CREE LIGHTING VSL Series User manual

Troubleshooting
?
Problem Possible Cause Solutions
LEDs stop working
LEDs flash on and off
The power line is improperly connected.
The power plug is loose.
The LED driver malfunctions.
The LED chip is damaged.
The output of the driver is abnormal.
The LED chip breaks down.
Reconnect the power cable.
Firmly plug the power in.
Replace with new driver.
Replace with new LEDs.
Replace with new driver.
Replace with new LED chip.
Check inside the lamp
1 2
3
Version 06
IEC 60598
TECHNICAL INFORMATION
VSL Series
LED Streetlight
Voltage & Frequency: 220-240V - 50/60hz
Power Factor: >0.9
IP Rating: IP66
The fixture equipped with NEMA receptacle has an IP 65. It has been designed for working connected to a NEMA device that must be compliant
with the
ANSI C136.41-2013 standard, Without a NEMA device connected the fixture doesn’t work.
The IP rating of the fixture without a NEMA device connected is the same of the NEMA receptacle without Shorting Cap, thus IP20.
A dedicated Shorting cap is available as an accessory.
Insulation Class: I or II
Instllation methods: Fixed, outdoor use. Suitable also for indoor application.
TA min/max (°C): -30°C / + 40°C (input power A,B,C)
TA min/max (°C): -30°C / + 35°C (input power D)
Max. weight: 9,2 kg
Risk group 1 UNLIMITED according to IEC 62471:2008
30W/50W/80W/120W/150W
Version 07
DIRECTIVE 2012/19/EU (WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT – WEEE):
Information for users.This product complies with EU Directive 2012/19/EU. The crossed-out
wastebasket symbol on the appliance means that at the end of its useful lifespan, the product
must be disposed of separately from ordinary household wastes. The user is responsible for
delivering the appliance to an appropriate collection facility at the end of its useful lifespan.
Appropriate separate collection to permit recycling, treatment and environmentally compatible
disposal helps prevent negative impact on the environment and human health and promotes
recycling of the materials making up the product. For more information on available collection
facilities, contact your local waste collection service or the shop where you bought this appliance.

Installation Instructions
Pole Mount (Adjustable Angle)
Physical Dimensions(Unit:mm)
∅66
M8x25
6
763
167
352
∅84
2
We appreciate your purchase!
Please read the instruction manual before installation and keep it for future reference.
Reminder
Warning
1. To avoid damage, falling, electric shock or fire, please do not modify the lamp or replace accessories without
confirming with the supplier first.
2. Please authorize only qualified personnel to install the lamp and ensure they follow the instruction manual.
Any improper installation might cause falling, electric shock, fire, or other injury, damage or hazard.
3. Please disconnect power before installation or any maintenance of the lamp.
4. Please disconnect power if it begins to smoke or emit odors, since fire or electric shock may occur. Ask a
qualified person to inspect and maintain the luminaire.
5. Please do not dismantle the lamp without the supplier’s authorization.
6. Please do not touch the power supply when the lamp is operating.
7. If the external flexible cable or cord of the luminaire is damaged, it should only be replaced by the supplier,
a service agent or qualified person.
8. Terminal block not included. The electrical fitting must be installed by a licensed electrician.
9. The light source contained in this luminaire shall only be replaced by the manufacturer or his service agent
or a similar qualified person.
10. Only to be installed outside arms reach.
11. For use in environments where an accumulation of non-conductive dust on the luminaire may be expected.
12.Mounting heights of lights not higher than 15m.
Caution risk of electric shock
8
1
2
Connect wires as reque
s
ted
1
30W 50W 80W 120W 150W
Technical Parameters
Product
Specifications
Outlook
Dimensions
Luminaire
Net Weight
-30°C to + 40°C (INPUT POWER A, B,B5, C)
-40°C to +70°C
LL
N1-10V
Dimmable
N
L
N
brown black
blue white
1 2
DIM+
DIM-
L
N
brown black
blue white
yellow/green green
black red
DIM+
1 2
Non-
Dimmable
gray brown
DIM-
A B
A
B
1
1
2
2
15°
15°
15°
15°
M10x16 8
13.The luminaire shall be positioned so that prolonged staring into the luminaire at a distance closer than X
(see table below) meter is not expected.
LL
N1-10V
Dimmable
N
L
N
brown black
blue white
1 2
DIM+
DIM-
L
N
brown black
blue white
black red
DIM+
1 2
Non-
Dimmable
gray brown
DIM-
CLASS I
CLASS II
yellow/green green
680
160
282
∅84
Working
Temperature
Storing
Temperature
6.5±0.5kg 6.8±0.5kg 8.7±0.5kg
680x282x160mm 763x352x167mm
Optics
Version
A (30W)
B (80W)
D (150W)
C (120W)
DOUBLE
DOUBLE
DOUBLE
DOUBLE
Insulation: LV Supply vs
CONTROL CONDUCTORS
-30°C to + 35°C (INPUT POWER D)
8.9±0.5kg
B5 (50W) DOUBLE
1-10V /DALI
Dimmable
1-10V / DALI
Dimmable
