Features, Catalog Logic
and Options
Ballasts
Fixtures are supplied standard
with electronic ballasts.
Magnetic, energy saving ballasts
are available with T8 lamps only
(LEOC8). An optional radio
interference filter (RIF) is
commonly used with magnetic
ballasts to reduce radio
interference with sensitive
equipment.
Circuitry
All individual input circuits will be
supplied with a quick disconnect
module (QDM) to facilitate ease of
maintenance and installation.
GCO and FNL options are
commonly run on separate
circuits. Each will be supplied with
a QDM, separate from the primary
lamp sources and will require
additional switching and wiring by
others. All primary lamp sources
are wired onto the same circuit
unless specified otherwise (See
Switching Controls).
Switching Contr ols
No switching option specified
implies the fixture will ship with
input leads left unwired for switch
wiring to be completed in field as
desired.
PS4-4-position pull chain
switching. All primary lamps
wired in sequence by following:
lower lamps on, upper lamps on,
all lamps on, all lamps off. (120V
only, brushed nickel finish,
installed in center of unit on
bottom of power tray).
PS1D-2 position pull chain switch,
controls the bottom lamp
compartment only. (120V only,
brushed nickel finish, installed in
center of unit on bottom of power
tray). Upper lamp compartment is
on a separate circuit to be wired
and switched at wall or as desired.
LVCP-Low voltage controller,
patient controlled. Mounted
inside unit for patient control of
all primary lamps-upper and
lower lamp compartments. Wired
in sequence for lower lamps on,
upper lamps on, all lamps on, all
lamps off. Includes 1/4" phone
jack type receptacle centered in
bottom of wire way for input
control by others or may be used
with accessory MBC-momentary
button cord switch (See
accessories).
LVCF-Low voltage controller,
facility controlled. Mounted
inside unit, controller is left
unwired for specific wiring/control
requirements of facility. Includes
1/4" phone jack type receptacle,
centered in bottom of wire way
for input control by others or may
be used with accessory MBC-
momentary button cord switch
(See accessories).
Other Options
EBP-The emergency battery pack
option is a good candidate for
facilities that do not have
emergency generator systems.
Test switch and indicator light will
be installed on top of unit in
middle of the power tray. (Not
available with all options, consult
customer service).
FNL- Fluorescent night-light, 2-pin
(G23 Base), 7 or 9w twin tube
lamp installed in center of upper
compartment of fixture, uses a
magnetic ballast. FNL is wired on
a separate circuit. (Lamps by
others).
GCO-Grounded convenience
outlet. White in color on units
with white finish; black in color on
all other finish options, wired on a
separate circuit. (120V only,
maximum 10 amps, installed on
bottom right side facing unit; add
"L" for installation on left side of
unit, GCOL).
GLR-Fuse and holder, Wired to
primary lamp circuit only.
(Consult customer service for
additional fusing options).
NRL-White LED nurses chart
reading light. Directed so as not
to discomfort the patient while
awake or sleeping. Switched
separately via rocker switch, both
lamp and switch located on the
bottom of the power tray. White
in color on units with white finish;
black in color on all other finish
options (120V only, installed on
either the right or left side, facing
unit; add "R" for installation on
right side of unit, NRLR; add "L"
for installation on left side of
unit, NRLL).
RIF-Radio interference filter, for
use with magnetic T8 ballast only.
(1 per ballast). (Not available with
all options, consult customer
service).
SF1-Tamper-proof Torx™-head
fasteners
DTP-Decorative Trim Panel.
This option allows the user to
specify a wide assortment of
laminate patterns available from
"Wilsonart® Laminate". The
pattern is placed in the front panel
of the MPWC. Can be matched to
any interior decorating theme,
furniture color or wood grain.
Example: DTPWM-Decorative
Trim Panel, Windsor Mahogany
Accessories
MBC-Momentary button cord
switch. May be used with LVCP or
LVCF options to control lamps. All
units are wired at factory as
specified per catalog logic (See
Switching Controls).
VRSD-Torx™-head tamper-proof
screwdriver (for use with SF1
option)
Maint enance
The MPWC is designed to
facilitate ease of maintenance.
Its three part assembly makes for
efficient installation. No tools are
required for relamping or
substituting electrical power trays
on standard fixtures. When
maintenance is required, simply
loosen the two end thumbscrews
and slide the partial clamshell,
front lens assembly forward and
off. The lamps and power tray
will now be accessible and can be
removed by quarter-turn
fasteners. This assembly hangs
suspended on the back pan while
it is easily disconnected via a
quick disconnect power
connector. Spare units can speed
the maintenance process by easily
substituting the power tray, thus
causing less disruption in the
room.
