Contec CNT16-8GY User manual

F&eIT Series
16Bits Isolated
Up-Counter Module
12 - 24VDC type
CNT16-8(FIT)GY
5VDC type
CNT16-8L(FIT)GY
User’s Manual
CONTEC CO.,LTD.

CNT16-8(FIT)GY, CNT16-8L(FIT)GY i
Check Your Package
Thank you for purchasing the CONTEC product.
The product consists of the items listed below.
Check, with the following list, that your package is complete. If you discover damaged or missing items,
contact your retailer.
Product Configuration List
- Module (One of the following) ...1
[CNT16-8(FIT)GY, or CNT16-8 L(FIT)GY]
- First Step Guide …1
- CD-ROM [F&eIT Series Setup Disk] *1 …1
- Interface connector plug ...1
*1 The CD-ROM contains various software and User’s Manual (this manual)
Module Interface connector plug
CNT16-8L
Device
ID
COM 0
NC
COM1
NC
0
3
1
2
6
5
4
7
CD-ROM
First step guide [F&eIT Series Setup Disk]
4567
0123
0
4
0
4
6
2
5
1
3
7

ii CNT16-8(FIT)GY, CNT16-8L(FIT)GY
Copyright
Copyright 2004 CONTEC CO., LTD. ALL RIGHTS RESERVED.
No part of this document may be copied or reproduced in any form by any means without prior written
consent of CONTEC CO., LTD.
CONTEC CO., LTD. makes no commitment to update or keep current the information contained in this
document. The information in this document is subject to change without notice.
All relevant issues have been considered in the preparation of this document. Should you notice an
omission or any questionable item in this document, please feel free to notify CONTEC CO., LTD.
Regardless of the foregoing statement, CONTEC assumes no responsibility for any errors that may
appear in this document or for results obtained by the user as a result of using this product.
Trademarks
F&eIT is a registered trademark or trademark of CONTEC CO., LTD. Other company and product
names that are referred to in this manual are generally trademarks or registered trade trademark.

CNT16-8(FIT)GY, CNT16-8L(FIT)GY iii
Table of Contents
Check Your Package............................................................................................................................i
Copyright ............................................................................................................................................ii
Trademarks .........................................................................................................................................ii
Table of Contents...............................................................................................................................iii
1. Before Using the Product 1
About the Module............................................................................................................................... 1
Features........................................................................................................................................ 1
Functions and control method by controller connected .............................................................. 2
Customer Support............................................................................................................................... 4
Web Site....................................................................................................................................... 4
Limited One-Year Warranty............................................................................................................... 4
How to Obtain Service ....................................................................................................................... 4
Liability............................................................................................................................................... 4
Safety Precautions .............................................................................................................................. 5
Safety Information....................................................................................................................... 5
Handling Precautions................................................................................................................... 5
Environment................................................................................................................................. 7
Inspection..................................................................................................................................... 7
Storage ......................................................................................................................................... 7
Disposal ....................................................................................................................................... 7
2. Module Nomenclature and Settings 9
Nomenclature of Module Components .............................................................................................. 9
Setting a Device ID............................................................................................................................. 9
Setup Method............................................................................................................................... 9
LED Indicator................................................................................................................................... 10
3. Connecting to an External Device 11
Interface Connector .......................................................................................................................... 11
How to Connect an Interface Connector ................................................................................... 11
Signal Layout on the Interface Connector................................................................................. 12
External I/O Circuits......................................................................................................................... 13

iv CNT16-8(FIT)GY, CNT16-8L(FIT)GY
4. Using the I/O Address Map 15
Starting I/O Address ......................................................................................................................... 15
List of I/O Address Maps ................................................................................................................. 16
Specifications Common to F&eIT Products..................................................................................... 20
Product Information................................................................................................................... 20
Bit Assignments for I/O Ports ..........................................................................................................22
Flow of Count Values....................................................................................................................... 22
Operation Commands ....................................................................................................................... 23
Description of Input Commands....................................................................................................... 24
Reading a Count (command 00h - 07h).....................................................................................24
Interrupt mask (command 11h) ................................................................................................. 24
Status (command 12h) ............................................................................................................... 25
Count control (Command 14h).................................................................................................. 25
Digital Filter (command 15h).................................................................................................... 25
Description of Output Commands.................................................................................................... 26
Initial Count Value (command 00h - 07h) ................................................................................26
Count Data Latching (command 10h) ....................................................................................... 26
Interrupt Mask (command 11h)................................................................................................. 26
Status Reset (command 12h) ..................................................................................................... 27
Counter initialization (command 13h)....................................................................................... 27
Counter control (command 14h)................................................................................................ 27
Digital Filter (command 15h).................................................................................................... 28
Examples...........................................................................................................................................30
Pulse Count (no interrupts)........................................................................................................30
Pulse Count (with interrupts).....................................................................................................33
5. Using the Memory Address Map 39
Module Information Area.......................................................................................................... 40
Module Information Area.......................................................................................................... 47
Basic I/O Data Area................................................................................................................... 50
Examples...........................................................................................................................................51
6. System Reference 57
Block Diagram.................................................................................................................................. 57
Specifications....................................................................................................................................58
Physical Dimensions......................................................................................................................... 60

1. Before Using the Product
CNT16-8(FIT)GY, CNT16-8L(FIT)GY 1
1. Before Using the Product
This chapter provides information you should know before using the product.
About the Module
This product is an expansion module (device module) that up-counts pulse signals input from an external
device. The product is used in combination with the I/O controller module < CPU-CAxx(FIT)GY > (*1)
or microcontroller unit < CPU-SBxx(FIT)GY > (*1) in the F&eIT Series.
Each < CNT16-8(FIT)GY > module can count a maximum of eight pulse signals. The pulse signals are
input via opto-couplers. The external power supply can be in the range 12 - 24 VDC.
The < CNT16-8L(FIT)GY > has the same count function as the < CNT16-8(FIT)GY > but operates on a
5 VDC external power supply.
Please read this manual carefully to create application programs and configure the system, such as
setting the switches and connecting it to external devices.
*1 The "x" in a model code represents a single digit (or no digit) indicating different products. (The
same convention applies below).
Features
- Performs a 16-bit up-count for eight channels.
- Isolated from each other by an opto-coupler, offering good noise immunity.
- A digital filter is included to prevent miscounting due to chattering on the input pulses.
- A rotary switch allows you to set device IDs to help you keep track of device numbers.
- Like other F&eIT series products, the module has a 35mm DIN rail mounting mechanism as
standard. A connection to a controller module can be effected on a lateral, stack basis in a unique
configuration, which permits a simple, smart system configuration without the need for a backplane
board.

1. Before Using the Product
2CNT16-8(FIT)GY, CNT16-8L(FIT)GY
Functions and control method by controller connected
The CNT16-8(FIT)GY and CNT16-8L(FIT)GY can be connected to a variety of controllers.
Supported controllers
Microcontroller Unit : CPU-SBxx(FIT)GY
I/O Controller Module : CPU-CAxx(FIT)GY
Monitoring & Control Server Unit : SVR-MMF2(FIT)
Monitoring & Control Server Unit : SVR-MMF(FIT)GY
Check each controller to which the module can be connected as well as the method of controlling the
module when connected to that controller.
Connections to controllers
O: Permitted
×: Not permitted
CPU-SBxx(FIT)GY
CPU-CAxx(FIT)GY
SVR-MMF2(FIT)
SVR-MMF(FIT)GY
CNT16-8(FIT)GY ΟΟΟΟ
CNT16-8L(FIT)GY ΟΟΟΟ
Device ID setting range 0 - 7 0 - 7 0 - 7 0 - 7

1. Before Using the Product
CNT16-8(FIT)GY, CNT16-8L(FIT)GY 3
Control method by controller connected
CPU-SBxx(FIT)GY
CPU-CAxx(FIT)GY
SVR-MMF2(FIT)
SVR-MMF(FIT)GY
Control using the I/O address map Ο
Control using the memory address map Ο
FIT Protocol Ο
API-CAP(W32) Ο
API-SBP(W32) Ο
Control over the web
(as set from within the browser) ΟΟ
Control via the Windows driver *
* The API-SBP(W32) is included in the development kit [DTK-SBxx(FIT)GY]; the other drivers are bundled with each
controller.
Control using the I/O address map
When connected to the CPU-SBxx(FIT)GY, the module can receive I/O instructions directly from the
controller module. For details, see Chapter 4 “Using the I/O Address Map”.
Control using the memory address map
When connected to the CPU-CAxx(FIT)GY, the module can be accessed from the host computer over
the network. The module is assigned with its device ID in the memory managed by the controller
module. The application running on the host computer controls the module by reading/writing the
memory managed by the controller module. For details, see Chapter 5 “Using the Memory Address
Map”.
Control via the Windows driver
For the functions and settings available when using the Windows driver, refer to the reference manual
and online help for each module.
Control over the web
You can monitor collected data and manage the log over the web. You can use your familiar browser to
easily make various settings. For details, refer to the reference manual for the SVR-MMF2(FIT),
SVR-MMF(FIT)GY.

1. Before Using the Product
4CNT16-8(FIT)GY, CNT16-8L(FIT)GY
Customer Support
CONTEC provides the following supportservices for you to use CONTEC products more efficiently and
comfortably.
Web Site
Japanese http://www.contec.co.jp/
English http://www.contec.com/
Chinese http://www.contec.com.cn/
Latest product information
CONTEC provides up-to-date information on products.
CONTEC also provides product manuals and various technical documents in the PDF.
Free download
You can download updated driver software and differential files as well as sample programs available in
several languages.
Note! For product information
Contact your retailer if you have any technical question about a CONTEC product or need its price,
delivery time, or estimate information.
Limited One-Year Warranty
CONTEC products are warranted by CONTEC CO., LTD. to be free from defects in material and
workmanship for up to one year from the date of purchase by the original purchaser.
Repair will be free of charge only when this device is returned freight prepaid with a copy of the original
invoice and a Return Merchandise Authorization to the distributor or the CONTEC group office, from
which it was purchased.
This warranty is not applicable for scratches or normal wear, but only for the electronic circuitry and
original products. The warranty is not applicable if the device has been tampered with or damaged
through abuse, mistreatment, neglect, or unreasonable use, or if the original invoice is not included, in
which case repairs will be considered beyond the warranty policy.
How to Obtain Service
For replacement or repair, return the device freight prepaid, with a copy of the original invoice. Please
obtain a Return Merchandise Authorization number (RMA) from the CONTEC group office where you
purchased before returning any product.
* No product will be accepted by the CONTEC group without the RMA number.
Liability
The obligation of the warrantor is solely to repair or replace the product. In no event will the warrantor
be liable for any incidental or consequential damages due to such defect or consequences that arise from
inexperienced usage, misuse, or malfunction of this device.

1. Before Using the Product
CNT16-8(FIT)GY, CNT16-8L(FIT)GY 5
Safety Precautions
Understand the following definitions and precautions to use the product safely.
Safety Information
This document providessafety information using the following symbols to prevent accidents resulting in
injury or death and the destruction of equipment and resources. Understand the meanings of these labels
to operate the equipment safely.
DANGER DANGER indicates an imminently hazardous situation which, if not avoided, will
result in death or serious injury.
WARNING WARNING indicates a potentially hazardous situation which, if not avoided, could
result in death or serious injury.
CAUTION CAUTION indicates a potentially hazardous situation which, if not avoided, may
result in minor or moderate injury or in property damage.
Handling Precautions
CAUTION
- Do not modify the module. CONTEC will bear no responsibility for any problems, etc., resulting
from modifying this module.
- Do not use or store the equipment in a hot or cold place, or in a place that is subject to severe
temperature changes.
(Operating temperature range: 0 - 50°C)
- Do not use or store the equipment in a place subject to direct sunlight or near a heating device,
such as a stove.
- Do not use or store the equipment in a dusty or humid place.
(Operating humidity range: 10 - 90%RH, No condensation)
- As this product contains precision electronic components, do not use or store in environments
subject to shock or vibration.
- Do not use or store the product near equipment generating a strong magnetic field or radio waves.
- If you notice any strange odor or overheating, please unplug the power cord immediately.
- In the event of an abnormal condition or malfunction, please consult the dealer from whom the
equipment was purchased.
- To avoid electric shock, please do not touch the system with a wet hand.
- Do not open the module casing. CONTEC will disclaim any responsibility for equipment whose
casing has been opened.
- To prevent damage, please do not subject the module to impact or bend it.
- To prevent contact malfunction, please do not touch the metallic pins on the external module
connector.

1. Before Using the Product
6CNT16-8(FIT)GY, CNT16-8L(FIT)GY
- The module contains switches that need to be properly set. Before using the module, please
check its switch settings.
- To avoid malfunction, please do not change the module switch settings in an unauthorized
manner.
- Do not operate the device module when the power for the Controller Module is on.
To avoid malfunction, please be sure to turn off the power for the Controller Module.
FCC PART 15 Class A Notice
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in commercial
environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful
interference at his own expense.
NOTE
Change or modifications not expressly approved the manufacturer can void the user's
authority to operate this equipment.
WARNING TO USER

1. Before Using the Product
CNT16-8(FIT)GY, CNT16-8L(FIT)GY 7
Environment
Use this product in the following environment. If used in an unauthorized environment, the module may
overheat, malfunction, or cause a failure.
Operating temperature
0 - 50°C
Operating humidity
10 - 90%RH (No condensation)
Corrosive gases
None
Floating dust particles
Not to be excessive
Inspection
Inspect the product periodically as follows to use it safely.
CNT16-8L
Device
ID
COM 0
NC
COM 1
NC
0
3
1
2
6
5
4
7
4567
0123
0
4
0
4
6
2
5
1
3
7
- Check that the ventilation slit has no obstruction and
has no dust or foreign matter adhering.
Storage
When storing this product, keep it in its original packing form.
(1) Put the module in the storage bag.
(2) Wrap it in the packing material, then put it in the box.
(3) Store the package at room temperature at a place free from direct sunlight, moisture, shock,
vibration, magnetism, and static electricity.
Disposal
When disposing of the product, follow the disposal procedures stipulated under the relevant laws and
municipal ordinances.

1. Before Using the Product
8CNT16-8(FIT)GY, CNT16-8L(FIT)GY

2. Module Nomenclature and Settings
CNT16-8(FIT)GY, CNT16-8L(FIT)GY 9
2. Module Nomenclature and Settings
Nomenclature of Module Components
Figure 2.1 shows the names of module components.
In the figure, the indicated switch settings represent factory settings.
CNT16-8(FIT)GY CNT16-8L(FIT)GY
LED indicator
Input
Device ID
Input
Device ID
CNT16-8
Device
ID
COM 0
NC
COM 1
NC
0
3
1
2
6
5
4
7
4567
0123
0
4
0
4
6
2
5
1
3
7
CNT16-8L
Device
ID
COM 0
NC
COM 1
NC
0
3
1
2
6
5
4
7
4567
0123
0
4
0
4
6
2
5
1
3
7
LED indicator
Figure 2.1. Names of Module Components
Setting a Device ID
The controller module distinguishes and keeps track of the modules that are connected to it by assigning
device IDs to them. Each module, therefore, should be assigned a unique ID.
A Device ID can be assigned in a 0 - 7 range, so that a maximum of eight modules can be distinguished.
The factory setting for the Device ID is [0].
Setup Method
A Device ID can be set by turning the rotary switch that is located on the module face.
A Device ID can be assigned by turning the switch.
Device
ID
0
4
0
4
6
2
5
1
3
7
Factory setting:
(Device ID = 0)
Figure 2.2. Setting a Device ID

2. Module Nomenclature and Settings
10 CNT16-8(FIT)GY, CNT16-8L(FIT)GY
LED Indicator
Table 2.1. LED Indicator
Name Function LED indicator
ON: Indicates current flowing in the input pin
(Counting pulse signal)
Status LED
Input indicator (0 - 7):
GREEN
OFF: Indicates no current flowing in the input
pin (Not counting pulse signal)

3. Connecting to an External Device
CNT16-8(FIT)GY, CNT16-8L(FIT)GY 11
3. Connecting to an External Device
Interface Connector
How to Connect an Interface Connector
When connecting the Module to an external device, you can use the supplied connector plug.
To wire the Module, strip the sheath about 9 - 10mm from an end of the wire and insert the exposed wire
into an opening. Tighten the screw to fasten the inserted wire. Applicable wires are AWG28 - 16.
Turn the screw to fasten the wire.
CNT16-8L
Device
ID
COM 0
NC
COM 1
NC
0
3
1
2
6
5
4
7
- Connector used:
3.81mm pitch, 12-pin type, 8.0A rated current
MC1,5/12-GF-3,81 [made by Phoenix Contact Corp.]
- Applicable plug (bundled):
Front screw type with connector stopper flange
FRONT-MC 1,5/12-STF-3,81 [made by Phoenix Contact Corp.]
Applicable wire: AWG28 - 16
9 - 10mm
4567
0123
0
4
0
4
6
2
5
1
3
7
Figure 3.1. Connecting an Interface Connector and Connectors That Can Be Used
CAUTION
Removing the connector plug by grasping the cable can break the wire.

3. Connecting to an External Device
12 CNT16-8(FIT)GY, CNT16-8L(FIT)GY
Signal Layout on the Interface Connector
The Module can be connected to an external device using a 12-pin connector that is provided on the
Module face.
COM 0--- +/-COM
N.C.
0 --- IN 0
1 --- IN 1
2 --- IN 2
3 --- IN 3
4 --- IN 4
N.C.
5 --- IN 5
6 --- IN 6
7 --- IN 7
Common plus/minus
for input port
COM 1--- +/-COM
Pulse input: 4points
Pulse input: 4points
Common plus/minus
for input port
Figure 3.2. Signal Layout on the Interface Connector

3. Connecting to an External Device
CNT16-8(FIT)GY, CNT16-8L(FIT)GY 13
External I/O Circuits
Input section
Figure 3.3 or 3.4 shows the input equivalent circuit for the interface section.
The signal input section consists of an opto-isolated input (compatible with both current sink output and
current source output). An external power supply is therefore required to drive the input section of this
module. The power requirement for the < CNT16-8(FIT)GY > is about 8 mA per input channel at
24 VDC (about 4 mA at 12 VDC) and for the < CNT16-8L(FIT)GY > is about 4 mA per input channel at
5 VDC.
Vcc
3kΩ
3kΩ
External circuitModule
Optocoupler
Input
pin
Input
pin
+/-
common
Input contact
point
Input contact
point
12V - 24VDC
External
power supply
Optocoupler
Figure 3.3. Input Circuit < CNT16-8(FIT)GY >
Vcc
1.2kΩ
1.2kΩ
External circuitModule
Optocoupler
Input
pin
Input
pin
+/-
common
Input contact
point
Input contact
point
Optocoupler
5VDC
External
power supply
Figure 3.4. Input Circuit < CNT16-8L(FIT)GY >

3. Connecting to an External Device
14 CNT16-8(FIT)GY, CNT16-8L(FIT)GY
Current sink
output
Optocoupler Input
pin
Plus
common
12V - 24VDC
External
power supply
External circuitModule
3kΩ
Vcc
Figure 3.5. Example of a Connection to Current Sink Output < CNT16-8(FIT)GY >
Current sink
output
Optocoupler Input
pin
Plus
common
5VDC
External
power supply
External circuitModule
1.2kΩ
Vcc
Figure 3.6. Example of a Connection to Current Sink Output < CNT16-8L(FIT)GY >
Current
source
output
Optocoupler Input
pin
Minus
common
12V - 24VDC
External
power supply
External circuitModule
3kΩ
Vcc
Figure 3.7. Example of a Connection to Current Source Output < CNT16-8(FIT)GY >
Current
source
output
Optocoupler Input
pin
Minus
common
5VDC
External
power supply
External circuitModule
1.2kΩ
Vcc
Figure 3.8. Example of a Connection to Current Source Output < CNT16-8L(FIT)GY >

4. Using the I/O Address Map
CNT16-8(FIT)GY, CNT16-8L(FIT)GY 15
4. Using the I/O Address Map
Starting I/O Address
When connected to a CPU-SBxx(FIT)GY, the Module can directly receive I/O commands from the
controller module. Depending on how the Device ID is set, the I/O addresses indicated below will be
used exclusively by the Module.
Because the address bus on which I/O address space is allocated is not fully decoded in 16 bits, four
starting I/O addresses exist for each Device ID.
If the Device ID is set to 0h, one of the four addresses (0800h, 0840h, 0880h, or 08C0h) will be used as
a starting I/O address.
Table 4.1. List of Starting I/O Addresses
< CNT16-8(FIT)GY, CNT16-8L(FIT)GY >
ID No. Occupied I/O address
0 0800h - 081Fh(recommended) 0840h - 085Fh 0880h - 089Fh 08C0h - 08DFh
1 1800h - 181Fh(recommended) 1840h - 185Fh 1880h - 189Fh 18C0h - 18DFh
2 2800h - 281Fh(recommended) 2840h - 285Fh 2880h - 289Fh 28C0h - 28DFh
3 3800h - 381Fh(recommended) 3840h - 385Fh 3880h - 389Fh 38C0h - 38DFh
4 4800h - 481Fh(recommended) 4840h - 485Fh 4880h - 489Fh 48C0h - 48DFh
5 5800h - 581Fh(recommended) 5840h - 585Fh 5880h - 589Fh 58C0h - 58DFh
6 6800h - 681Fh(recommended) 6840h - 685Fh 6880h - 689Fh 68C0h - 68DFh
7 7800h - 781Fh(recommended) 7840h - 785Fh 7880h - 789Fh 78C0h - 78DFh
For detailed specifications on the I/O space that is managed by the controller module, see the controller
module manual.
