CREE LIGHTING 304 Series Installation instructions

304 Series
Includes: Mounting 0, R and Y
DISASSEMBLY INSTRUCTIONS
Tools:
Disassembly Instructions
Light Source (LS)
For End User (EU)
LS-EU
I.Follow points "a-b" of paragraph PS-EU
II.Unscrew screws 19 to remove optical pac-
kage 17 from heatsink 18
III.Replace all damaged optical package 17
with a new one
IV.Screw back screws 19 to attach the new
optical package to the heatsink 18, with a
torque of 2.7 Nm
V.Reconnect the socket to the plug of the
connectors 5 on the LED bar cables
For Control Authority (CA)
LS-CA
1.Follow points "I-II" of paragraph LS-EU
2.Remove gasket 20 from cover 17.1
3.Remove components 17.2 and 17.3 to re-
move the LED bar 17.4
N° DOC: DI022RLER0 Rev: 00 Latest release date: 19/11/2021
Models :
304 Mnt 0, R, Y Light Sources
codes
Power Supply
codes
LYD#
LXD#
XA-Q#
LE#
PH#
X-30X-#
Warning: Before opening the appliance, remove voltage from the mains line.
5
17.1
18
19 5
17.2
17.3
17.4
20
Disassembly Instructions
Power Supply (PS)
For End User (EU)
PS-EU
a.Remove frame 1 from housing 2
of the appliance, unscrewing
screws 4
b.Disconnect the socket from the
plug of connectors 5 on the LED
bar cables
c.Loosen the cable press 6 so as to
allow the outgoing cable to slide
d.Unscrew screws 7 to free power
supply unit 8 from the appliance
e.Disconnect the heads of the po-
wer cord from terminal block 9
(see section PS-AC)
f.Remove all power supply group 8
g.Replace power supply group 8
with a new one
h.Reconnect the heads of the po-
wer cord on terminal block 9 of
the new group 8
i. Screw 7 back to fix the new
group 8
j.Tighten the cable press 6 to lock
the outgoing cable
k.Reconnect the socket to the plug
of the connectors 5 on the LED
bar cables
l. Screw back 4 to fix the frame on
the appliance
9
13
11
14
10
12
8
1
2
35
54
7
6
8
N° DOC: DI022RLER0 Rev: 00 Latest release date: 19/11/2021
© 2021 Cree Lighng, A company of IDEAL INDUSTRIES. All rights reserved. For informaonal purposes only. Content is subject to change.
See www.creelighng.com/warranty for warranty and specicaons. Cree® and the Cree logo are registered trademarks of Cree, Inc.
www.creelighng-europe.com
Dissassembly instructions
End of Life (EL)
Light Source (LS) Follow instructions of the paragraph LS-CA
Power Supply (PS) Follow instructions of the paragraph PS-CA
Disassembly Instructions
Power Supply (PS)
For Control Authority (CA)
PS-CA
A.Follow points "a-f" of paragraph PS-EU
B.Unscrew the ground screws 12
C.Unscrew screws 13 that attach metal plate 11 to lid 3
D.Unscrew screws 14 that attach driver 10 to plate 11
and remove driver 10
E. Disconnect the cables of the surge 15 and unscrew
its screws from plate 11; remove the surge 15
F.Detach module 16 from plate 11
9
11
10
12
3
13
14
13
14
15
15
16
DIRECTIVE 2012/19/EU (WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT – WEEE): Information for users.
This product complies with EU Directive 2012/19/EU. The crossed-out wastebasket symbol on the appliance means that at the end of its useful lifespan, the product must be dispo-
sed of separately from ordinary household wastes. The user is responsible for delivering the appliance to an appropriate collection facility at the end of its useful lifespan. Appropriate
separate collection to permit recycling, treatment and environmentally compatible disposal helps prevent negative impact on the environment and human health and promotes recy-
cling of the materials making up the product. For more information on available collection facilities, contact your local waste collection service or the shop where you bought this ap-
pliance.
