CREE LIGHTING LEDway Series Installation instructions

LEDway Series
Street Lights
Includes: LEDway Road, LEDway Multi, LEDway Tunnel
DISASSEMBLY INSTRUCTIONS
Tools:
Disassembly Instructions
Light Source (LS)
For End User (EU)
LS-EU
I.Follow points "a-b" of paragraph PS-EU
II.Unscrew screws 4 and remove optical
packets 1 from heatsink 2
III.Replace damaged optical packages 1
with new optical packages
IV.Screw back 4 with a torque of 2.7 Nm
V.Reconnect connectors 3
VI.Close the device by closing the appro-
priate clips 6
For Control Authority (CA) LS-CA
1.Follow points I - II of paragraph LS-EU
2.Remove gasket 5 from cover 1.1
3.Remove components 1.2 and 1.3 to remo-
ve the LED bar 1.4
N° DOC: DI114RLER0 Rev: 00 Latest release date: 19/11/2021
Models :
LEDway Road
LEDway Multi
LEDway Tunnel
Light Sources
codes
Power supply
codes
LYD#
LXD#
XA-Q# PH#
Warning: Before opening the appliance, remove voltage from the mains line.
3
2
1
4
3
3
4
1.1
1.2
1.3
1.4
5

Disassembly Instructions
Power Supply (PS)
For End User (EU)
PS-EU
a.Access the wiring compartment by opening the appro-
priate clips 6
b.Disconnect the socket from the plug of connectors 7
on the LED bar cables
c.Unplug from terminal block socket 8 to disconnect the
general power supply
d.Unscrew the earth screw 9 paying attention to the not-
ched washers
e.Unscrew screw 10 that secures metal plate 11 on door
12
f.Remove the wiring plate 11 with the components on
board: driver 13, module 14 and surge protector 15
g.Replace the old wiring plate with a new one
h.Screw 10 on plate 11 and door 12 via a torque of 2.5
Nm, restoring the cable ties to lock the cables
i. Screw 9 back on plate 11 and door 12 by reapplying
the notched washers, using a torque of 2.5 Nm
j.Reconnect the LED bar cables and the outgoing cable
on connector 7 and terminal block 8 of driver 13 (see
attached wiring diagrams)
k.Close the door by hanging up the appropriate clips 6
For control Auhority (CA) PS-CA
A.Follow points "a-b" of paragraph PS-EU
B.Unscrew the screws that attach driver 13 to plate 11
C.Extract driver 13
D.Detach module 14 from plate 11
E.Unscrew the screws that attach module 15 to plate 11
6
8
15
14
11
13
7
9
10
12
N° DOC: DI114RLER0 Rev: 00 Latest release date: 19/11/2021

© 2021 Cree Lighng, A company of IDEAL INDUSTRIES. All rights reserved. For informaonal purposes only. Content is subject to change.
See www.creelighng.com/warranty for warranty and specicaons. Cree® and the Cree logo are registered trademarks of Cree, Inc.
www.creelighng-europe.com
Dissassembly instructions
End of Life (EL)
Light Source (LS) Follow instructions of the paragraph LS-CA
Power Supply (PS) Follow instructions of the paragraph PS-CA
DIRECTIVE 2012/19/EU (WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT – WEEE): Information for users.
This product complies with EU Directive 2012/19/EU. The crossed-out wastebasket symbol on the appliance means that at the end of its useful lifespan, the product must be dispo-
sed of separately from ordinary household wastes. The user is responsible for delivering the appliance to an appropriate collection facility at the end of its useful lifespan. Appropriate
separate collection to permit recycling, treatment and environmentally compatible disposal helps prevent negative impact on the environment and human health and promotes recy-
cling of the materials making up the product. For more information on available collection facilities, contact your local waste collection service or the shop where you bought this ap-
pliance.
