the lead-wire to
create the connector for operation check.
* The lead-wire is not included in the package. Please use the recommended wire, AWG28-16.
* The configurable controller requires a signal setting from Web browser menu.
1
Place the operation check connector into the digital I/O connector of the controller.
2
Fasten the screws with
a driver to secure the
lead-wire.
Go on to
the next page
Operation check connector
6 5 4 3 2 1
1
2
3
4
5
6
MCOM
DIO0
DIO1
DIO2
DIO3
N.C.
Pin number
▼
Signal name
▼
Lead-wires
On your computer, start up Internet Explorer 11 and enter IP address (10.1.1.101) of the controller in
the address bar, then press [Enter].
The screen asking your user name and password appear. Enter them in the dialog box and click [OK]
to show Web browser menu.
3
10.1.1.101
User name :
[Default setting]
mc341
Password : mc341

― 14 ―
Go on to
the next page
From Web browser menu, go to [Module setting] in [Maintenance menu] and click the Controller
image or in the Module list.
4
Change those DIO0, DIO1 set in the Step 1 to value DIO0⇒DI, DIO1⇒D 1O respectively.
(Default settings are all DI)
Click after setting.
51
Configure
set
Module setting
Change values

― 15 ―
Go on to
the next page
6After changing the settings, go to in the Maintenance menu and click the button save
to ROM to save the changes.
PWR LED will be on once the changes are saved (saving time: approx. 20 seconds).
After completion of the saving, click [Reboot/Shutdown] to reboot the controller (approx. 1 minute).
7To create a monitoring view screen, open [Monitoring edit] in [Maintenance menu], and change to
[Run] in the Mode that is located on the upper-right side.
save to ROM

― 16 ―
Go on to
the next page
8From Components list on the left side, select “Switch” and “Lamp” controls and drag & drop them
onto the “Layer area”.
9(1) Click the “Switch” control on the layer area to activate.
(2) Click [! OnPressd] in the [Property tab] on the right side, (3)and click “ ” icon in the Link Box.
(4)Select [CPU_DO01] in Device Tree and click (5) .
This connects the Switch and the connector [DIO1].
Drag & Drop
Layer area
OK
12
4
5
3

― 17 ―
10
(1) Click the “Lamp” control on the layer area to activate.
(2) Click [value] in the [Property tab] on the right side, (3) and click “ ” icon in the Link Box.
(4) Select [CPU_DI00] in Device Tree and click (5) .
11
Clicking the Switch on the Layer area turns the Lamp on/off. This also turns on/off the LED of the
controller.
This confirms that the controller is operating properly.
This connects the Lamp and the connector [DIO0].
OK
1
2
4
5
3
Click the Switch to turn
on/off
The Lamp turns on/off

― 18 ―
Handy Functions
The M2M controller contains functions to monitor and operate measured or calculated values, as well as to
customize pages. Moreover, the controller features a function to assemble processing tasks such as
calculation and controlling by placing the controls on the pages like drawing them in the flowchart.
- A monitoring screen can be created easily.
- No expert knowledge of programming required. Simply monitor through Web browser.
- Remote monitoring of facilities to check the conditions, troubles, performances, and to stop
operations.
- No development environment is required. Signal processing can be added easily through Web
browser.
- Programming can be done by script language with the controls through Web browser.
CONPROSYS HMI
CONPROSYS VTC
(Human Machine Interface)
(Visual Task Control)
Monitoring function
Task function
Facilities
Remote location
M2M controller
M2M controller
Easy creating a monitoring screen.
Easy setting through Web browser.
For operation details, please visit the Contec website and refer to the manuals on line.
http://data.conprosys.com/help/hmi/v1/en/
For operation details, please visit the Contec website and refer to the manuals on line.
http://data.conprosys.com/help/task/v1/en/

― 19 ―
When connecting to the network, be aware of security-related problems. See the
examples of Security measures below and set up the product properly along with the
network devices.
[Information security risks]
- Unauthorized access from the outside through a network could cause the system halt,
data damage, or exposure to malware * 1.
- Invaded and used as a stepping stone, a device might attack the others through
networks. (a victim becomes an assailant)
- Information might leak without realizing due to the connection to the network.
- Secondary damages such as harmful rumors, liability in damages, social credibility fall,
and opportunity loss are expected led by the troubles described above.
*1…Malware (Malicious Software) is software that brings harm to a computer system and performs unintended
operations.
[Security measures - e.g.]
- Do not keep using the default password. (Refer to the product manual for the
password setting).
- Set a strong password.
⇒Combined with upper and lowercase letters, and numbers so that it cannot be easily
analogized by others.
- Change the password periodically.
- Disable unnecessary network services and functions.
- Restrict access to the network with network devices.
- Restrict ports to be released on the network with network devices.
- Create a closed network connection using such as dedicated network or VPN*2.
*2…VPN (Virtual Private Network): a secured network that wards off unauthorized access by protecting the
communication path with authentication and encryption.
Unfortunately, there are no perfect ways to avert unauthorized access or close a
security hole that are endlessly found day and night. Please understand that risks
are always involved with the Internet connection, and we strongly recommend a
user should constantly update information security measures.
Security Warning
